Installation and safety information
Fender lowering kit
Indian FTR 1200 S
From model year 2019

Installation manual for Indian FTR 1200 S from model year 2019
• Revision: 00 • 11/12/2019 • © ABM Fahrzeugtechnik GmbH Page 2 of 4
Caution
Important safety advice:
 Working on motorcycles poses a safety risk. Some work may only be carried out by appropriately
qualified personnel. Faulty work can have serious consequences and may pose a threat to life and
health. Only undertake installation works if you are sufficiently qualified and have an official workshop
manual as well as all relevant service notifications available. Otherwise, we strongly recommend that
the installation is carried out or at least checked in a specialist workshop.
 Any work in relation to the installation, removal and tightening torque of original parts should always be
carried out in compliance with the workshop manual.
 All screws must be attached with thread-locking fluid. However, this should only be done after the
installation is complete.
 It is your responsibility to check the product regularly and to determine if a service or replacement is
required.
 Please bear in mind that some products are safety-relevant parts of your vehicle. After a fall or collision,
check the product and if there is the slightest indication of damage, you must replace it.
 Some products require registration.
 These products have been designed for a standard vehicle. ABM® Fahrzeugtechnik GmbH makes no
warranty or guarantee of any kind for any damages whatsoever arising out of the combination with
other component parts not tested by ABM, as a consequence of improper installation or inadequate
maintenance.
 Brake fluid may damage painted surfaces and fairings. Use suitable means to protect all of the surfaces
against damage.
1
Preparation
 Please read the entire safety information and installation manual carefully.
 A motorcycle not securely positioned can fall over during the following work. Therefore, make sure
that the motorbike is positioned on solid, flat ground and is secured against falling over and rolling
away.
 Keep children and pets away from the work area.
 Protect removed parts from damage.
 Please note when disassembling individual parts which screws are used to fasten them. Keep
these parts and screws and unless specified otherwise, reuse when assembling.

Installation manual for Indian FTR 1200 S from model year 2019
• Revision: 00 • 11/12/2019 • © ABM Fahrzeugtechnik GmbH Page 3 of 4
3
Installation: Frontfender lowering kit
Make sure that the motorbike is positioned securely.
Remove the original fender completely.
Attach the brackets to the fork using the countersunk screws.
Use thread-locking fluid (medium strength).
Tightening torque 8 Nm
Align fender and reattach it to the brackets using the
screws provided.
Use thread-locking fluid (medium strength).
Tightening torque 8 Nm

Installation manual for Indian FTR 1200 S from model year 2019
• Revision: 00 • 11/12/2019 • © ABM Fahrzeugtechnik GmbH Page 4 of 4
 All wires must be laid in a manner which prevents them from bending or getting pulled during spring
deflection movements and which adequately protects them against rubbing.
 After completing the work, check that all components and screws are tight and functioning correctly. Also
check the rear wheel's freewheel and the functionality of the brake system.
 Afterwards, a test drive must be done! After completing the test drive, the tightness of all screw connections
must be checked, as well as the adequate freedom of access of all moving parts. Re-test the rear wheel's
freewheel and check the brake system for overheating.
4
Final check
