1/10 LUXURY TOURING CAR1/10 LUXURY TOURING CAR
1/10 LUXURY TOURING CAR
INSTRUCTION
MANUAL

2
BEFORE YOU START
The T2‘007 is a high-competition, high-quality, 1/10-scale touring car intended
for persons aged 16 years and older with previous experience building and
operating RC model racing cars. This is not a toy; it is a precision racing model. This
model racing car is not intended for use by beginners, inexperienced customers,
or by children without direct supervision of a responsible, knowledgeable adult.
If you do not fulfill these requirements, please return the kit in unused and
unassembled form back to the shop where you have purchased it.
Before building and operating your T2‘007, YOU MUST read through all of the
operating instructions and instruction manual and fully understand them to get
the maximum enjoyment and prevent unnecessary damage. Read carefully and
fully understand the instructions before beginning assembly.
Make sure you review this entire manual, the included set-up book, and examine
all details carefully. If for some reason you decide the T2‘007 is not what you
wanted or expected, do not continue any further. Your hobby dealer cannot
accept your T2‘007 kit for return or exchange after it has been partially or fully
assembled.
Contents of the box may differ from pictures. In line with our policy of continuous
product development, the exact specifications of the kit may vary without prior
notice.
SAFETY PRECAUTIONS
Contains:
LEAD (CAS 7439-92-1) ANTIMONY (CAS 7440-36-0)
WARNING: This product contains a chemical known to the state of California to
cause cancer and birth defects or other reproductive harm.
CAUTION: CANCER HAZARD
Contains lead, a listed carcinogen. Lead is harmful if ingested. Wash thoroughly
after using. DO NOT use product while eating, drinking or using tobacco
products. May cause chronic effects to gastrointestinal tract, CNS, kidneys, and
blood. MAY CAUSE BIRTH DEFECTS.
When building, using and/or operating this model always wear protective
glasses and gloves.
Take appropriate safety precautions prior to operating this model. You are
responsible for this model‘s assembly and safe operation! Please read the
instruction manual before building and operating this model and follow
all safety precautions. Always keep the instruction manual at hand for quick
reference, even after completing the assembly. Use only genuine and original
authentic XRAY parts for maximum performance. Using any third party parts on
this model will void guaranty immediately.
Improper operation may cause personal and/or property damage. XRAY and
its distributors have no control over damage resulting from shipping, improper
construction, or improper usage. XRAY assumes and accepts no responsibility for
personal and/or property damages resulting from the use of improper building
materials, equipment and operations. By purchasing any item produced by XRAY,
the buyer expressly warrants that he/she is in compliance with all applicable
federal, state and local laws and regulation regarding the purchase, ownership
and use of the item. The buyer expressly agrees to indemnify and hold harmless
XRAY for all claims resulting directly or indirectly from the purchase, ownership
or use of the product. By the act of assembling or operating this product, the
user accepts all resulting liability. If the buyer is not prepared to accept this
liability, then he/she should return this kit in new, unassembled, and unused
condition to the place of purchase.
IMPORTANT NOTES – GENERAL
• This product is not suitable for children under 16 years of age without the
direct supervision of a responsible and knowledgeable adult.
• Carefully read all manufacturers warnings and cautions for any parts used in
the construction and use of your model.
• Assemble this kit only in places away from the reach of very small children.
• First-time builders and users should seek advice from people who have
building experience in order to assemble the model correctly and to allow the
model to reach its performance potential.
• Exercise care when using tools and sharp instruments.
• Take care when building, as some parts may have sharp edges.
• Keep small parts out of reach of small children. Children must not be allowed
to put any parts in their mouth, or pull vinyl bag over their head.
• Read and follow instructions supplied with paints and/or cement, if used (not
included in kit).
• Immediately after using your model, do NOT touch equipment on the
model such as the motor and speed controller, because they generate high
temperatures. You may seriously burn yourself seriously touching them.
• Follow the operating instructions for the radio equipment at all times.
• Do not put fingers or any objects inside rotating and moving parts, as this
may cause damage or serious injury as your finger, hair, clothes, etc. may get
caught.
• Be sure that your operating frequency is clear before turning on or running
your model, and never share the same frequency with somebody else at the
same time. Ensure that others are aware of the operating frequency you are
using and when you are using it.
• Use a transmitter designed for ground use with RC cars. Make sure that no
one else is using the same frequency as yours in your operating area. Using
the same frequency at the same time, whether it is driving, flying or sailing,
can cause loss of control of the RC model, resulting in a serious accident.
• Always turn on your transmitter before you turn on the receiver in the car.
Always turn off the receiver before turning your transmitter off.
• Keep the wheels of the model off the ground when checking the operation of
the radio equipment.
• Disconnect the battery pack before storing your model.
• When learning to operate your model, go to an area that has no obstacles
that can damage your model if your model suffers a collision.
• Remove any sand, mud, dirt, grass or water before putting your model away.
• If the model behaves strangely, immediately stop the model, check and clear
the problem.
• To prevent any serious personal injury and/or damage to property, be
responsible when operating all remote controlled models.
• The model car is not intended for use on public places and roads or areas where
its operation can conflict with or disrupt pedestrian or vehicular traffic.
• Because the model car is controlled by radio, it is subject to radio interference
from many sources that are beyond your control. Since radio interference can
cause momentary loss of control, always allow a safety margin in all directions
around the model in order to prevent collisions.
• Do not use your model:
- Near real cars, animals, or people that are unaware that an RC car is being
driven.
- In places where children and people gather
- In residential districts and parks
- In limited indoor spaces
- In wet conditions
- In the street
- In areas where loud noises can disturb others, such as hospitals and
residential areas.
- At night or anytime your line of sight to the model may be obstructed or
impaired in any way.
To prevent any serious personal injury and/or damage to property, please be
responsible when operating all remote controlled models.
Failure to follow these instructions will be considered as abuse and/or neglect.
CUSTOMER SUPPORT
XRAY Europe
Pred Polom 762
91101 Trenčín
Slovakia, EUROPE
Phone: [phone]
Fax: [phone]
Email: [e-mail]
We have made every effort to make these instructions as easy to understand as possible.
However, if you have any difficulties, problems, or questions, please do not hesitate to
contact the XRAY support team at [e-mail]. Also, please visit our Web site
at www.teamxray.com to find the latest updates, set-up information, option parts, and
many other goodies. We pride ourselves on taking excellent care of our customers.
You can join thousands of XRAY fans and enthusiasts in our online community at:
www.teamxray.com
XRAY USA
RCAmerica, 167 Turtle Creek Boulevard Suite C
Dallas, Texas 75207
USA
Phone: [phone] * [phone]
Fax: [phone]
Email: [email protected]

3
IMPORTANT NOTES – ELECTRICAL
• Insulate any exposed electrical wiring (using heat shrink tubing or electrical
tape) to prevent dangerous short circuits. Take maximum care in wiring,
connecting and insulating cables. Make sure cables are always connected
securely. Check connectors for if they become loose. And if so, reconnect
them securely. Never use R/C models with damaged wires. A damaged wire
is extremely dangerous, and can cause short-circuits resulting in fire. Please
have wires repaired at your local hobby shop.
• Low battery power will result in loss of control. Loss of control can occur due to
a weak battery in either the transmitter or the receiver. Weak running battery
may also result in an out of control car if your car‘s receiver power is supplied
by the running battery. Stop operation immediately if the car starts to slow
down.
• When not using RC model, always disconnect and remove battery.
• Do not disassemble battery or cut battery cables. If the running battery short-
circuits, approximately 300W of electricity can be discharged, leading to fire
or burns. Never disassemble battery or cut battery cables.
• Use a recommended charger for the receiver and transmitter batteries
and follow the instructions correctly. Over-charging, incorrect charging, or
using inferior chargers can cause the batteries to become dangerously hot.
Recharge battery when necessary. Continual recharging may damage battery
and, in the worst case, could build up heat leading to fire. If battery becomes
extremely hot during recharging, please ask your local hobby shop for check
and/or repair and/or replacement.
• Regularly check the charger for potential hazards such as damage to the
cable, plug, casing or other defects. Ensure that any damage is rectified
before using the charger again. Modifying the charger may cause short-circuit
or overcharging leading to a serious accident. Therefore do not modify the
charger.
• Always unplug charger when recharging is finished.
• Do not recharge battery while battery is still warm. After use, battery retains
heat. Wait until it cools down before charging.
• Do not allow any metal part to short circuit the receiver batteries or other
electrical/electronic device on the model.
• Immediately stop running if your RC model gets wet as may cause short
circuit.
• Please dispose of batteries responsibly. Never put batteries into fire.
WARRANTY
XRAY guarantees this model kit to be free from defects in both material and
workmanship within 30 days of purchase. The total monetary value under
warranty will in no case exceed the cost of the original kit purchased. This
warranty does not cover any components damaged by use or modification or
as a result of wear. Part or parts missing from this kit must be reported within
30 days of purchase. No part or parts will be sent under warranty without proof
of purchase. Should you find a defective or missing part, contact the local
distributor. Service and customer support will be provided through local hobby
store where you have purchased the kit, therefore make sure to purchase any
XRAY products at your local hobby store. This model racing car is considered
to be a high-performance racing vehicle. As such this vehicle will be used in
an extreme range of conditions and situations, all which may cause premature
wear or failure of any component. XRAY has no control over usage of vehicles
once they leave the dealer, therefore XRAY can only offer warranty against all
manufacturer‘s defects in materials, workmanship, and assembly at point of
sale and before use. No warranties are expressed or implied that cover damage
caused by what is considered normal use, or cover or imply how long any
model cars‘ components or electronic components will last before requiring
replacement.
Due to the high performance level of this model car you will need to periodically
maintain and replace consumable components. Any and all warranty coverage
will not cover replacement of any part or component damaged by neglect,
abuse, or improper or unreasonable use. This includes but is not limited to
damage from crashing, chemical and/or water damage, excessive moisture,
improper or no maintenance, or user modifications which compromise the
integrity of components. Warranty will not cover components that are considered
consumable on RC vehicles. XRAY does not pay nor refund shipping on any
component sent to XRAY or its distributors for warranty. XRAY reserves the right to
make the final determination of the warranty status of any component or part.
Limitations of Liability
XRAY makes no other warranties expressed or implied. XRAY shall not be liable
for any loss, injury or damages, whether direct, indirect, special, incidental, or
consequential, arising from the use, misuse, or abuse of this product and/or any
product or accessory required to operate this product. In no case shall XRAY‘s
liability excess the monetary value of this product.
Take adequate safety precautions prior to operating this model. You
are responsible for this model’s assembly and safe operation.
Disregard of the any of the above cautions may lead to accidents,
personal injury, or property damage. XRAY MODEL RACING CARS
assumes no responsibility for any injury, damage, or misuse of this
product during assembly or operation, nor any addictions that may
arise from the use of this product.
All rights reserved.
QUALITY CERTIFICATE
XRAY MODEL RACING CARS uses only the highest quality materials, the best
compounds for molded parts and the most sophisticated manufacturing processes
of TQM (Total Quality Management). We guarantee that all parts of a newly-
purchased kit are manufactured with the highest regard to quality. However, due
to the many factors inherent in model racecar competition, we cannot guarantee
any parts once you start racing the car. Products which have been worn out,
abused, neglected or improperly operated will not be covered under warranty.
We wish you enjoyment of this high-quality and high-performance RC car and
wish you best success on the track!
In line with our policy of continuous product development, the exact specifications of the kit may
vary. In the unlikely event of any problems with your new kit, you should contact the model shop
where you purchased it, quoting the part number.
We do reserve all rights to change any specification without prior notice. All rights reserved.
R/C & BUILDING TIPS
• Make sure all fasteners are properly tightened. Check them periodically.
• Make sure that chassis screws do not protrude from the chassis.
• For the best performance, it is very important that great care is taken to ensure
the free movement of all parts.
• Clean all ball-bearings so they move very easily and freely.
• Tap or pre-thread the plastic parts when threading screws.
• Self-tapping screws cut threads into the parts when being tightened. Do not use
excessive force when tightening the self-tapping screws because you may strip
out the thread in the plastic. We recommended you stop tightening a screw
when you feel some resistance.
• Ask your local hobby shop for any advice.
Please support your local hobby shop. We at XRAY Model Racing Cars support
all local hobby dealers. Therefore we ask you, if at all possible, to purchase
XRAY products at your hobby dealer and give them your support like we do. If
you have difficulty finding XRAY products, please check out www.teamxray.com
to get advice, or contact us via email at [e-mail], or contact the XRAY
distributor in your country.

4
SYMBOLS USED
L=R
2x
CA
OIL
CORRECT WRONG
Overtightened
The threads
are stripped.
Part bags used Assemble left and right
sides the same way
Assemble in the specified
order
Pay attention here Assemble as many times
as specified (here twice)
Apply CA glue
TOOLS REQUIRED
EQUIPMENT REQUIRED
EQUIPMENT INCLUDED
Apply oil Use pliers
Silicone Shock Oil
Scissors Side Cutters Hobby Knife Reamer
(HUDY #107600)
Pliers
HUDY TOOLS: Allen: 1.5mm, 2.0mm, 2.5mm, 3.0mm
Socket: 7.0mm
Transmitter Steering ServoReceiver
Grease
TL
05
Tighten screw
gently
Apply thread lock
Lexan Paint Battery Charger Wheels & Tires & Inserts
Apply grease
GR
Turnbuckle Tool
Ensure smooth non-
binding movement
2.0 mm
3.0 mm
1.5 mm
7.0 mm
CONTENTS
Speed Controller
6-cell Battery Pack
(Inline)
Pinion Gear and Setscrew
190mm Bodyshell
Electric Motor
Fibre Tape
WARNINGS 2-3
TOOLS AND ACCESSORIES 4
0. KIT 5
1. BALL DIFFERENTIAL & FRONT MULTI-DIFF 6-7
2. FRONT & REAR SUSPENSION 8-10
3. CENTRAL TRANSMISSION 11-13
4. FRONT & REAR TRANSMISSION 14-17
5. STEERING 18-19
6. SHOCK ABSORBERS 20-21
7. FRONT & REAR ASSEMBLY 22-24
8. FINAL ASSEMBLY 25-27

5
KIT
The XRAY T2’007 comes partially pre-assembled. Before starting assembly, disassemble the chassis parts, noting the position and orientation of the parts, particularly
the bulkheads. Keep the parts, including the screw hardware, close at hand. In the assembly steps that follow, each section begins with a parts list. Parts indicated
with STYLE B are from the previously disassembled chassis parts in section 0.
CA
At the beginning of each section is an exploded view of the parts to be assembled. There is also a
list of all the parts and part numbers that are related to the assembly of that section.
The part descriptions are color-coded to make it easier for you to identify the source of a part.
Here are what the different colors mean:
STYLE A - indicates parts that are included in the bag marked for the section.
STYLE B - indicates parts that were set aside in Section 0.
STYLE C - indicates parts that are already assembled from previous steps.
0. KIT (FACTORY PRE-ASSEMBLED)
COLOR INDICATIONS
CORRECT INCORRECT
Lightly file edges of battery slots to remove
sharp edges.
Please note that the US Foam-Spec 3.5mm
Extra-Thick Chassis requires the battery slots to
be filed more than the standard 2.5mm thick
chassis.
Do not file battery slots too much, or batteries
may protrude below the chassis bottom.
To protect and seal edges of graphite parts, sand edges smooth and then apply CA glue.
Do this for: chassis edges; filed battery slots, countersunk holes for front bumper screws.
For the US extra-thick chassis, we recommend rounding the bottom forward edge of the
chassis (using a file or sandpaper).
CA
Apply only a bit of CA glue on
the countersunk holes
903306
903306
302018
303029
303018 301122 (EU RUBBER-SPEC)
301123 (US FOAM-SPEC)
302018
303018
303019
For the US extra-thick chassis, we recommend rounding the
bottom forward edge of the chassis (using a file or sandpaper).
30 1122 T2 CHASSIS 2.5MM GRAPHITE - RUBBER-SPEC - MULTI-FLEX™
30 1123 T2 CHASSIS 3.5MM GRAPHITE - EXTRA-THICK - FOAM-SPEC
30 2018 T2‘007 ALU FRONT LOWER SUSP. ADJUST. BULKHEAD
30 3018 T2‘007 ALU REAR LOWER SUSP. ADJUST. BULKHEAD
30 3019 T2‘007 RIGHT ALU LAYSHAFT BULKHEAD
30 3029 T2‘007 MOTOR MOUNT BULKHEAD
90 3306 HEX SCREW SFH M3x6 (10)

6
FACTORY PREASSEMBLED
GREASE
966080
C 8
963030
ST 3x8
930138
BA 3x8
930508
BB 5x8
930120
B 2.4
FRONT MULTI-DIFF™
EU RUBBER-SPEC ONLY
30 5000 BALL DIFFERENTIAL WITH LABYRINTH DUST COVERS™ - SET - 7075 T6
30 5010 ALU DIFF LONG OUTPUT SHAFT - HARD COATED - 7075 T6
30 5020 ALU DIFF SHORT OUTPUT SHAFT - HARD COATED - 7075 T6
30 5040 SCREW FOR EXTERNAL DIFF ADJUSTMENT - HUDY SPRING STEEL
30 5050 DIFF PULLEY 34T WITH LABYRINTH DUST COVERS
30 5082 DIFF WASHER 17x23x1 (2)
30 5102 XRAY MULTI-DIFF™ T1FK'05, T2
30 5112 MULTI-DIFF MAIN AXLE T1FK‘05, T2
30 5121 MULTI-DIFF LOCKING AXLE - HUDY SPRING STEEL
30 5131 INNER DRIVESHAFT ADAPTER - HUDY SPRING STEEL (2)
30 5150 TIMING BELT PULLEY 34T
30 9319 UNIVERSAL SET OF PLASTIC SHIMS (included in Last Aid Bag)
90 2305 HEX SCREW SH M3x5 (10)
93 0120 CARBIDE BALL 2.4 MM (12)
93 0138 CARBIDE BALL-BEARING AXIAL F3-8 3x8x3.5
93 0508 BALL-BEARING MR85ZZ 5x8x2.5 (2)
96 3030 CONE WASHER ST 3x8x0.5 (10)
96 6080 CH-CLIP 8 (10)
97 0100 O-RING 10x1.5 (10)
98 1212 PIN 2x11.8 (10)
1. BALL DIFFERENTIAL & FRONT MULTI-DIFF ™
FACTORY PREASSEMBLED
LONG DIFF SHAFT
SHORT DIFF SHAFT
BAG
930508
BB 5x8
SHORT DIFF SHAFT
LONG DIFF SHAFT
CUTAWAY VIEW
GR
GR
GR
305150
305150
305112
305131
970100
981212
902305
309319
(included in Last Aid Bag)
305131
305150
305121
GR
Insert CH-clip into the groove with nose pliers
CUTAWAY VIEW
BALL DIFFERENTIAL
8.0 mm
3.2 mm
7.8 mm
3.0 mm
305050
305020 930508
305082 930120
305050 305082 966080
963030 930138 305010 305040 305050

7
BALL DIFFERENTIAL & FRONT MULTI-DIFF ™
902305
SH M3x5 309319
SHIM 6x9x2
FRONT MULTI-DIFF ™ (EU RUBBER-SPEC ONLY)
981212
P 2x12 970100
O 10x1.5
DIRECTION OF TURN
FRONT MULTI-DIFF ™ SETTINGS
STANDARD ONE-WAY SOLID ONE-WAY FULL-TIME SOLID AXLE
Outdrive shafts (left and right) are not connected to each
other, nor to front main axle.
Off-power:
Outdrive shafts rotate forward independently of each other
and front main axle.
On-power:
Both outdrive shafts rotate with front main axle (locked in
one-way bearings)
Best used when...
traction is high, the car leans towards off-power understeer
and the track does not require braking for the corners. Will
give maximum off-power steering and increase efficiency
(more runtime). Best suited to a smooth driving style.
Both outdrive shafts (left and right) are connected
together by internal locking axle, but are not
connected to front main axle.
Off-power:
Both connected outdrive shafts rotate forward
together (but independent of front main axle).
On-power:
Both outdrive shafts rotate with front main axle
(locked in one-way bearings).
Best used when...
traction is medium to high and the track does not
require braking for the corners. Will give good off-
power steering and efficiency.
Both outdrive shafts (left and right) are connected
to front main axle by internal locking axle and
locking pin.
Off-power and on-power:
Both outdrive shafts rotate with front main axle.
Best used when...
traction is low to medium, the car leans towards
off-power oversteer and/or the track requires
braking for the corners. Will give less off-power
steering and efficiency (less runtime). Best suited to
an aggressive driving style.
Cutaway view Cutaway view Cutaway view
Front main axle
Outdrive shaft
(Left)
Outdrive shaft
(Right)
Front main axle
Outdrive shaft
(Left)
Outdrive shaft
(Right)
Locking axle
Front main axle
Outdrive shaft
(Left)
Outdrive shaft
(Right)
Locking
axle
Locking
pin
O-ring
Spacer
Spacer
Spacer
Spacer
Spacer
Spacer
DO NOT TIGHTEN THE DIFF COMPLETELY
THE DIFF MUST BE BROKEN IN PROPERLY !
IMPORTANT: When you build the differential, do not tighten it fully initially; the differential needs to be broken in properly. When you build the diff tighten it very
gently. When you put the diff in the car and complete the assembly, run the car for a few minutes, tighten the diff a little bit, and then recheck the diff. Repeat this
process several times until you have the diff tightened to the point you want it. Final adjustments should ALWAYS be made with the diff in the car and on the track.
Apply one-way lube
In case of excessive play use composite shims
included in the Last Aid bag.
OIL
LONGSHORT

8
303134
903306
301122 (EU RUBBER-SPEC)
301123 (US FOAM-SPEC)
903306
302044
303018 303018 302033
902318
303122
303123
307313
303123
901408
303161 (EU RUBBER-SPEC)
303162 (US FOAM-SPEC)
902316
302044 302033
901308
303134
903306
903306
903306
903306
302018 302018
303134
302044 302033
902316
303134
302044
302033
902316
901308
901408
307215
302161 (EU RUBBER-SPEC)
302162 (US FOAM-SPEC)
303019
303029
2. FRONT & REAR SUSPENSION
BAG
02
30 2033 T2 ALU NUT FOR SUSPENSION HOLDER (2)
30 2044 T2 LOWER SUSPENSION HOLDERS (2+2+2)
30 2161 T2 FRONT SUSPENSION ARM - HARD - RUBBER-SPEC
30 2162 T2 FRONT SUSPENSION ARM - EXTRA-HARD - FOAM-SPEC
30 3122 ALU SHIM 3x6x1.0MM (10)
30 3123 ALU SHIM 3x6x2.0MM (10)
30 3134 ALU SHIM FOR LOWER SUSP. HOLDER 3x7.5x1.5 (10)
30 3161 T2 REAR SUSPENSION ARM - HARD - RUBBER-SPEC
30 3162 T2 REAR SUSPENSION ARM - EXTRA-HARD - FOAM-SPEC
30 7215 T2 FRONT SUSPENSION PIVOT PIN (2)
30 7313 T2 REAR SUSPENSION PIVOT PIN (2)
90 1308 HEX SCREW SB M3x8 (10)
90 1408 HEX SCREW SB M4x8 (10)
90 2316 HEX SCREW SH M3x16 (10)
90 2318 HEX SCREW SH M3x18 (10)
90 3306 HEX SCREW SFH M3x6 (10)
30 1122 T2 CHASSIS 2.5MM GRAPHITE - RUBBER-SPEC - MULTI-FLEX™
30 1123 T2 CHASSIS 3.5MM GRAPHITE - EXTRA-THICK - FOAM-SPEC
30 2018 T2‘007 ALU FRONT LOWER SUSP. ADJUST. BULKHEAD
30 3018 T2‘007 ALU REAR LOWER SUSP. ADJUST. BULKHEAD
30 3019 T2‘007 RIGHT ALU LAYSHAFT BULKHEAD
30 3029 T2‘007 MOTOR MOUNT BULKHEAD
90 3306 HEX SCREW SFH M3x6 (10)
BAG
02.1

9
903306
SFH M3x6
901308
SB M3x8
901408
SB M4x8
901308
SB M3x8
901408
SB M4x8
REAR LEFT ARM REAR RIGHT ARM
RIGHT REAR ARM
FRONT LEFT ARMFRONT RIGHT ARM
LEFT REAR ARM
REAR ARMS
2. FRONT & REAR SUSPENSION
3mm
2.0mm
3mm
4x8mm
3x8mm
L=R
FRONT LEFT ARM
FRONT RIGHT ARM
L=R
COMPLETED ASSEMBLY
3x8mm
4x8mm
COMPLETED ASSEMBLY
FRONT ARMS
L=R
EU RUBBER-SPEC
0.8mm
US FOAM-SPEC
1.7mm
EU RUBBER-SPEC
0.5mm
US FOAM-SPEC INITIAL POSITION
US EU
INITIAL POSITION
USEU
INITIAL POSITION
US EU
INITIAL POSITION
USEU
L=R

10
DETAIL
2. FRONT & REAR SUSPENSION
47.5 mm
3x16mm
51.5 mm
3x7.5x1.5mm
3x6x2mm
3x6x1mm
3x7.5x1.5mm
3x16mm
3x18mm
DETAIL
DETAIL
2x 1:1
L=R
L=R
2x
3x7.5x1.5mm
3x7.5x1.5mm
3x16mm
DETAIL
L=R
REAR LEFT ARM
REAR RIGHT ARM
Roll Center Position:
-0.75mm
Roll Center Position:
0mm
Standard Setting
Roll Center Position:
+0.75mm
Use these suspension holders for
initial assembly
Use these suspension holders for
initial assembly
Roll Center Position:
-0.75mm
Roll Center Position:
0mm
Standard Setting
Roll Center Position:
+0.75mm
FRONT LEFT ARM
FRONT RIGHT ARM
303122
SHIM 3x6x1
902316
SH M3x16
303123
SHIM 3x6x2
303134
SHIM 3x7.5x1.5
902318
SH M3x18
902316
SH M3x16
303134
SHIM 3x7.5x1.5

11
305431
305784 (EU RUBBER-SPEC)
305886 (US FOAM-SPEC)
940510
902306
303044
306513
903306
902306
302022
902305
302078
941015 305000
302078
940510
965050
305575
305519
981212
302078
902306
902306
302098
902306
303094
302022
305442
941015
302078
305102 (EU RUBBER-SPEC)
305000 (US FOAM-SPEC)
3. CENTRAL TRANSMISSION
BAG
30 2022 T2 ALU UPPER CLAMP FOR BULKHEADS (2)
30 2078 T2‘007 SET OF COMPOSITE HUBS FOR BULKHEADS (4+2)
30 2098 T2 SHOCK TOWER FRONT 3.0MM GRAPHITE
30 3044 T2‘007 REAR UPPER DECK 2.5MM GRAPHITE - WIDE
30 3094 T2 SHOCK TOWER REAR 3.0MM GRAPHITE
30 5431 HIGH-PERFORMANCE KEVLAR DRIVE BELT FRONT 3 x 507 MM
30 5442 HIGH-PERFORMANCE KEVLAR DRIVE BELT REAR 3 x 180 MM
30 5519 T2 ALU SOLID LAYSHAFT
30 5575 FIXED PULLEY 20T (2)
30 5784 SPUR GEAR 84T / 48
30 5787 SPUR GEAR 87T / 48 (OPTION)
30 5790 SPUR GEAR 90T / 48 (OPTION)
30 5882 SPUR GEAR 112T / 64 (OPTION)
30 5884 SPUR GEAR 114T / 64 (OPTION)
30 5886 SPUR GEAR 116T / 64
30 5888 SPUR GEAR 118T / 64 (OPTION)
30 6513 T2‘007 ALU LOW TOP DECK MOUNT (2)
90 2305 HEX SCREW SH M3x5 (10)
90 2306 HEX SCREW SH M3x6 (10)
90 3306 HEX SCREW SFH M3x6 (10)
90 3308 HEX SCREW SFH M3x8 (10)
94 0510 HIGH-SPEED BALL-BEARING 5x10x4 RUBBER SEALED (2)
94 1015 HIGH-SPEED BALL-BEARING 10x15x4 RUBBER SEALED (2)
96 5050 E-CLIP 5 (10)
98 1212 PIN 2x12 (10)
30 5000 BALL DIFFERENTIAL WITH LABYRINTH DUST COVERS™ - SET - 7075 T6
30 5102 XRAY MULTI-DIFF T1FK’05, T2, T2R
03
BAG
03.1

12
902305
SH M3x5
965050
C5
981212
P 2x12
940510
BB 5x10x4
941015
BB 10x15x4
NOTE ORIENTATION
XRAY Multi-Diff is not included
in US FOAM-SPEC kit. The US
FOAM-SPEC kit includes front
ball-differential.
TO LOOSEN FRONT BELT:
Rotate both front nylon hubs in arrow direction (A)
TO TIGHTEN FRONT BELT:
Rotate both front nylon hubs in arrow direction (B)
FRONT BELT TENSION ADJUSTMENT
AB
TO LOOSEN REAR BELT:
Rotate both front nylon hubs in arrow direction (A)
TO TIGHTEN REAR BELT:
Rotate both front nylon hubs in arrow direction (B)
REAR BELT TENSION ADJUSTMENT
BA
INITIAL POSITION:
PLACE TAB IN THIS NOTCH
L=R L=R
INITIAL POSITION:
PLACE TAB IN THIS NOTCH
! IMPORTANT
Insert composite bushings perfectly straight
in bulkheads so the bearings spin freely. If the
bearings do not spin freely, reinstall the composite
bushings properly.
CUTAWAY VIEW
3. CENTRAL TRANSMISSION

13
902306
SH M3x6
902306
SH M3x6
903306
SFH M3x6
902306
SH M3x6
L=R L=R
Position the rear top deck inside of the rear drive belt
DETAIL
! IMPORTANT
When building the EU Rubber-Spec
chassis, DO NOT use these alu stands
for initial set-up. These alu stands are
recommended for use only on the US
Foam-Spec chassis, when running foam
tires, or in very high-grip conditions.
3. CENTRAL TRANSMISSION

14
901302
SB M3x2.5
981210
P 2x10
902312
302663
303141
303361
902205
305350
901304
940510
303210
303032
305231
901302
302664
305240
305323
305340
981210
303351
307321
902314
302663
302346
302291
902205
305350
901304
303210
303032
305240
305323
981210
307221
307455
302664
902306
901302
305231
940510
302252
305340 902310
302345
902306
307455
TIP
1.5MM ALLEN WRENCH
GR
THREAD LOCK
4x
DO NOT OVERTIGHTEN
GREASE
For easy and comfortable installation of
the plastic caps use pliers as shown.
BAG
4. FRONT & REAR TRANSMISSION
04
30 2252 T2 COMPOSITE STEERING BLOCK
30 2291 T2 STEEL STEERING BUSHING (2+2)
30 2345 T2 COMPOSITE C-HUB FRONT BLOCK, RIGHT - 4° DEG.
30 2346 T2 COMPOSITE C-HUB FRONT BLOCK, LEFT - 4° DEG.
30 2663 T2 BALL JOINT 5 MM - OPEN (8)
30 2664 T2 BALL JOINT 5 MM UNIDIRECTIONAL - OPEN (4)
30 3032 T2 ALU QUICK ROLL-CENTER HOLDER™ 4.9MM (2)
30 3141 ALU SHIM 3x5x1.0MM (10)
30 3210 REAR TURNBUCKLE L/R 25 MM - HUDY SPRING STEEL (2)
30 3351 T2 COMPOSITE UPRIGHT 1° OUTBOARD TOE-IN - RIGHT
30 3361 T2 COMPOSITE UPRIGHT 1° OUTBOARD TOE-IN - LEFT
30 5231 T2 DRIVE SHAFT COUPLING - HUDY SPRING STEEL
30 5240 DRIVE SHAFT REPLACEMENT PLASTIC CAP 3 MM (4)
30 5323 T2 DRIVE SHAFT - HUDY SPRING STEEL
30 5340 T2 DRIVE AXLE - HUDY SPRING STEEL
30 5350 T2 ALU WHEEL HUB (2)
30 7221 T2 FRONT ARM PIVOT PIN (2)
30 7321 T2 REAR ARM PIVOT PIN (2)
30 7455 T2 PIVOT BALL 5.0 MM DOUBLE BEVEL SHOULDERS (10)
90 1302 HEX SCREW SB M3x2.5 (10)
90 1304 HEX SCREW SB M3x4 (10)
90 2205 HEX SCREW SH M2x5 (10)
90 2306 HEX SCREW SH M3x6 (10)
90 2310 HEX SCREW SH M3x10 (10)
90 2312 HEX SCREW SH M3x12 (10)
90 2314 HEX SCREW SH M3x14 (10)
94 0510 HIGH-SPEED BALL-BEARING 5x10x4 RUBBER SEALED (2)
98 1210 PIN 2x10 (10)
TL

15
902205
SH M2x5
940510
BB 5x10x4
981210
P 2x10
902205
SH M2x5
940510
BB 5x10x4
981210
P 2x10
902310
SH M3x10
53.0 mm52.5 mm
1:1 1:1
4. FRONT & REAR TRANSMISSION
1R = RIGHT SUSPENSION BLOCK 1° OUTBOARD TOE-IN
1L = LEFT SUSPENSION BLOCK 1° OUTBOARD TOE-IN
2x
COMPLETED ASSEMBLY
LEFT STEERING BLOCK = RIGHT STEERING BLOCK
2x
COMPLETED ASSEMBLY
L=R
2x
COMPLETED ASSEMBLY
MOLDED DOT
FRONT RIGHT = FRONT LEFT REAR RIGHT = REAR LEFT
SPECIAL UNIDIRECTIONAL BALL-JOINT WITH MOLDED DOT
4x
4x
L=R
RIGHT C-HUB "4R"
LEFT C-HUB "4L"
4x
SHORT
LONG

16
303141
SHIM 3x5x1
902306
SH M3x6
902312
SH M3x12
307455
PB 5mm
901304
SB M3x4
1:1
4. FRONT & REAR TRANSMISSION
REAR VIEW
Quick Roll CenterTM tabs in lower inner holes
25 mm
2x
3x5x1mm
L=R
TIGHTEN GENTLY
After you tighten the screw into the upright, pull
the linkage upward so the ball joint " snaps " onto
the pivot ball. The whole assembly should move
freely.
DETAIL STEP
"1L"
"1R"
"CLICK"
INITIAL POSITION

17
902306
SH M3x6
902314
SH M3x14
307455
PB 5mm
901304
SB M3x4
1:1
4. FRONT & REAR TRANSMISSION
FRONT VIEW
23 mm
2x
L=R
"4L"
"4R"
DETAIL STEP
"CLICK"
TIGHTEN GENTLY
Quick Roll CenterTM tabs in lower inner holes
INITIAL POSITION
After you tighten the screw into the upright, pull
the linkage upward so the ball joint
" snaps " onto
the pivot ball. The whole assembly should move
freely.

18
BAG
30 1159 ALU COUNTERSUNK SHIM (4)
30 1178 T2‘007 UPPER DECK - NARROW - RUBBER-SPEC - MULTI-FLEX™
30 1179 T2‘007 UPPER DECK - WIDE - FOAM-SPEC - MULTI-FLEX™
30 2504 XRAY QUICK-SAVER™ - ADJUSTABLE SERVO SAVER SET
30 2551 SERVO SAVER PLASTIC COVER - ECCENTRIC (2)
30 2581 T2‘007 COMPOSITE SERVO HORN - KO, JR, AIRTRONICS
30 2583 T2‘007 COMPOSITE SERVO HORN - FUTABA, ROBE
30 2610 ADJ. TURNBUCKLE M3 L/R 40 MM - HUDY SPRING STEEL (2)
30 2630 ADJ. TURNBUCKLE L/R 20 MM - HUDY SPRING STEEL (2)
30 2652 T2‘007 BALL END 5 MM WITH THREAD (2)
30 2663 T2 BALL JOINT 5 MM - OPEN (8)
30 3210 REAR TURNBUCKLE L/R 25 MM - HUDY SPRING STEEL (2)
30 6513 T2‘007 ALU LOW TOP DECK MOUNT (2)
30 7455 T2 PIVOT BALL 5.0 MM DOUBLE BEVEL SHOULDERS (10)
90 2305 HEX SCREW SH M3x5 (10)
90 2306 HEX SCREW SH M3x6 (10)
90 2310 HEX SCREW SH M3x10 (10)
90 3306 HEX SCREW SFH M3x6 (10)
90 3310 HEX SCREW SFH M3x10 (10)
93 0407 BALL-BEARING MR74ZZ 4x7x2.5 (2)
302551
930407
903310
301159
306513
903306
307455
302663
307455
302610
302663
902310
302581
or 302583
302652
301178 (EU RUBBER-SPEC)
301179 (US FOAM-SPEC)
902310
302630
902305
902306
302504
302504
307455
302663
902310
302551
930407
902306
902306
902306
05
1:1
1:1
903310
SFH M3x10
302504
FACTORY ASSEMBLED
approximately 49mm
SERVO LINK
65.5mm 63.5mm
Adjust servo link to fit your servo
There are 5 different Ackermann settings possible to set with the Quick-Saver ™
5. STEERING
INITIAL POSITION
1 STEP OUT
5 STEPS OUT
5
4
3
2
1
5
4
3
2
1

19
307455
PB 5mm
902310
SH M3x10
902305
SH M3x5
902306
SH M3x6
903306
SFH M3x6
930407
BB 4x7x2.5
307455
PB 5mm
902310
SH M3x10
RIGHT STEERING
ROD 63.5mm
LEFT STEERING
ROD 65.5mm
SERVO LINK
! IMPORTANT
The hole in top deck for the eccentric bearing holder is not
directly along the centerline of the top deck, but rather is
slightly off-center. Mount the top deck so that the off-center
hole is to the RIGHT of the centerline.
! IMPORTANT
When building the EU
Rubber-Spec chassis, DO
NOT use these alu stands
for initial set-up. These alu
stands are recommended
for use only on the US
Foam-Spec chassis, when
running foam tires, or in
very high-grip conditions.
US Foam-Spec
Top Deck
EU Rubber-Spec
Top Deck
5. STEERING
F = Futaba, Robe
K = KO, JR, Airtronics, Sanwa
Splines for servo
on this side
FREE MOVEMENT
FREE MOVEMENT
INITIAL POSITION
FRONT
TAB TO FRONT
INITIAL POSITION
TAB TO FRONT
3x5mm

20
30 3241 BALL UNIVERSAL 5.8 MM HEX (4)
30 8035 COMPOSITE PISTONS ADJUSTABLE + NON-ADJUST. (SET 2+6)
30 8040 SHOCK ADJ. NUT ALU + O-RING (4+4)
30 8080 SHOCKABSORBER MEMBRANES (4)
30 8090 SHOCK FOAM INSERTS (4)
30 8301 T2 XRAY SHOCK ABSORBER-SET 4-STEP - SHORT (2)
30 8316 T2 SHOCK BALL JOINT - OPEN (4)
30 8330 T2 COMPOSITE FRAME SHOCK PARTS 4-STEP - SHORT
30 8351 T2 SHOCK CAP-NUT ALU (2)
30 8361 T2 HARDENED SHOCK SHAFT (2)
30 8380 ADDITIONAL XRAY ULTIMATE RACING SPRINGS (20)
30 8390 XRAY SELECTED ULTIMATE RACING SPRINGS (24)
96 1032 WASHER S 3.2 (10)
96 5019 E-CLIP 1.9 (10)
96 5023 E-CLIP 2.3 (10)
97 0050 O-RING 5x1 (10)
97 0121 O-RING 12.1x1.6 (10)
97 1031 SILICONE O-RING 3.1x1.6 (10)
Properly functioning shocks are very important to the performance of your car. This XRAY shock set contains parts to build four externally-adjustable or non-adjustable shocks.
Both adjustable and non-adjustable shocks feature XRAY's unique keying system that positively locks the pistons to the shock rods.
Carefully cut the parts from the frames, and then VERY carefully trim any excess flash with a sharp hobby knife. We recommend you use extra-fine sandpaper to gently smooth small
flashing. The side walls of the pistons must be perfectly round and smooth for proper operation.
We recommend you build all four shocks simultaneously. Ensure you have a clean work area to build the shocks.
Assemble FOUR adjustable shock rod assemblies by performing the following steps.
1. Press a #965023 (C 2.3) E-clip into the lower groove in the shock rod.
2. Place a #961032 (S 3.2) washer onto the shock rod atop the C-clip.
3. Press the piston assembly onto the shock rod, aligning flat in pistons
with flat on the shock rod.
4. Press a #965019 (C 1.9) E-clip into the upper groove in the shock rod.
5. Apply a drop or two of shock oil to the piston rod assembly,
and then insert the shock rod assembly into the shock body.
Cutaway view of
assembled adjustment collar
1. Lubricate the inner edge of a #970121 (O12.1x1.6) O-ring with
a drop or two of shock oil. Insert it into the groove of a #308040 threaded collar.
2. Carefully thread the collar onto the shock body as shown.
Be careful not to cross-thread the collar on the shock body.
965019
C 1.9
965023
C 2.3
961032
S 3.2
965019
C 1.9
965023
C 2.3
Apply a drop or two of shock oil to the piston pieces. Press upper piston (A) into lower
piston (B) as shown. The upper piston with holes (A) has a small tab that must exactly fit
into one of the notches in lower piston (B).
A
B
Assemble FOUR non-adjustable piston rod assemblies by performing the following steps.
Use the 3-hole non-adjustable pistons.
1. Press a #965023 (C 2.3) E-clip into the lower groove in the shock rod.
2. Press a 3-hole piston onto the shock rod, aligning flat in piston with flat on the shock rod.
3. Press a #965019 (C 1.9) E-clip into the upper groove of the shock rod.
4. Apply a drop or two of shock oil to the piston rod assembly, and then insert the shock rod assembly
into the shock body.
ADJUSTABLE PISTONS
NON-ADJUSTABLE PISTONS
970121
O 12.1x1.6
Cutaway view of
adjustable piston
BAG
A
B
OIL
OIL
4x
4x
4x
4x
ADJUSTABLE PISTONS
NON-ADJUSTABLE PISTONS
Large E-clip
Small E-clip
06
308330
! IMPORTANT
USE ONLY special T2 ball-joints (part #308316).
DO NOT USE ball joints on #308330 parts tree.
OIL
OIL
6. SHOCK ABSORBERS
308351 308330
308090
308080
308330
970121
308040
308382~308388
308393~308398
970050
971031
308330
308330
308316
303241
308361
965023
308035
965019
308035
2 HOLES 3 HOLES 4 HOLES 1-4 HOLES
NON ADJUSTABLE
ADJUSTABLE
961032
308035
