Wyndham Collection WC-R4100-72 User manual

WC-R4100-72
INSTALLATION
Prior to installation please check received
items against the "Packing List".
Please report any missing items to your
retailer immediately. Professional installation recommended.
Protect all surfaces from sharp objects,
high heat sources,direct prolonged
sunlight and chemical hazards.
PACKING LIST
1122
4 4
2
1
Vanity/Counter/Sink
Electric drill Silicone Tape measure Drill bit ( Pencil Screwdriver)
INSTALLATION INSTRUCTIONS
Φ8
Insert the anchor into the screw hole
for reinforcement.
1122
12
12
4
X
Diameter 8mm
Depth 40mm
Mark screw position
Draw horizontal line
PACKING LIST
REQUIRED TOOLS NOT IN BOX
Mark the position of the screw holes on the wall by measuring the space
between the centers of the mounting brackets on the back of the vanity.
Vertical position (X) is decided by the purchaser. Remember to mark low
enough to accommodate the sink on the top of the vanity counter or it
will be too high when installed. Use a spirit level to ensure the screw
holes are horizontal.

wall
34
56
Attach vanity to wall by lowering onto
the mounting brackets Adjust the mounting attachment as
required
Attach counter to cabinet with silicone
sealant applied to top of front and side
cabinet edges. Do not over-apply. Allow
to dry for 24 hours for proper curing.
Licensed professional installation is
recommended. These instructions are
for mounting into studs or other in-wall
reinforcement, drywall alone is not
sufficient to support wall-hung
vanities. Other installation techniques
may require a licensed professional.
silicone
silicone
LLoowweerr ssccrreeww
aaddjjuussttss ddeepptthh
UUppppeerr ssccrreeww aaddjjuussttss
vveerrttiiccaall ppoossiittiioonn
