WC-B051-60
INSTALLATION
• Professional installation recommended.
• Prior to installation please check received
items against the “Packaging List”.
Please report any missing items to your
retailer immediately.
• Protect all surfaces from sharp objects,
high heat sources, direct prolonged
sunlight and chemical hazards.
Counter / 1 Main cabinet / 1 Screws for mirror / 6 Cover / 6
0
1
234
12300mm
"-
CHN
Tape measure Pencil Electric Drill Phillips Screwdriver Adjustable Wrench Spirit Level Quality Sealant
INSTALLATION AND ADJUSTMENT OF HINGES (if required)
PACKING LIST
REQUIRED TOOLS NOT IN BOX
INSTALLATION INSTRUCTIONS
Please use appropriate glue to secure sink to counter. Professional installation recommended.
install remove adjust height adjust laterally adjust depth
1 Mark placement of sink on back of counter. 2 Apply a continouous bead of quality
sealant to the top surface(rim) of the sink.
3 Turn the counter top upside down and place
it on a clean scratch resistant surface.
Center the sink over the cutout.
Porcelain Sinks / 2
Front of sink
Back of sink

WC-B051-60
INSTALLATION
4 Drill holes according to the main cabinet in
wall.
7 Install the counter. Seal around the top of
the cabinet with clear silicone sealant.
8 Remove the handles from inside the cabinet
doors and drawers and reinstall on the outside
Do not over-tighten when reattaching.
5 Put expanding screws into holes. 6 Drill screws into expanding screws. Put
covers onto the screws.
(1)
(2)
(3)
Install the mirror: use a pencil to mark the
placement of the screw holes on the wall,drill
the holes and insert the plastic wall anchors.
Install the screws into the wall anchors,
leaving enough of the screw exposed to hang
the mirror - approx 1/4" - 1/2".
6-8mm
9
10
