Infomir MAG424w3 User manual

Instruction Manual
Linux based
Set-Top Box
MAG424
MAG424w3

Set-Top Box MAG424, MAG424w3. Instruction Manual
Regulatory information
EU
This equipment has been tested and found to comply
with the essential requirements of the following
Directives: 2014/30/EU, 2014/35/EU, 2014/53/EU,
2009/125/EC, 2011/65/EU. This product is in accordance
with Directive 2012/19/EU.
Hereby, Telecommunication Technology LLC declares that
MAG424w3 with the radio equipment type
802.11a/b/g/n/ac + Bluetooth Low Energy is in compliance
with Directive 2014/53/EU.The full text of the EU
declaration of conformity is available at the following
internet address:
www.infomir.eu/eng/support/declarations
This device is certied for indoor deployment only in the
5150-5350 MHz band. Do not install or use this device
outdoors in that frequency in the Europian Union.
FCC Compliance Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment
and receiver.
•Connect the equipment to an outlet on a circuit
dierent from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution:
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received, including
interference that may cause undesired operation.
CAUTION:
Unauthorized antennas, modications, or attachments could
damage the device and violate FCC regulations. Changes or
modications not expressly approved by responsible party
could void the user’s authority to operate the equipment.

Set-Top Box MAG424, MAG424w3. Instruction Manual WarrantyInstruction Manual
Warranty term:
Europe, MEASA and Oceania:
2 years from date of sale (but not more than 2,5
years from manufacture date).
The USA, Americas, Russia, Ukraine and other
regions:
1 year from date of sale (but not more than 1,5
years from manufacture date).
See the date of manufacture at «Product
Information» section. By virtue of the present
Coupon, the absence of defects in manufacturing
of the product and its compounds is warranted for
a year-term counted since date of sale. If during the
mentioned warranty term the defects of materials
or operation of product will be found, the product
would be repaired or its defective parts would be
replaced free of charge in the warranty processing
center with compliance with warranty conditions.
FCC Radiation Exposure Compliance
(only for MAG424w3):
This equipment complies with radio frequency (RF)
exposure limits set forth by the Federal Communications
Commission for an uncontrolled environment. This
equipment should be installed and operated with a
minimum distance of 20 centimeters between the
radiator and your body. This transmitter must not be
co-located or operating in conjunction with any other
antenna or transmitter.
Deployment Statement (only for MAG424w3):
This device is certied for indoor deployment only in the
5150-5250 MHz band. Do not install or use this device
outdoors in that frequency in the United States.
The model MAG424w3 contains FCC ID: 2AATL-6222D-UUB
Note: Specications are subject to change without
notice. Infomir reserves the right to revise this publication
and to make changes in its content from time to time
by posting new specications and other content at
www.infomir.eu

Warranty Processing Centers List:
Europe:
ZLS Services GmbH
Hamburger Allee 56. 60486, Frankfurt am Main, Germany
Tel: [phone]
e-mail: [email protected]om
The USA, Canada and Latin America:
Infomir USA
174 Bay 49th Street. Brooklyn, NY 11214 USA
Tel: [phone]
e-mail: [email protected]
Russia, Belarus:
Tel.: [phone]
e-mail: [email protected]om
MEASA and Oceania:
PROGRESSIVE TECHNOLOGY F.Z.E
Warehouse B1-40. Sheikh Rashid Bin Saeed Al Maktoum
Street
Ajman Free Zone
45573, Ajman, UAE
Tel: [phone]
e-mail: [email protected]om
Ukraine:
Telecommunication Technologies LLC
4/D, Nebesnoi Sotni Avenue. Odesa, 65121, Ukraine
Tel: [phone]
e-mail: [email protected]om
Warranty Service Coupon
(to be lled in by a shop-assistant)
Date of Sale:
Company-Seller:
Address of Company-Seller:
Place of Stamp
I have no claims as to appearance and
package contents. I accept the conditions of
warranty service.
Signature of Customer:
Manufacturer:
Telecommunication Technologies LLC
1 Mytna Square, Odesa, 65026, Ukraine
Warranty processing centersWarranty

Warranty conditions
1. The present warranty is only valid if the defective
product is provided with property lled in Warranty
Service Coupon. If date of sale is not pointed, the
warranty term is counted since date of the product
manufacturing which is dened under serial number.
Warranty processing center reserves the right to
refuse free warranty service and parts replacement
in case the mentioned above documents are
not presented or the lled in it information is not
complete or unreadable.
2. The present warranty does not enable the right for
compensation and cover of loss received as a result
of rearrangement of the product.
3. The present guarantee is invalid if model or serial
number of the product is altered, erased, removed
or unreadable, or warranty seal is broken.
4. The present warranty does not cover the following:
4.1. Any adaptations and alterations with the aim of
perfection and widening of the common scope of
the product application specied in the Manual.
4.2. Devices and accessories not specied in the coupon.
4.3. Damage caused in result of:
a) Improper maintenance including but not limited by following:
(1) use of the product not according to its intended purpose
or Manual;
(2) mounting and maintenance of the product in conditions not
corresponding to safety standards and regulations valid in
the country of use;
(3) incorrect software installation provided by service operator.
b) Repair performed by not authorized service centers or dealers;
c) Accidents, lightning stroke, ood, re, incorrect ventilation;
d) Transporting excluding cases when it is carried out by ASC;
e) Faults of system in which the present product had been using.
5. These warranty conditions do not intend to restrict
or limit in any way statutory rights of customers
which may not be altered in some jurisdictions
and other customers’rights which may arise out
of any agreements with third parties, provided
that nothing contained in such agreements states
or implies that the manufacturer or manufacturer
aliates assume any obligations or liabilities other
than those expressly stipulated in this Warranty
Service Coupon.
While maintaining warranty liabilities on product
repair or replacement, Manufacturer takes no
responsibilities for personal data safety, including
logins, passwords, paid or free subscriptions, settings,
portals, media les, content and software installed or
set up by Customer or other third parties.

Copyrights and Trademarks
Notice of Copyright
Telecommunication Technologies LLC. All rights
reserved. The Information contained herein is the
property of Telecommunication Technologies LLC
(the Company). Not any part hereof can be copied,
reprinted, transferred, retyped, saved in search engine,
modied or translated into any other language,
including computer one, nor sublicensed in any way,
whether electronic, mechanical, magnetic, optical,
chemical, manual or other one, without prior written
consent by the Company Manager responsible for the
Product. Any Illegal use of the materials contained
herein, by any person, will lead the person to the
responsibility for the Company’s damages.
Software Use Agreement
IMPORTANT - read carefully: when using the Software
with your device, you agree thereby with every clauses
of the Software Use Agreement. If you do not agree with
the terms and conditions of the Software Use Agreement,
you should immediately stop using the device and return
it to your services provider completely.
License provision. Limitations
According to this Agreement, Telecommunication
Technologies LLC and your services provider are jointly
to provide you with non-exclusive and non- transferrable
license, without the right to sublicense, for use of all
software and documents with the product only.You
recognize and acknowledge that Telecommunication
Technologies LLC and your services’provider may regularly
renew, change or extend the product software abilities. You
conrm that:
a) You will not take attempts to change, extend, or
decompile, disassembly, or redesign, nor otherwise get
access to the software source code.
b) You will not take attempts to delete or upload the
product software. Any sale or transfer of the product will be
ruled hereby.
Ownership
The Manufacturer and the Manufacturer’s own licensors
keep all the rights constituting ownership, Including patent,
copyright trademark, and other Intel factual property for
the Software; and any Improvement and modication of
the Software. You recognize and acknowledge that the
license according hereof does not grant you ownership for
the Software but only restricted right of use It according to
provisions of this Agreement.
Warranty for the Software
To the maximum extent according to applicable law, the
Company does not make any submission and declines
any and all warranties, whether express or implied, as to
the Software, including, with no limitations, any implied
demand warranties, correspondence to target destination,

abuse of rights of third parties, neither those being result
of interrelations or result of commerce. The Company
does not guarantee the Software will be free of defects
or errors; that any defects or errors will be corrected, or
any function abilities of the Software will meet all your
requirements.
Warranty
Warranty for your product is supplied via your
services’ provider. In the event your product requires
maintenance service, you should contact the services’
supplier directly.
Trademarks
, Infomir, MAG are the trademarks of Infomir
Group. Manufactured under license from Dolby
Laboratories. Dolby, Dolby Audio, and the double-D
symbol are trademarks of Dolby Laboratories.
Redesigning and disassembling is illegal.
Linux® is the registered trademark of Linus Torvalds in the
U.S. and other countries.
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator,
Inc. in the United States and other countries.
Infomir disclaims proprietary interest in the marks
and names of others.
Copyrights and Trademarks Terms of using
Safe and Ecient Using
Device does not contain harmful or hazardous
substances.
Accessories
Use the accessories supplied with your arrangement or
recommended by the manufacturer only. Using of the
accessories which are not supplied or not sanctioned by
the manufacturer may be dangerous for the User or do
harm to the arrangement operation. Using of the not
appropriate accessories eliminates guarantees of the
product therewith.
Water and Moisture
To avoid damage that can cause ignition of the present
product or lesion to the User with electrical current, the
product and its accessories should not be undergone
with any liquids, rain or high moisture.
Do not use the present product in the places where it
may be exposed to the contact with a liquid or vapor.

Specications
Physical Parameters
Model: MAG424, MAG424w3
Weight: 180 g
Dimensions (approximately): 115 mm depth,
115 mm width, 28 mm height
Operation temperature and Humidity
1C - 40; 5% ~ 93%RH
Ethernet Interface
Ethernet Connector: RJ-45
Speed: Auto-choice, 10/100 Mbit/s
Indicators: Green – Activity, Yellow – Connection
Wi-Fi Interface
Built-in Wi-Fi Dual-band a/b/g/n/ac 2x2 MIMO (only
MAG424w3). Operating frequency bands:
802.11 b/g/n 2400-2483.5 MHz, 802.11 a/n/ac 5150-5350,
5470-5725, 5725-5850 MHz
Output power (E.I.R.P.):
IEEE 802.11 b/g/n/ac <20 dBm (100mW),
IEEE 802.11 a <23 dBm (200mW)
Internal Antenna gain (max):
3,68 dBi (5GHz), 2,66 dBi (2.4GHz)
Bluetooth Interface
Bluetooth 4.2 (only MAG424w3) Operating
frequency bands: 2400-2483.5 MHz
Output power (E.I.R.P.) <20 dBm (100 mW)
Internal Antenna gain (max): 3,38 dBi
HDMI Interface
Type: HDMI 2.0
USB Interface
Type: USB 2.0, USB 3.0
S/PDIF Interface (optional)
Type: TOSLINK (optical)
Supported Audio-Video Formats
Video codecs: MPEG1/2 MP@HL, MPEG4 part 2 (ASP),
H.265 Main/Main [email protected] High 2160p@60 fps (optional),
H.264 AVC [email protected] 2160p@30 fps, XviD, 3D video support
Video containers: TS, MTS, AVI, MPEG, MP4, MOV, MKV, M2TS,
VOB, 3GP
Audio codecs: MPEG L1/L2/L3, AAC-LC, HE AAC V1/V2, APE, FLAC
This product supports Dolby Digital PlusTM
Supported video modes: PAL, NTSC, 576p, 720p, 1080p,
1080i, 2160p
Subtitles: DVB, PGS, SRT, SSA/ASS, SUB, Teletext subs,
WebVtt, Closed caption
Audio-Video Interfaces (optional)
Audi Connectors: TRRS (On adapter cable:
White=Left channel, Red=Right channel)

Product Care
Maintenance of Product
The product should not be disassembled. The tries of the
disassembling of the product may be dangerous for your
life and for serviceability of the product.
The self-supporting disassembling invalidates you the
product guarantee.
The maintenance should be aected by qualied specialists
in the warranty processing centers only.
The product possesses protective sealing.
Breaking or changing of the mentioned sealing invalidates
guarantee of the product.
Cleaning
The product and accessories should be rubbed with dry
cloth or tissue only.
To ensure safety, before shell cleaning switch the power
supply o the alternative current socket.
The shell may be cleaned from persistent spots with a
slightly wet cloth or cleaning tissue.
Do not use cleaner or polish, benzyl, solvents, abrasive
items, liquid or aerosol detergent means for the product
and accessories cleaning.
Output: 2 V RMS
Nominal load: 10K
Composite Video Interface: TRRS (Yellow connector on
adapter cable).
Output: 1Vp-p
Power supply Interface
Connector: DC cylindrical 2.1 mm x 5.5 mm
Type: center plus
Input: 12 V±10%
Power consumption: less than 10W in typical conditions
External Power Supply Unit
Type: Pulse with universal inlet
Input: 110-240 V AC, 50-60Hz, 0.5A max
Output: 12 V DC, 1A, 12 W
Average active eciency: 83% (min)
Eciency at low load (10%): 79.54% (min)
No-load power consumption: < 0.1W
Package
Type: cardboard box
Dimensions (approx.): 214 mm width, 119 mm depth,
57 mm height
Shipping weight: 517 g

The Product Unpacking and Installation
Aer the product extraction out of the package it is
necessary to handle it with care, do not drop, shake it
and aord other inuence. The product is designed for
horizontal allocation onto at surface.
Do not place the product onto slippery surface, in place
where it may be exposed to vibration or hazard to drop
and other possible risks to the product to be damaged
which may cause invalidation the product guarantee.
Do not dispose the product onto so surface like on the
carpet, bed, etc., for such surfaces cease access to the
ventilation openings and complicate air ow that may
cause the product overheating and invalidate guarantee
in result.
Do not locate the product into the furniture in case of
vacant clearance around the product is not provided for
the suicient product ventilation.
Do not place the product in place where it may be
exposed to inuence of direct sunlight, next to the sources
of open re and convectors.
Do not dispose the product on surfaces which in operating
process may get warm, for instance, video record player or
intensier and do not put anything on the top of the shell
as well. Do not cover the product with anything.
Containing liquids objects, such as vase, plant pot are
not to be placed next to or on the product. Do not touch
or move the product during its operation. Switch o the
product if you need to shi it.
The product is intended for use indoors.
The power supply cord is to be put to prevent its
deformation and jamming and touching it well. The
power supply cord is not to be laid under the carpets or
blocked with anything where any damage may not be
noticed.
For AC/DC Adapter, the socket outlet must be near the
equipment and shall be easily accessible.
Power supply unit
The product should be used with power supply unit
provided by the manufacturer only.
The power supply unit is tted out with plug which is
intended for connecting to socket in your country usage.
In case of the necessity in the product connecting in other
country or in the region with other data of electric circuit
the power supply unit adopted for use in the specied
area should be received from the manufacturer.
Operation
The outer power supply unit of the product is getting
warm in operation. In case of outer power supply unit
gets hot, switch o promptly and get in touch with the
equipment supplier for its replacement.

Protection from atmospheric electricity or not using for
a long time
On coming the thunderstorm and also in case of the
product is intended to be in no use for a long time,
disconnect the power supply cord out of socket, switch o
Ethernet, video and audio cables. It is to protect the product
from thunder discharges and power surges in the circuit.
Usage with Plasma Displays
In the product usage for watching with plasma screens do
not pause the picture for more than 5 minutes, otherwise
it with other objects as may cause ‘burn-out’ pixels on the
screen. It is not considered as a defect of the product but
peculiarity of plasma screens structure. The producer does
not bear the responsibility for damages had been caused
in such manner.
The Arrangement Designation
The product is intended to select digital audio & video
channels from transport streams, decode and display
them on TV. Any other use is prohibited. It means
Telecommunication Technologies LLC insists on the product
usage in entirely accordant to the law of copyright.
The compliance with the specied laws leaves on
conscience of the user. The unauthorized copying of the
protected materials or spreading of the specied copies
under denite conditions may violate the law of copyright
and is to be previously adopted by possessor of the rights
for the further commercial use.
Updating Soware
The product possesses the capability of automatic
soware updating. The manufacturer and your services
provider reserve the right for automatic soware
updating to improve the product functional capability.
During the soware updating the product should not be
used for watching and switched o until the complete
soware updating. During the soware updating the
product switching o is inadmissible. The updating takes
several minutes and since then you are able to continue
enjoy on all delights of digital television services.

1. Fn - Reset to factory settings/
select the boot mode
2. USB 2.0, 3.0
3. LED
4. Power On/Standby
1. S/PDIF*
2. RCA 3,5 mm jack*
3. MicroSD
4. HDMI
5. Ethernet LAN Port
6. Power Supply
Front Panel
Back Panel
About your MAG424, MAG424w3
*
*
* Optional, may not be available on your device

Connecting with HDMI – best quality
Connecting with AUDIO/VIDEO Input – good quality
1. Red
2. White
3. Yellow
Connecting to MAG424, MAG424w3
*
*
*
*
* Optional, may not be available on your device
Warning! Switch o all the devices (TV, amplier, etc.) and take the power supply unit out of the socket
before connecting or disconnecting any cable. If the amplier is not connected leave digital audio
outputs disconnected.

Using Remote Control to control the Device
This section explains how to unpack Remote Control
(RC) and prepare it for work. Your service provider can
supply the product with an alternative RC. In that case
please refer to the manual supplied by your service
provider. Remote Control requires two batteries type
AAA, R03, LR03, UM-4, 286. Important information about
using batteries. Do not mix dierent types of battery or
old and new batteries.Do not use rechargeable batteries
with the remote control. Remove the batteries from the
remote control if you are not going to use it for several
weeks, to avoid the risk of leakage. Please respect your
environment and any local regulations and dispose of
old batteries in a responsible manner.
Caution! Do not attempt to recharge the
batteries.Immediately remove any leaking
batteries. Take care when handling leaking
batteries as they may cause burns to the skin
or eyes, or other physical injuries.
Introduction to the Programmable
Remote Control Unit (optional)
The MAG424, MAG424w3 package includes a remote
control with a block of ve programmable buttons
(marked with blue print colour). You may want to choose
these buttons for controlling other devices (your TV set or
amplier). To program the buttons, do the following:
1. Place infrared LEDs of both Remote Controls (STB RC and TV
RC) opposite each other at a maximum distance of 5 cm.
2. On the STB RC, press the‘Red’and ‘Blue’buttons of ‘Addi-
tional functions’at the same time and hold them together
for 3 seconds. Access to the setup is conrmed when the
visual LEDs under‘TV power’button (Green) and ‘STB power’
button (Red) turn ON and remain ON.
3. On the STB RC, press the button that will store the copied
data, the LED under‘STB power’button will blink once and
remains ON, to indicate selection of allowed button.
4. On the TV RC, press the button, whose function you wish
to copy to the STB remote. Hold the button until the LED un-
der the‘TV Power’button (Green) on STB RC blinks twice to
indicate successful operation. Both visual LEDs remain ON.
5. The STB R will continue in the copying setup mode and
will wait for the user’s input to other STB remote buttons
according to steps 3 and 4.
6. To nish the copying process, press the‘OK’button on the
STB RC. Both LEDs will double blink and turn OFF.
Reset
Make sure RC is in idle mode (no IR-transmission or visual
activity). Press‘SETUP’and ‘OK’ buttons at the same time and
hold up (about 2 seconds) until the visual LEDs under‘TV
Power’button (Green) and‘STB Power’button (Red) turn ON.
Then, release both pressed buttons – the LEDs will turn OFF in
1 second. Reset is done.

RCU
Home
TV Power*
Quick access to‘IPTV
channels’ section
Mute*
A/VTV
TV
APP
789
456
123
0
PIP
OK
EPG
AV*
V P
STB Power
Refresh
Rewing
Electronic Program
Guide
Fast Forward
Keyboard
TV
V
APP
OK
EPG
P
PIP
Resize
Volume*
* buttons allowed to store copied data

Product information
Product:
Serial Number:
MAC:
The set includes the following:
Set-Top Box
External Power Supply 12V
IR Remote Control
AAA batteries
Instruction manual
Package box
- 1 pcs.
- 1 pcs.
- 1 pcs.
- 2 pcs.
- 1 pcs.
- 1 pcs.
Optionally the set may include the following:
3,5 mm Jack to 3 RCA cable
LAN network cable
HDMI cable length less than 3 m
- 1 pcs.
- 1 pcs.
- 1 pcs.
970562
