OPERATING MANUAL
ba77145e02 12/2017
Lab 865
pH METER
Lab 865
M
CAL
STO
AR
RCL
F1 F2
ENTER

2ba77145e02 12/2017
Lab 865
Copyright © 2017 Xylem Analytics Germany GmbH
Printed in Germany.
For the most recent version of the manual, please visit
www.si-analytics.com.

Lab 865 - Contents
Lab 865 Contents
ba77145e02 12/2017 3
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 Lab 865 meter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1.1 Safety information in the operating manual . . . . . . . . . . . . 7
2.1.2 Safety signs on the meter . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1.3 Further documents providing safety information . . . . . . . . 7
2.2 Safe operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2.1 Authorized use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2.2 Requirements for safe operation . . . . . . . . . . . . . . . . . . . . 8
2.2.3 Unauthorized use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3 Initial commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3.1 Inserting the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.3.2 Connecting the power pack . . . . . . . . . . . . . . . . . . . . . . . 11
3.3.3 Mounting the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 General operating principles . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.1 Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.2 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1.3 Status information (meter) . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1.4 Socket field . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2 Switching on the meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3 Switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4 Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4.1 Measured value display . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4.2 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4.3 Menus and dialogs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.4.4 Elements in menus and dialogs. . . . . . . . . . . . . . . . . . . . 16
4.4.5 Example 1 on navigation: Setting the language . . . . . . . 17
4.4.6 Example 2 on navigation: Setting the date and time . . . . 19
5 pH value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.1 Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Contents Lab 865
4 ba77145e02 12/2017
5.1.1 Measuring the pH value . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.1.2 Measuring the temperature . . . . . . . . . . . . . . . . . . . . . . 23
5.2 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.2.1 Why calibrate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.2.2 When do you have to calibrate? . . . . . . . . . . . . . . . . . . . 24
5.2.3 Automatic calibration (AutoCal) . . . . . . . . . . . . . . . . . . . 24
5.2.4 Manual calibration (ConCal) . . . . . . . . . . . . . . . . . . . . . . 27
5.2.5 Calibration points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2.6 Calibration data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2.7 Continuous measurement control (CMC function) . . 33
6 ORP voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.1 Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.1.1 Measuring the ORP . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.1.2 Measuring the temperature . . . . . . . . . . . . . . . . . . . . . . 36
6.2 ORP calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.1 Measurement settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.1.1 Changing the settings for pH measurements . . . . . . . . . 37
7.1.2 Buffer sets for calibration . . . . . . . . . . . . . . . . . . . . . . . . 38
7.1.3 Calibration interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.2 Settings for ORP measurements . . . . . . . . . . . . . . . . . . . . . . . 41
7.3 Sensor-independent settings . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.3.1 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.3.2 Data storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.4 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.4.1 Resetting the measurement settings . . . . . . . . . . . . . . . 43
7.4.2 Resetting the system settings. . . . . . . . . . . . . . . . . . . . . 44
8 Data storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1 Manual storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.2 Automatic storage at intervals . . . . . . . . . . . . . . . . . . . . . . 46
8.3 Measurement data storage . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.1 Editing the measured value storage . . . . . . . . . . . . . . . . 48
8.3.2 Erasing the measurement data storage . . . . . . . . . . . . . 50
8.3.3 Measurement dataset. . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8.3.4 Storage locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
9 Transmitting data (USB interface). . . . . . . . . . . . . . . . . . . . . 51
9.1 Options for data transmission . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.2 Connecting a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
9.3 MultiLab Importer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
10 Maintenance, cleaning, disposal. . . . . . . . . . . . . . . . . . . . . . 53
10.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
10.1.1 General maintenance activities . . . . . . . . . . . . . . . . . . . 53

Lab 865 Contents
ba77145e02 12/2017 5
10.1.2 Replacing the batteries. . . . . . . . . . . . . . . . . . . . . . . . . . 53
10.2 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
10.3 Packing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
10.4 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
11 What to do if.... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
11.1 pH/ORP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
11.2 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
12 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
12.1 Measuring ranges, resolution, accuracy . . . . . . . . . . . . . . . . . 58
12.2 General data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
13 Firmware update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
14 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
15 Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Overview Lab 865
6 ba77145e02 12/2017
1 Overview
1.1 Lab 865 meter
The compact Lab 865 precision pH meter enables you to perform pH measure-
ments rapidly and reliably.
The Lab 865 provides the maximum degree of operating comfort, reliability and
measuring certainty for all applications.
The USB interface can be used for data transmission to a PC and for software
updates of the meter.
1.2 Sensors
A measuring system ready to measure consists of the Lab 865 meter and a
suitable sensor.
Suitable sensors are pH electrodes and ORP electrodes.
1 Keypad
2 Display
3 Socket field
Lab 865
M
CAL
STO
AR
RCL
F1 F2
ENTER
1
2
3

Lab 865 Safety
ba77145e02 12/2017 7
2 Safety
2.1 Safety information
2.1.1 Safety information in the operating manual
This operating manual provides important information on the safe operation of
the meter. Read this operating manual thoroughly and make yourself familiar
with the meter before putting it into operation or working with it. The operating
manual must be kept in the vicinity of the meter so you can always find the infor-
mation you need.
Important safety instructions are highlighted in this operating manual. They are
indicated by the warning symbol (triangle) in the left column. The signal word
(e.g. "CAUTION") indicates the level of danger:
NOTE
indicates a possibly dangerous situation where goods might be damaged
if the actions mentioned are not taken.
2.1.2 Safety signs on the meter
Note all labels, information signs and safety symbols on the meter and in the
battery compartment. A warning symbol (triangle) without text refers to safety
information in this operating manual.
2.1.3 Further documents providing safety information
The following documents provide additional information, which you should
observe for your safety when working with the measuring system:
• Operating manualsof sensors and other accessories
• Safety datasheets of calibration or maintenance accessories (such as buffer
solutions, electrolyte solutions, etc.)
WARNING
indicates a possibly dangerous situation that can lead to seri-
ous (irreversible) injury or death if the safety instruction is not
followed.
CAUTION
indicates a possibly dangerous situation that can lead to
slight (reversible) injury if the safety instruction is not fol-
lowed.

Safety Lab 865
8 ba77145e02 12/2017
2.2 Safe operation
2.2.1 Authorized use
This meter is authorized exclusively for pH and ORP measurements in the
laboratory.
Only the operation and running of the meter according to the instructions and
technical specifications given in this operating manual is authorized (see
section 12 TECHNICAL DATA, page 58).
Any other use is considered unauthorized.
2.2.2 Requirements for safe operation
Note the following points for safe operation:
• The meter may only be operated according to the authorized use specified
above.
• The meter may only be supplied with power by the energy sources
mentioned in this operating manual.
• The meter may only be operated under the environmental conditions
mentioned in this operating manual.
• The meter may only be opened if this is explicitly described in this operating
manual (example: Inserting the batteries).
2.2.3 Unauthorized use
The meter must not be put into operation if:
• it is visibly damaged (e.g. after being transported)
• it was stored under adverse conditions for a lengthy period of time (storing
conditions, see section 12 TECHNICAL DATA, page 58).

Lab 865 Commissioning
ba77145e02 12/2017 9
3 Commissioning
3.1 Scope of delivery
pH meter Lab 865
4 batteries 1.5 V Mignon type AA
Power pack
USB cable
Stand
Stand holder
Comprehensive operating manual
Short instructions
CD-ROM with
– USB drivers
– comprehensive operating manual
– software MultiLab Importer
3.2 Power supply
The Lab 865 is supplied with power in the following ways:
Mains operation with the supplied power pack
Battery operation (4 x alkaline manganese batteries, type AA)
USB operation via a connected USB-B cable
3.3 Initial commissioning
Perform the following activities:
Insert the supplied batteries
For mains operation: Connect the power pack
If necessary, mount a stand
Switch on the meter (see section 4.2 SWITCHING ON THE METER, page 14)
Set the date and time (see section 4.4.6 EXAMPLE 2 ON NAVIGATION: SETTING
THE DATE AND TIME, page 19)

Commissioning Lab 865
10 ba77145e02 12/2017
3.3.1 Inserting the batteries
You can operate the meter either with normal batteries or with
rechargeable batteries (Ni-MH). In order to charge the batteries, an
external charging device is required.
1 Battery compartment
1. Open the battery compartment (1) on the underside of the meter.
CAUTION
Make sure that the poles of the batteries are positioned cor-
rectly.
The ±-signs on the batteries must correspond to the ± signs in
the battery compartment.
2. Place four batteries (type Mignon AA) in the battery compartment.
3. Close the battery compartment (1).
4. Set the date and time
(see section 4.4.6 EXAMPLE 2 ON NAVIGATION: SETTING THE DATE AND
TIME, page 19).
1

Lab 865 Commissioning
ba77145e02 12/2017 11
3.3.2 Connecting the power pack
3.3.3 Mounting the stand
The stand base can be mounted at the right side of the meter.
CAUTION
The line voltage at the operating site must lie within the input
voltage range of the original power pack (see section 12 TECH-
NICAL DATA, page 58).
CAUTION
Use original power packs only (see section 12 TECHNICAL DATA,
page 58).
1. Connect the plug of the power pack to the socket for the power pack on
the Lab 865.
2. Connect the original power pack to an easily accessible power outlet.
Lab865
M
CAL
STO
AR
RCL
F1 F2
ENTER
1
2

Operation Lab 865
12 ba77145e02 12/2017
4Operation
4.1 General operating principles
4.1.1 Keypad
In this operating manual, keys are indicated by brackets <..> .
The key symbol (e.g. <ENTER>) generally indicates a short keystroke (under
2sec) in this operating manual. A long keystroke (approx. 2 sec) is indicated
by the underscore behind the key symbol (e.g. <ENTER__>).
<F1>:
<F1__>:
<F2>:
<F2__>:
Softkeys providing situation dependent functions, e.g.:
<F1>/[Menu]: Opens the menu for measurement settings
<F1__>/[Menu]: Opens the menu for system settings
<On/Off>:Switches the meter on or off
<M>:Selects the measured parameter / Quits the settings
<CAL>:
<CAL__>:
Calls up the calibration procedure
Displays the calibration data
<STO>:
<STO__>:
Saves a measured value manually
Opens the menu for the automatic save function
<RCL>:
<RCL__>:
Displays the manually stored measured values
Displays the automatically stored measured values
<><>:
<__><__>:
Menu control, navigation
Increments, decrements values
Increments, decrements values continuously
<ENTER>:
<ENTER__>:
Opens the menu for measurement settings / confirms
entries
Opens the menu for system settings
<AR> Freezes the measured value (HOLD function)
Switches the AutoRead measurement on or off
F1
F2
STOSTO
RCL
ARAR

Lab 865 Operation
ba77145e02 12/2017 13
4.1.2 Display
4.1.3 Status information (meter)
1 Status information (sensor)
2 Measured value (with unit)
3 Measured parameter
4 Continuous measurement control (CMC function)
5 Sensor symbol (calibration evaluation, calibration interval)
6 Measured temperature (with unit)
7 Status information (meter)
8 Softkeys and date + time
AR Stability control (AutoRead) is active
HOLD Measured value is frozen (<AR> key)
Batteries are almost empty
HOLD AR
25.0
6.093
pH
°C
4
3
2
5
6
7
8
1
AutoCal
01.02.2014
08:00
Menu USB output

Operation Lab 865
14 ba77145e02 12/2017
4.1.4 Socket field
4.2 Switching on the meter
1 pH electrode
2 Reference electrode
3 Temperature sensor
4 Mini USB-B interface
5 Power pack
6 Service interface
CAUTION
Only connect sensors to the meter that cannot return any volt-
ages or currents that are not allowed (> SELV and > current
circuit with current limiting).
Almost all customary sensors meet these requirements.
1. Press the <On/Off> key.
The meter performs a self-test.
The display shows the manufacturer's logo while the self-test is being
performed.
The measured value display appears.
123456
pH
6.949
25.0 °C
01.02.2014
08:00
Menu USB output

Lab 865 Operation
ba77145e02 12/2017 15
4.3 Switching off
Automatic switch-off
function
The instrument has an automatic switch-off function in order to save the
batteries (see section 7.3.1 SYSTEM, page 42). The automatic switchoff
switches off the measuring instrument if no key is pressed for an adjustable
period.
The automatic switchoff is not active
if the communication cable is connected
if the Automatic data storage function is active, or with automatic data trans-
mission
if the power pack is connected
Display illumination The meter automatically switches off the display illumination if no key is
pressed for 30 seconds. The illumination is switched on with the next keystroke
again.
You can also generally switch the display illumination on or off (see section
7.3.1 SYSTEM, page 42).
4.4 Navigation
The principles of navigation in menus and dialogs are explained in the following
sections.
4.4.1 Measured value display
In the measured value display, open the setting menus with the <F1> softkey.
The current functions of the softkeys are shown on the display.
Use <F1>/[Menu] (short pressure) to open the menu for calibration and
measurement settings for the displayed measured parameter.
Use <F1__>/[Menu] (long pressure (approx. 2 s) to open the Storage & con-
fig menu with the sensor-independent settings.
Use the keys of the keypad to carry out further functions such as storage or cali-
bration (see section 4.1.1 KEYPAD, page 12). These functions are not available
in other operating situations.
4.4.2 Operating modes
The meter has the following operating modes:
1. Press the <On/Off> key.

Operation Lab 865
16 ba77145e02 12/2017
4.4.3 Menus and dialogs
The menus for settings and dialogs in procedures contain further subelements.
To select a subelement, use the <><>keys. The current selection is dis-
played with a frame.
To make further settings, switch to the next higher menu level with
<F1>[Back].
Use <M> to return to the measured value display.
4.4.4 Elements in menus and dialogs
Submenus
The name of the submenu is displayed at the upper edge of the frame. Sub-
menus are opened by confirming with <ENTER>. Example:
Settings
Settings are indicated by a colon. The current setting is displayed on the
right-hand side. The setting mode is opened with <ENTER>. Subsequently,
the setting can be changed with <><>and <ENTER>. Example:
Operating
mode
Description
Measuring The measurement data of the connected sensor are shown
in the measured value display
Calibration The course of a calibration with calibration information, func-
tions and settings is displayed
Storage in
memory
The meter stores measuring data automatically or manually
Transmit-
ting data
The meter transmits measurement data and calibration
records to the USB interface automatically or manually.
Setting The system menu or a sensor menu with submenus, set-
tings and functions is displayed
General
Interface
Clock
Service information
Reset
System
01.02.2014
08:00
Back

Lab 865 Operation
ba77145e02 12/2017 17
Functions
Functions are designated by the name of the function. They are immediately
carried out by confirming with <ENTER>.
Example: Display the Calibration record function.
Messages
Information is marked by the i symbol. It cannot be selected. Example:
4.4.5 Example 1 on navigation: Setting the language
1. Press the <On/Off> key.
The measured value display appears.
The instrument is in the measuring mode.
Language: English
Beep:Off
Illumination:On
Contrast:50 %
Switchoff time:1 h
General
01.02.2014
08:00
Back
Calibration record
Calibration data storage
Buffer:
One point calibration:Yes
Calibration interval:7 d
Unit for slope:mV/pH
[
i ]
pH
01.02.2014
08:00
Back
Calibration record
Calibration storage
Buffer:
One point calibration:Yes
Calibration interval:7 d
Unit for slope:mV/pH
[
i ]
pH
01.02.2014
08:00
Back

Operation Lab 865
18 ba77145e02 12/2017
2. Using <F1__>/[Menu], open the Storage & config menu.
The instrument is in the setting mode.
3. Select the System submenu with <><>.
The current selection is displayed with a frame.
4. Open the System submenu with <ENTER>.
5. Select the General submenu with <><>.
The current selection is displayed with a frame.
6. Open the General submenu with <ENTER>.
pH
6.949
25.0 °C
01.02.2014
08:00
Menu USB output
System
Data storage
Storage & config
01.02.2014
08:00
Back
General
Interface
Clock
Service information
Reset
System
01.02.2014
08:00
Back

Lab 865 Operation
ba77145e02 12/2017 19
4.4.6 Example 2 on navigation: Setting the date and time
The measuring instrument has a clock with a date function. The date and time
are shown in the measured value display.
When storing measured values and calibrating, the current date and time are
automatically stored as well.
The correct setting of the date and time and date format is important for the fol-
lowing functions and displays:
Current date and time
Calibration date
Identification of stored measured values.
Therefore, check the time at regular intervals.
7. Open the setting mode for the Language with <ENTER>.
8. Select the required language with <><>.
9. Confirm the setting with <ENTER>.
The meter switches to the measuring mode.
The selected language is active.
After a fall of the supply voltage (empty batteries), the date and time
are reset.
Language: English
Beep:Off
Illumination:On
Contrast:50 %
Switchoff time:1 h
General
01.02.2014
08:00
Back
Language: English
Beep:Off
Illumination:On
Contrast:50 %
Switchoff time:1 h
General
01.02.2014
08:00
Back

Operation Lab 865
20 ba77145e02 12/2017
The date format can be switched from the display of day, month, year
(dd.mm.yyyy) to the display of month, day, year (mm/dd/yyyy or mm.dd.yyyy).
1. In the measured value display:
Using <F1__>/[Menu], open the Storage & config menu.
The instrument is in the setting mode.
2. Select and confirm the System / Clock menu with <><>and
<ENTER>.
The setting menu for the date and time opens up.
3. Select and confirm the Time menu with <><>and <ENTER>.
The hours are highlighted.
4. Change and confirm the setting with <><>and <ENTER>.
The minutes are highlighted.
5. Change and confirm the setting with <><>and <ENTER>.
The seconds are highlighted.
6. Change and confirm the setting with <><>and <ENTER>.
The time is set.
7. If necessary, set the Date and Date format. The setting is made similarly
to that of the time.
8. To make further settings, switch to the next higher menu level with
[Back]<F1>.
or
Switch to the measured value display with <M>.
The instrument is in the measuring mode.
Date format:dd.mm.yyyy
Date:01.02.2014
Time:08:00:25
Clock
01.02.2014
08:00
Back
