Xstream PE-5024HWEBGEN User manual

operation manual
* IMPORTANT SAFETY INSTRUCTIONS
* SAVE THESE INSTRUCTIONS

2
table of contents
Introduction
4 Using the Operators Manual
Product Identification
5 Pressure Washer
5 Engine
Safety
6 Understanding the Machine Safety Decal
7 Safety Rules
7 Hazard Symbols and Meanings
Gas Washer Components
14 Component Chart
Assembly
15 Unpack the Pressure Washer
15 Attach Handle
Pre-Operation Checklist
16 Follow the Checklist Below
16 Connect Hose and Water Supply to Pump
Starting Your Washer
17 How to Start your Pressure Washer
Shutting Down Your Washer
21 How to Shut Down your Pressure Washer
Electric Washer Components
22 Component Chart

3
table of contents
Introduction
4 Using the Operators Manual
Product Identification
5 Pressure Washer
5 Engine
Safety
6 Understanding the Machine Safety Decal
7 Safety Rules
7 Hazard Symbols and Meanings
Gas Washer Components
14 Component Chart
Assembly
15 Unpack the Pressure Washer
15 Attach Handle
Pre-Operation Checklist
16 Follow the Checklist Below
16 Connect Hose and Water Supply to Pump
Starting Your Washer
17 How to Start your Pressure Washer
Shutting Down Your Washer
21 How to Shut Down your Pressure Washer
Electric Washer Components
22 Component Chart
Power Cord Connection
23 Connection Safety
Starting Your Electric Washer
25 How to Start your Pressure Washer
Shutting Down Your Electric Washer
28 How to Shut Down your Pressure Washer
Spray Tips
29 How to Use Spray Tips
29 Change Spray Tips
29 Usage Tips
Using Black Soap Nozzle
30 Apply Detergent
Trouble Shooting
31 Gas Engine Trouble Shooting Chart
32 Electric Motor Trouble Shooting Chart
33 Pump Trouble Shooting Chart
Storage
34 Winter Storage
34 Long Term Storage
34 Protect Fuel System
34 Storing the Engine
35 Other Storage Tips

4
Using the Operator’s manual
The operating manual is an important part of your pressure washer and
should be read thoroughly before initial use, and referred to often to make
sure adequate safety and service concerns are being addressed.
Reading the owner’s manual thoroughly will help avoid any personal injury
or damage to your machine. The information in this manual will offer you
the most effective tools for cleaning as well as the safest. By knowing
how best to operate this machine you will be better positioned to show
others who may also operate the unit.
This manual contains information for the complete range of pressure
washers, and is placed in order starting from the safety requirements
to the operating functions of your machine. You can refer back to the
manual at any time to help troubleshoot any specific operating functions,
so store it with the machine at all times.
Notice
Actual pressure released at the point of discharge may very by machine
due to varying factors including: Volume of water being fed to the ma-
chine by the water source, the inclusion of a Chemical injector in the line,
or variations in Engine performance
Attention: Read through the complete
manual prior to the initial use of your
pressure washer.
introduction

5
product identification
Record Identification Numbers
Pressure Washer
If you need to contact an Authorized Dealer or Customer Service line (1-
866-770-1711) for information on servicing, always provide the product
model and identification numbers.
You will need to locate the model and serial number for the machine and
record the information in the places provided below.
Date of Purchase:
Dealer Name:
Dealer Phone:
Product Identification Numbers
Model Number:
Serial Number:
Engine
Horse Power:

6
safety
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING – When using this product basic precautions should
always be followed, including the following:
1. Read all the instructions before using the product.
2. To reduce the risk of injury, close supervision is necessary when a
product is used near children.
3. Know how to stop the product and bleed pressures quickly. Be
thoroughly familiar with the controls.
4. Stay alert – watch what you are doing.
5. Do not operate the product when fatigued or under the influence
of alcohol or drugs.
6. Keep operating area clear of all persons
7. Do not overreach or stand on unstable support. Keep good
footing and balance at all times.
8. Follow the maintenance instructions specified in the manual.

7
Understanding the Machine Safety Labels
The machine safety label shown below is placed on your machine
to draw attention to potential safety hazards.
safety
OPERATING INSTRUCTIONS/ INSTRUCTIONS D’UTILISATION
1
• CONNECT STANDARD GARDEN HOSE TO UNIT (MINIMUM SIZE 5/8 I.D.).
• RELIER UN BOYEAU D’ARROSAGE ORDINAIRE À L’UNITÉ. (DIA. INTÉRIEUR MINIMUM 5/8”.)
2
• SNAP HIGH PRESSURE HOSE SECURELY INTO UNIT.
• RACCORDER SOLIDEMENT LE BOYEAU DE HAUTE PRESSION À L’UNITÉ.
3
• TURN ON WATER SUPPLY
• OUVRIR LE ROBINET D’EAU.
4
• MUST PULL GUN TRIGGER ALLOWING AIR TO ESCAPE FROM SYSTEM.
• PRESSER LA GÂCHETTE DU PISTOLET POUR ÉVACUER L’AIR DU SYSTÈME.
5
• WHEN ALL AIR HAS ESCAPED, START ENGINE WHILE GUN IS STILL OPEN.
• LORSQU’IL NE RESTE PLUS D’AIR, DÉMARRER LE MOTEUR TOUT EN GARDANT LE PISTOLET
OUVERT.
6
• USE BLACK NOZZLE WITH LARGE HOLE TO ENGAGE SOAP INJECTOR.
• UTILISER LA BUSE EN LAITON ÉQUIPÉE D’UN LARGE TROU POUR VAPORISER LE SAVON.
Always wear eye protection.
Porter toujours des lunettes de sécurité.
High pressure sprays can cause serious bodily injury.
Use with Caution. Les jets à haute pression peuvent
causer de graves blessures corporelles. Soyez prudent.
Do not let unit freeze.
La pompe risquerait de surchauer.
Warranty is void if you exceed preset pressure
causing severe damage to gauge and unloader.
Ne pas exposer cette unité au gel la guarantie n’est
pas applicable si vous exédez la mesure de préssion
PSI indiqué. Causez beaucoup de dommage à la
indicateur et la dechargeur.
PSI
Do not leave unit running longer than 1 minute
without using or pump will overheat. Ne pas laisser
fonctionner inutilement l’unité pendant plus d’une minute.
WARNING! PRECAUTIONS!
FOR OUTDOOR USE ONLY
THIS PRODUCT IS PROHIBITTED FOR INDOOR USE BECAUSE THE ENGINE PRODUCES HARMFUL CARBON MONOXIDE.
IF INHALED, CARBON MONOXIDE MAY CAUSE SERIOUS INJURY OR DEATH.
85.609.158
85.609.158
WARNING!

8
safety
The safety alert symbol ( ) is used with a signal word (DANGER,
CAUTION, WARNING), a pictorial and/or a safety message to alert
you to hazards.
DANGER indicates a hazard which, if not avoided, will result in death
or serious injury.
WARNING indicates a hazard which, if not avoided, could result in
death or serious injury.
CAUTION indicates a hazard which, if not avoided, might result in
minor or moderate injury.
NOTICE indicates a situation that could result in equipment damage.
Follow safety messages to avoid or reduce the risk of injury or
death.
Hazard Symbols and Meanings
Save these Instructions
Safety Rules
This is the safety alert symbol. It is
used to alert you to potential personal
injury hazards. Obey all safety
messages that follow this symbol to
avoid possible injury or death.
explosion
kickback
fall fluid injection moving parts read manual
hot surface flying objects slippery
fire electric shock toxic fumes

9
safety
WARNING
Fuel and its vapors are extremely flammable and
explosive.
Fire or explosion can cause severe burns or death.
When Adding or Draining Fuel
• Turn pressure washer OFF and let it cool at least 2 minutes before
removing fuel cap. Loosen cap slowly to relieve pressure in tank.
• Fill or drain fuel tank outdoors.
• DO NOT overfill tank. Allow space for fuel expansion.
• If fuel spills, wait until it evaporates before starting engine.
• Keep fuel away from sparks, open flames, pilot lights, heat, and other
ignition sources.
• DO NOT light a cigarette or smoke.
When Starting Equipment
• Ensure spark plug, muffler, fuel cap, and air cleaner are in place.
• DO NOT crank engine with spark plug removed.
When Operating Equipment
• DO NOT tip engine or equipment at angle which causes fuel to spill.
• DO NOT spray flammable liquids.
When Transporting or Repairing Equipment
• Transport/repair with fuel tank EMPTY or with fuel shutoff valve OFF.
• Disconnect spark plug wire.
When Storing Fuel or Equipment with Fuel in Tank
• Store away from furnaces, stoves, water heaters, clothes dryers, or
other appliances that have pilot light or other ignition source because
they can ignite fuel vapors.
WARNING
Risk of electrocution.
Contact with power source can cause electric shock
or burn.
• NEVER spray near power source.

10
safety
WARNING
Starter cord kickback (rapid retraction) can result in
bodily injury. Kickback will pull hand and arm toward
engine faster than you can let go.
Broken bones, fractures, bruises, or sprains could
result.
• NEVER pull starter cord without first relieving spray gun pressure.
• When starting engine, pull cord slowly until resistance is felt and then
pull rapidly to avoid kickback.
• After each starting attempt, where engine fails to run, always point
spray gun in safe direction and squeeze spray gun trigger to release
high pressure.
• Firmly grasp spray gun with both hands when using high pressure
spray to avoid injury when spray gun kicks back.
WARNING
Running engine gives off carbon monoxide, an odorless,
colorless, poison gas.
Breathing carbon monoxide can cause headache,
fatigue, dizziness, vomiting, confusion, seizures, nausea,
fainting or death.
Some chemicals or detergents may be harmful if inhaled
or ingested, causing severe nausea, fainting, or
poisoning.
• Operate pressure washer ONLY outdoors.
• Keep exhaust gas from entering a confined area through windows,
doors, ventilation intakes, or other openings.
• DO NOT start or run engine indoors or in an enclosed area, even if
windows and doors are open.
• Use a respirator or mask whenever there is a chance that vapors may
be inhaled.
• Read all instructions with mask so you are certain the mask will
provide the necessary protection against inhaling harmful vapors.

11
safety
WARNING
Contact with muffler area can result in serious burns.
Exhaust heat/gases can ignite combustibles, structures
or damage fuel tank causing a fire.
• DO NOT touch hot parts and AVOID hot exhaust gases.
• Allow equipment to cool before touching.
• Keep at least 5 feet (1.5 m) of clearance on all sides of pressure
washer including overhead.
WARNING
Use of pressure washer can create puddles and
slippery surfaces.
Kickback from spray gun can cause you to fall.
• Operate pressure washer from a stable surface.
• The cleaning area should have adequate slopes and drainage to
reduce the possibility of a fall due to slippery surfaces.
• Be extremely careful if you must use the pressure washer from a
ladder, scaffolding, or any other similar location.
• Firmly grasp spray gun with both hands when using high pressure
spray to avoid injury when spray gun kicks back.
WARNING
Risk of eye injury.
Spray can splash back or propel objects.
• Always wear safety goggles when using this equipment or in vicinity
of where equipment is in use.
• Before starting the pressure washer, be sure you are wearing
adequate safety goggles.
• NEVER substitute safety glasses for safety goggles.

12
safety
WARNING
Starter and other rotating parts can entangle hands,
hair, clothing, or accessories.
• NEVER operate pressure washer without protective housing or
covers.
• DO NOT wear loose clothing, jewelry or anything that may be caught
in the starter or other rotating parts.
• Tie up long hair and remove jewelry.
WARNING
The high pressure stream of water that this equipment
produces can cut through skin and its underlying
tissues, leading to serious injury and possible
amputation.
Spray gun traps high water pressure, even when engine
is stopped and water is disconnected, which can cause
injury.
• DO NOT allow CHILDREN to operate pressure washer.
• NEVER repair high pressure hose. Replace it.
• NEVER repair leaking connections with sealant of any kind. Replace
o-ring or seal.
• NEVER connect high pressure hose to nozzle extension.
• Keep high pressure hose connected to pump and spray gun while
system is pressurized.
• ALWAYS point spray gun in safe direction and squeeze spray gun
trigger, to release high pressure, every time you stop engine.
• NEVER aim spray gun at people, animals, or plants.
• DO NOT secure spray gun in open position.
• DO NOT leave spray gun unattended while machine is running.
• NEVER use a spray gun which does not have a trigger lock or trigger
guard in place and in working order.
• Always be certain spray gun, nozzles and accessories are correctly
attached.

13
safety
NOTICE
High pressure spray may damage fragile items including glass.
• DO NOT point spray gun at glass when using red 0° spray tip.
• NEVER aim spray gun at plants.
NOTICE
Improper treatment of pressure washer can damage it and shorten its
life.
• If you have questions about intended use, ask dealer or contact
nearest authorized dealer.
• NEVER operate units with broken or missing parts, or without
protective housing or covers.
• DO NOT by-pass any safety device on this machine.
• DO NOT tamper with governed speed.
• DO NOT operate pressure washer above rated pressure.
• DO NOT modify pressure washer in any way.
• Before starting pressure washer in cold weather, check all parts of
the equipment to be sure ice has not formed there.
• NEVER move machine by pulling on hoses. Use handle provided on
unit.
• Check fuel system for leaks or signs of deterioration, such as chafed
or spongy hose, loose or missing clamps, or damaged tank or cap.
Correct all defects before operating pressure washer.
WARNING
Unintentional sparking can result in fire or electric
shock.
When Adjusting or Making Repairs to Your Pressure Washer
• Disconnect the spark plug wire from the spark plug and place the
wire where it cannot contact spark plug.
When Testing for Engine Spark
• Use approved spark plug tester.
• DO NOT check for spark with spark plug removed.

14
Read this operator’s manual and safety
rules before operating your pressure
washer.
gas washer components
1. Spray Tips Detergent, 0°, 15°, and 40°: for various high pressure cleaning applications.
2. High Pressure Hose Connect one end to water pump and the other end to spray gun.
3. Pressure Control Knob Varies pressure of high pressure spray.
4. Water Inlet Connection for garden hose.
5. High Pressure Outlet Connection for high pressure hose.
6. Pump Develops high pressure.
7. Oil Level Indicator Level should be at halfway
8. Detergent Siphoning Tube/Filter Use to siphon pressure washer safe detergent into
the low pressure stream.
9. Choke Lever Prepares a cold engine for starting.
10. Fuel Valve Used to turn fuel supply on and off to engine.
11. Recoil Starter Used for starting the engine manually.
12. Throttle Lever Sets engine in starting mode for recoil starter.
13. Engine Switch Set switch to “On” for recoil starting. Set switch to “Off” to stop a
running engine.
14. Air Filter Protects engine by filtering dust and debris out of intake air.
15. Fuel Tank Fill tank with regular unleaded fuel. Always leave room for fuel expansion.
16. Spray Gun Extension with Quick Connect Nozzles Controls the application of
water onto cleaning surface with trigger device. Includes trigger lock. Allows you to
switch between five different spray tips.
1.
16.
2.
5.
9.
8.
10.
6.
11.
13.
7.
3.
12.
14. 15. 4.

15
Your pressure washer requires some assembly and is ready for use after
it has been properly serviced with the recommended oil and fuel.
If you have any problems with the assembly of your pressure washer,
please call the pressure washer help line. If calling for assistance, please
have the model and serial number from the data tag available.
Unpack the Pressure Washer
1. Remove the parts bag, accessories, and inserts included with
pressure washer.
2. Open box completely by cutting each corner from top to bottom.
3. Ensure you have all included items prior to assembly.
Attach Handle
1. Place handle (A) onto handle supports (B) connected to main unit.
Make sure holes (C) in handle align with holes on handle supports.
assembly
NOTE: It may be necessary to move the handle supports from
side to side in order to align the handle so it will slide over the
handle supports.
3. Insert multi-colored quick connect spray tips and other supplied
accessories in spaces provided on handle.
2. Insert carriage bolts through holes from outside of unit and
attach a plastic knob from inside of unit. Tighten by hand.
C
B
A

16
pre-operation checklist
Follow the Checklist Below Prior to Using the Machine Each Time
1. Check to ensure the engine oil is at the proper level.
Use SAE 10W30 Oil
2. Check the 2 handle knobs to ensure they are tight and will not vibrate
loose.
3. Add fuel to the gas tank.
4. Connect and tighten the garden hose to the GHA (garden hose inlet)
connection.
** Water must be turned on prior to starting the washer, pull the
spray trigger to ensure water is moving the through the lines and
out the nozzle without any leaks before starting the unit.**
5. Review the safety guidelines in the manual prior to starting the unit.
If you have any issues operating the pressure washer, call the customer
service line.
Connect Hose and Water Supply to Pump Before Starting
WARNING
DO NOT start your pressure washer without the water
supply turned on.
• Failure to do so will result in damaging the pump from overheating
and void the warranty.
WARNING
Always check the level of the engine oil prior to starting
the washer.
• Failure to do so could cause the engine to seize if the oil is low or
empty.

17
starting your washer
How to Start Your Pressure Washer
To start your pressure washer for the first time, follow these instructions
step-by-step. This starting information also applies if you have let the
pressure washer sit idle for at least a day.
1. Place pressure washer near an outside water source capable of
supplying water at a flow rate greater than 3.8 gallons per minute and
no less than 20 PSI at pressure washer end of garden hose. DO NOT
siphon supply water.
2. Make sure unit is in a level position.
3. Connect garden hose to water inlet on pressure washer pump.
4. Attach wand extension to spray gun. Tighten by hand.
5. Choose desired spray tip, pull back nozzle extension collar, insert spray
tip and release collar. Tug on spray tip to make sure it is securely in
place. See Spray Tips.
NOTICE
DO NOT run the pump without the water supply connected and
turned on.
• Damage to equipment resulting from failure to follow this instruction
will void warranty.

18
6. Uncoil high pressure hose and attach quick connect end of hose to
base of spray gun. Pull down on collar of quick connect, slide onto
spray gun and let go of collar. Tug on hose to be sure of tight
connection.
7. Similarly, attach other end of high pressure hose to high pressure
outlet (A) on pump. Pull down on collar of quick connect, slide onto
pump and let go of collar. Pull on hose to be sure of tight connection.
8. Turn Water Supply on, point gun in a safe direction and squeeze the
trigger to purge the pump of air and debris. Do this for at least 30
seconds.
9. Take a look at all connections to make sure there are no leaks or loose
connections.
IMPORTANT: DO NOT siphon standing water for the water supply. Use
ONLY cold water (less than 100°F/38°C).
WARNING
The high pressure stream of water that this
equipment produces can cut through skin and its
underlying tissues, leading to serious injury and
possible amputation.
• NEVER connect high pressure hose to nozzle extension.
• Keep high pressure hose connected to pump and spray gun while
system is pressurized.
• Always be certain spray gun, nozzles and accessories are correctly
attached.
starting your washer
AA
BB
axial pump triplex pump
Pump Uses 30W Non-Detergent Mineral Oil

19
starting your washer
10. Connect the garden hose to the water inlet. Tighten by hand.
11. To start the machine, locate the engine switch on the side of the
engine, and switch it to the ON position. (see component chart to
locate switch) Check to ensure fuel valve is in the ON position and if
starting cold apply the choke.
12. Pull recoil cord slowly until resistance is felt and then pull rapidly to
avoid kickback. Make sure to position yourself in a balanced
position. DO NOT place hand on engine muffler for balance, this will
result in severe burn.
WARNING
Running engine gives off carbon monoxide, an odorless,
colorless, poison gas.
Breathing carbon monoxide can cause headache,
fatigue, dizziness, vomiting, confusion, seizures,
nausea, fainting or death.
• Operate pressure washer ONLY outdoors.
• Keep exhaust gas from entering a confined area through windows,
doors, ventilation intakes, or other openings.
• DO NOT start or run engine indoors or in an enclosed area, even if
windows and doors are open.
IMPORTANT: Before starting the pressure washer, be sure you
are wearing adequate safety goggles.
WARNING
Risk of eye injury.
Spray can splash back or propel objects.
• Always wear safety goggles when using this equipment or in vicinity
of where equipment is in use.
• Before starting the pressure washer, be sure you are wearing
adequate safety goggles.
• NEVER substitute safety glasses for safety goggles.

20
starting your washer
WARNING
Starter cord kickback (rapid retraction) can result in
bodily injury. Kickback will pull hand and arm toward
engine faster than you can let go.
Broken bones, fractures, bruises, or sprains could
result.
• NEVER pull starter cord without first relieving spray gun pressure.
• When starting engine, pull cord slowly until resistance is felt and then
pull rapidly to avoid kickback.
• After each starting attempt, where engine fails to run, always point
spray gun in safe direction and squeeze spray gun trigger to release
high pressure.
• Firmly grasp spray gun with both hands when using high pressure
spray to avoid injury when spray gun kicks back.
WARNING
The high pressure stream of water that this equipment
produces can cut through skin and its underlying
tissues, leading to serious injury and possible
amputation.
Spray gun traps high water pressure, even when engine
is stopped and water is disconnected, which can cause
injury.
• DO NOT allow CHILDREN to operate pressure washer.
• NEVER repair high pressure hose. Replace it.
• NEVER repair leaking connections with sealant of any kind. Replace
o-ring or seal.
• NEVER connect high pressure hose to nozzle extension.
• Keep high pressure hose connected to pump and spray gun while
system is pressurized.
• ALWAYS point spray gun in safe direction and squeeze spray gun
trigger, to release high pressure, every time you stop engine.
• NEVER aim spray gun at people, animals, or plants.
• DO NOT secure spray gun in open position.
• DO NOT leave spray gun unattended while machine is running.
• NEVER use a spray gun which does not have a trigger lock or trigger
guard in place and in working order.
• ALWAYS be certain spray gun, nozzles and accessories are correctly
attached.
