Xray RX8 User manual

1
1/8
LUXURY
ON-ROAD RACING
CAR
INSTRUCTION
MANUAL

2
BEFORE YOU START
The RX8 is a high-competition, high-quality, 1/8-scale nitro car intended for persons aged 16 years and older
with previous experience building and operating RC model racing cars. This is not a toy; it is a precision racing
model. This model racing car is not intended for use by beginners, inexperienced customers, or by children
without direct supervision of a responsible, knowledgeable adult. If you do not fulll these requirements, please
return the kit in unused and unassembled form back to the shop where you have purchased it.
Before building and operating your RX8, YOU MUST read through all of the operating instructions and instruction
manual and fully understand them to get the maximum enjoyment and prevent unnecessary damage.
Read carefully and fully understand the instructions before beginning assembly.
Make sure you review this entire manual, the included set-up book, and examine all details carefully. If for some
reason you decide the RX8 is not what you wanted or expected, do not continue any further. Your hobby dealer
cannot accept your RX8 kit for return or exchange after it has been partially or fully assembled.
Contents of the box may differ from pictures. In line with our policy of continuous product development, the exact
specications of the kit may vary without prior notice.
SAFETY PRECAUTIONS
 This product contains a chemical known to the state of California to cause cancer and birth
defects or other reproductive harm.
 CANCER HAZARD
Wash thoroughly after using. DO NOT use product while eating, drinking or using tobacco products. May
cause chronic effects to gastrointestinal tract, CNS, kidneys, and blood. MAY CAUSE BIRTH DEFECTS.
When building, using and/or operating this model always wear protective glasses and gloves.
Take appropriate safety precautions prior to operating this model. You are responsible for this model‘s
assembly and safe operation! Please read the instruction manual before building and operating this model
and follow all safety precautions. Always keep the instruction manual at hand for quick reference, even after
completing the assembly. Use only genuine and original authentic XRAY parts for maximum performance.
Using any third party parts on this model will void guaranty immediately.
Improper operation may cause personal and/or property damage. XRAY and its distributors have no
control over damage resulting from shipping, improper construction, or improper usage. XRAY assumes and
accepts no responsibility for personal and/or property damages resulting from the use of improper building
materials, equipment and operations. By purchasing any item produced by XRAY, the buyer expressly
warrants that he/she is in compliance with all applicable federal, state and local laws and regulation
regarding the purchase, ownership and use of the item. The buyer expressly agrees to indemnify and hold
harmless XRAY for all claims resulting directly or indirectly from the purchase, ownership or use of the
product. By the act of assembling or operating this product, the user accepts all resulting liability. If the buyer
is not prepared to accept this liability, then he/she should return this kit in new, unassembled, and unused
condition to the place of purchase.
• Keep the wheels of the model off the ground when checking the operation of the radio equipment.
• Disconnect the battery pack before storing your model.
• When learning to operate your model, go to an area that has no obstacles that can damage your model
if your model suffers a collision.
• Remove any sand, mud, dirt, grass or water before putting your model away.
• If the model behaves strangely, immediately stop the model, check and clear the problem.
• To prevent any serious personal injury and/or damage to property, be responsible when operating all
remote controlled models.
• The model car is not intended for use on public places and roads or areas where its operation can conict with
or disrupt pedestrian or vehicular trafc.
• Because the model car is controlled by radio, it is subject to radio interference from many sources that
are beyond your control. Since radio interference can cause momentary loss of control, always allow a
safety margin in all directions around the model in order to prevent collisions.
• Do not use your model:
- Near real cars, animals, or people that are unaware that an RC car is being driven.
- In places where children and people gather
- In residential districts and parks
- In limited indoor spaces
- In wet conditions
- In the street
- In areas where loud noises can disturb others, such as hospitals and residential areas.
- At night or anytime your line of sight to the model may be obstructed or impaired in any way.
To prevent any serious personal injury and/or damage to property, please be responsible when operating
all remote controlled models.
IMPORTANT NOTES – GENERAL
• This product is not suitable for children under 16 years of age without the direct supervision of a
responsible and knowledgeable adult.
• Carefully read all manufacturers warnings and cautions for any parts used in the construction and use
of your model.
• Assemble this kit only in places away from the reach of very small children.
• First-time builders and users should seek advice from people who have building experience in order to
assemble the model correctly and to allow the model to reach its performance potential.
• Exercise care when using tools and sharp instruments.
• Take care when building, as some parts may have sharp edges.
• Keep small parts out of reach of small children. Children must not be allowed to put any parts in their
mouth, or pull vinyl bag over their head.
• Read and follow instructions supplied with paints and/or cement, if used (not included in kit).
• Immediately after using your model, do NOT touch equipment on the model such as the motor and
speed controller, because they generate high temperatures. You may seriously burn yourself seriously
touching them.
• Follow the operating instructions for the radio equipment at all times.
• Do not put ngers or any objects inside rotating and moving parts, as this may cause damage or
serious injury as your nger, hair, clothes, etc. may get caught.
• Be sure that your operating frequency is clear before turning on or running your model, and never
share the same frequency with somebody else at the same time. Ensure that others are aware of the
operating frequency you are using and when you are using it.
• Use a transmitter designed for ground use with RC cars. Make sure that no one else is using the same
frequency as yours in your operating area. Using the same frequency at the same time, whether it is
driving, ying or sailing, can cause loss of control of the RC model, resulting in a serious accident.
• Always turn on your transmitter before you turn on the receiver in the car. Always turn off the receiver
before turning your transmitter off.
FAILURE TO FOLLOw ThESE INSTRUCTIONS wILL BE CONSIdEREd AS ABUSE ANd/OR NEGLECT.
CUSTOMER SUPPORT

K Výstavisku 6992
91101 Trenčín
Slovakia, EUROPE
Phone: [phone]
Fax: [phone]
Email: [e-mail]
We have made every effort to make these instructions as easy to understand as possible. However, if you have
any difculties, problems, or questions, please do not hesitate to contact the XRAY support team at info@tea-
mxray.com. Also, please visit our Web site at www.teamxray.com to nd the latest updates, set-up information,
option parts, and many other goodies. We pride ourselves on taking excellent care of our customers.
You can join thousands of XRAY fans and enthusiasts in our online community at:

RCAmerica, 2970 Blystone Lane, Suite 109
Dallas, Texas 75220
USA
Phone: [phone] * [phone]
Fax: [phone]
Email: [email protected]
IMPORTANT NOTES – NITRO ENGINES
• Always test the brakes and the throttle before starting your engine to avoid losing control of the model.
• Make sure the air lter is clean and oiled.
• Never run your engine without an air lter. Your engine can be seriously damaged if dirt and debris get
inside the engine.
• For proper engine break-in, please refer to the manual that came with the engine.
• Do not run near open ames or smoke while running your model or while handling fuel.
• Some parts will be hot after operation. Do not touch the exhaust or the engine until they have cooled.
These parts may reach 275°F during operation!

3
IMPORTANT NOTES – ELECTRICAL
• Insulate any exposed electrical wiring (using heat shrink tubing or electrical tape) to prevent dangerous
short circuits. Take maximum care in wiring, connecting and insulating cables. Make sure cables are
always connected securely. Check connectors for if they become loose. And if so, reconnect them securely.
Never use R/C models with damaged wires. A damaged wire is extremely dangerous, and can cause
short-circuits resulting in re. Please have wires repaired at your local hobby shop.
• Low battery power will result in loss of control. Loss of control can occur due to a weak battery in either
the transmitter or the receiver. Weak running battery may also result in an out of control car if your car‘s
receiver power is supplied by the running battery. Stop operation immediately if the car starts to slow
down.
• When not using RC model, always disconnect and remove battery.
• Do not disassemble battery or cut battery cables. If the running battery short-circuits, approximately
300W of electricity can be discharged, leading to re or burns. Never disassemble battery or cut battery
cables.
• Use a recommended charger for the receiver and transmitter batteries and follow the instructions
correctly. Over-charging, incorrect charging, or using inferior chargers can cause the batteries to become
dangerously hot. Recharge battery when necessary. Continual recharging may damage battery and, in
the worst case, could build up heat leading to re. If battery becomes extremely hot during recharging,
please ask your local hobby shop for check and/or repair and/or replacement.
• Regularly check the charger for potential hazards such as damage to the cable, plug, casing or other
defects. Ensure that any damage is rectied before using the charger again. Modifying the charger may
cause short-circuit or overcharging leading to a serious accident. Therefore do not modify the charger.
• Always unplug charger when recharging is nished.
• Do not recharge battery while battery is still warm. After use, battery retains heat. Wait until it cools
down before charging.
• Do not allow any metal part to short circuit the receiver batteries or other electrical/electronic device on
the model.
• Immediately stop running if your RC model gets wet as may cause short circuit.
• Please dispose of batteries responsibly. Never put batteries into re.
wARRANTY
XRAY guarantees this model kit to be free from defects in both material and workmanship within 30 days
of purchase. The total monetary value under warranty will in no case exceed the cost of the original kit
purchased. This warranty does not cover any components damaged by use or modication or as a result
of wear. Part or parts missing from this kit must be reported within 30 days of purchase. No part or parts
will be sent under warranty without proof of purchase. Should you nd a defective or missing part, contact
the local distributor. Service and customer support will be provided through local hobby store where you
have purchased the kit, therefore make sure to purchase any XRAY products at your local hobby store. This
model racing car is considered to be a high-performance racing vehicle. As such this vehicle will be used
in an extreme range of conditions and situations, all which may cause premature wear or failure of any
component. XRAY has no control over usage of vehicles once they leave the dealer, therefore XRAY can only
offer warranty against all manufacturer‘s defects in materials, workmanship, and assembly at point of sale
and before use. No warranties are expressed or implied that cover damage caused by what is considered
normal use, or cover or imply how long any model cars‘ components or electronic components will last before
requiring replacement.
Due to the high performance level of this model car you will need to periodically maintain and replace
consumable components. Any and all warranty coverage will not cover replacement of any part or component
damaged by neglect, abuse, or improper or unreasonable use. This includes but is not limited to damage
from crashing, chemical and/or water damage, excessive moisture, improper or no maintenance, or user
modications which compromise the integrity of components. Warranty will not cover components that are
considered consumable on RC vehicles. XRAY does not pay nor refund shipping on any component sent to
XRAY or its distributors for warranty. XRAY reserves the right to make the nal determination of the warranty
status of any component or part.

XRAY makes no other warranties expressed or implied. XRAY shall not be liable for any loss, injury or
damages, whether direct, indirect, special, incidental, or consequential, arising from the use, misuse, or
abuse of this product and/or any product or accessory required to operate this product. In no case shall
XRAY‘s liability excess the monetary value of this product.
Take adequate safety precautions prior to operating this model. You are responsible for this model’s
assembly and safe operation.

            



QUALITY CERTIFICATE
XRAY MODEL RACING CARS uses only the highest quality materials, the best compounds for molded parts
and the most sophisticated manufacturing processes of TQM (Total Quality Management). We guarantee
that all parts of a newly-purchased kit are manufactured with the highest regard to quality. However, due
to the many factors inherent in model racecar competition, we cannot guarantee any parts once you start
racing the car. Products which have been worn out, abused, neglected or improperly operated will not be
covered under warranty. We wish you enjoyment of this high-quality and high-performance RC car and wish
you best success on the track!



Products may potentially have small amounts of corrosion on them. This may be caused by variances in
weather during different times of the year, humidity in the shop or during shipping, and other contributing
factors. Even though we have taken all precautions and protection methods to prevent corrosion, these small
amounts of corrosion (if present) are unavoidable and considered to be acceptable.


R/C & BUILdING TIPS
• Make sure all fasteners are properly tightened. Check them periodically.
• Make sure that chassis screws do not protrude from the chassis.
• For the best performance, it is very important that great care is taken to ensure the free movement of all parts.
• Clean all ball-bearings so they move very easily and freely.
• Tap or pre-thread the plastic parts when threading screws.
• Self-tapping screws cut threads into the parts when being tightened. Do not use excessive force when
tightening the self-tapping screws because you may strip out the thread in the plastic. We recommended
you stop tightening a screw when you feel some resistance.
• Ask your local hobby shop for any advice.
Please support your local hobby shop. We at XRAY Model Racing Cars support all local hobby dealers.
Therefore we ask you, if at all possible, to purchase XRAY products at your hobby dealer and give them your
support like we do. If you have difculty nding XRAY products, please check out www.teamxray.com to get
advice, or contact us via email at [e-mail], or contact the XRAY distributor in your country.
IMPORTANT NOTES – NITRO FUEL
• Handle fuel only outdoors. Never handle nitro fuel indoors, or mix nitro fuel in a place where ventilation
is bad.
• Only use nitro fuel for R/C models. Do not use gasoline or kerosene in R/C models as it may cause a re
or explosion, and ruin your engine.
• Nitro fuel is highly inammable, explosive, and poisonous. Never use fuel indoors or in places with open
res and sources of heat.
• Always keep the fuel container cap tightly shut.
• Always read the warning label on the fuel container for safety information.
• Nitro-powered model engines emit poisonous vapors and gasses. These vapors irritate eyes and can be highly
dangerous to your health. We recommend wearing rubber or vinyl gloves to avoid direct contact with nitro fuel.
• Nitro fuel for RC model cars is made of the combination of the methyl alcohol, castor or synthetic oil,
nitro methane etc. The ammability and volatility of these elements is very high, so be very careful
during handling and storage of nitro fuel.
• Keep nitro fuel away from open ame, sources of heat, direct sunlight, high temperatures, or near
batteries.
• Store fuel in a cool, dry, dark, well-ventilated place, away from heating devices, open ames, direct
sunlight, or batteries. Keep nitro fuel away from children.
• Do not leave the fuel in the carburetor or fuel tank when the model is not in use. There is danger that
the fuel may leak out.
• Wipe up any spilled fuel with a cloth
• Be aware of spilled or leaking fuel. Fuel leaks can cause res or explosions.
• Do not dispose of fuel or empty fuel containers in a re. There is danger of explosion.

4
EQUIPMENT REQUIRED
TOOLS REQUIRED
INCLUDED NOT INCLUDED
SyMbOLS USED
XRAY Silicone Shock Oil
Transmitter Steering & Throttle Servos
Receiver & Personal
Transponder
Battery Charger
Wheels & Tires
Starter Box (HUDY #104400)
& Battery Pack
Manifold & Exhaust
Engine
Air Filter & Oil Tire Truer
(HUDY #102003)
Model R/C Car Fuel
(nitromethane)
Threadlock & CA Glue
Glowplug Igniter
HUDY TOOLS
Reamer
(HUDY #107600)
Wrench Glowplug/Clutchnut
(HUDY #107581)
Phillips 3.5mm
Allen Ball 2.5mm
Slotted Screwdriver 4.0mm
Exhaust Spring / Caster Clip Remover
Allen 1.5 / 2.0 / 2.5 / 3.0mm
RX8 Pinion Tool Set
(XRAY #349901)
Flywheel Tool
(HUDY #182010)
Pliers
Side Cutters
(HUDY #189010)
Hobby Knife
One-Way Lube
(HUDY #106231)
Bearing Oil
(HUDY #106230)
Apply cyanoacrylate (CA) glue
Follow Set-Up Book
Part bags used
Assemble left and right sides the same way
Assemble in the specified order
Pay attention here
Assemble as many times as specified (here twice)
Apply thread lock
Number of teeth
Apply oil (may indicate specific type)
Follow tip here
Cut off remaining material
Scale
Ensure smooth non-binding movement
3.0 mm
Turnbuckle Tool
(HUDY #181030)





WHEELBASE
Apply grease
Use pliers
Graphite Grease
(HUDY #106210)
Fibre Tape (HUDY #107870)
Double-sided Tape
Scissors
(HUDY #188990)
Lexan® Paint
Bodyshell
Receiver Battery Pack

5
bAG
CUTAWAY VIEW
ONE-WAY LUBE
ONE-WAY LUBE
STEP DETAIL
NOTE
ORIENTATION
OIL
OIL
1. FRONT ONE-WAy & REAR SOLID AXLE
345070
345010
345024
968140
345070
968120
345000 FRONT ONE-WAY - SET
345010 FRONT ONE-WAY AXLE
345024 COMPOSITE FRONT ONE-WAY AXLE PULLEY 24T
345070 FRONT ONE-WAY AXLE OUTDRIVE ADAPTER - HUDY SPRING STEEL™ (2)
345800 COMPOSITE BELT PULLEY COVER SET
345100 REAR SOLID AXLE - SET
345110 REAR SOLID AXLE SHAFT
345148 COMPOSITE REAR SOLID AXLE PULLEY 48T
968120 C-CLIP 12 (10)
968140 C-CLIP 14 (10)
980324 PIN 3x24 (10)
980324
345110
345148 968120
345800
01
968120
C 12
980324
P 3x24
968140
C 14

6
bAG
2. REAR SUSPENSION
3.0mm
42.5mm





Tighten gently
Right thread
Left thread
3.0mm
2x
2x
2x

During initial assembly, tighten each composite hex nut until the pivot
ball starts to bind, then loosen slightly.
Verify that the pivot balls move freely.
Tighten composite hex nuts
using HUDY
tool #107581
Follow the TECH TIP on page
31 to install the pivot balls
When you use INNER position on the
upright, use SHORTER ball joint.

When you use OUTER position on the
upright, use LONGER ball joint.
The length of the ball joint depends on the upright
position. See page 7, step 3.
902308
SH M3x8
901410
SB M4x10
901306
SB M3x6
345310 306219
901316
343310
343110
342070
337250
303241
901410
342630
345360
901303
962121
941218
342070
941218
343285
343150
901306
343130
337253
345280
902308
343120
902308
303241 BALL UNIVERSAL 5.8 MM HEX (4)
306219 COMPOSITE SET OF SERVO SHIMS (4)
337250 STEEL PIVOT BALL 8.4 MM (2)
337253 COMPOSITE ADJUSTING NUT M10x1 (4)
342070 COMPOSITE SET OF BUSHINGS (2)
342630 ADJ. TURNBUCKLE L/R 20 MM - HUDY SPRING STEEL™ (2)
343110 COMPOSITE SUSPENSION ARM REAR LOWER RIGHT
343120 COMPOSITE SUSPENSION ARM REAR LOWER LEFT
343130 COMPOSITE SUSPENSION ARM REAR UPPER
343150 C. REAR UPPER CAMBER LINK BALL JOINT 5.8MM - SHORT & LONG (2+2)
343285 PIVOT BALL 6.8MM (2)
343310 COMPOSITE UPRIGHT REAR
345280 WHEEL SPRING (2)
345310 REAR WHEEL AXLE - HUDY SPRING STEEL™
345360 ALU REAR WHEEL LOCK - SWISS 7075 T6 (2)
941218 HIGH-SPEED BALL-BEARING 12x18x4 RUBBER SEALED (2)
901303 HEX SCREW SB M3x3 (10)
980322
962121
962120
901306 HEX SCREW SB M3x6 (10)
901316 HEX SCREW SB M3x16 (10)
901410 HEX SCREW SB M4x10 (10)
902308 HEX SCREW SH M3x8 (10)
962120 WASHER S 12x15x0.5 (10)
962121 WASHER S 12x15x1.0 (10)
980322 PIN 3x22 (10)
02.1

7
REAR TRACK WIDTH
REAR ROLL CENTER
COMPOSITE SET OF BUSHINGS
0.5mm
1mm
1mm
Concentric



Eccentric



2.2mm
2.1mm
2x
2x
2x
2x
IN OUT
1+1 0.5
1+0.5 1
1 1+0.5
0.5 1+1
0 1+1+0.5
SHIM SHIM
Centered
2mm
Tighten gently Tighten fully
6mm
2. REAR SUSPENSION
Bearing oil
Bearing oil
When using eccentric bushings, both
bushings must be in same position.

       
      
     
   

962120
S 12x15x0.5
962121
S 12x15x1.0
941218
BB 12x18x4
901303
SB M3x3
306219
SHIM 3x6x2
901316
SB M3x16
980322
P 3x22
OIL
OIL

8
WHEELBASE
REAR ROLL CENTER
REAR TRACK WIDTH

bAG
Before tightening the screws, insert the
brake disk between the brake pads.
Evenly tighten the screws fully (CW), and
then loosen both screws by one turn (CCW).
The brake disk should have a small amount
of play between the brake pads.
COMPOSITE SET OF BUSHINGS
Use 0mm suspension holders for initial assembly
 
2mm

2. REAR SUSPENSION
BEARING
OIL
344180
965090
903416
345320
903308
901303
981208
902318
342180
357210
342317
903412
901405
344110
342316
345450
940508
344040
940508
344050
341100
347320 343050 903308
342317
302080
342316
344140
344130
345820
345510 903412
342070
941218
345100
343020
343055
940815
343010
302080 COMPOSITE CASTER CLIPS SET 4+3+2+1 MM (2)
341100 CHASSIS 5MM - CNC MACHINED - SWISS 7075 T6
342070 COMPOSITE SET OF BUSHINGS (2)
342180 COMPOSITE LOWER SUSP. ARM CLIPS (2)
342316 COMPOSITE REAR UPPER SUSP. ECCENTRIC BUSHING (4)
342317 COMPOSITE REAR LOWER SUSP. ECCENTRIC BUSHING (4)
343010 COMPOSITE LOWER BULKHEAD REAR RIGHT
343020 COMPOSITE LOWER BULKHEAD REAR LEFT
343050 COMPOSITE REAR BULKHEAD COVER
343055 COMPOSITE REAR LOWER SUSP. ARM HOLDER
344040 BRAKE CAM POST - SWISS 7075 T6
344050 COMPOSITE BRAKE UPPER PLATE + CLAMPS FOR REAR ANTI-ROLL BAR
344110 VENTILATED BRAKE DISC - PRECISION-GROUND
344130 BRAKE PAD SET
344140 BRAKE DISK ADAPTER - SWISS 7075 T6
344180 BRAKE DISK SPRING (2)
345320 REAR DRIVE SHAFT 61MM - HUDY SPRING STEEL™
345450 PUR® REINFORCED DRIVE BELT REAR 8.0 x 204 MM
345510 2-SPEED SHAFT 8MM - SUPER LIGHTWEIGHT - HUDY SPRING STEEL™
345820 COMPOSITE 2-SPEED BELT PULLEY 20T - CENTER
347320 REAR UPPER INNER PIVOT PIN (2)
357210 LOWER INNER PIVOT PIN F/R (2)
901303 HEX SCREW SB M3x3 (10)
901405 HEX SCREW SB M4x5 (10)
902318 HEX SCREW SH M3x18 (10)
903308 HEX SCREW SFH M3x8 (10)
903412 HEX SCREW SFH M4x12 (10)
903416 HEX SCREW SFH M4x16 (10)
940508 HIGH-SPEED BALL-BEARING 5x8x2.5 RUBBER SEALED (2)
940815 HIGH-SPEED BALL-BEARING 8x14x4 RUBBER SEALED (2)
941218 HIGH-SPEED BALL-BEARING 12x18x4 RUBBER SEALED (2)
965090 E-CLIP 9 (10)
981208 PIN 2x8 (10)
903412
SFH M4x12
902318
SH M3x18
940508
BB 5x8x2.5
02.2

9

COMPOSITE SET OF BUSHINGS

2. REAR SUSPENSION
BEARING
OIL
BEARING
OIL
BEARING
OIL
BEARING
OIL

Place tab in this notch
AB


Rotate BOTH rear composite bushings in
arrow direction (A)

Rotate BOTH rear composite bushings
in arrow direction (B)

Tighten setscrew
onto at spot
THREADLOCK
The brake disc must freely
move between the brake pads.
If not, loosen the two screws
holding the brake pads.



965090
C 9
901405
SB M4x5
941218
BB 12x18x4
940815
BB 8x14x4

Both bushings must be
in same position

10
REAR CAMBER RISE
REAR ROLL CENTER

Tighten fully
setscrew M3x6
2x
2mm
903308
SFH M3x8
903308
SFH M3x8
903412
SFH M4x12
940508
BB 5x8x2.5
903416
SFH M4x16
901303
SB M3x3
981208
P 2x8
BEARING
OIL
3x8
3x8
4x16
4x16
4x12
4x12
COMPOSITE SET OF BUSHINGS

2. REAR SUSPENSION
Use 0mm suspension holders for initial assembly

11
REAR ANTI-ROLL BAR


2. REAR SUSPENSION
bAG
50.3mm
Tighten gently
Tighten fully
NOTE THE ANGLE DIFFERENCE BETWEEN
THE BALL JOINTS
Wire should be ush with
end of pivot ball
BEARING
OIL
02.3
901305
902310
302291
341380
902310
902312
902314
901303
341360 902314
343070
902310
343080
343070
344050
901303
940508
903308
302080
343030
343428
347330 333460
303210
341330
333450
341370
302080 CASTER CLIPS SET 4+3+2+1 MM (2)
302291 STEEL STEERING BUSHING (2+2)
303210 ADJ. TURNBUCKLE M3 L/R 25 MM - SPRING STEEL (2)
333450 ANTI-ROLL BAR BALL JOINT 5.8 MM (2)
333460 COMPOSITE ANTI-ROLL BAR BALL JOINT 5.8 MM (4)
341330 COMPOSITE REAR BODY HOLDER
341360 COMPOSITE REAR BODY HOLDER SCREW (2)
341370 COMPOSITE REAR BODY HOLDER ARM
341380 COMPOSITE REAR BODY CENTERING PLATE
343030 GRAPHITE REAR BRACE
343070 BELT TENSIONER SET
343080 GRAPHITE SHOCK TOWER REAR
343428 ANTI-ROLL BAR REAR 2.8 MM - SET
344050 COMPOSITE BRAKE UPPER PLATE + CLAMPS FOR REAR ANTI-ROLL BAR
347330 REAR BODY HOLDER ARM PIN (2)
940508 HIGH-SPEED BALL-BEARING 5x8x2.5 RUBBER SEALED (2)
901303 HEX SCREW SB M3x3 (10)
901305 HEX SCREW SB M3x5 (10)
902310 HEX SCREW SH M3x10 (10)
902312 HEX SCREW SH M3x12 (10)
902314 HEX SCREW SH M3x14 (10)
903308 HEX SCREW SFH M3x8 (10)
901303
SB M3x3
940508
BB 5x8x2.5

12
REAR BODY MOUNT
REAR BODY MOUNT
Only tighten setscrew enough to
remove excessive free play; anti-roll
bar must still move freely.
3x12
3x8
3x8
3x3
3x3
3x14
2x





(STEP )
2mm
Distance according to
bodyshell
2mm

SHIMS (STEP )


901303
SB M3x3
901305
SB M3x5
902312
SH M3x12
902314
SH M3x14
902310
SH M3x10
902310
SH M3x10
902314
SH M3x14
903308
SFH M3x8
2. REAR SUSPENSION
3x10 3x14
3x14

13
3. REAR TRANSMISSION
bAG
➊
➋


➌
➍
➎

Use the belt pulley cover 18T
with hole diameter of 10mm
7.5mm
8mm
➌
STEP DETAIL
STEP DETAIL
➊

345545 COMPOSITE 2-SPEED GEAR 45T (2nd) OPTION
  
345547 COMPOSITE 2-SPEED GEAR 47T (2nd) OPTION
345548 COMPOSITE 2-SPEED GEAR 48T (1st) OPTION
  
345550 COMPOSITE 2-SPEED GEAR 50T (1st) OPTION
345500 2-SPEED - SET
345520 CARRIER FOR 2-SPEED GEAR (2nd) - SWISS 7075 T6
345530 ALU DRIVE FLANGE WITH ONE-WAY BEARING - SWISS 7075 T6
345540 COMPOSITE 2-SPEED GEAR BOX SHOE - SET
345541 COMPOSITE 2-SPEED GEAR BOX SHOE
345546 COMPOSITE 2-SPEED GEAR 46T (2nd)
345549 COMPOSITE 2-SPEED GEAR 49T (1st)
345570 ADAPTER 2-SPEED
345580 GEAR BOX SPRING C=11.5 (2) - OPTION
345581 GEAR BOX SPRING C=13 (2)
345800 COMPOSITE BELT PULLEY COVER SET
345838 COMPOSITE SIDE BELT PULLEY 18T o8 - REAR
901305 HEX SCREW SB M3x5 (10)
902314 HEX SCREW SH M3x14 (10)
903306 HEX SCREW SFH M3x6 (10)
950814 BALL-BEARING 8x14x4 FLANGED (2)
965070 E-CLIP 7 (10)
980314 PIN 3x14 (10)
981312 PIN 3x12 (10)
983404 ROLLER PIN 4x4 MM (2)
901305
950814
983404
981312 980314
345800
345540
902314
965070
345549
345530 903306
345546 950814
345520
903306 345570
983404
345541 345838
965070
345581
345800
18
980314
P 3x14
965070
C 7

14
TRANSMISSION
2-SPEED TRANSMISSION
901305
SB M3x5
902314
SH M3x14
983404
RP 4x4
903306
SFH M3x6
965070
C 7
981312
P 3x12
950814
BB 8x14x4
➊
➊
➋
➋➌
➍
➍
➎
➎
Setscrews must NOT
protrude
Top of screw head
should be level with
hole bottom edge










➊
➋
➌
Do not overtighten gap-setting
setscrews. Only tighten until roller
pins contact the center hub.
ONE WAY LUBE




BEARING OIL
Use HUDY Reamer #107600 to slightly chamfer
the edges on all 3 holes for screws from inside. Use HUDY Reamer #107600 to slightly chamfer
the edges on all 3 holes for screws from inside.

3. REAR TRANSMISSION
46
46
49
49

15
WHEELBASE
FRONT ROLL CENTER
COMPOSITE SET OF BUSHINGS

IN OUT
1+1 0.5
1+0.5 1
1 1+0.5
0.5 1+1
0 1+1+0.5

4. FRONT SUSPENSION
bAG
PIVOT BALLS MUST MOVE FREELY.
During initial assembly, tighten each composite hex nut
until the pivot ball starts to bind, then loosen slightly. Verify
that the pivot balls move freely.
Tighten the composite hex nuts
using HUDY tool #107581
Tighten
gently
Tighten
fully
THREAD
LOCK
BEARING
OIL
BEARING OIL
GRAPHITE GREASE
(HUDY # 106210)
Tighten the screw fully when the
pin is installed.
DETAILSTEP
0.5mm
1mm
1mm
NOTE ORIENTATION
When using eccentric bushings, both
bushings must be in same position
Concentric





Eccentric
2x
2x
SHIM SHIM

04.1
962120
S 12x15x0.5
962121
S 12x15x1.0
941218
BB 12x18x4
901303
SB M3x3
980262
P 2.5x12
337250 STEEL PIVOT BALL 8.4 MM (2)
337253 COMPOSITE ADJUSTING NUT M10x1 (4)
342070 COMPOSITE SET OF BUSHINGS (2)
342110 COMPOSITE SUSPENSION ARM FRONT LOWER
342130 COMPOSITE SUSPENSION ARM FRONT UPPER
342210 COMPOSITE STEERING BLOCK RIGHT
342220 COMPOSITE STEERING BLOCK LEFT
342410 COMPOSITE FRONT ANTI-ROLL BAR HOLDERS
342440 ANTI-ROLL BAR FRONT FEMALE - HUDY SPRING STEEL™
342450 ANTI-ROLL BAR FRONT MALE - HUDY SPRING STEEL™
345210 FRONT WHEEL AXLE - HUDY SPRING STEEL™
345220 FRONT CVD DRIVE SHAFT 71MM - HUDY SPRING STEEL™
345230 DRIVE SHAFT COUPLING - HUDY SPRING STEEL™
345260 ALU FRONT WHEEL LOCK - SWISS 7075 T6 (2)
345280 WHEEL SPRING (2)
941218 HIGH-SPEED BALL-BEARING 12x18x4 RUBBER SEALED (2)
901303 HEX SCREW SB M3x3 (10)
901306 HEX SCREW SB M3x6 (10)
901308 HEX SCREW SB M3x8 (10)
901408 HEX SCREW SB M4x8 (10)
902320 HEX SCREW SH M3x20 (10)
961032 WASHER S 3.2 (10)
962120 WASHER S 12x15x0.5 (10)
962121 WASHER S 12x15x1.0 (10)
980262 PIN 2.5x12 (10)
980320 PIN 3x20 (10)
901303
901306
901306
345230
980262
941218
342410
342220
941218
345260
337253
901303
980320
901408
901308
345280
342110
902320
901408
961032
902320
342130
962121
342070
342070
962121
345210
342440
901308
342450
337250
345220
901308
342210
962120

16
FRONT CAMBER
4. FRONT SUSPENSION
FRONT ANTI-ROLL BAR
1. Pre-thread mount with the setscrew.
2. After anti-roll bar is inserted, install
and tighten the setscrew.
3x8
3x8
3x8
3x6
3x6
3x20
3x20
4x8
4x8



2x
Centered
2.6mm
3mm
1.8mm
2.5mm
2x
2x


Tighten
gently
Tighten gently, tighten fully
when the drive pins are
assembled. Page 18, step 2
901303
SB M3x3
901308
SB M3x8
901306
SB M3x6
901308
SB M3x8
961032
S 3.2
901408
SB M4x8
902320
SH M3x20
980320
P 3x20
Tighten gently Tighten fully

17
WHEELBASE
bAG
2x
2x


4. FRONT SUSPENSION


Rotate BOTH front composite
bushings in arrow direction (A)

Rotate BOTH front composite
bushings in arrow direction (B)

Place tab in this notch
BEARING
OIL
2mm
A
B
903412
SFH M4x12
941218
BB 12x18x4
04.2
901408
342070
941218
903412
903412
902310
342080
345430
342315
902310
342040
347210
302080
342180
342020
342030
342010
345000
337310
302080 COMPOSITE CASTER CLIPS SET 4+3+2+1 MM (2)
337310 PIVOT PIN (2)
342010 COMPOSITE LOWER BULKHEAD FRONT RIGHT
342020 COMPOSITE LOWER BULKHEAD FRONT LEFT
342030 COMPOSITE UPPER ARM HOLDER RIGHT
342040 COMPOSITE UPPER ARM HOLDER LEFT
342070 COMPOSITE SET OF BUSHINGS (2)
342080 GRAPHITE SHOCK TOWER FRONT
342180 COMPOSITE LOWER SUSP. ARM CLIPS (2)
342315 COMPOSITE FRONT UPPER SUSP. ECCENTRIC BUSHING (4)
345430 PUR® REINFORCED DRIVE BELT FRONT 6.0 x 204 MM
347210 FRONT LOWER INNER PIVOT PIN (2)
901408 HEX SCREW SB M4x8 (10)
902310 HEX SCREW SH M3x10 (10)
903412 HEX SCREW SFH M4x12 (10)
941218 HIGH-SPEED BALL-BEARING 12x18x4 RUBBER SEALED (2)


Both bushings must
be in same position
COMPOSITE SET OF BUSHINGS


18
WHEELBASE
FRONT ROLL CENTER
FRONT CAMBER RISE
CASTER
Ensure that the suspension arms move freely.
Ensure that the eccentric holders move freely.
Do not insert ball into cup too deeply
or bars will bind during operation
Each anti-roll bar blade has a hex hole at its end. Use
a 1.5mm hex wrench to adjust the blades.
Tighten fully
4mm 2mm1mm

2x
2x
4. FRONT SUSPENSION
902310
SH M3x10
901408
SB M4x8
902310
SH M3x10
COMPOSITE SET OF BUSHINGS
Use 0mm suspension holders for initial assembly


19
5. FRONT TRANSMISSION
bAG
BEARING
OIL
BEARING
OIL
➍
STEP ➌DETAIL

18
Use the belt pulley cover 18T
with hole diameter of 9mm.
STEP DETAIL


903310
SFH M3x10
940613
BB 6x13x5
965050
C 5
981262
P 2.5x12
343070 BELT TENSIONER SET
345440 PUR® REINFORCED DRIVE BELT SIDE 6.0 x 432 MM
345710 FRONT MIDDLE SHAFT - HUDY SPRING STEEL™
345720 COMPOSITE FRONT MIDDLE SHAFT HOLDER - HARD
345800 COMPOSITE BELT PULLEY COVER SET
345858 COMPOSITE FRONT BELT PULLEY 18T o6 - CENTER
345888 COMPOSITE SIDE BELT PULLEY 28T - FRONT
345889 COMPOSITE SIDE BELT PULLEY 29T - FRONT
346230 COMPOSITE RADIO PLATE MOUNTS (L+R)
901408 HEX SCREW SB M4x8 (10)
902312 HEX SCREW SH M3x12 (10)
903308 HEX SCREW SFH M3x8 (10)
903310 HEX SCREW SFH M3x10 (10)
940613 HIGH-SPEED BALL-BEARING 6x13x5 RUBBER SEALED (2)
950510 BALL-BEARING 5x10x4 FLANGED (2)
965050 E-CLIP 5 (10)
981262 PIN 2.5x12 (10)
345800
940613
346230
901408
903308
345800
965050
981262
965050
965050
345440
940613
345720
343070
902312
950510
901408
903310 343070
345710
345800
345888
345889
903310
345858

20
GEARING


1. Release upper screw
2. Move belt tensioner as needed
3. Re-tighten upper screw
TO ADJUST THE BELT TENSIONER:
5. FRONT TRANSMISSION
Tighten gently
Tighten gently




STEP DETAIL
981262
P 2.5x12
965050
C 5
901408
SB M4x8
903310
SFH M3x10
903308
SFH M3x8
902312
SH M3x12
950510
BB 5x10x4
Use the belt
pulley cover 29T
ø6mm
13.4mm
STEP DETAIL


29
BEARING
OIL
THREAD
LOCK
