Xerox Wide Format 6030 User manual

Version 3.0
January 2006
Xerox 6030/6050 Wide Forma
t
Copier/Printer User Guide
701P45100

Xerox Corporation
Global Knowledge & Language Services
800 Phillips Road Bldg. 845-17S
Webster, NY 14580
Copyright © 2006 Xerox Corporation. All rights reserved.
Printed in the United States of America.
Copyright protection claimed includes all forms and matters of copy-
righted material and information now allowed by statutory or judicial
law or hereinafter granted, including without limitation, material gener-
ated from the software programs that are displayed on the screen such
as styles, templates, icons, screen displays, looks, etc.
AIX is a trademark of International Business Machines Corporation.
AutoCAD is a registered trademark of AutoDesk, Inc.
HDI is an acronym for Heidi® Device Interface. Heidi is a registered
trademark of AutoDesk, Inc.
HP-GL is a trademark of Hewlett-Packard Company.
Macintosh and AppleTalk are registered trademarks of Apple Com-
puter, Inc.
Microsoft® Windows, Windows 95/98, Windows Me, Windows NT®,
Windows® XP, Windows® 2000, Windows® Server 2003 are trade-
marks of Microsoft Corporation.
Internet Explorer is a copyright protected program of Microsoft Corpo-
ration.
Netscape is a registered trademark of Netscape Communications Cor-
poration.
Solaris and SunOS are registered trademarks of Sun Microsystems, Inc.
UNIX is a registered trademark of Open Group Company Limited
XEROX®, The Document Company®, the digital X®, Xerox
6030/6050 Wide Format Printer, and Versatec are the trademarks of or
licensed to XEROX CORPORATION.

Preface
Thank you for using the Xerox 6030/6050 Wide Format Copier/Printer User Guide
(hereinafter known as 6030/6050 Wide Format).
This User Guide describes the basic operations and the detailed functions of the Xerox
6030/6050 Wide Format Copier, Printer, and integrated Scanner. It also includes usage
precautions, safety, replenishing toner, replacing paper, troubleshooting, and other
general instructions.
The explanations provided in this User Guide assume that the user has a basic
knowledge of operating the computer and network configuration in use. Refer to the
manuals supplied with the computer, Windows related documentation, and the manuals
supplied with the network system for details on computer and network operations.

Conventions
This User Guide uses the following symbols and conventions:
< > key Indicates the keys on the keyboard.
Press the <Enter> key.
[ ] Indicates the menus and display items on the screens.
Select either the [On] or [Off] buttons to display [Job
Name], [Owner], and [Reason] in that order.
""Indicates areas of reference within this User Guide.
Also indicates messages.
Refer to "3.2 Print Services".
A message stating " Additional Port Information Required. The
Device could not be identified
" appears.
Indicates important information which you should read.
Indicates additional information on operations or features.
Indicates reference sources.
Indicates examples.

Safety Notes
Read these safety notes carefully before using this product to ensure you operate the equipment safely.
Your Xerox product and recommended supplies have been designed and tested to meet strict safety
requirements. These include safety agency approval, and compliance with established environmental
standards. Please read the following instructions carefully before operating the product and refer to
them as needed to ensure the continued safe operation of your product.
The safety and environment testing and performance of this product have been verified using Xerox
materials only.
WARNING: Any unauthorized alteration, which may include the addition of new
functions or connection of external devices, may affect the product
certification. Please contact your authorized local dealer for more
information
Warning Markings
All warning instructions marked on or supplied with the product should be followed.
Warning This WARNING alerts user to areas of the product where there is the
possibility of personal injury.
Warning This WARNING alerts users to areas of the product where there are
heated surfaces, which should not be touched.
WARNING MARKINGS
WARNING
This product is certified manufactured and tested in compliance with strict safety
and radio frequency interference regulations. Any unauthorized alteration which,
includes the addition of new functions or the connection of external devices, may
affect this certification. Please contact your local XEROX Limited representative
for a list of approved accessories.
WARNING
In order to allow this equipment to operate in proximity to Industrial, Scientific, and
Medical (ISM) equipment, the external radiation from the ISM equipment may have
to be limited or special mitigation measures taken.

WARNING
Shielded cables must be used with this equipment to maintain compliance with
Council Directive 89/336/EEC.
Electricity at Work Regulations
The Electricity at Work Regulation 1989 came into force in England and Wales on the 1 April 1990.
This 1989 Regulation places a duty on all employers and self-employed persons to ensure the electrical
system in their premises are constructed, maintained and operated in such a manner as to prevent, so far
as reasonably practical, danger. This includes ensuring all electrical equipment connected to such elec-
trical systems are safely constructed, maintained and operated. All Xerox equipment have been
designed to exacting safety standards. They have all undergone a variety of stringent safety tests includ-
ing earth bond, insulation resistance and electrical strength tests. Xerox manufacturing plants have been
awarded ISO 9000 quality certification and are subject to regular audits by the British Standards Institu-
tion or equivalent national standards body. Xerox equipment which has been properly and regularly ser-
viced and maintained should not have to undergo additional specific safety tests pursuant to the 1989
Regulation. Customers wishing to complete safety testing should contact Xerox for advice prior to any
test implementation. Xerox equipment should, however, be properly and regularly serviced and main-
tained at all times.
QUESTION: What is the Electricity at Work Regulation?
ANSWER: The Electricity at Work Regulation 1989 came into force in England and Wales on the
1 April 1990. This 1989 Regulation places a duty on all employers and self-employed persons to ensure
the electrical systems in their premises are constructed, maintained and operated in such a manner as to
prevent, so far as reasonably practicable, danger. This includes ensuring all electrical products con-
nected to such electrical systems are safely constructed, maintained and operated.
QUESTION: Does Xerox comply with the Electricity at Work Regulation?
ANSWER: The regulation places a duty on all employers and self-employed persons to ensure the elec-
trical systems in their premises are, effectively safe. The regulation does not impose on, amongst others,
manufacturers or suppliers of such electrical systems. However, rest assured that all Xerox equipment
which Xerox and its authorized distributors supplies to customers, conform with all the relevant safety
legislation and standards.
QUESTION: Is Xerox equipment safe?
ANSWER: All Xerox equipment supplied by Xerox and their authorized distributors conform to all
relevant safety legislation and standards.
The Electricity at Work Regulation (in England and Wales) UK ONLY

QUESTION: Is the Xerox equipment in my premises safe?
ANSWER: All Xerox equipment supplied by Xerox and its authorized distributors conform to all rele-
vant safety legislation and standards. However, like all electrical equipment, they have to be regularly
serviced and maintained by competent persons. Xerox Customer Service Engineers ensure Xerox equip-
ment is serviced and maintained to exacting Xerox safety standards. If you would like your Xerox
equipment to be serviced and maintained to such high standards, please contact your local Xerox Cus-
tomer Service Organization. They will be pleased to assist you.
QUESTION: Does the Xerox equipment in my premises comply with the Electricity at Work Regula-
tions?
ANSWER: All employers and self-employed persons must ensure that the electrical systems in their
premises are safe. This will include ensuring Xerox equipment in such premises is safe. Xerox Product
Safety function has prepared a guide which contains a list of tests which may be completed by your
Xerox Customer Service Organization.
THESE TESTS MUST BE CARRIED OUT ONLY BY PERSONS WHO POSSESS THE RELEVANT SKILL,
KNOWLEDGE AND EXPERIENCE TO CARRY OUT SUCH TESTS.
Please contact the Xerox Customer Service Organization for further information.
THE USE OF INAPPROPRIATE TEST PROCEDURES AND TEST EQUIPMENT MAY PROVIDE MISLEADING
RESULTS AND MAY CAUSE DEATH, PERSONAL INJURY AND/OR DAMAGE TO PROPERTY.
QUESTION: I would like to carry out my own safety tests on the Xerox equipment in my premises.
ANSWER: You may, of course, request such tests as you deem necessary to satisfy yourself that your
Xerox equipment is safe. Your Xerox Customer Support will be pleased to advise you on such
testing.
QUESTION: I require records of all tests
ANSWER: After safety testing, your Xerox Customer Service Engineer will provide you with a certifi-
cate which details the results of all tests completed. In the event of any defect being noted, the Xerox
equipment will be switched off and disconnected from the supply until the defect has been corrected.
You will be advised of such action to enable such defects to be corrected.
PLEASE NOTE: YOU MUST ENSURE THAT YOUR XEROX EQUIPMENT IS SAFE AT ALL TIMES
Electrical Supply
This product shall be operated from the type of electrical supply indicted on the
product 's data plate label. If you are not sure that your electrical supply meets the
requirements, please consult your local power company for advice.

This product must be connected to a protective earth circuit.
This product is supplied with a plug that has a protective earth pin. This plug will fit
only into an earthed electrical outlet. This is a safety feature. To avoid risk of elec-
tric shock, contact your electrician to replace the electrical outlet if you are unable
to insert the plug into it. Never use an earthed adapter plug to connect the product
to an electrical outlet that lacks an earth connection terminal.
Operator Accessible Areas
This equipment has been designed to restrict operator access to safe areas only.
Operator access to hazardous areas is restricted with covers or guards, which
would require a tool to remove. Never remove these covers or guards.
Maintenance
Any operator product maintenance procedures will be described in the user docu-
mentation supplied with the product. Do not to carry out any maintenance on this
product, which is not described in the customer documentation.
Cleaning Your Product
Before cleaning this product, unplug the product from the electrical outlet. Always
use materials specifically designated for this product; the use of other materials
may result in poor performance and may create a hazardous situation. Do not use
aerosol cleaners; they may be explosive and flammable under certain circum-
stances.
WARNING

Ensure that the power connection for your machine satisfies these require-
ments
•Use only the power cord supplied with this equipment.
•The socket outlet shall be installed near the equipment and shall be easily accessible.
•Plug the power cord directly into a grounded electrical outlet. Do not use an extension cord. If
you do not know whether or not an outlet is grounded, consult a qualified electrician.
•This equipment is to be used on a dedicated 20A, 208-240 Vac 60Hz circuit or 16A, 220-240
Vac 50Hz circuit. The equipment must be connected to a grounded main outlet. If this
machine needs to be moved to a different location, contact a Xerox service representative or
your authorized local representative or service support organization.
•Improper connection of the equipment-grounding conductor can result in electrical shock.
•Do not place this equipment where people might step on or trip on the
power cord.
•Do not place objects on the power cord.
•Do not override or disable electrical or mechanical interlocks.
•Do not obstruct the ventilation openings.
•Never push objects of any kind into slots or openings on this equipment.
Emergency Power Off
If any of the following conditions occur, switch off the power to the machine imme-
diately and disconnect the power cord from the electrical outlet. Call an authorized
local service representative to correct the problem.
•The equipment emits unusual noise or odors.
•The power cord is damaged or frayed.
•A wall panel circuit breaker, fuse, or other safety device has been tripped.
•Liquid is spilled into the copier/printer.
•The equipment is exposed to water.
•Any part of the equipment is damaged.
The only method to remove all power from the machine is to disconnect the power cord plug from the electrical outlet.
WARNING - Electrical Safety Information
CAUTION

Disconnect Device
The power cable is the disconnect device for this equipment. It is attached to the
back of the machine as a plug-in device. To remove all electrical power from the
equipment, disconnect the power cable from the electrical outlet.
Xerox equipment and supplies have been designed and tested to meet strict
safety requirements. These include safety agency examination, approval and com-
pliance with established environmental standards. To ensure the continued safe
operation of your Xerox/Fuji Xerox equipment, follow these safety guidelines at all
times.
Do These:
•Always connect equipment to a correctly grounded power outlet. If in doubt, have the outlet
checked by a qualified electrician.
•Always locate the machine on a solid support surface (not on plush carpet) that has
adequate strength to support the weight of the machine.
•This equipment must be connected to a protective earth circuit.
This equipment is supplied with a plug that has a protective earth pin. This plug will
fit only into an earthed electrical outlet. This is a safety feature. To avoid risk of
electric shock, contact your electrician to replace the electrical outlet if you are
unable to insert the plug into it. Never use a plug that lacks an earth connection
terminal to connect the product to an electrical outlet.
•Always follow all warnings and instructions that are marked on or supplied with the
equipment.
•Always exercise care when moving or relocating equipment. Please contact your local Xerox/
Fuji Xerox Service Department, or your local support organization to arrange relocation of
the product to a location outside of your building.
•Always locate the equipment in an area that has adequate ventilation, and the room for
servicing. See the Install guide for minimum dimensions.
•Always use materials and supplies specifically designed for your Xerox/Fuji Xerox
equipment. Use of unsuitable materials may result in poor performance.
•Always unplug this equipment from the electrical outlet before cleaning.
Do Not Do These:
•Never use a plug that lacks an earth connection terminal to connect the product to an
electrical outlet.
•Never attempt any maintenance function that is not specifically described in this
documentation.
•This equipment should not be placed in a built-in installation unless proper ventilation is
provided, please contact your Authorized local dealer for further information.
Operational Safety Information

•Never remove covers or guards that are fastened with screws. There are no operator
serviceable areas within these covers.
•Never locate the equipment near a radiator or any other heat source.
•Never push objects of any kind into the ventilation openings.
•Never override or "cheat" any of the electrical or mechanical interlock devices.
•Never operate the equipment if you notice unusual noises or odors. Disconnect the power
cord from the electrical outlet and contact your local Xerox/Fuji Xerox Service Representative
or Service Provider immediately.
Do not attempt any maintenance procedure that is not specifically described in the
documentation that is supplied with your copier/printer.
•Do not use aerosol cleaners. The use of cleaners that are not approved may cause poor
performance of the equipment, and could create a dangerous condition.
•Use supplies and cleaning materials only as directed in this manual. Keep all of these
materials out of the reach of children.
•Do not remove covers or guards that are fastened with screws. There are no parts behind
these covers that you can maintain or service.
•Do not perform any maintenance procedures unless you have been trained to do them by an
authorized local dealer or unless a procedure is specifically described in the user manuals.
This product will produce ozone during normal operation. The ozone produced is
heavier than air and is dependent on copy volume. Providing the correct environ-
mental parameters as specified in the Xerox installation procedure will ensure that
the concentration levels meet safe limits.
If you need additional information about ozone, please request the Xerox publica-
tion Ozone by calling 1-800-828-6571 in the United States and Canada. In other
markets please contact your authorized local dealer or Service Provider.
Maintenance Information
Ozone Safety Information

Store all consumables in accordance with the instructions given on the package or
container.
•Keep all consumables away from the reach of children.
•Never throw toner, toner cartridges, or toner containers into an open flame.
United States, Canada, Europe, Australia/
New Zealand
This equipment has been tested and found to comply with the limits for a class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interfer-
ence in which case the user will required to correct the interference at his own
expense.
Changes and modifications to this equipment not specifically approved by Xerox/
Fuji Xerox may void the user's authority to operate this equipment.
Shielded interface cables must be used with this equipment to maintain compli-
ance with FCC regulations in the United States and the Radio Communications
Act 1992 in Australia/New Zealand as applicable.
Canadian EME
This Class "A" digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe "A" est conforme à la norme NMB-003 du
Canada.
For Consumables
Radio Frequency Emissions

This product is certified by the following Agencies using the Safety standards listed.
Agency Standard
TUV Rheinland of North America, Inc. UL60950:2000 (USA)
Can/CSA-c22.2 No. 60950-00 (Canada)
TUV Rheinland Japan Ltd. IEC60950:1999
Product Safety Certification

Regulatory Information
CE Mark
The CE mark applied to this product symbolizes Xerox's declaration of conformity
with the following applicable Directives of the European Union as of the dates indi-
cated:
January 1, 1995: Council Directive 72/23/EEC amended by Council directive 93/
68/EEC, approximation of the laws of the member states related to low voltage
equipment.
January 1, 1996: Council directive 89/336/EEC, approximation of the laws of the
member states related to electromagnetic compatibility.
March 9, 1999: Council Directive 99/5/EC, on radio equipment and telecommuni-
cations terminal equipment and the mutual recognition of their conformity.
A full declaration of conformity, defining the relevant directives and referenced
standards, can be obtained from your Authorized local dealer.
WARNING: In order to allow this equipment to operate in proximity to Industrial
Scientific and Medical (ISM) equipment, the external radiation from the ISM equip-
ment may have to be limited or special mitigation measures taken.
WARNING: This is a Class A product. In a domestic environment the product may
cause radio frequency interference, in which case the user may be required to
take adequate measures.
WARNING: Shielded interface cables must be used with this product to maintain
compliance with Council Directive 89/336/EEC.

Environmental Compliance
USA - Energy Star
As an ENERGY STAR partner, Xerox Corporation/Fuji Xerox has determined that
(the basic configuration of) this product meets the ENERGY STAR guidelines for
energy efficiency.
The ENERGY STAR and ENERGY STAR MARK are registered United States
trademarks.
The ENERGY STAR Office Equipment Program is a team effort between U.S.,
European Union and Japanese governments, and the office equipment industry to
promote energy-efficient copiers, printers, fax, multifunction machine, personal
computers, and monitors. Reducing product energy consumption helps combat
smog, acid rain and long-term changes to the climate by decreasing the emissions
that result from generating electricity.
Xerox ENERGY STAR equipment is preset at the factory to enter a ”low power”
state and/or shut off completely after a specified period of use. These energy-sav-
ing features can reduce product energy consumption in half when compared to
conventional equipment.
Canada - Environmental Choice
Terra Choice Environmental Services, Inc. of Canada has verified that this product
conforms to all applicable Environmental Choice EcoLogo requirements for mini-
mized impact to the environment.
As a participant in the Environmental Choice program, Xerox Corporation has
determined that this product meets the Environmental Choice guidelines for
energy efficiency.
Environment Canada established the Environmental Choice program in 1988 to
help consumers identify environmentally responsible products and services.
Copier, printer, digital press and fax products must meet energy efficiency and
emissions criteria, and exhibit compatibility with recycled supplies. Currently, Envi-
ronmental Choice has more than 1,600 approved products and 140 licensees.
Xerox has been a leader in offering EcoLogo approved products.

Product Recycling and Disposal
USA
Xerox operates a world wide equipment take back and reuse/recycle program.
Contact your Xerox Sales Representative (1-800-ASK-XEROX) to determine
whether this Xerox product is part of the program. For more information about
Xerox environmental programs, visit www.xerox.com/environment.
If you are managing the disposal of your Xerox product, please note that the prod-
uct contains lead, mercury and other materials whose disposal may be regulated
due to environmental considerations. The presence of lead and mercury is fully
consistent with global regulations applicable at the time that the product was
placed on the market. For recycling and disposal information, contact your local
authorities. In the United States, you may also refer to the Electronic Industries
Alliance web site: www.eiae.org.

Illegal Copies and Printouts
USA
Congress, by statute, has forbidden the reproduction of the following subjects under
certain circumstances. Penalties of fine or imprisonment may be imposed on those
guilty of making such reproductions.
1. Obligations or Securities of the United States Government, such as:
Certificates of Indebtedness National Bank Currency
Coupons from Bonds Federal Reserve Bank Notes
Silver Certificates Gold Certificates
United States Bonds Treasury Notes
Federal Reserve Notes Fractional Notes
Certificates of Deposit Paper Money
Bonds and Obligations of certain agencies of the government, such as FHA, etc.
Bonds. (U.S. Savings Bonds may be photographed only for publicity purposes in
connection with the campaign for the sale of such bonds.)
Internal Revenue Stamps. (If it is necessary to reproduce a legal document on
which there is a canceled revenue stamp, this may be done provided the
reproduction of the document is performed for lawful purposes.)
Postage Stamps, canceled or uncanceled. (For philatelic purposes, Postage
Stamps may be photographed, provided the reproduction is in black and white and
is less than 75% or more than 150% of the linear dimensions of the original.)
Postal money Orders.
Bills, Checks, or Draft of money drawn by or upon authorized officers of the United
States.

1. Stamps and other representatives of value, of whatever denomination, which
have been or may be issued under any Act of Congress.
2. Adjusted Compensation Certificates for Veterans of the World Wars.
3. Obligations or Securities of any Foreign Government, Bank, or Corporation.
4. Copyrighted materials, unless permission of the copyright owner has been
obtained or the reproduction falls within the "fair use" or library reproduction
rights provisions of the copyright law. Further information of these provisions
may be obtained from the Copyright Office, Library of Congress, Washington,
D.C. 20559. Ask for Circular R21.
5. Certificates of Citizenship or Naturalization. (Foreign Naturalization Certificates
may be photographed.)
6. Passports. (Foreign Passports may be photographed.)
7. Immigration Papers.
8. Draft Registration Cards.
9. Selective Service Induction Papers that bear any of the following Registrant's
information:
Earnings or Income Dependency Status
Court Record Previous military service
Physical or mental condition
Exception: United States military discharge certificates may be photographed.
10. Badges, Identification Cards, Passes, or Insignia carried by military personnel,
or by members of the various Federal Departments, such as FBI, Treasury, etc.
(unless photograph is ordered by the head or such department or bureau.)
Reproducing the following is also prohibited in certain states:
Automobile Licenses - Drivers' Licenses - Automobile Certificates of Title.
The above list is not all-inclusive, and no liability is assumed for its completeness or
accuracy. In case of doubt, consult your attorney.

Canada
Parliament, by statute, has forbidden the reproduction of the following subjects
under certain circumstances. Penalties of fine or imprisonment may be imposed on
those guilty of making such reproductions.
1. Current bank notes or current paper money.
2. Obligations or securities of a government or bank.
3. Exchequer bill paper or revenue paper.
4. The public seal of Canada or of a province, or the seal of a public body or
authority in Canada, or of a court of law.
5. Proclamations, orders, regulations or appointments, or notices thereof (with
intent to falsely cause same to purport to have been printed by the Queen's
Printer for Canada, or the equivalent printer for a province).
6. Marks, brands, seals, wrappers or designs used by or on behalf of the
Government of Canada or of a province, the government of a state other than
Canada or a department, board, Commission or agency established by the
Government of Canada or of a province or of a government of a state other than
Canada.
7. Impressed or adhesive stamps used for the purpose of revenue by the
Government of Canada or of a province or by the government of a state other
than Canada.
8. Documents, registers or records kept by public officials charged with the duty of
making or issuing certified copies thereof, where the copy falsely purports to be
a certified copy thereof.
9. Copyrighted material or trademarks of any manner or kind without the consent of
the copyright or trademark owner.
The above list is provided for your convenience and assistance, but it is not all-
inclusive, and no liability is assumed for its completeness accuracy. In case of
doubt, consult your solicitor.

Other Countries
Copying certain documents may be illegal in your country. Penalties of fine or
imprisonment may be imposed on those found guilty of making such reproductions.
- Currency notes
- Bank notes and cheques
- Bank and government bonds and securities
- Passports and identification cards
- Copyright material or trademarks without the consent of the owner
- Postage stamps and other negotiable instruments
This list is not inclusive and no liability is assumed for either its completeness or
accuracy. In case of doubt, contact your legal counsel.
These Xerox Digital Copiers/Printers are in compliance with various governmental
agencies and national safety regulations. All system ports meet the requirements
for Safety Extra Low Voltage (SELV) circuits for connection to customer-owned
devices and networks. Additions of customer-owned or third-party accessories that
are attached to these printers/copiers must meet or exceed the requirements pre-
viously listed. All modules that require external connection must be installed per
Xerox installation procedures.
Safety Extra Low Voltage Approval
