Xray Nitro Micro NT18T User manual

2
cmyk nt18t manual page02
BEFORE YOU START
The NT18T is a high-quality, 1/18-scale nitro truck intended for persons aged 16 years
and older with previous experience building and operating RC model racing cars. This
is not a toy; it is a precision car model. This model racing car is not intended for use
by beginners, inexperienced customers, or by children without direct supervision of
a responsible, knowledgeable adult. If you do not fulfill these requirements, please
return the kit in unused and unassembled form back to the shop where you have
purchased it. Before building and operating your NT18T, YOU MUST read through all
of the operating instructions and instruction manual and fully understand them to get
the maximum enjoyment and prevent unnecessary damage. Read carefully and fully
understand the instructions before beginning assembly.
Make sure you review this entire manual, the included engine instructions, and examine
all details carefully. If for some reason you decide the NT18T is not what you wanted or
expected, do not continue any further. Your hobby dealer cannot accept your NT18T kit
for return or exchange after it has been partially or fully assembled.
Contents of the box may differ from pictures. In line with our policy of continuous
product development, the exact specifications of the kit may vary without prior notice.
CUSTOMER SUPPORT
XRAY Europe
Pred Polom 762
91101 Trenčín
Slovakia, EUROPE
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
We have made every effort to make these instructions as easy to understand as possible.
However, if you have any difficulties, problems, or questions, please do not hesitate to
contact the XRAY support team at [e-mail]. Also, please visit our Web site
at www.teamxray.com to find the latest updates, set-up information, option parts, and
many other goodies. We pride ourselves on taking excellent care of our customers.
You can join thousands of XRAY fans and enthusiasts in our online community at:
www.teamxray.com
XRAY USA
RCAmerica, 167 Turtle Creek Boulevard Suite C
Dallas, Texas 75207
USA
Phone: [phone] * [phone]
Fax: [phone]
E-mail: [email protected]
SAFETY PRECAUTIONS
WARNING: This product contains a chemical known to the state of California to cause
cancer and birth defects or other reproductive harm.
When building, using and/or operating this model always wear protective glasses
and gloves.
Take appropriate safety precautions prior to operating this model. You are responsible
for this model‘s assembly and safe operation! Please read the instruction manual before
building and operating this model and follow all safety precautions. Always keep the
instruction manual at hand for quick reference, even after completing the assembly.
Use only genuine and original authentic XRAY parts for maximum performance. Using
any third party parts on this model will void guaranty immediately.
Improper operation may cause personal and/or property damage. XRAY and
its distributors have no control over damage resulting from shipping, improper
construction, or improper usage. XRAY assumes and accepts no responsibility for
personal and/or property damages resulting from the use of improper building
materials, equipment and operations. By purchasing any item produced by XRAY,
the buyer expressly warrants that he/she is in compliance with all applicable federal,
state and local laws and regulation regarding the purchase, ownership and use of the
item. The buyer expressly agrees to indemnify and hold harmless XRAY for all claims
resulting directly or indirectly from the purchase, ownership or use of the product. By
the act of assembling or operating this product, the user accepts all resulting liability.
If the buyer is not prepared to accept this liability, then he/she should return this kit in
new, unassembled, and unused condition to the place of purchase.
Failure to follow these instructions will be considered as abuse and/or neglect.
In line with our policy of continuous product development, the exact specifications of the kit may vary. In the unlikely
event of any problems with your new kit, you should contact the model shop where you purchased it, quoting the part
number. We do reserve all rights to change any specification without prior notice. All rights reserved.

3
cm
y
k nt18t manual pa
g
e03
IMPORTANT NOTES – GENERAL
• This product is not suitable for children under 16 years of age without the direct supervision
of a responsible and knowledgeable adult.
• Carefully read all manufacturers warnings and cautions for any parts used in the
construction and use of your model.
• Assemble this kit only in places away from the reach of very small children.
• First-time builders and users should seek advice from people who have building experience
in order to assemble the model correctly and to allow the model to reach its performance
potential.
• Exercise care when using tools and sharp instruments.
• Take care when building, as some parts may have sharp edges.
• Keep small parts out of reach of small children. Children must not be allowed to put any
parts in their mouth, or pull vinyl bag over their head.
• Read and follow instructions supplied with paints and/or cement, if used (not included in
kit).
• Immediately after using your model, do NOT touch equipment on the model such as the
engine and muffler, because they generate high temperatures. You may seriously burn
yourself seriously touching them.
• Follow the operating instructions for the radio equipment at all times.
• Do not put fingers or any objects inside rotating and moving parts, as this may cause
damage or serious injury as your finger, hair, clothes, etc. may get caught.
• Be sure that your operating frequency is clear before turning on or running your model,
and never share the same frequency with somebody else at the same time. Ensure that
others are aware of the operating frequency you are using and when you are using it.
• Use a transmitter designed for ground use with RC cars. Make sure that no one else is
using the same frequency as yours in your operating area. Using the same frequency at
the same time, whether it is driving, flying or sailing, can cause loss of control of the RC
model, resulting in a serious accident.
• Always turn on your transmitter before you turn on the receiver in the car. Always turn off
the receiver before turning your transmitter off.
• Keep the wheels of the model off the ground when checking the operation of the radio
equipment.
• Disconnect the battery pack before storing your model.
• When learning to operate your model, go to an area that has no obstacles that can
damage your model if your model suffers a collision.
• Remove any sand, mud, dirt, grass or water before putting your model away.
• If the model behaves strangely, immediately stop the model, check and clear the
problem.
• To prevent any serious personal injury and/or damage to property, be responsible when
operating all remote controlled models.
• The model car is not intended for use on public places and roads or areas where its operation
can conflict with or disrupt pedestrian or vehicular traffic.
• Because the model car is controlled by radio, it is subject to radio interference from many
sources that are beyond your control. Since radio interference can cause momentary loss
of control, always allow a safety margin in all directions around the model in order to
prevent collisions.
• Do not use your model:
- Near real cars, animals, or people that are unaware that an RC car is being
driven.
- In places where children and people gather
- In residential districts and parks
- In limited indoor spaces
- In wet conditions
- In the street
- In areas where loud noises can disturb others, such as hospitals and
residential areas.
- At night or anytime your line of sight to the model may be obstructed or
impaired in any way.
To prevent any serious personal injury and/or damage to property, please be
responsible when operating all remote controlled models.
IMPORTANT NOTES – ELECTRICAL
• Insulate any exposed electrical wiring (using heat shrink tubing or electrical tape) to
prevent dangerous short circuits. Take maximum care in wiring, connecting and insulating
cables. Make sure cables are always connected securely. Check connectors for if they
become loose. And if so, reconnect them securely. Never use R/C models with damaged
wires. A damaged wire is extremely dangerous, and can cause short-circuits resulting in
fire. Please have wires repaired at your local hobby shop.
• Low battery power will result in loss of control. Loss of control can occur due to a weak
battery in either the transmitter or the receiver. Weak running battery may also result in
an out of control car if your car‘s receiver power is supplied by the running battery. Stop
operation immediately if the car starts to slow down.
• When not using RC model, always disconnect and remove battery.
• Do not disassemble battery or cut battery cables. If the running battery short-circuits,
approximately 300W of electricity can be discharged, leading to fire or burns. Never
disassemble battery or cut battery cables.
• Use a recommended charger for the receiver and transmitter batteries and follow the
instructions correctly. Over-charging, incorrect charging, or using inferior chargers
can cause the batteries to become dangerously hot. Recharge battery when necessary.
Continual recharging may damage battery and, in the worst case, could build up heat
leading to fire. If battery becomes extremely hot during recharging, please ask your local
hobby shop for check and/or repair and/or replacement.
• Regularly check the charger for potential hazards such as damage to the cable, plug,
casing or other defects. Ensure that any damage is rectified before using the charger

4
cmyk nt18t manual page04
R/C & BUILDING TIPS
• Make sure all fasteners are properly tightened. Check them periodically.
• Make sure that chassis screws do not protrude from the chassis.
• For the best performance, it is very important that great care is taken to ensure the free
movement of all parts.
• Clean all ball-bearings so they move very easily and freely.
• Tap or pre-thread the plastic parts when threading screws.
• Self-tapping screws cut threads into the parts when being tightened. Do not use excessive
force when tightening the self-tapping screws because you may strip out the thread in the
plastic. We recommended you stop tightening a screw when you feel some resistance.
• Ask your local hobby shop for any advice.
Please support your local hobby shop. We at XRAY Model Racing Cars support all local hobby
dealers. Therefore we ask you, if at all possible, to purchase XRAY products at your hobby
dealer and give them your support like we do. If you have difficulty finding XRAY products,
please check out www.teamxray.com to get advice, or contact us via email at info@teamxray.
com, or contact the XRAY distributor in your country.
IMPORTANT NOTES – NITRO ENGINES
• Always test the brakes and the throttle before starting your engine to avoid losing control of
the model.
• Make sure the air filter is clean and oiled.
• Never run your engine without an air filter. Your engine can be seriously damaged if dirt and
debris get inside the engine.
• For proper engine break-in, please refer to the manual that came with the engine.
• Do not run near open flames or smoke while running your model or while handling fuel.
• Some parts will be hot after operation. Do not touch the exhaust or the engine until they
have cooled. These parts may reach 275°F during operation!
IMPORTANT NOTES – NITRO FUEL
• Handle fuel only outdoors. Never handle nitro fuel indoors, or mix nitro fuel in a place
where ventilation is bad.
• Only use nitro fuel for R/C models. Do not use gasoline or kerosene in R/C models as it
may cause a fire or explosion, and ruin your engine.
• Nitro fuel is highly inflammable, explosive, and poisonous. Never use fuel indoors or in
places with open fires and sources of heat.
• Always keep the fuel container cap tightly shut.
• Always read the warning label on the fuel container for safety information.
• Nitro-powered model engines emit poisonous vapors and gasses. These vapors irritate eyes
and can be highly dangerous to your health. We recommend wearing rubber or vinyl gloves to
avoid direct contact with nitro fuel.
• Nitro fuel for RC model cars is made of the combination of the methyl alcohol, castor or
synthetic oil, nitro methane etc. The flammability and volatility of these elements is very
high, so be very careful during handling and storage of nitro fuel.
• Keep nitro fuel away from open flame, sources of heat, direct sunlight, high temperatures,
or near batteries.
• Store fuel in a cool, dry, dark, well-ventilated place, away from heating devices, open
flames, direct sunlight, or batteries. Keep nitro fuel away from children.
• Do not leave the fuel in the carburetor or fuel tank when the model is not in use. There is
danger that the fuel may leak out.
• Wipe up any spilled fuel with a cloth
• Be aware of spilled or leaking fuel. Fuel leaks can cause fires or explosions.
• Do not dispose of fuel or empty fuel containers in a fire. There is danger of explosion.
FIRST AID
• Do not swallow nitro fuel or get it in your eyes. If this happens, immediate measures
should be taken.
• If fuel is swallowed, immediately drink large quantities of water and induce vomiting.
Consult a physician or poison control center immediately.
• If fuel gets into the eyes, rinse them well with water, and then consult a physician
immediately.
• If fuel gets onto the skin, wash it with soap and water well.
again. Modifying the charger may cause short-circuit or overcharging leading to a serious
accident. Therefore do not modify the charger.
• Always unplug charger when recharging is finished.
• Do not recharge battery while battery is still warm. After use, battery retains heat. Wait until
it cools down before charging.
• Do not allow any metal part to short circuit the receiver batteries or other electrical/
electronic device on the model.
• Immediately stop running if your RC model gets wet as may cause short circuit.
• Please dispose of batteries responsibly. Never put batteries into fire.

5
cm
y
k nt18t manual pa
g
e05
SYMBOLS USED
TOOLS REQUIRED
INCLUDED
EQUIPMENT REQUIRED INCLUDED IN #38 0791
Hobby KnifeHUDY 7.0mm
Socket #170070
Side Cutters Needlenose Pliers Curved Scissors Hole Reamer
# 107600
1:1
L=R
1
CA
2x
C
Self-tapping screws cut threads into the parts when being tightened. Excessive force may
permanently damage parts when tightening screws. It is recommended to stop tightening
when the part is attached or when some resistance is felt after the threaded portion enters
the plastic.
Overtightened
CORRECT WRONG
The threads are stripped.
TL
Micro ServoReceiverTransmitter
Engine + Muffler
Receiver Battery Switch with
Cables
Battery Charger Transmitter
Batteries
CA GlueLexan Paint Fuel Glow Plug
Igniter
Hudy Start-Box
#10 4300
(Typically AA type)(Ni-MH
recommended)
Differential
Assembly Tool
Phillips Screwdriver 1.5mm Allen
Wrench
Assemble as
many times
as specified
(here twice)
Cut off
remaining
material
Cut off
remaining
material from all
plastic parts.
Cut off
shadded
portion
Ensure smooth
non-binding
movement
Apply instant
glue
Pivot ball
type used
Pay attention
here
Assemble in
the specified
order
Assemble left
and right
sides the
same way
Part bags
used
True-to-scale
diagram
Car
orientation
Tighten screw
gently
Apply thread
lock
2x

6
cmyk nt18t manual page06
385062
385531
385531
970040
930610
385062
930020
385035
385095
930407
385002
960025
930812
385002
907270
385002
930025
385002
1. FRONT DIFFERENTIAL
BAG
385002 COMPOSITE ADJUSTABLE BALL DIFFERENTIAL
385035 BEVELED DIFF. GEAR FOR BALL DIFF.
385062 GEARBOX CASE M18T
385095 BALL DIFF D - WASHER (2)
385531 MAIN DRIVESHAFT PINION GEAR & HUB M18T
907270 SCREW PHILLIPS 2.5x20 (10)
930020 BALL STEEL 2.4MM (24)
930025 BALL-BEARING AXIAL 2.5x5.4x0.8
930407 BALL-BEARING MR74ZZ 4x7x2.5 (2)
930610 BALL-BEARING MR106ZZ 6x10x3 (2)
930812 BALL-BEARING MR128ZZ 8x12x3.5 (2)
970040 O-RING 4x1 (10)
960025 NUT M2.5 (10)
01

7
cm
y
k nt18t manual pa
g
e07
2x
GR
GR
CUT OFF
1. 2.
VERY IMPORTANT !
FACTORY PRE-ASSEMBLED
DIFFERENTIAL BREAK-IN AND
ADJUSTMENT:
The ball differentials in the NT18T comes
pre-built from the factory, but you must still perform
a proper break-in on them in order to have them perform
properly and give long life. The key is to gradually tighten the
diff to break it in properly and obtain the correct tightness. DO
NOT overtighten the diff initially or damage will result.
When breaking in the diff, the balls create a groove in the diff rings; this is normal and
essential for proper operation. If you overtighten the diff initially, the balls will mar the
surface of the rings (and damage the parts) instead of creating a proper groove in the rings.
Adjusting the differentials is easy to do. Tighten the diff until you feel some resistance; you
do not need to make large adjustments - 1/16 or 1/8 of a turn will make a noticeable
change in diff tightness.
Reassemble the truck, run it for a few minutes, and then tighten each diff a little bit.
Repeat this several times to break in the diff and set the correct tightness.
3.
ALIGN FLAT SPOTS
ALIGN FLAT
SPOTS
930020
B 2.4
930407
BB 4x7x2.5
907270
2.5x20
960025
N M2.5
930025
BA 2.5x0.8 930812
BB 8x12x3.5

8
ASSEMBLED VIEW
ASSEMBLED VIEW
4. 5. 6.
cmyk nt18t manual page08
CUT OFF
ORIENTATION
ORIENTATION
NOTE
ORIENTATION
930610
BB 6x10x3
970040
O 4x1

9
02
cm
y
k nt18t manual pa
g
e09
BAG
385002 COMPOSITE ADJUSTABLE BALL DIFFERENTIAL
385035 BEVELED DIFF. GEAR FOR BALL DIFF.
385062 GEARBOX CASE M18T
385095 BALL DIFF D - WASHER (2)
385531 MAIN DRIVESHAFT PINION GEAR & HUB M18T
385601 COMPOSITE SPUR GEAR ADAPTER
385654 STEEL SPUR GEAR 54T / 48
907270 SCREW PHILLIPS 2.5x20 (10)
910253 SCREW PHILLIPS FH M2.5x3 (10)
930020 BALL STEEL 2.4MM (24)
930025 BALL-BEARING AXIAL 2.5x5.4x0.8
930407 BALL-BEARING MR74ZZ 4x7x2.5 (2)
930610 BALL-BEARING MR106ZZ 6x10x3 (2)
930812 BALL-BEARING MR128ZZ 8x12x3.5 (2)
970040 O-RING 4x1 (10)
960025 NUT M2.5 (10)
2. REAR DIFFERENTIAL
385002
930812
960025
385002
930407
385095
930020
385035
385062
385002
930025
385002
907270
930610
385654
385601
970040
910253
385062
385531

10
cmyk nt18t manual page10
2x
GR
GR
CUT OFF
1. 2.
VERY IMPORTANT !
FACTORY PRE-ASSEMBLED
DIFFERENTIAL BREAK-IN AND
ADJUSTMENT:
The ball differentials in the NT18T comes
pre-built from the factory, but you must still perform
a proper break-in on them in order to have them perform
properly and give long life. The key is to gradually tighten the
diff to break it in properly and obtain the correct tightness. DO
NOT overtighten the diff initially or damage will result.
When breaking in the diff, the balls create a groove in the diff rings; this is normal and
essential for proper operation. If you overtighten the diff initially, the balls will mar the
surface of the rings (and damage the parts) instead of creating a proper groove in the rings.
Adjusting the differentials is easy to do. Tighten the diff until you feel some resistance; you
do not need to make large adjustments - 1/16 or 1/8 of a turn will make a noticeable
change in diff tightness.
Reassemble the truck, run it for a few minutes, and then tighten each diff a little bit.
Repeat this several times to break in the diff and set the correct tightness.
3.
ALIGN FLAT SPOTS
ALIGN FLAT
SPOTS
930020
B 2.4
930407
BB 4x7x2.5
907270
2.5x20
960025
N M2.5
930025
BA 2.5x0.8 930812
BB 8x12x3.5

11
14.
4. 14. 6. 14. 7.
14.
5.
cm
y
k nt18t manual pa
g
e11
ASSEMBLED VIEW
ASSEMBLED VIEW
ORIENTATION
NOTE
ORIENTATION
CUT OFF
910253
M2.5x8 930610
BB 6x10x3
970040
O 4x1

12
cmyk nt18t manual page12
3. REAR SUSPENSION
BAG
381130 NT18T ALU CHASSIS - CNC MACHINED 7075 T6
381210 LOWER FRONT & REAR BUMPER M18T
382200 COMPOSITE SUSPENSION BLOCK, L+R (2)
382650 SET OF STEERING PARTS
383120 SET OF REAR LOWER SUSPENSION ARMS M18T (2)
383150 SET OF REAR UPPER SUSPENSION ARMS M18T (2)
383240 LINKAGE REAR M18T (2)
385300 COMPOSITE DRIVE SHAFT SET M18T (2)
387542 NICKEL COATED PIVOT BALL 4.2 MM TYPE C (14)
387563 NICKEL COATED PIVOT BALL 6.3 MM TYPE A (14)
387564 NICKEL COATED PIVOT BALL 6.3 MM TYPE B (8)
901325 HEX SCREW SB M3x25 (10)
905208 SCREW PHILLIPS 2.2x8 (10)
03
381130
906258
905260
905208
383120
387564
930610
382200
387564
383150
905208
905264
385300
905212
387542
905210
382650
383240
381210
981208
385300
901325
387563
387563
ORIENTATION
905210 SCREW PHILLIPS 2.2x10 (10)
905212 SCREW PHILLIPS 2.2x12 (10)
905260 SCREW PHILLIPS 2.5x10 (10)
905264 SCREW PHILLIPS 2.5x14 (10)
906258 SCREW PHILLIPS FH 2.5x8 (10)
930610 BALL-BEARING MR106ZZ 6x10x3 (2)
981208 PIN 2x8 (10)

13
2. 3.1.
CHECK
cm
y
k nt18t manual pa
g
e13
ORIENTATION
Install pivot balls with fingers or with the handle of a tool.
5.4 mm4.8 mm
SAME
LENGTH
LEFT LOWER ARM
RIGHT LOWER ARM
L
L=R
R
2x
A
A
A
A
B
B
B
A
L=R
2x
6 mm
1:1
NOTE ORIENTATION
OF ALL PIVOT BALLS
DETAIL
TIP
981208
P 2x8
901325
SB 3x25 AB

14
6.
7.
4. 5.
DETAIL
cmyk nt18t manual page14
ORIENTATION
ORIENTATION
4.8 mm 5.4 mm
2x
RIGHT
LEFT
RIGHT LEFT
RIGHT UPPER ARM
LEFT UPPER ARM
NOTE ORIENTATION
OF ALL PIVOT BALLS
TIGHTEN
GENTLY
A
A
A
A
B
B
B
A
930610
BB 6x10x3
905208
2.2x8
AB

15
14.
8. 14. 10.
14.
11.
14.
9.
cm
y
k nt18t manual pa
g
e15
1:1
L=R
2x
ORIENTATION
4.4 mm
L=R
L=R L=R
C
C
930610
BB 6x10x3
905264
2.5x14
905260
2.5x10
905210
2.2x10
905212
2.2x12
905260
2.5x10
905264
2.5x14
905210
2.2x10
905212
2.2x12
1mm
3mm
TIGHTEN
GENTLY
C

16
14.
12. 14. 13.
cmyk nt18t manual page16
ASSEMBLED VIEW
ORIENTATION
DETAIL
NOTE ORIENTATION
ORIENTATION ORIENTATION
906258
2.5x8

17
cm
y
k nt18t manual pa
g
e17
ORIENTATION
4. FRONT SUSPENSION
BAG
381210 LOWER FRONT & REAR BUMPER M18T
382120 SET OF FRONT LOWER SUSPENSION ARMS M18T (2)
382150 SET OF FRONT UPPER SUSPENSION ARMS M18T (2)
382200 SET OF FRONT UPPER SUSPENSION ARMS M18T (2)
384110 BRAKE DISK - LASER CUT - PRECISION-GROUND
384140 BRAKE DISK COLLAR (2)
385300 COMPOSITE DRIVE SHAFT SET M18T (2)
385523 ALU MAIN DRIVESHAFT NT18T
387563 NICKEL COATED PIVOT BALL 6.3 MM TYPE A (14)
387564 NICKEL COATED PIVOT BALL 6.3 MM TYPE B (8)
387565 NICKEL COATED PIVOT BALL 6.3 MM TYPE D (2)
901325 HEX SCREW SB M3x25 (10)
905208 SCREW PHILLIPS 2.2x8 (10)
04
905260 SCREW PHILLIPS 2.5x10 (10)
905262 SCREW PHILLIPS 2.5x12 (10)
905264 SCREW PHILLIPS 2.5x14 (10)
906258 SCREW PHILLIPS FH 2.5x8 (10)
930610 BALL-BEARING MR106ZZ 6x10x3 (2)
981208 PIN 2x8 (10)
905208
387564
382120
930610
382200
382150
387564
905208
905264
901325
981208
385300
381210
385523
384110
384140
906258
387563
387565
905260
387563
905262

18
1. 2.
CHECK
3.
cmyk nt18t manual page18
5.4 mm
4.8 mm 6.1 mm
B
D
B
D
DETAIL
L=R
2x
6 mm
1:1
SAME
LENGTH
L
L=R
R
2x
NOTE ORIENTATION
OF ALL PIVOT BALLS
LEFT LOWER ARM
RIGHT LOWER ARM
A
B
A
ABD
B
FL
FL
FL
FR
FR
FR
ORIENTATION
The marks “FR” and “FL”
must be from BOTTOM of
the arms.
981208
P 2x8
901325
SB 3x25 ABD

19
4. 5. 6.
7.
DETAIL
cm
y
k nt18t manual pa
g
e19
ORIENTATION
5.4 mm
4.8 mm
NOTE ORIENTATION OF ARMS
A
A
A
B
B
A
RIGHT UPPER ARM
LEFT
RIGHT
RIGHT LEFT
LEFT UPPER ARM
NOTE ORIENTATION
OF ALL PIVOT BALLS
TIGHTEN
GENTLY
L=R
2x
B
A
FL
FL
FL
FL
FL
FL
FR
FR
FR FR
FR
FR
ORIENTATION
The marks “FR” and
“FL” must be from
BOTTOM of the arms.
ORIENTATION
The marks “FR” and “FL” must be
from TOP of the arms.
The marks “FR” and
“FL” must be from
BOTTOM of the arms.
FL
FL
FL
FR
FR
FR
930610
BB 6x10x3
905208
2.2x8
AB

20
cmyk nt18t manual page20
L=R
14.
9.
DETAIL
ORIENTATION
ORIENTATION
Note orientation
of the collar.
ASSEMBLED CUT-AWAY VIEW
14.
8.
LEFT
RIGHT
905264
2.5x14
905260
2.5x10 905262
2.5x12
4x TIGHTEN
GENTLY
905264
2.5x14
905260
2.5x10
905262
2.5x12
930610
BB 6x10x3
