Xilinx ML501 User manual
ML501 QuickStart
May 2008
Overview
•Setup
•Boot with ACE-loader ACE File
•Observe LCD and Terminal messages
•Load new Configuration
•Re-load ACE-loader
ML501 MicroBlaze Hardware
•The ML501 MicroBlaze design
hardware includes:
–DDR2 Interface (256 MB)
–BRAM
–External Memory Controller (EMC)
•ZBT SRAM, Flash, and USB
–Networking
–UART
–Interrupt Controller
–System ACE CF Interface
–GPIO (IIC, LEDs and LCD)
–AC97, and PS/2 Controllers
–DVI Controller
–PLB and OPB Arbiters
–OPB2PLB Bridge
Additional Setup Details
•Refer to ml501_overview_setup document for details on:
–Software Requirements
–ML501 Board Setup
•Equipment and Cables
•Software
•Network
–Terminal Programs
•This presentation requires the
9600-8-N-1 Baud terminal setup
Note: Presentation applies to the ML501
Hardware Setup
•Connect the Xilinx Parallel
Cable IV (PC4) to the
ML501 board
•Connect the RS232 null
modem cable to the
ML501 board
Note: Presentation applies to the ML501
Hardware Setup
•The ML501 uses a DVI video
interface
•Connect a DVI monitor
or
•Use a DVI/VGA adapter
to connect a VGA monitor
–http://www.belkin.com
Note: Presentation applies to the ML501
Hardware Setup
•USB Keyboard
–www.dell.com
Note: Presentation applies to the ML501
Factory CompactFlash
•The CompactFlash shipped with the ML501 board has the
following ace files preloaded:
Note: Presentation applies to the ML501
Select Boot Configuration
•Insert the Factory CompactFlash into the ML501 board (1)
•Set the DIP switches as seen here (00010101) (2)
•Power-up the ML501 board
Note: Presentation applies to the ML501
1
2
Bootload
•The system_bootload.ace loads:
Note: Presentation applies to the ML501
Bootload
•The terminal window also reflects the bootload application
•Use the left/center/right buttons to choose an application or type a
number in the terminal window
•After each demo, push the SysACE reset to return to bootload
Note: Presentation applies to the ML501
Slideshow
•Type 1, to launch the slideshow application in Configuration 1
•The slideshow loads the presentation into memory then presents it
Note: Presentation applies to the ML501
Slideshow
•The slideshow app will present a series of slides on the Monitor:
Note: Presentation applies to the ML501
Web Server
•Type 2, to launch the web server application in Configuration 2
–Note: You may need to turn off your browser's proxy and specify a direct
connection to the Internet in your browser options
Note: Host IP is 1.2.3.9, subnet mask is 255.0.0.0; Ethernet connection is 100 Full Duplex
Web Server
•In your web browser, enter http://1.2.3.4:8080/index.html
Note: Presentation applies to the ML501
Simon
•Type 3, to launch the Simon application in Configuration 3
Note: Presentation applies to the ML501
USB Keyboard
•Type 5, to launch the USB Keyboard application in Configuration 5
•Type ML501 and view results:
Note: Presentation applies to the ML501
My ACE
•Type 6, to launch the My ACE application in Configuration 6
Note: Presentation applies to the ML501
Ringtone
•Type 7, to launch the Ringtone application in Configuration 7
•Press any key then press 1-7 to play a simple melody
Note: Presentation applies to the ML501
Documentation
•Virtex-5
–Silicon Devices
http://www.xilinx.com/products/silicon_solutions
–Virtex-5 Multi-Platform FPGA
http://www.xilinx.com/products/silicon_solutions/fpgas/virtex/virtex5
–Virtex-5 Family Overview: LX, LXT, SXT, and FXT Platforms
http://www.xilinx.com/support/documentation/data_sheets/ds100.pdf
–Virtex-5 FPGA DC and Switching Characteristics Data Sheet
http://www.xilinx.com/support/documentation/data_sheets/ds202.pdf
