Appendix K
Xerox 4045 Printer
This appendix describes the features and fonts available for the
Xerox 4045 printer.
Features The Xerox 4045 printer features:
°Downloaded or cartridge fonts. All fonts must be purchased
through Xerox.
°Printer resident memory for graphics and font downloading.
The user may purchase a variable amount of memory for the
Xerox 4045; we recommend the maximum for use with fonts
and graphics.
Cartridge
and
Downloaded
Fonts
CliqPage supports the following fonts, in any size, available
through Xerox.
°Tms Rmn
°Helv
°Century Schoolbook
°Univers
Before using cartridge fonts, you must inform CliqPage through
the font downloading scripts. See Appendix A in this manual for
details. This downloading/informing must be done for each font
and pointsize you plan to use. It is recommended that a script be
set up for every font and pointsize in the cartridge.
If you have purchased fonts in disk form from Xerox, they should
be loaded into the /xerox/raster directory within the fonts sub-
directory. Do not change the names of the original Xerox files.
The Xerox fonts are in MS-DOS format. Depending on your
computer system, a number of programs are available for direct
reading and/or transmittal of the data. Then download the needed
fonts to the printer.
CliqPage –Appendix K-1

CliqPage uses the following codes to access these fonts.
Code Type
ZA Times Roman Normal
ZB Times Roman Italics
ZC Times Roman Bold
ZD Times Roman Bold Italic
ZE Helvetica Normal
ZF Helvetica Italics
ZG Helvetica Bold
ZH Helvetica Bold Italics
ZI Century Normal
ZJ Century Italics
ZK Century Bold
ZL Century Bold Italics
ZM Univers Normal
ZN Univers Italics
ZO Univers Bold
ZP Univers Bold Italics
S Special Characters
Limitations Please note that additional special characters listed in Appendix C
may not be available.
Only characters present in the Xerox fonts can be printed with
CliqPage.
There is a limit of seven fonts per page on the Xerox 4045. The
printer’s memory is shared among downloaded fonts and graphics.
Graphics The Xerox 4045 can handle integrated text and graphics.
The amount of memory available for graphics depends on the
amount purchased with the machine and how much has been used
for downloaded fonts.
A total of six graphics may be used on a page of output.
The Xerox 4045 printer cannot produce shades or patterns and the
printer ignores these commands.
K-2 CliqPage –Appendix

Unprintable
Margins When laser printers print close to the edge of the paper, print den- sity can become unreliable. Therefore, it is recommended that all
margins be a minimum of one half inch.
