XTRONIC DFX-300 User manual

- 1 -
PRODUCT SPECIFICATIONS
Model XTR-DFX-300
Dimensions (assembled) 15.25” L x 10.0” W x 17.5” H
Weight 15.5 lbs
Working Environment 32°F ~ 104°F / 0°C ~ 40°C
Storing Environment -4°F ~ 176°F / -20°C ~ 80°C
Storage Humidity 35% - 45%
Maximum Air Speed 5 m/s
Particulate Matter Rating >3 Microns
Silicone Work Mat Dimensions 15.625” L x 15.25” W
Cord Length 52 in
PACKAGE CONTENTS
• Main Power Unit
• High Efficiency Fiber Filters (4) (installed)
• Large Format Silicone Work Mat
• Multi-directional Fans (4) (installed)
• Anti-static Grounding Alligator Clip
• Lint Roller

- 2 -
SAFETY PRECAUTIONS
1. Always use a grounded outlet for the unit.
2. Always turn the power off and unplug the unit when not in use.
3. Do not use the unit for any application other than its intended use.
4. Do not modify the unit in any way.
5. When replacing consumable parts, only use approved
manufacturer parts.
6. Do not get the unit wet or use when your hands are wet.

- 3 -
USER INTERFACE
1
2
3
5
4
67
1. Unit Top Cover
2. Dual Light System Controls
3. Protective Glass Shield
4. Slip Resistant Feet
5. Silicone Work Mat
6. Dual Air Flow Volume Control Knobs
7. Unit Back Cover (not shown)
BACK OF UNIT
1
2
3
1. Power Cord Socket
2. Fuse
3. Power Switch

- 4 -
SET-UP
1. Place the anti-static mat on the bottom of the unit.
2. Carefully clean the work area with the included lint roller or cloth
that doesn’t collect particles.
3. Plug the anti-static grounding alligator clip into the back of the main
unit.
4. Plug the 3-Prong AC cord into a 110/120v grounded outlet to
prevent electric shock or injury.
5. Turn on the power switch located on the back of the main unit.
6. Turn the adjustable air output knobs to a medium setting and let
the unit run for 5-10 minutes to ensure all dust has been cleared
from the work area.
7. Clip the anti-static grounding alligator clip onto the device being
repaired to ensure there is no static build up while the work is
performed.

- 5 -
OPERATING INSTRUCTIONS
1. Vacuum the high efficiency fiber filters on the back and top of the
unit without removing them. This will help ensure dust doesn’t get
into the unit when cleaning the other filters.
2. Reaching inside the work area, vacuum the high efficiency fiber
filters that cover the fans (top and back) to remove any debris that
could hinder efficient air flow.
3. Clean the work area (including the silicone mat) with the dust
removal roller and/or any other anti-static cleaning tools.
Note: If the unit is not cleaned regularly dust will swirl around the work
area.
This unit has two sets of air flow fans. The set of fans on the top of the
unit pulls air flow into the workspace, the second set of fans on the back
of the unit pulls air out the back of the unit. Each of these set of fans can
be controlled independently, allowing you to optimize it for the type of
work being done.
4. Once all dust has been removed from the area and unit, the fans
can be turned on using the Air Adjust knobs on the left side of the
unit.
Note: It is not necessary to run the fans at max power the entire time.
Running the fans at max power will decrease the life of the fan
motors and a higher speed can cause dust to swirl around the
work area. A slower fan speed can help to ensure dust is moved

- 6 -
away and not swirled around the work area, while increasing the
life of the fan motors.
This device comes with two lighting options. 1) Work Lights - bright
LEDs that ensure the work area is brightly lit for a clear crisp view of the
device and 2) Dust Detection Lights - Green LEDs that allow for easy
dust detection while working to ensure no dust gets inside of the device
being repaired. Both lights are adjustable for user preference and work
situation.
5. The dual lighting system is activated with the switches on the right
side of the unit. Each light can be operated independently. The
light intensity can be adjusted using the Light Adjustment knobs.
6. Power the fans on to a medium setting and let them run for 5 -10
minutes to ensure that there is no dust or other particles left in the
work area.

- 7 -
MAINTENANCE
MAIN UNIT
• Keep the main unit turned off and unplugged when not in use.
• Use a damp cloth to clean the unit as needed.
FIBER FILTERS
• This unit uses 4 high efficiency fiber filters. These filters are found
attached to the unit covers on the top and back and under the fans
inside the unit.
• The fiber filters can be vacuumed on a regular basis to remove
dust.
• If the fiber filters require more than vacuuming will provide, they
can be removed and washed with warm water. They will need to
dry fully before being placed back in the unit.
REPLACING THE FUSE
Fuse
Extra Fuse
Compartment
Fuse Clip
Fuse
Compartment
1. Unplug the power cord from the outlet.
2. Remove the fuse compartment by pressing a flat head screwdriver
into the divot just inside the power socket under the fuse
compartment.
3. The fuse that is in use will be in the fuse clip, the extra fuse is
below it. If the fuse is damaged, replace it with the new fuse.
4. Insert the fuse compartment back into the unit.
