Module Programming
Page 8
1
10-pin
D2D
1st
12-pin
14-pin
2nd
3rd &
Solid
10-pin
D2D
XL202
10-pin
D2D
SmartStart
OR
The module be disconnected from any power source before SmartStart canDBALL2 must
be connected to it. Failing to do so could damage .2DBALL
a. To ensure that the D2D communication between SmartStart and works properly,DBALL2
the Gray wire must be connected to a ground source ( SmartStart), and the Brown orRev B
Blue loop must be cut ( SmartStart).Rev A
b. Do connect the 2-pin harness (on SmartStart). Power and ground will be provided byNOT
the D2D connector.DBALL2
Connect SmartStart to using the D2D port.DBALL2
SmartStart Installation
Connect 202 to using the D2D port.XL DBALL
XL202 Installation
Refer to the Diagnostics section on page for more information and for troubleshooting purposes.LED 10
Rev.: 20 706221
Platform: DBALL2
Firmware: HK7 Remote Start Ready Installation(RSR)
© 201 Directed.7 All rights reserved.
Connect the 10-pin 2-pin harnesses to, 1 and 14-pin
DBALL, then w .ait until the turns solid redLED ON
Note: To skip the transponder programming and use
convenience features only press the programming button
5 times. The LED will turn orange then proceed to step 2.
3
Turn the key to the position.ON
The will flash orange then turn solid green for 3LED
seconds, and turn .OFF
Note: If transponder programming was skipped, the LED
turns ON solid orange for 3 seconds then shuts OFF when
programming is done.
Key OUT
OFF
START
ON
Turn the key to the position and remove it from ignition.OFF the
You have successfully completed th module programming sequence.is
2Key IN
OFF
START
ON
&&
Flash
orange Off
&
Important
Make all the required connections to the vehicle, as described in the wiring diagram(s) found in this guide, and double check to
ensure everything is correct prior to moving onto the next step.
Note: Before connecting either the 202 or SmartStart module to 2, it is important to ensure that the proper feature andXL DBALL
function programming is selected using Xpress (version 4. or higher). Visit www.directechs.com to download the latestVIP 5
version of the application.
Warning! To take advantage of advanced features, you must use Xpress 4.5 (and higher) or the Directechs Mobile app.VIP
When the flashing operation is successful, you can proceed with the programming instructions below.
Flashing a module using your computer:
1. Connect the interface module to your computer using the
XKLoader2.
2. Go to www.directechs.com using Internet Explorer, and
select the button.Config for RSR
3. Follow the instructions to select your vehicle, installation
type, and configure your options.
4. Once you have configured the firmware options, click on the
FLASH button.
Flashing a module using your smartphone or tablet
1. Connect the interface module to your oader3.XKL
2. Launch the Directechs Mobile app on your smartphone or
tablet.
3. Select and follow the on screenFLASH YOUR MODULE
instructions.
Orange
3 seconds
