Product Safety Data Sheet
Phaser 6140
Page 1 of 3
_________________________________________________________________________
PRODUCT DESCRIPTION
Phaser 6140 Color Printer
MANUFACTURER INFORMATION
XEROX Corporation
P.O. Box 1000
Wilsonville, Oregon 97070-1000
PRODUCT DIMENSIONS
Depth Width Height
Phaser 6140N/DN 457 mm / 18.0 inches 400 mm / 15.8 inches 415 mm / 16.4 inches
WEIGHT
Phaser 6140N 18.35 kg / 40.5 lbs
Phaser 6140DN 19.5 kg / 43.0 lbs
ELECTRICAL INFORMATION
115 V 230 V
Voltage (Volts) 110-127 Vac 220-240 Vac
Frequency (Hertz) 50/60 Hz 50/60 Hz
Current (Amps) 9 A 5 A
PRODUCT SAFETY CERTIFICATION
Standard Certifying Body
Low Voltage Directive •2006/95/EC XEROX Limited
CB Report & Certificate •IEC 60950-1:2005
•EN 60950-1:2006
•IEC 60825-1:1993 +A1:1997 +A2:2001
•EN 60825-1:1994 +A1:2002 +A2:2001
TÜV Rheinland
UL Report •UL 60950-1, 1st Edition
•CAN/CSA C22.2 No. 60950-1-03, 1st
Edition
UL
ELECTROMAGNETIC COMPATIBILITY CERTIFICATION
Standard Certifying Body
EMC Directive •2004/108/EC XEROX Limited
EMC Report •FCC Part 15 Subpart B, Class B
•EN 55022:2006, Class B
•EN 61000-3-2:2006, Class A
•EN 61000-3-3:1995 +A1:2001
+A2:2005
•EN 55024:1998 +A1:2001 +A2:2003
EMC Kashima

Product Safety Data Sheet
Phaser 6140
Page 2 of 3
_______________________________________________________________________________
POWER CONSUMPTION
115 V
Off Mode (Wh/hr) Power Save (Wh/hr) Standby (Wh/hr) Run Mode (Wh/hr)*
0 5 38 333
230 V
Off Mode (Wh/hr) Power Save (Wh/hr) Standby (Wh/hr) Run Mode (Wh/hr)*
0 6 39 335
*color simplex printing
HEAT OUTPUT
115 V
Off Mode (BTU/hr) Power Save (BTU/hr) Standby (BTU/hr) Run Mode (BTU/hr)*
0 17 129 1137
230 V
Off Mode (BTU/hr) Power Save (BTU/hr) Standby (BTU/hr) Run Mode (BTU/hr)*
0 20 134 1143
NOTE: The electrical power information provided should not be used to define the electrical support required for
this product. Consult your Xerox representative if you require detailed information.
*color simplex printing
OPERATING ENVIRONMENT
Ambient Temperature (°C / °F) Relative Humitidy (%)
Operating 10 to 32°C / 50 to 90°F 15 to 85% RH
Non-Operation -20 to 40°C / -4 to 104°F to % RH
LIGHT SOURCE
Laser – FDA/CDRH Accession Number 0831196-000
AUDIBLE NOISE
Declared noise emissions in accordance with ISO 9296:
Model: Phaser 6140N
(Base Configuration) Idling Operating (Standard Mode 20ppm)
LWAd (1B=10dB)LWAd = 3.7 B LWAd = 6.6 B
Bystander Position (1.0 m) LpA = 22 dB LpA = 51 dB

Product Safety Data Sheet
Phaser 6140
Page 3 of 3
_______________________________________________________________________________
CHEMICAL EMISSIONS
Tested in accordance with RAL-UZ 122:
Emission Rate (mg/h)
(monochrome - Printing Phase)
Ozone <0.076 mg/h
Styrene 0.24 mg/h
Particles (Dust) 0.32 mg/h
TVOC 2.9 mg/h
Benzene <0.0003 mg/h
OZONE FILTER REPLACEMENT
Not applicable
