WT sensor PCT005 User manual

1 www.wtsensor.com
PCT005 Electrical Contact Bimetal Temperature Sensor
Features
■ Temperature measurement
range
■Easy installation
■High temperature
measurement accuracy
■Long-term stability
■Long life cycle
Applications
■Electric power, aerospace
industry
■Temperature measurement
in textile, food and other fields
■Atomic energy, petroleum,
chemical
Notes:
1 Please read the Instruction Manual of
the product carefully before installation
and check the relevant information of
the product.
2.Follow the instructions to install,
otherwise it will cause product damage
and other potential failures
3 Misuse of the product may cause
danger or personal injury.
Product overview
The bimetal temperature sensor integrates bimetal
thermometer and thermal resistance (couple) to meet the
requirements of on-site temperature measurement and
long-distance transmission. It can directly measure
liquid, steam and gas media in the range of -80 ~ 500
degrees Celsius during various production processes
and the temperature on solid surfaces.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for reference only. Do
not use this document as a product installation guide.
3 Complete installation, operation, and maintenance information is provided
in the instructions of the product.
4 Misuse of the product may cause danger or personal injury.

2 www.wtsensor.com
Techincal Indicators
Model
Measurement
Ranges：℃
ranges
Protection tube
material
Insertion depth
L mm
Bimetal
temperature
sensor
-80—40
-40~60
0~50
0~150
0~200
0~400
0~500
0~650
1.0
1.5
1Cr-18N19Ti
304
316
316L
Hastelloy
C-276
F46
150
200
300
400
500
750
1000
2000
form
D
A
B
E
d
Axial type
105
23
178
120
Φ10
Φ12
Φ14
155
23
178
120
Radial type
105
40
135
105
72
150
42
Universal type
Bimetallic
thermometer
105
40
175
98
Product parameters
Thermal response time:
≤40s
Accuracy class
1.0, 1.5FS
Thermocouple
Class I, 1.5 ℃, Class II, 2.5 ℃
Thermal resistance
Class A ±(0.15 + 0.0051t1)
Class B ±(0.30 + 0.0051t1)
Protection class
IP65
diameter
100, 150

3 www.wtsensor.com
How to order
PCT005 -1 - B-100 - 0~400℃450 - 1
Temperature
measurement range
Eg: 0 ~ 400 ℃
Dial diameter
Eg:100
Insertion depth
Eg: 450
Product model:
PCT005
Accuracy level:
A :1.0
B, 1.5
Installation fixed form:
1. No fixed thread
2.Movable external
thread
3.Movable internal
thread
4, fixed thread
5. Fixed flange
6. Ferrule thread
7. Ferrule flange
Protection tube
material:
1:304 (typical)
2:1Cr-18N19Ti
3:316
4:316L
5:Hastelloy C-276
6:F46

4 www.wtsensor.com
Wotian reserves the right to make any change in this publication without notice. The information
provided is believed to be accurate and reliable as of this product sheet.
