Wyndmere Classic User manual

C L A S S I C
Ultrasonic Nebulizer
Cool Mist Aromatherapy Diffuser
Wyndmere Naturals
800-207-8538
PARTS INCLUDED
Nebulizer, Adapter, Cover, Umbrella Cover, Dispersal Nozzle
PRODUCT FEATURES
Safety: No flame or heat source since the cool mist is generated
by ultrasonic vibrations.
User Friendly: Level of mist and output duration can be adjusted
to reflect your personal needs.
Operation: Once filled the unit can operate up to 5 hours.
Digital Control: Digitally programmed to stop automatically when
minimum water level is reached. Energy efficient!
Functions: Can be used as a nebulizer, humidifier or air purifier.
Features: Special night-light with ON/Off control.
SPECIFICATIONS
External Dimension: 5” high x 6” round
Transformer: 110V – 24V/750mA; 220V-24V/800mA
Max working voltage: 24V/750mA
Max input: 18W
Operation frequency: 1.7 MHZ
Atomizing rate: 50 – 60 ml/hr (max)
Particle size: Approximately 3 micro-meters
Max Water level: No more than 1” or to marker
Min Water level: Automatically shuts off at ½”
Capacity: Approximately 9 fl oz
2
Instruction Manual
wyndmerenaturals.com

COMPONENT DESCRIPTION
A Swivel Dispersal Nozzle
B Water Level Sensor
C Umbrella Cover
D Water Tank
E Transducer/Silver Membrane
F Cover
G Power ON/OFF
H Timer Control
I Setting Indicator Lights
J LED Lights ON/OFF
K Mist Output Control
TIMER CONTROL (5 settings)
One Light: Unit works continuously; automatically stops
when water level drops below minimum
Two Lights: Unit works continuously for 2 hours and will
automatically shut off
Three Lights: Unit disperses for 5 seconds and rests for 40 seconds
Four Lights: Unit disperses for 15 seconds and rests for 50 seconds
Five Lights: Unit disperses for 30 minutes and rests for 15 minutes
MIST OUTPUT CONTROL (3 settings)
One Light: Mist output low
Three Lights: Mist output medium
Five Lights: Mist output high 3
OPERATING INSTRUCTIONS
1. Remove the Cover and Dispersal Nozzle.
2. Position the nebulizer in the desired location before filling with water. This
will help prevent water from overflowing into the interior where the electrical
grid resides.
3. Protect surfaces from water spillage or mist.
4. Fill the water tank with distilled water (recommended). The minimum level is
½ inch and the maximum is no higher than 1” (at the water level marker).
Over-filling may prevent adequate airflow and mist output.
5. Add 3-5 drops of pure essential oil to the water.
6. Securely replace the Cover and Dispersal Nozzle.
7. With dry hands, plug the power supply into the back of the unit.
8. Plug the adapter into a standard household outlet.
9. Press Power ON/OFF (F) once to turn on. Press again to turn off.
10. Select the preferred timer setting by pressing the Timer Control (G) the
appropriate number of times.
11. Select the preferred mist intensity by pressing the Mist Output Control (H)
the appropriate number of times.
12. Press LED Lights ON/OFF (I) once to turn on. Press again to turn off.
CLEANING THE NEBULIZER
1. DO NOT IMMERSE THE UNIT IN WATER.
2. DO NOT WASH IN DISHWASHER.
3. DO NOT USE any commercial cleaning agents as they can adversely affect
the atomizing rate.
4. Clean the unit with a soft cotton cloth after each use.
5. Gently clean with distilled vinegar to remove mineral deposits or rubbing
alcohol to remove essential oil residue.
4

SAFETY INSTRUCTIONS
1. Please follow the instructions to operate the product.
2. Use only the adapter supplied to operate the unit.
3. Do not fill above the water level marker. Over-filling may
damage the unit.
4. Plug in the power supply only after filling the unit with water.
5. Keep the unit on a flat and secure surface at all times.
6. Before moving the unit, make sure to unplug it from the power
source and empty the tank of water.
7. Do not operate the unit with wet hands.
8. Unplug the unit when not in use.
9. If a problem arises, shut off and unplug the unit. Do not attempt to
open the unit; repairs should be carried out only by a qualified
service center.
10. Do not immerse the unit in water.
11. The unit will automatically stop working once the water reaches the
minimum level.
12. For indoor use only.
13. Keep away from young children and pets.
5
TROUBLESHOOTING/ Solving Problems
6
The unit does
not power on or
stay powered
on.
•Check that the power supply is securely
plugged into the socket at the rear of the unit.
•Check that the main plug is securely plugged
into the wall socket.
•Check that there is adequate water in the tank
and that the water level is correct.
•Check that the Water Level Sensor is moving
freely.
PROBLEM
SOLUTION
There is no
dispersal when
powered on or
less dispersal
than usual.
•Check for correct water level.
•Check that the Water Level Sensor is moving
freely and not jammed.
•Check that the Transducer /Silver Membrane
is free of residual essential oil or mineral
deposits. See ‘CLEANING THE NEBULIZER’.
•Check that the top cover and nozzle are
securely positioned.
•Restart the unit.
Unit shuts off
shortly after
powering on
•Check the Timer Control setting. The third,
fourth and fifth settings operate with short
bursts and longer rest cycles.
