Introduction
Thank you for choosing to purchase this quality product. To minimise the risk of injury, we ask you to
always take some basic safety precautions when using this product. Please read this operating manual
carefully and make sure that you understand it.
Keep these operation instructions in a safe place.
Description
The engine stand, having a capacity of up to 450 kg, provides an ideal help for working on engines or
transmissions. A large variety of adjustments and adaption possibilities offer a high degree of flexibility
and security. While working, turn the engine about 360° to get access even to areas that are difficult to
reach normally. The four installation points can be easily adjusted regarding angle and distance and
thus allow a universal adjustment for any engine – with the four steel rollers ensuring a safe position
and easy drivability of the entire construction.
Safety instructions/warnings
The owner and/or user must have read and understood the operating instructions of the device before
using it. Installed personnel should be cautious, competent, trained, and qualified in the safe handling
of the working equipment used when working with motors and their components. Warnings should be
read and understood.
•Be familiar with the application control, the application process, and the warnings.
•Make sure that all connectors are attached and secure.
•Make sure to know the contents of the instructions for use.
•This device is not intended to be used by persons (including children) with reduced physical or
mental abilities or with a lack of experience and knowledge, unless they be supervised and/or
instructed by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the device.
•Ensure that the load is free and no obstacles may hinder/prevent the lifting.
•Make sure that the load cannot shift or slide.
•Check the loading balance after a few centimetres before proceeding further.
•Avoid that the load swings.
•Make sure that there is nobody near the charge.
•Warn persons about the charge lifted.
•Immediately contact your superior or workshop if something unforeseen happens.
•Never exceed the maximum charge capacity.
•Never use damaged, inoperative engine supports.
•Never use bent, damaged, or worn lifting devices.
•Never lift charges with obstacles possibly hindering.
•Stay concentrated and do not allow any distraction during the process.
•Never use the load receptacle to lift, help, or transport people.
•NEVER LIFT CHARGES ABOVE PERSONS’ HEADS!
•Unsecured charges might lead to injuries of limbs or bones, even to fatal ones.
•Do not leave loads lifted unattended.
•Avoid contact between the engine stand and other objects.
•Never try to extend or expand the lifting device.
•Do not use welding equipment near the support.
•Always make sure that the workplace is well-lit.

https://www.XPOtool.com Item 30155 Page 4
The Tool Experts
05 2022-1
•Make sure to wear solid shoes.
•Use a hair net for long hair.
•Wear appropriate clothing.
•Take off jewellery (rings, earrings, watches, etc.).
•Make sure not to wear loose strips or belts.
•Only use the engine support if you feel able to.
•Long working in a standing position can lead to dizziness. Make regular breaks and drink
enough.
•Do not overload the support. Never use the engine support as you would use a jack. The engine
support is only meant to assist you in installing and removing parts of your vehicle.
•Only use the engine support on a level and solid surface that can bear the load indicated.
•Before beginning work on/under a vehicle, ensure that the vehicle itself is properly raised and
secured.
•Never open the screw connections under pressure/load.
•Make sure that the load is centred on the support.
Exploded view and parts list
A = rear wheel assembly; B = wheel hub facing inwards
№
Name
Qty.
№
Name
Qty.
1
Main post
1
14
Caster 3″
2
3
Side leg connection
1
15
Nut
4
4
Screw ½″×1″ LG
1
17
Washer
4
5
Mounting plate
1
19
E-ring
2
6
Lock pin
1
20
Front leg
1
7
Mounting arms
1
21
Side leg caster
1
8
Screw 11⁄20″×2⅖″ LG
4
22
Label
1

https://www.XPOtool.com Item 30155 Page 5
The Tool Experts
05 2022-1
9
Washer
4
23
Rear wheel 3½″
2
10
Nut
4
24
Screw ⅖″×2⅘″ LG
4
11
Spring ring
4
25
Spring ring
4
12
Washer
4
26
Handle (not shown)
1
Technical specifications
Capacity (㎏)
450
Size (㎜)
800 × 800 × 870
Weight (㎏)
18.2
Important Note:
Reproduction and any commercial use (of parts) of this operating manual, requires a written permission
of WilTec Wildanger Technik GmbH.
