X-Rite PANTONE i1 PRO 3 PLUS User manual

EN
3
EQUIPMENT INFORMATION
If this product is used in a manner not specified by the instruction, the safety protection provided by the device
may be impaired or become inoperable.
CE Declaration
Manufacturer’s Name: X-Rite, Incorporated
Authorized Representative: X-Rite, Incorporated
Siemensstraße 12b • 63263 Neu-Isenburg • Germany
Phone:[phone] • Fax: [phone]
Model Name: i1Pro
Directive(s) Conformance: EMC 2004/108/EC LVD 2006/95/EC
FEDERAL COMMUNICATIONS COMMISSION NOTICE
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
INDUSTRY CANADA COMPLIANCE STATEMENT
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
NOTE: USB interface cable ( 2.0 m) shipped with this device must be used in order to maintain compliance with
the desired CE mark requirements, FCC Part 15 Rules, and Canadian ICES-003.
• Modifications not expressly approved by the manufacturer could void the user's authority to operate
Use of this equipment in a manner other than that specified by X-Rite, Incorporated may compromise
design integrity and become unsafe.
WARNING: This instrument is not for use in explosive environments.
ADVERTENCIA – NO use este aparato en los ambientes explosivos.
AVVERTIMENTO – NON usare questo apparecchio in ambienti esplosivi.
WARNUNG: Das Gerät darf in einer explosiven Umgebung NICHT verwendet werden.
AVERTISSEMENT: Cet instrument ne doit pas être utilisé dans un environnement explosif.
the equipment under FCC rules.
Safety InformationSafety InformationImportant Notices
CE Declaration
Hereby, X-Rite, Incorporated, declares that this device is in compliance with the essential
requirements and other relevant provisions of Directive(s) EMC 2014/30/EU, LVD 2014/35/EC,
and RoHS 2011/65/EU.
FEDERAL COMMUNICATIONS COMMISSION NOTICE
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
INDUSTRY CANADA COMPLIANCE STATEMENT
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
NOTE: USB interface cable shipped with this device must be used in order to maintain compliance with the desired
CE mark requirements, FCC Part 15 Rules, and Canadian ICES-003.

EN
4 5
User Manual
Table of contents
Package Contents 6
Device Overview 8
Installation 10
Device Status Indicators 12
Calibrating the Device 14
Scan Measurement 16
Single Pass Scan Measurement 20
Spot Measurement 22
Display Measurement 24
Ambient Light Measurement 26
Projector Measurement 28
General Maintenance 32
Troubleshooting 34
Warranty 36
Service and Support 37
Specication 38
English 5
Deutsch 43
Français 81
Italiano 119
Español 157
Português 195
日本語 233
한국어 271
简体中文 310

EN
6 7
Package Contents
1. Tripod Holder (optional)
2. Ambient Light Measuring Head (optional)
3. Ambient Light Measuring Head Case (optional)
4. Polarization Filter & Tubus (optional)
5. Polarization Filter & Tubus Case (optional)
6. Display Holder
7. Positioning Target
8. Calibration Plate
9. i1Pro 3 Device
10. USB Cable
11. Backer Board (optional)
12. Ruler (optional)
13. ColorChecker Proof (optional)
14. ColorChecker Classic (optional)
15. User Manual
16.CerticateofPerformance(notshown)
17. Carrying Case (not shown)
1
234
5
6
7
8
9
10
11
12
14
13
15

EN
8 9
Device Overview
1. Status indicator
2. Measurement button
3. Limiting aperture
4. Type label with serial number
5. Positioning sensor
6. Reference gap for ruler mount
7. Mounting interface for accessories
8. USB connector port
3
1
2
4
5
67
8

EN
10 11
Installation
Before you can use your device or see its status, you need to install the software
application on your computer. Please do not plug the device‘s USB cable into your
computer until after you have installed the software application.
1. Visit https://www.xrite.com/i1profiler to download the i1Profiler application and
install the software application on your computer.
2. Review all instructions in this user manual before you start using your new device.
3. After you have completed the software installation process, attach your i1Pro 3
PLUS device to your computer‘s USB port. If connected successfully the status
indicator lights up solid white.
The X-Rite i1Pro 3 will not work if it is connected to the USB port on your
keyboard or to a USB hub without external power supply.
i1Pro 3 power rating: 5 V 500 mA.
4

EN
12 13
The i1Pro 3 device is equipped with a device status indicator on its top housing. The
device status indicator provides feedback on the current status of the device, and
guides you through the measurement process.
General device status:
off The device is either not connected to your computer, or the latest
software to control the device is not installed or running on your
computer.
solid white The device is connected to power/USB.
pulsating white The device is connected and ready for measurement.
solid red The calibration of the device failed due to a hardware problem
(see troubleshooting section for further information).
short green pulse Indicates that the measurement button has been pressed and
the scanning motion can be started.
To avoid interference of the device status indicator with the measurement process, the
device status indicator is turned off during measurement.
Device Status Indicator

EN
14 15
Calibrating the Device
If you own multiple devices make sure that the serial number on the front and back
of the calibration plate matches the serial number of your i1Pro 3 device. Refer to the
user guide of your measurement software for additional information on the calibration
process.
1. In the center of the calibration plate is a slider to protect the white calibration tile.
Open this protective slider until it clicks into place to access the white reference
ceramic tile on this calibration plate.
2. Place the i1Pro 3 measurement device on the calibration plate. The device must
seatrmlyonthecalibrationplate.
3. Start the calibration mode in the software, and press the measurement button on
the device or in the software. Status indicator light switches off during calibration.
Once the device is successfully calibrated the status indicator light pulsates white.
If the calibration fails the status indicator light pulsates red and then returns to
solid white.
4. Whenthecalibrationisnishedyoushouldclosetheprotectivesliderforthewhite
reference ceramic tile.
A clean white reference ceramic tile is essential for providing accuracy of
your measurements. The protection cover should always be closed when
the white reference ceramic tile is not in use. If necessary you can clean the
white reference ceramic tile with isopropyl alcohol and a soft clean cloth.
1
2
3

EN
16 17
Scan Measurement
Measurement conditions
The i1Pro 3 measurement device supports multiple measurement conditions. In a
single pass scan measurement, the patches are illuminated with the LEDs in the
i1Pro 3 device.
Single Pass Measurement is required for measurement condition
• ISO13655M0|TungstenlamentlampwithUVincluded(NoFilter)
• ISO 13655 M1 | D50
• ISO 13655 M2 | Illumination with UV excluded (UVcut)
• ISO 13655 M3 | Polarization (UVcut)
• OBC | X-Rite Optical Brightener Compensation
The status indicator on the i1Pro 3 device guides you through the measurement
process.
M3Polarizationmaybeusefulinreectionmodeformeasuringmaterialshighly
reective/glossy,nonstandardmaterialsliketextiles,ceramics,etc.,andinksthatare
not fully dry.
Virtual aperture technology
During a scan measurement the i1Pro 3 device is performing 400 measurements per
second.Theautomaticpatchdetectionofthedeviceidentiesuseablemeasurements
made on a patch and unusable measurements made between two patches. Valid
measurements on a patch are averaged and the device reports the averaged result
to the software. Thanks to this technology the virtual aperture of the i1Pro 3 device
adapts to the length of a patch. For best measurement results the length of the
patches on your test chart should be selected based on the resolution of your printer.
In some cases, increasing the width of the patches will yield more accurate results.

EN
18 19
Scan Measurement
To prepare your i1Pro 3 device for a scan measurement you need to mount the
i1Pro 3 device on the ruler. Make sure your device is calibrated and the status
indicator is pulsating white before you mount it.
1. Use the magnet bars to secure the test chart on the backer board.
2. Place the ruler on the backer board.
3. Position the i1Pro 3 device in the carriage on the ruler. Make sure that the
positioning pins on the carriage slide into the reference gaps on the bottom of the
i1Pro 3 device. Double-check that the i1Pro3deviceseatsrmlyinthecarriage.
4. During scanning measurement make sure that the device’s limiting aperture glides
smoothly on the guide rail of the ruler.
5. Align the backer board for ease of use during scanning. Only apply light pressure
to the device when scanning.
The distance between the i1Pro 3 device and the surface of the printing
substrate is critical for the accuracy of your measurements. If the limiting
aperture of the device or the edge of the ruler‘s guide rail is worn out you
should replace them. Spare parts can be ordered through X-Rite‘s Service
Centers.
1
1
1
2
3

EN
20 21
Single Pass Scan Measurement
2xgreenash therowwasmeasuredsuccessfully.
2xredash therowwasnotmeasuredsuccessfullybecausenotallpatches
could be recognized. Measure the row again, but reduce your
measurement speed and make sure that the device starts and
ends the measurement before and after the patches of the test
chart.
4xredash therowwasnotmeasuredsuccessfullybecauseyoustarted
reading the patches too early without giving the LEDs enough
time to warm up. Measure the row again but allow the lamp time
to heat up before you start moving the i1Pro 3 device.
1x green;
2xredash therowwasmeasuredsuccessfullybutthesoftwareexpected
the measurement of a different row. Check if the row you
measured is the row the software is expecting.
5. Position the ruler with the device in front of the next row of your test chart and
measure the next row.
1. Make sure that your device is calibrated and the status indicator is pulsating white.
2. Position the ruler with the device on the substrate in front of row #1 of your test
chart. It does not matter if you scan the row from left to right or right to left.
3. Set your software to single scanning mode.
4. Press the measurement button on the device and wait for a short green pulse
before you start moving the device to the opposite side of the ruler. Hold the
measurement button pressed until you have reached the far end of your test chart.
The short delay before the measurement process is required to warm up the
LEDs. The status indicator on the device provides feedback if the measurement
was successful:
45

EN
22 23
Spot Measurement
To prepare your i1Pro 3 device for spot measurement you need to mount the i1Pro 3
device on the positioning target. Make sure your device is calibrated and the status
indicator is pulsating white before you mount the device. Refer to the user guide of
your measurement software for further details on the spot measurement process.
1. Mount the i1Pro 3 measurement device on the positioning target by inserting the
mounting connector on the positioning target in the mounting interface at the rear
of the i1Pro 3 device.
2. Congureyoursoftwaretotakespotmeasurements.
3. Position the device on the patch you would like to measure and press the device
down to the positioning target.
4. Press the measurement button on the device. Status indicator light switches off
during a measurement and pulsates green once the measurement has been
successfullynished.
5. To remove the i1Pro 3 device from the positioning target, gently pull the mounting
connector with the positioning target out of the mounting interface at the rear of
the i1Pro 3 device.
1
3
4

EN
24 25
Display Measurement
To prepare your i1Pro 3 device for a display measurement you need to mount the i1Pro 3
device on the display holder. Make sure your device is calibrated and the status indicator
is pulsating white before you mount the device.
1. You can adjust the length of the counter weight of the display holder for the size of
your screen. The counter weight is equipped with hook-and-loop fasteners on both
ends which allow you to shorten and lengthen the display holder to the correct length.
2. Mount the i1Pro 3 measurement device on the display holder by inserting the
mounting connector on the display holder in the mounting interface at the rear of
the i1Pro 3 device. Make sure that the nose of the i1Pro3deviceseatsrmlyinthe
display holder.
3. Fix the limiting aperture of the i1Pro 3 measurement device in the middle of your
screen.
4. Set the software for display measurement and start the measurement process in the
application. Status indicator lights switch off during measurement.
5. To remove the i1Pro 3 device from the display holder, gently pull the mounting
connector with the display holder out of the mounting interface at the rear of the i1Pro
3 device.
NOTE: Displays cannot be measured in M3 mode.
1
2
3

EN
26 27
Ambient Light Measurement
Before you start measuring, please attach the ambient light measuring head on the
limiting aperture of the i1Pro 3 device. If you own multiple devices make sure that the
serial number on the ambient light measuring head matches the serial number of your
i1Pro 3 device. The ambient light measuring head can also be used in conjunction with
the tripod holder.
1. Check that the instrument is calibrated to measure ambient light. (i.e. pulsating
white when ambient measurement mode is selected.) Calibrating ambient has
to be performed on white calibration base. The ambient light measuring head is
stored in the ambient head storage case.
2. Attach the ambient light measuring head on the limiting aperture of the i1Pro
3 device. The arrow on the ambient light measuring head must point to the
“unlocked” marking on the i1Pro 3 device.
3. Rotate the ambient light measuring head clockwise until it stops. The arrow will
stop slightly beyond the “locked” mark on the i1Pro 3 device.
4. Congureyourapplicationsoftwaretoambientlightmeasurementmodeand
press the measurement button on the device to take measurements.
NOTE: Ambient light cannot be measured in M3 mode.
2
3
4

EN
28 29
Projector Measurement
To prepare your i1Pro 3 device for projector measurements you can use the device on
the tripod holder, or mount the tripod holder on a tripod with one of the two standard
screws you supply (1). Next you need to mount the i1Pro 3 device on the tripod holder.
Make sure that your device is calibrated and the status indicator is pulsating white
before you mount the device.
1. If you are mounting the tripod holder on a tripod, follow the instructions for
mounting a tripod head in the user manual of your tripod.
2. Mount the i1Pro 3 measurement device on the tripod holder by inserting the
mounting connector on the tripod holder in the mounting interface at the rear of
the i1Pro 3 device.
3. To remove the i1Pro 3 device from the tripod holder, gently pull the mounting
connector with the tripod holder out of the mounting interface at the rear of the
i1Pro 3 device.
2
1

EN
30 31
Projector Measurement
Setup the i1Pro 3 device for projector measurements.
1. Place the i1Pro 3 device on the tripod holder next to the projector or at a distance
in front of your screen.
2. Open the locking screw on the tripod holder and adjust the angle of the i1Pro 3
device. The limiting aperture of the i1Pro 3 should point towards the center of your
screen. Close the locking screw once the device is in the right position.
3. Adjust the lighting of your room to the same conditions as you will use for the
projector and presentation.
4. Congureyoursoftwareforprojectormeasurementandfollowtheinstructionson
the screen.
NOTE: Projectors cannot be measured in M3 mode.
1
2

EN
32 33
General Maintenance
To maintain the measurement performance of your i1Pro 3 over its life time, it is
important to observe some rules and to periodically clean certain parts that are critical
for measurement performance. A clean white tile and protective glass are absolutely
critical for measurement accuracy.
• The i1Pro 3 device is sensitive to mechanical shocks. To avoid damage during
transport the i1Pro 3 must be always shipped in its original packaging.
• Do not store or operate the i1Pro 3 device in dirty, greasy or dusty environments.
Do not use the i1Pro 3 in environments with temperatures higher than 35°C
(95ºF) or less than 10°C (50ºF). Do not store the i1Pro 3 in environments with
temperatures higher than 50°C (122ºF) or less than -10°C (14ºF).The plastic
housing of the device may be cleaned using a cloth dampened in water with a
soap solution if necessary.
• The protection glass in the limiting aperture of the i1Pro 3 device may become
dusty after some time. You can remove the protective glass to clean it and the
inside of the limiting aperture:
1. Turn the limiting aperture counter-clockwise until the arrow points to the
“unlocked” position on the i1Pro 3 device.
2. Remove the limiting aperture from the device. Avoid touching the optics.
3. Remove the protection glass from the aperture by rotating counter-clockwise
until the recessed arrow inside the protective glass points to the "unlocked"
icon.
4. Clean both sides of the protection glass and the inside of the limiting aperture
with isopropyl alcohol on a soft clean cloth. This same cleaning method
appliestotheoptionalpolarizationlter.
5. Re-assemble the protection glass in the limiting aperture by rotating it
clockwise until it stops (arrow pointing to the "locked" icon).
6. Mount the limiting aperture back on the device with the arrow pointing at the
“unlocked” position on the i1Pro 3 device.
7. To lock the limiting aperture turn it clockwise until the arrow points to the
“locked” position on the i1Pro 3 device.
• Keep the white reference ceramic tile clean at all times. You can clean the white
reference ceramic tile with isopropyl alcohol on a soft clean cloth if required.
• Do not touch the diffuser disc of the ambient light measuring head. If necessary,
clean it with compressed air or isopropyl alcohol.
• The guide ruler including the "zebra stripe" can be cleaned with isopropyl alcohol
when required.
1
2
3

EN
34 35
Troubleshooting
Diagnostic Software
Use the i1Diagnostics software if you believe your i1Pro 3 is not functioning properly.
If the status indicator turns solid red after calibration the i1Pro 3’s internal sensor
diagnostic has discovered a problem.
In this case please perform the following steps:
1. Download the i1Diagnostics software at www.xrite.com/i1diagnostics and install
the software on your computer.
2. Launch i1Diagnostics Software.
3. Perform a functionality check by following the instructions given from the
i1Diagnostics Software.
4. If i1Diagnostics software reports an error store the test report and contact your
nearest X-Rite Support Center. As an alternative you can also take a look at our
online support resources http://xrite.com/support/i1Proler to troubleshoot your
issue.

EN
36 37
Warranty
X-Rite warrants this Product against defects in material and
workmanship for a period of twelve (12) months from the
date of shipment from X-Rite’s facility, unless mandatory
law provides for longer periods. During such time, X-Rite
will either replace or repair at its discretion defective parts
free of charge.
X-Rite’s warranties herein do not cover failure of warranted
goods resulting from: (i) damage after shipment, accident,
abuse, misuse, neglect, alteration or any other use not in
accordance with X-Rite’s recommendations, accompanying
documentation,publishedspecications,andstandard
industry practice; (ii) using the device in an operating
environmentoutsidetherecommendedspecicationsor
failure to follow the maintenance procedures in X-Rite’s
accompanyingdocumentationorpublishedspecications;
(iii) repair or service by anyone other than X-Rite or its
authorized representatives; (iv) the failure of the warranted
goods caused by use of any parts or consumables not
manufactured, distributed, or approved by X-Rite; (v) any
attachmentsormodicationstothewarrantedgoodsthat
are not manufactured, distributed or approved by X-Rite.
Consumable parts and Product cleaning are also not
covered by the warranty.
X-Rite‘s sole and exclusive obligation for breach of the
above warranties shall be the repair or replacement of any
part, without charge, which within the warranty period is
proven to X-Rite‘s reasonable satisfaction to have been
defective. Repairs or replacement by X-Rite shall not revive
an otherwise expired warranty, nor shall the same extend
the duration of a warranty.
Customer shall be responsible for packaging and shipping
the defective product to the service center designated by
X-Rite. X-Rite shall pay for the return of the product to
Customer if the shipment is to a location within the region in
which the X-Rite service center is located. Customer shall
be responsible for paying all shipping charges, duties, taxes,
and any other charges for products returned to any other
locations. Proof of purchase in the form of a bill of sale or
receipted invoice which is evidence that the unit is within
the Warranty period must be presented to obtain warranty
service. Do not try to dismantle the Product. Unauthorized
dismantling of the equipment will void all warranty claims.
Contact the X-Rite Support or the nearest X-Rite Service
Center, if you believe that the unit does not work anymore or
does not work correctly.
THESE WARRANTIES ARE GIVEN SOLELY TO BUYER
AND ARE IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING BUT NOT
LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE OR APPLICATION, AND NON-INFRINGEMENT.
NO EMPLOYEE OR AGENT OF X-RITE, OTHER THAN
AN OFFICER OF X-RITE, IS AUTHORIZED TO MAKE ANY
WARRANTY IN ADDITION TO THE FOREGOING.
IN NO EVENT WILL X-RITE BE LIABLE FOR ANY OF
BUYER’S MANUFACTURING COSTS, OVERHEAD, LOST
PROFITS, GOODWILL, OTHER EXPENSES OR ANY
INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES BASED UPON BREACH OF ANY WARRANTY,
BREACH OF CONTRACT, NEGLIGENCE, STRICT TORT,
OR ANY OTHER LEGAL THEORY. IN ANY EVENT OF
LIABILITY, X-RITE’S MAXIMUM LIABILITY HEREUNDER
WILL NOT EXCEED THE PRICE OF THE GOODS OR
SERVICES FURNISHED BY X-RITE GIVING RISE TO
THE CLAIM.
Service and Support
RECERTIFICATION
X-Riterecommendsanannualrecerticationofi1Pro3 spectrophotometer. Contact your X-Rite dealer or the nearest
X-RiteServiceCentertondoutmoreaboutrecertication.
SERVICE CENTERS
Visit our i1Pro 3 website at http://xrite.com to locate the nearest X-Rite Service Center or contact your X-Rite dealer
for more information.
SUPPORT OPTIONS
WearecondentyouwillbepleasedwithyournewX-Riteproduct.Atthesametime,weunderstandyourneedfor
on-demandsupportandtrainingintoday’scomplexandrapidlyevolvingworkows.Becauseofthiswearemaking
the following on-line and free support tools available to registered users.
These support tools are found at: www.xrite.com/support/i1Proler
•Freeandunlimitedaccesstothei1Prolerinteractivetrainingvideo;availablewithinthei1Prolersoftwaretoo.
• Free and unlimited access to the X-Rite on-line Help Desk, which includes detailed and helpful support articles
related to frequently asked questions.
• Free access to X-Rite’s e-mail support and call center during the warranty period for issues resulting from
general product use provided:
- You are the original registered user of the product
 -Youareusingthecurrentversionofi1Prolersoftware
- You are using currently supported hardware and supported platform (operating system)
Becausewerecognizetheneedforadvancedsupportrelatedtousingi1ProlerandX-Riteproductsinvarious
workows,aswellassupportinpostwarrantytimeperiods,wearehappytoofferfeebasedsupportprogramsand
training options delivered by X-Rite’s highly experienced Color Experts.
For complete information, please visit www.xrite.com/i1Proler/Supportoptions

EN
38 39
Specication
Spectral
engine:
i1Pro 3 PLUS: i1®technology (holographic diffraction grating with 128 pixel
diode array) with built-in wavelengths check
Spectral range: 380 - 730 nm
Physical sampling interval: 3.5 nm
Optical resolution: 10 nm
Spectral reporting: 380 nm ... 730 nm in 10 nm steps
Measurement frequency in scanning
mode: 400 measurements per second
Optics: Measurement geometry: 45º/0º ring illumination optics, ISO 13655:2017
Measurement aperture: 8 mm (0.31”) diameter
(effective measurement aperture during scanning is depending on the
patch size and measurement speed)
Illumination spot size: 12 mm (0.47”)
Light source: i1Pro 3 LED Illumination (including UV)
Reectance
measurement: spectralreectance[dimensionless]
Measurement conditions: M0: UV included - ISO 13655:2017 M1: D50 - ISO 13655:2017
M2: ISO 13655:2017 M3: Polarization - ISO 13655:2017
OBC: OpticalBrightenerCompensation(OBC)withi1Prolersoftware
Calibration: Manual on external ceramic white reference
Measurement background: white, ISO 13655:2017; for measurements on backup board
Minimal patch size in spot mode
(Width x Height):
14 x 14 mm (0.55” x 0.55”)
Minimal patch size in scanning mode
(Width x Height):
Maximum scan length:
16 x 16 mm (0.63” x 0.63”) with i1iO
16 x 16 mm (0.63” x 0.63”) with sensor ruler
20 x 16 mm (0.79” x 0.63”) without sensor ruler
20 x 16 mm (0.79” x 0.63”) with sensor ruler in M3 Mode
22 x 16 mm (0.87” x 0.63”) without sensor ruler in M3 Mode
515 mm (20.28")
Inter-Instrument-Agreement: 0.4∆E00*average,1.0∆E00*max.
(deviation from X-Rite manufacturing standard at a temperature of 23ºC
(73.4ºF) on 12 BCRA tiles (D50, 2º))
Short-term repeatability: 0.1∆E94*onwhite(D50,2°,meanof10measurementsevery3son
white)
Emission
measurement: spectralradiance[mW/nm/m2/sr],luminance[cd/m2]
Measurement range: 0.2 - 5000 cd/m2on a typical LCD-Monitor
Short-term repeatability: x,y ±0.002 typ. (5000 K, 80 cd/m2)
Ambient light
measurement:
i1Pro 3 PLUS: spectralirradiance[mW/nm/m2],illuminance[lux]
cosine corrected diffusor light measurement head
Interface: USB 1.1
