Mi Air Purifier 3H User Manual

This version is for private use only and should not be distributed.
1
Warning
• Turn off and unplug the purifier before moving it.
• The purifier cannot turn on when the fan grille and the filter compartment cover are not installed properly.
• Maintain a distance of at least 20 cm between the air inlets and walls or other objects.
• Frequently remove dust, hair, and other particles from the outer mesh screen of the filter, so as to reduce the
chance of bacteria growth.
• Remove dust, hair, and particles from the purifier's air inlets to prevent a reduction of air intake.
• Cover the air outlet to prevent dust, hair, and other particles from falling in when the purifier is le unused for a
long time.
To avoid fire, electric shocks, or other damage, use the power cord and electrical outlet as instructed below:
• Do not excessively pull, twist or bend the power cord, as this may expose or break the cord's core.
• The power cord must be plugged into a suitable electrical outlet.
• Use the power cord that was provided with the purifier, do not use any third party power cords.
• Always unplug the purifier before carrying out maintenance to or moving the air purifier.
• When the power cord is damaged, it must be replaced with a genuine power cord purchased from the
manufacturer or aer-sales service department.
• Immediately stop using the purifier when it makes unusual sounds, gives off bad odors, overheats, or its fan
rotates irregularly.
• Do not stick your fingers or foreign objects into the protective parts, movable parts, air inlets, or air outlets.
• Keep objects such as hairs or fabrics away from the purifier to avoid blocking the air inlets or air outlets.
• Do not sit on, lean on or tilt the purifier.
• When using in conjunction with gas-fueled appliances (such as gas stoves, gas heaters), please ventilate
sufficiently to avoid carbon monoxide poisoning.
• Do not pour liquids, nor throw powders or other small substances into the purifier's air outlet.
Do not use the purifier in the following circumstances, as they may result in electric shocks, fire, or other
damage:
• Near open flames, such as candles, incense burners, stoves, fireplaces, cigarees, firecrackers, lighters, multi-
purpose torches, candle lighters, or fire pans.
• Near appliances that generate high temperatures, such as electric heaters, fan heaters, electric foot warmers,
electric stoves, electric irons.
• Make sure no inflammable objects get into the purifier.
• In unstable locations where the purifier can easily fall over.
• In environments that are extremely hot, humid, or damp, such as bathrooms.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• · Cleaning and user maintenance shall not be made by children without supervision.

This version is for private use only and should not be distributed.
2
Product Overview
Read this manual carefully before use, and retain it for future reference.
Note: Illustrations of the product, accessories, and user interface in this user manual are
for reference purposes only. The actual product and functions may vary due to product
enhancements.
Display On/Off
Buon
Laser Particle
Sensor
Filter
Compartment
Cover
Power Cord
Connector
Temperature &
Humidity Sensor
OLED Display
Front Rear
Fan Grille
On/Off & Mode
Buon

This version is for private use only and should not be distributed.
3
Product Overview
Display
On/Off & Mode Buon
Temperature
Humidity
PM2.5
Mode
Wi-Fi
Air Quality Indicator
One of the colors below will display
according to the PM2.5 value
25℃60%
025
Auto: Automatically switches modes
according to air quality condition.
Sleep: Ultra-low noise for a
comfortable sleeping environment.
Low speed
Medium speed
High speed
Manual: Set and save the coverage
area and the purifying efficiency in
the app.
Green
Orange
Red
0-75 μg/m3
76-150 μg/m3
150 μg/m3or higher

This version is for private use only and should not be distributed.
4
Installation
Open the filter
compartment
Press the buckle to open the
filter compartment, and make
sure the filter is installed
correctly.
1Connect to an outlet
Connect the power cord
to the connector at the
boom of the purifier, and
then plug it into an outlet.
3
Remove the power cord
package
Remove the power cord
package, and close the filter
compartment.
2

This version is for private use only and should not be distributed.
5
On/Off & Mode Buon
Tap to turn on the purifier, then tap to
switch modes. Press and hold for two
seconds to turn off the purifier.
Display On/Off Buon
Press the buon on the back of the
purifier to adjust the display's brightness,
or to turn the display on/off.
How to Use
Placing the purifier in a suitable
location
For optimal performance, maintain the
recommended distances between the
purifier, and walls and other objects (refer
to the illustration above).
Note: It is recommended to keep doors and
windows closed for a beer purifying effect when
using the purifier.

This version is for private use only and should not be distributed.
6
Reseing Wi-Fi
When the phone cannot connect to the
purifier, simultaneously press and hold
the On/Off & Mode buon and the Display
On/Off buon for five seconds. Once you
hear a beep, the purifier's Wi-Fi has been
reset successfully.
Connect with Mi Home / Xiaomi
Home App
This product works with Mi Home / Xiaomi
Home app*. Control your device with Mi
Home / Xiaomi Home app.
Scan the QR code to download and
install the app. You will be directed
to the connection setup page if the
app is installed already. Or search
"Mi Home / Xiaomi Home" in the app
Store to download and install it.
Open Mi Home / Xiaomi Home app, tap "+" on the upper
right, and then follow prompts to add your device.
*The app is referred to as Xiaomi Home app in Europe
(except for Russia). The name of the app displayed on
your device should be taken as the default.
Note: The version of Mi Home app might have been
updated, please follow the instructions based on the
current app version.
Filter Status Notifications
1Filter Installation
Notification
No filter detected, or the installed
filter is not genuine.
2Filter Service Life
Notification
When the purifier detects that
the filter's service life is more
than 10%, either unplug and plug
in the power cord again then turn
on the purifier, or open and close
the filter compartment then
turn on the purifier, the filter's
remaining service life (in %) will
appear on the display.
3Filter Replacement
Notification
The filter replacement period
is 6–12 months. If the filter's
service life is 10% or less, the
display will show a QR code and
the filter's remaining service life
(in %) whenever you turn on the
purifier.
Note: Refer to the Filter Replacement
instructions on the inside of the filter
compartment cover.
Note: The filter may produce odors when it absorbs
excessive harmful gases. It is recommended to store
the filter in a place with good lighting and ventilation to
improve the activity of the activated carbon and restore
its particle adsorption capacity. Please replace the filter
when its recommended service life is due.
Install an
genuine filter
Filter
remaining
90%
Filter
remaining
2%

This version is for private use only and should not be distributed.
7
Care & Maintenance
Make sure the purifier is turned off and unplugged.
Cleaning the filter compartment
Use a vacuum cleaner or a so cloth to
remove any dust from the air inlets or
the filter compartment, so as to ensure
optimal ventilation and purification.
Cleaning the laser particle sensor
The latch of the particle sensor's cover is
located just above the inside of the filter
compartment. Remove the cover, by
pushing a finger up against the latch (as
shown in Illustration A).
Use an air blow gun or a hair dryer to
clean the cover and the sensor (as shown
in Illustration B).
Note: Do not use hot air.
Illustration A
Illustration B

This version is for private use only and should not be distributed.
8
Specifications
Name Mi Air Purifier
3H Rated Voltage 100–240 V~ Clean Air Delivery Rate (CADR Particles) 380 m3/h
Model AC-M6-SC Rated
Frequency 50/60 Hz
Formaldehyde Clean Air
Delivery Rate
(CADR Formaldehyde)
60 m3/h
Item
Dimensions
240 × 240 ×
520 mm Rated Power 38 W Network Standby Power Consumption < 2.0 W
Net Weight Approx.
4.8kg Noise Level 64 dB(A) Wireless Connectivity
Wi-Fi IEEE
802.11 b/g/n
2.4GHz
Area Efficiency 126 m2/h *
Particle
Purification
Efficiency
High Formaldehyde
Purification Efficiency High
Max RF Output Power Wi-Fi 2.4 G (2400 - 2483.5 MHz): 17.78 dBm
RFID (13.56MHz): 0 dBm
*Calculated according to standard GB/T 18801-2015
Regulatory Compliance Information
Europe — EU declaration of conformity
Hereby, Beijing Smartmi Electronic Technology Co., Ltd. declares that the radio
equipment - Mi Air Purifier 3H, type AC-M6-SC is in compliance with Directive 2014/53/
EU. The full text of the EU declaration of conformity is available at the following internet
address: hp://www.mi.com/global/service/support/declaration.html
Disposal and recycling information
All products bearing this symbol are waste electrical and electronic equipment (WEEE
as in directive 2012/19/EU) which should not be mixed with unsorted household waste.
Instead, you should protect human health and the environment by handing over your
waste equipment to a designated collection point for the recycling of waste electrical and
electronic equipment, appointed by the government or local authorities. Correct disposal and
recycling will help prevent potential negative consequences to the environment and human
health. Please contact the installer or local authorities for more information about the location
as well as terms and conditions of such collection points.

This version is for private use only and should not be distributed.
9
WARRANTY NOTICE
THIS WARRANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY HAVE OTHER RIGHTS
CONVEYED BY LAWS OF YOUR COUNTRY, PROVINCE OR STATE. INDEED, IN SOME
COUNTRIES, PROVINCES OR STATES, CONSUMER LAW MAY IMPOSE A MINIMUM
WARRANTY PERIOD. OTHER THAN AS PERMITTED BY LAW, XIAOMI DOES NOT EXCLUDE,
LIMIT OR SUSPEND OTHER RIGHTS YOU MAY HAVE. FOR A FULL UNDERSTANDING OF YOUR
RIGHTS WE INVITE YOU TO CONSULT THE LAWS OF YOUR COUNTRY, PROVINCE OR STATE.
1. LIMITED PRODUCT WARRANTY
XIAOMI warrants that the Products are free from defects in materials and workmanship
under normal use and use in accordance with the respective Product user manual, during the
Warranty Period.
The duration and conditions related to the legal warranties are provided by respective local
laws. For more information about the consumer warranty benefits, please refer to Xiaomi's
official website hps://www.mi.com/en/service/warranty/.
Xiaomi warrants to the original purchaser that its Xiaomi Product will be free from defects in
materials and workmanship under normal use in the period mentioned above.
Xiaomi does not guarantee that the operation of the Product will be uninterrupted or error free.
Xiaomi is not liable for damages arising from non-compliance with the instructions related to
the use of the Product.
2. REMEDIES
If a hardware defect is found and a valid claim is received by Xiaomi within the Warranty Period,
Xiaomi will either (1) repair the product at no charge, (2) replace the product, or (3) refund the
Product, excluding potential shipping costs.
3. HOW TO OBTAIN WARRANTY SERVICE
To obtain warranty service, you must deliver the Product, in its original packaging or similar
packaging providing an equal degree of Product protection, to the address specified by Xiaomi.
Except to the extent prohibited by applicable law, Xiaomi may require you to present proofs
or proof of purchase and / or comply with registration requirements before receiving warranty
service.
4. EXCLUSIONS AND LIMITATIONS
Unless otherwise stipulated by Xiaomi, this Limited Warranty applies only to the Product
manufactured by or for Xiaomi and identifiable by the trademarks, trade name or "Xiaomi" or
"Mi" logo.

This version is for private use only and should not be distributed.
10
The Limited Warranty does not apply to any (a) Damage due to acts of nature or God, for
example, lightning strikes, tornadoes, flood, fire, earthquake or other external causes; (b)
Negligence; (c) Commercial use; (d) Alterations or modifications to any part of the Product; (e)
Damage caused by use with non-Xiaomi products; (f) Damage caused by accident, abuse or
misuse; (g) Damage caused by operating the Product outside the permied or intended uses
described by Xiaomi or with improper voltage or power supply; or (h) Damage caused by service
(including upgrades and expansions) performed by anyone who is not a representative of
Xiaomi.
It is your responsibility to backup any data, soware, or other materials you may have stored or
preserved on the product. It is likely that the data, soware or other materials in the equipment
will be lost or reformaed during the service process, Xiaomi is not responsible for such
damage or loss.
No Xiaomi reseller, agent, or employee is authorized to make any modification, extension, or
addition to this Limited Warranty. If any term is held to be illegal or unenforceable, the legality
or enforceability of the remaining terms shall not be affected or impaired.
Except as prohibited by laws or otherwise promised by Xiaomi, the aer-sales services shall be
limited to the country or region of the original purchase.
Products which were not duly imported and/or were not duly manufactured by Xiaomi and/or
were not duly acquired from Xiaomi or a Xiaomi’s official seller are not covered by the present
warranties. As per applicable law you may benefit from warranties from the non-official retailer
who sold the product. Therefore, Xiaomi invites you to contact the retailer from whom you
purchased the product.
The present warranties do not apply in Hong Kong and Taiwan.
5. IMPLIED WARRANTIES
Except to the extent prohibited by applicable law, all implied warranties (including warranties
of merchantability and fitness for a particular purpose) will have a limited duration up to a
maximum duration of this limited warranty. Some jurisdictions do not allow limitations on the
duration of an implied warranty, so the above limitation will not be applied in these cases.
6. DAMAGE LIMITATION
Except to the extent prohibited by applicable law, Xiaomi shall not be liable for any damages
caused by accidents, indirect, special or consequential damages, including but not limited
to loss of profits, revenue or data, damages resulting from any breach of express or implied
warranty or condition, or under any other legal theory, even if Xiaomi has been informed of
the possibility of such damages. Some jurisdictions do not allow the exclusion or limitation of
special, indirect, or consequential damages, so the above limitation or exclusion may not apply
to you.

This version is for private use only and should not be distributed.
11
7. XIAOMI CONTACTS
For customers, please visit the website: hps://www.mi.com/en/service/warranty/
The contact person for the aer-sale service may be any person in Xiaomi's authorized service
network, Xiaomi's authorized distributors or the final vendor who sold the products to you. If in
doubt please contact the relevant person as Xiaomi may identify.
Manufactured by: Beijing Smartmi Electronic Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Room 201-203, Unit 6, Building A, No. 66,Zhufang Road, Qinghe, Haidian District,
Beijing
For further information, please go to www.mi.com
