ASSEMBLY GUIDE - X-SERIES SQUAT RACK – S90/S84 MULTI-GRIP CHIN-UP
PARTS:
(2) US-01001-V2 – Lateral Base Tube
(1) US-01001-V2A – Crossbeam 1
(1) US-01001-V2M – Crossbeam 2
(1) Multi-Grip Chin-Up
(4) US-002-V2 – Triangle Plate
(2) XS-S90-01001-V2 – X-SERIES 90”/82” UPRIGHT
(4) 2x3” Plastic
HARDWARE:
(3) 3.5” x 5/8” Bolts
(8) 4.5” x 5/8” Bolts
(8) 5” x 5/8” Bolts
(38) 5/8” washers
(19) 5/8” Lock Washers
(19) 5/8” Nut
REQUIRED TOOLS:
(1) 15/16” Socket or 24mm Socket
(1) 15/16” Wrench or 24mm Wrench
(1) Rubber Mallet
(1) Ladder or step stool
INSTRUCTIONS:
STEP 1.
Place Lateral Base in position where you wish to assemble rack with the 3” face down, 43”
apart, and parallel to each other. Place Crossbeam 1 at the furthest most set of holes between
Lateral Base Tube.
STEP 2.
Using 4.5” Bolts connect the Crossbeam 1 to the Lateral Base Tubes. Finger tighten hardware.
STEP 3.
Position Triangle Plate along the inside and outside of the Lateral Base Tube in the center.
Using 5” Bolts attach Triangle Plate to the Lateral Base Tube.
STEP 4.
Repeat Step 3 for the opposite side.
STEP 5.

With a helper, place Upright between the Triangle Plate, attach with 5” Bolts. Finger tighten
hardware.
STEP 6.
Repeat Step 5 for the opposite side.
STEP 7.
With a helper, place the Crossbeam 2 at your desired height and use 4.5” Bolts to join the three
parts. Finger tighten hardware.
STEP 8.
Line the Multi-Grip Chin-up to the left-most hole on 3” face of the Crossbeam 2 installed in Step
7. Use 3.5” Bolt and connect components, finger tighten hardware. Then swing Multi-Grip Chin-
up until horizontal and align with right second last hole from the right, use 3.5” Bolt and
connect components, finger tighten hardware. Using 3.5” Bolt place through the center hole of
the Multi-Grip Chin-up, finger tighten hardware.
STEP 9.
Fasten all hardware completely.
STEP 10.
Using a Rubber Mallet install 2x3” Plastic into the Lateral Base Tubes.
