XtendLan XL-ITB-101 User manual

XL-ITB-101
IP Set-top Box
UserManual

NOTICE
This document contains proprietary information protected by copyright, and this Manual and all the
accompanying hardware, software, and documentation are copyrighted. All rights are reserved. No
part of this document may be photocopied or reproduced by mechanical, electronic, or other means
in any form.
The manufacturer does not warrant that the hardware will work properly in all environments and
applications, and makes no warranty or representation, either expressed or implied, with respect to
the quality, performance, merchantability, or fitness for a particular purpose of the software or
documentation. The manufacturer reserves the right to make changes to the hardware, software,
and documentation without obligation to notify any person or organization of the revision or change.
All brand and product names are the trademarks of their respective owners.
© Copyright 2009
All rights reserved

3
Content
1. Overview......................................................................................................... 4
1.1 Features ...................................................................................................4
1.2 Accessories ..............................................................................................5
1.3 Environment .............................................................................................5
2. Physical Interface............................................................................................. 6
2.1 Front Panel ...............................................................................................6
2.2 Rear Panel................................................................................................ 6
2.3 LED Status ...............................................................................................6
2.4 Remote Controller ....................................................................................7
3. Minimum Configuration .................................................................................... 9
3.1 System Diagram .......................................................................................9
3.2 Software Environment ..............................................................................9
3.3 Use Set-top Box Accessories ...................................................................9
3.4 Set Static IP ............................................................................................ 10
3.5 Required Server Software ....................................................................... 11
4 EPG Page .........................................................................................................16
4.1 Booting .....................................................................................................16
4.2 Menu......................................................................................................... 17
4.3 TV .............................................................................................................18
4.4 Video ........................................................................................................19
4.5 Audio........................................................................................................ 21
4.6 Picture ......................................................................................................21
4.7 Admin........................................................................................................22
4.8 Information................................................................................................ 25
Q&A ..................................................................................................................... 27

4
1.Overview
With an Ethernet input and flexible video and audio output, XL-ITB-101 introduces high
performance solution by advanced video decoder H.264/AVC engines. This provides our
customers, ISPs or Telecoms, a cost effective way to deliver sophisticated interactive
digital television service including multicast streaming, video on demand, Internet access,
etc.
1.1 Features
HD (High Definition)
MPEG2 MP@HL
H.264/AVC main and high profile to level 4.1
VC-1 advanced profile @ level 3 (Option)
VC-1 simple and main profile (Option)
Audio decode: AAC LC, AAC LC+SBR Level 2, AAC+ Level 2, AAC+ Level 4
Audio decode: MPEG1 Layer 1, 2, MPEG 1 Layer 3 (MP3)
Audio decode: Windows Media Audio ( WMA) (Option)
HDMI 1.2/DVI 1.0 with HDCP 1.1
Supports different Middleware and Conditional Access vendors
Audio outputs:
Stereo Audio
Digital Audio surround via S/P-DIF (coaxial and optical)
Video outputs
SD: Composite, S-Video
HD: Component, HDMI/HDCP
SD: PAL, NTSC and SECAM
HD: 720p, 1080i, 1080p30
Full screen ,4:3 and 16:9 format
Independent simultaneous dual output HD/SD
IR remote controller
IPv6 support
10/100 BaseT Ethernet
UDP multicast streaming
Video on demand
No air-cooling fan

5
Conditional Access smartcard-less - OTP for storage of secure information and
special customer configurations.
Macrovision 7.1 (Option)
1.2 Accessories
• Infra Remote Controller
• Universal DC Adapter
• User Manual
1.3 Environment
1.3.1 Temperature
• High (40° C) / 72 hours; Low (0° C) / 72 hours; Cycle (Normal: 4 hours / High:
4 hours / Low: 4 hours): 10 times (Interval time : 2 hours)
1.3.2Humidity
• Operating: 0~85% (non-condensing)
• Non-Operating: 10％~ 90％(non-condensing)
1.3.3Vibration
• Amplitude: 1.5mm
• Frequency: 10 ~ 55Hz
• Cycle: 5 min
• Direction: X / Y / Z (1 hour)
1.3.4 Drop
• 90 cm with package (1 angle / 6 faces / 8 corner); 60 cm without package (1 angle / 6
faces / 8 corner)
1.3.5Noise
• 50dB (max.) at 1 meter
1.3.6ESD
• Condition 1: Contact 4KV / Air 8K; Condition 2: Contact 8KV / Air 12KV;
Condition 3: Contact / Air 20KV (Shut-Down mode)
1.3.7Surge
• Normal mode: 1KV; Common mode: 2KV
1.3.8Pulse
• +/- 2KV (2.5KHz~5KHz / 1 min)

6
2. Physical Interface
2.1 Front Panel
2.2 Rear Panel
2.3 LED Status
Name
Description
Color
Mode
Status
POWER
Power
Green
ON
O.K.
OFF
Power failure or disconnected
Red
ON
Standby mode
LINK
ETH link
Green
ON
WAN port is connected
OFF
WAN port is disconnected
IR
IR receiver indication
Green
Blinking
Received a correct signal from
remote controller

7
2.4 Remote Controller

8
No.
Item
Description
1
PWR
Normal/Standby
2
MUTE
Cancel the voice
3
GUIDE
Toggle to Video Playlist
4
Fast forward(VOD mode)
5
Play(VOD mode)
6
7
Increase one channel(multicasting mode)
8
Enter
9
Increase volume
10
Toggle the info panel on the full-screen TV screen
11
Exit the current screen to full-screen TV screen
12
Quit play(VOD mode)
13
Video on demand
14
15
16
Toggle the main menu
17
Decrease volume
18
Navigation
control the focus movement
19
Decrease one channel or clear text one by one
20
Picture-in-Picture mode
21
Toggle pip control
22
Pause when playing Stepping when paused(VOD mode)
Pause PVR. Only works on full-screen TV.
23
Toggle video between main and pip
24
Fast rewind(VOD mode)
25
Previous page(WEB mode)
Next page(WEB mode)
26
27
VCR
28
REC
Press once to bring up record screen, press again to start recording.

9
3. Minimum Configuration
This part describes a brief instruction about how to make XL-ITB-101 work. It uses a
minimum requirement to simulate real environment.
3.1 System Diagram
3.2 Software Environment
Using Microsoft Window 98/2000/XP operation system
Step 1: First go to My Network Places in your OS. Step
2: Select Properties of Local Area Connection. Step 3:
Select Properties of Internet Protocol (TCP/IP).
Step 4: Input the IP address, subnet mask, default gateway and DNS server address
manually.
3.3 Use Set-top Box Accessories

10
Using the DC adaptor
Many countries have different power cord configurations. Your set-top box should be supplied
with the correct one for your area.
Step 1: Plug the DC adapter into the power connector on the rear side of the set-top box.
Step 2: Connect the power cord to the DC adapter and then to a power outlet.
Loading batteries in the remote control
In the accessory box, you can find an AAA battery set and one remote control.
Step 1: Take off the plastic bag of remote control.
Step 2: Remove the lid of battery container.
Step 3: Put the battery into the battery container, and please follow the instruction described
in the container and maker sure the batteries are set in the right direction.
Step 4: Put on the lid of battery container.
Turning on the Set-top Box
Step 1: Plug the DC adaptor.
Step 2: See if the power LED light is on.
3.4 Set Static IP
The following steps are about how to change the IP address of STB.
Step1: After change, input telnet (STB IP address), for example, telnet 192.168.10.41 in
your computer’s command line. The login password is root.
Step2: Input vi rc.user to edit rc.user file, change the IP address of STB into the IP
address you want, for example, 192.168.10.88. Just remember to change the Gateway IP
address so that it belongs the same subnet.

11
Step3: Save and Exit(Press Esc, input :wq).
3.5 Required Server Software
It can use Windows or Linux to structure; Linux is our preferred and suggested.
OS
Fedora Core
Windows Server 2003
DHCP Server
Dhcp
Windows Built-in
Multicast Server
VLC Media Player
VLC Media Player
HTTP Server
Httpd
Windows IIS
RTSP Server
LIVE555 Media Server
LIVE555 Media Server
Time Server
Ntp
Windows Built-in
VLC media player can get from this link http://www.videolan.org/ and it acts as UDP
and HTTP multicast server or UDP unicast server.
There are some important points of using VLC
Run many VLC at un-powerful PC may cause performance issue and Windows OS is serious
than Linux.
VLC version 0.8.6b, 0.8.6c & 0.8.6d has problem when multicast 2 channels
above, no matter Linux or Windows. Version 0.8.6a is recommended.
VLC has some issue when multicast AAC audio and it transfers audio and
video PID to different value with original.

12
Run many VLC at un-powerful PC may cause performance issue and Windows OS is
serious than Linux.
VLC version 0.8.6b, 0.8.6c & 0.8.6d has problem when multicast 2 channels
above, no matter Linux or Windows. Version 0.8.6a is recommended.
VLC has some issue when multicast AAC audio and it transfers audio and
video PID to different value with original.
LIVE555 media server can get form http://www.live555.com/mediaServer/. It is a
complete RTSP server application. At our configuration, it plays for RTSP VOD Server.
Channel Table
The default TV channel table of XL-ITB-101 is as below. It is pre-stored at XL-ITB-101
and it’s
read-only. It want change to different channel, please refer chapter VII.
Channel
Protocol Address Port
UDP 224.1.1.10 1234
UDP 224.1.1.11 1234
UDP 224.1.1.12 1234
RTSP RTSP://192.168.10.108/1080_rueo2008_dome_dvd.ts
Step By Step
VLC Media Server
1. Install and set up DHCP server, install VLC Media Player.
2. After install, execute VLC by click desktop icon. Select “File”, “Open File…”
3. Click “Browse” button. Select media source that you want to multicast, click
“Open”. Enable “Stream/Save”, and then click “Settings…”.

13
4. There are two kinds of output protocol that XL-ITB-101 can support, UDP and
HTTP.
And two stream type: Multicast and Unicast.
UDP Multicast and Unicast
Enable “UDP” and input value of multicast channel IP and port such as channel
1: Address: 224.1.1.10, Port:1234
Click “OK” to save and close this window.
If unicast, just set Address to device IP. For example:
Address: 10.10.10.190, Port: 1234

14
5. Click “OK” to close window and start multicasting.

15
6. It can set repeat mode when multicast. Select “View”, “Playlist…”.
7. Click “Repeat one” to enable repeat mode. It has three kinds of repeat mode that you can
select: Shuffle, RepeatAll and Repeat One.
By our experience, the performance of VLC multicast at Windows OS maybe
decrease each time when repeat. This situation is much better at Linux OS.
There is some jitter when repeat at both OS, that caused by VLC. It is normal.
8. Now can connect Ethernet, output interface cable and power on XL-ITB-101.

16
After loading procedure, you can watch TV. The background of
menu page is multicast stream from 224.1.1.10.
9. Execute other VLC by click desktop icon and repeat above steps to set
other UDP
LIVE555 Media Server
1. The server is a console application (there is currently no GUI version). To
run the server, simply type "live555MediaServer".
2. Put media file that for VOD at the same directory
3. Play streams from VOD client using the URL
rtsp://<Server IP Address>/<Filename>
4. Please do not put blank at filename.
4 EPG Page
4.1 Booting

17
Key For All
There are some keys of remote are work for all pages:
POWER – This system can support 3 different types of power mode. You can
try on by pressing the button to make sure which type you are using.
Type 1: Click to stand-by and will be wake up by one more click.
Type 2: Click to reboot.
Type 3: Click to stand-by and will be reboot by one more click.
The default type of XL-ITB-101 is type 1.
4.2 Menu
This is default portal page of XL-ITB-101. When press “MENU” key at remote,
it jump to this page. Please use cursor key left and right to select function and
press “OK” for connection.

18
4.3 TV
This is the live TV page. The left-top corner shows channel number, file name ,
file format and volume number at start or channel changed.
Use the channel +/- keys to change channels.
Press the "Info" button and you can see status. When viewing these status
panels, you can also use the Right and Left arrow buttons to see additional
status. Press the "Info" button again to toggle the panel off.
Press the "Menu" button and you'll go to the XL-ITB-101 home page. Press
the arrow buttons to move to the TV window and press the "OK" button to go
back to full-screen TV.

19
Available Key:
0-9 -- Select channel by digital, only works at the channel already defined at
channel table. It can automatically change when only input one digital. For
example, press 7, the channel number means “CH 7-“ and change to channel
7 after waiting timeout.
CH+/- -- Switch channel。
STOP – Stop live TV and return to portal page.
PAUSE－Stop live TV temporarily.
PLAY- Pay live TV.
MUTE- Cancel the voice
4.4 Video
This is Video menu page, it plays video from USB storage.
This Video page is used for play local disk file. It can read media file from USB
device.(such as flash disk, hard drive, flash memory card…). It can support
transport stream format by extension ts. Connect USB device before enter this
page, it shows disk partition when page loaded. If connect after enter, please
click “admin” button to refresh streams, or else you won’t see its content.

20
Select program and click “OK” to start play.
Below key is only available at Video playing screen.
Available Key:
STOP -- Stop VOD and return to VOD menu page.
PLAY/PAUSE -- Control VOD play and pause. When trick playing, stop
playing and resume to normal speed.
F.R. & F.F. -- Control VOD play. Forward and rewind both have 42segments.
Press again at trick playing increase speed. This F.R. feature has not
implement at Normal RTSP Server by current software.
