WURM DOM-XP User manual

DOM-XP
4-channel weekly timer and telecontrol unit
DOM-XP_V2.10_PI_2019-04_EN Subject to technical modifications Page 1 of 4
Front view
Features
Telecontrol unit with the functions: On/Off, On/Off delay and wiping pulse (can be selected
separately for each channel)
Weekly timer with 4 channels
Master controller for BSM001
Mirroring of 4 switching channels via BSM001
Automatic summer/winter time changeover
Delay times per channel
Restoring of the logic switching state after a power failure
Manual operation of the channels through digital inputs
Documentation of the 4 digital inputs
Simple parameter settings
Display of relay states
Parameter setting through plain text menu and direct operation
Plug-in screw terminals
Clear text designation of switching outputs and digital inputs in FRIGODATA XP
Foreign-language front plates available on request
Direct connection of a CAN-USB to the service socket
Connection to the Wurm system through a Wurm CAN communication bus (C-BUS) and
FRIGODATA XP

DOM-XP
4-channel weekly timer and telecontrol unit
Page 2 of 4 Subject to technical modifications DOM-XP_V2.10_PI_2019-04_EN
Writing conventions
CAUTION
Avoid the described hazard: Otherwise minor or medium bodily injury or
property damage will result.
WARNING
Avoid the described hazard: Otherwise there is danger from electric voltage
that can lead to death or serious bodily injury.
For your safety
For safe operation and to avoid personal injury and equipment damage through operator error, always
read these instructions, become familiar with the device, and follow all safety instructions on the
product and in this document, as well as the safety guidelines of Wurm GmbH & Co. KG Elektronische
Systeme. Keep these instructions ready to hand for quick reference and pass them on with the device
if the product is sold.
Wurm GmbH & Co. KG Elektronische Systeme accepts no liability in case of improper use or use for
other than the intended purpose.
Target group
These instructions are intended for "service technicians".
Intended use
The device is a 4-channel weekly timer and telecontrol unit.
WARNING
Danger to life from electric shock and/or fire!
Switch off the power to the entire plant when carrying out installation, wiring or removal
work. Otherwise a mains voltage and/or external voltage may still be present even if the
control voltage is switched off. Always remove both power plugs (L and N).
Only qualified electricians are permitted to wire the device.
Use only the correct tools for all work.
Check all wiring after connection.
Take note of the maximum loads on all connections.
Never expose the device to moisture, for example due to condensation or cleaning
agents.
Take the
device out of operation if it is faulty or damaged and is therefore compromising
safe operation.
Do not open the device.

Do not attempt to repair the device yourself. If the device requires repairs, send it in with
an exact description of the fault.
CAUTION
Electromagnetic interference can cause faults!
Always use shielded data cables and place them far away from power lines.
Wurm Infocenter
paperless info
Software revisions and validity of documentation
Software version
V2.10
2019-04
Documentation status
Any software versions not listed are special solutions for individual projects and are not described in detail in this
document. This document automatically ceases to be valid if a new technical description is issued.
Manufacturer: Wurm GmbH & Co. KG Elektronische Systeme, Morsbachtalstraße 30, D-42857 Remscheid
For further information, see our website at www.wurm.de

DOM-XP
4-channel weekly timer and telecontrol unit
DOM-XP_V2.10_PI_2019-04_EN Subject to technical modifications Page 3 of 4
Circuit diagram
C-BUS interface Output relay
Digital inputs
Unused connections
must not be wired!
Installing and connecting
WARNING
Danger to life from electric shock and/or fire!
Switch off the power to the entire plant when carrying out installation, wiring or removal
work. Otherwise a mains voltage and/or
external voltage may still be present even if the
control voltage is switched off. Always remove both power plugs (L and N).
This device is designed for top-hat rail
installation. The housing is of a standard size and
is also suitable for installation in fuse boxes and
distribution switch boxes.
The devices can be positioned next to one
another without gaps.
53
106
90
58

DOM-XP
4-channel weekly timer and telecontrol unit
Page 4 of 4 Subject to technical modifications DOM-XP_V2.10_PI_2019-04_EN
Place the device with the upper guide edge on
the top-hat rail.
Then press the device gently downward until it
engages with the fastening safety catch on the
top-hat rail.
For wiring the data lines, we recommend using standard 2x2x0.8ø telephone cable with length up to
100m. The shielding must be grounded in the control cabinet. With cable lengths from 100m to 400m,
a shielded line with braided shield should be used.
For sensor extensions, it is recommended that sheathed cable be laid.
Cable length
Cross section
Up to 100m
0.75mm²
Up to 400m
1.5mm²
Technical data
Power supply
230V~, +10% / -15%, approx. 5VA
Digital inputs
4 x potential-free contact, for documentation only
(Internal power supply 12V=)
Output relay
4 x switching output, normally open contact, rated voltage
230V~, 4(2)A
Central unit
Single-chip microcomputer, data memory and quartz clock with
5000h power reserve
Monitoring system
Self-monitoring of data memory and microcomputer
Communication
3-wire CAN bus interface with integrated power supply,
galvanically isolated, service socket
Dimensions
(WxHxD) 106 x 90 x 58mm (DIN 43880)
Fastening
Top-hat rail TH 35-15 or TH 35-7.5 (DIN EN 60715)
Ambient temperature
Operation: 0...+55°C, storage: -25…+70°C
Weight
About 450g
CE conformity
−2014/30/EU (EMC Directive)
−2014/35/EU (Low Voltage Directive)
EAC conformity
−TR CU 004/2011
−TR CU 020/2011
RoHS II
Valid from
Version 2.10
