Xylem YSI MultiLab 4010P-1 User manual

OPERATIONS MANUAL
ba76141e03 03/2014
MultiLab 4010(P)-1
DIGITAL METER FOR IDS SENSORS (PH/ORP/D.O./COND)
4010P-1
4010-1
4010-1
Printermodul
4010P-1

2ba76141e03 03/2014
MultiLab 4010-1
For the most recent version of the manual, please visit www.ysi.com.
Contact YSI
1725 Brannum Lane
Yellow Springs, OH 45387 USA
Tel: [phone]
800-765-4974
Email: environme[email protected]
Internet: www.ysi.com
Copyright ©2014 Xylem Inc.

MultiLab 4010-1 - Contents
MultiLab 4010-1 Contents
ba76141e03 03/2014 3
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 MultiLab 4010-1 meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 MultiLab 4010P-1 meter with integrated printer . . . . . . . . . . . . . 8
1.3 Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3.1 IDS sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3.2 Automatic sensor recognition . . . . . . . . . . . . . . . . . . . . . . 9
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.1 Safety information in the operating manual . . . . . . . . . . . 11
2.1.2 Safety signs on the meter . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.3 Further documents providing safety information . . . . . . . 11
2.2 Safe operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.1 Authorized use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.2 Requirements for safe operation . . . . . . . . . . . . . . . . . . . 12
2.2.3 Unauthorized use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3 Initial commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3.1 Inserting the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.3.2 Connecting the power pack . . . . . . . . . . . . . . . . . . . . . . . 15
3.3.3 Mounting the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1 General operating principles . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.1 Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.2 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1.3 Status information (meter) . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1.4 Instrument connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.1.5 Sensor info. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.2 Switching on the meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.3 Switching off the meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.4 Login with a user name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.5 Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.5.1 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.5.2 Measured value display . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.5.3 Menus and dialogs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.5.4 Example 1 on navigation: Setting the language . . . . . . . 24

Contents MultiLab 4010-1
4ba76141e03 03/2014
4.5.5 Example 2 on navigation: Setting the date and time . . . 26
5 pH value. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.1 Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.1.1 Measuring the pH value . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.1.2 Measuring the temperature . . . . . . . . . . . . . . . . . . . . . . 29
5.2 pH calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2.1 Why calibrate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2.2 When do you have to calibrate? . . . . . . . . . . . . . . . . . . . 30
5.2.3 Carrying out automatic calibration (AutoCal) . . . . . . . . . 30
5.2.4 Carrying out manual calibration (ConCal) . . . . . . . . . . . 33
5.2.5 Calibration points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.2.6 Calibration data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.2.7 Continuous measurement control (CMC function) . . 39
5.2.8 QSC function (sensor quality control) . . . . . . . . . . . . 40
6 ORP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.1 Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.1.1 Measuring the ORP . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.2 ORP calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7 Dissolved oxygen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7.1 Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7.1.1 Measuring D.O. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7.1.2 Measuring the temperature . . . . . . . . . . . . . . . . . . . . . . 47
7.2 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
7.2.1 Why calibrate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
7.2.2 When to calibrate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
7.2.3 Calibration procedures . . . . . . . . . . . . . . . . . . . . . . . . . . 47
7.2.4 1-point calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.2.5 2-point calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
7.2.6 Calibration data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
8 Conductivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
8.1 Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
8.1.1 Measuring the conductivity . . . . . . . . . . . . . . . . . . . . . . . 53
8.1.2 Measuring the temperature . . . . . . . . . . . . . . . . . . . . . . 55
8.2 Temperature compensation. . . . . . . . . . . . . . . . . . . . . . . . . . . 55
8.3 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
8.3.1 Why calibrate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
8.3.2 When to calibrate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
8.3.3 Determining the cell constant
(calibration in control standard) . . . . . . . . . . . . . . . . . 56
8.3.4 Calibration data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.1 pH measurement settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.1.1 Settings for pH measurements . . . . . . . . . . . . . . . . . . . . 59
9.1.2 Buffer sets for calibration . . . . . . . . . . . . . . . . . . . . . . . . 60
9.1.3 Calibration interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
9.2 ORP measurement settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 63

MultiLab 4010-1 Contents
ba76141e03 03/2014 5
9.2.1 Settings for ORP measurements . . . . . . . . . . . . . . . . . . 63
9.3 D.O. measurement settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
9.3.1 Settings for D.O. sensors
(menu for measurement and calibration settings) . . . . . 63
9.3.2 Enter Sensor cap coefficients. . . . . . . . . . . . . . . . . . . . . 65
9.3.3 DO % Saturation local . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9.4 Cond measurement settings . . . . . . . . . . . . . . . . . . . . . . . . . . 66
9.4.1 Settings for IDS conductivity sensors . . . . . . . . . . . . . . . 66
9.5 Sensor-independent settings . . . . . . . . . . . . . . . . . . . . . . . . . . 68
9.5.1 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
9.5.2 Data storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
9.5.3 Automatic Stability control . . . . . . . . . . . . . . . . . . . . . . . 69
9.5.4 Automatic shutoff function . . . . . . . . . . . . . . . . . . . . . . . 69
9.5.5 Display illumination. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
9.6 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
9.6.1 Resetting the measurement settings . . . . . . . . . . . . . . . 70
9.6.2 Resetting the system settings. . . . . . . . . . . . . . . . . . . . . 72
10 Data storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
10.1 Manual data storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
10.2 Automatic data storage at intervals . . . . . . . . . . . . . . . . . . 74
10.3 Measured value data storage . . . . . . . . . . . . . . . . . . . . . . . . . 76
10.3.1 Editing the measured value data storage . . . . . . . . . . . . 76
10.3.2 Erasing the measurement data storage . . . . . . . . . . . . . 77
10.3.3 Measurement dataset. . . . . . . . . . . . . . . . . . . . . . . . . . . 77
10.3.4 Storage locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
11 Transmitting data (USB interfaces). . . . . . . . . . . . . . . . . . . . 79
11.1 Outputting current measurement data . . . . . . . . . . . . . . . . . . . 79
11.2 Transmitting data (to a PC) . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
11.3 Connecting the PC / USB-B interface (USB Device) . . . . . 79
11.4 Options for data transmission to a PC . . . . . . . . . . . . . . . . . . . 80
11.5 MultiLab Importer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
11.6 BOD Analyst Pro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
12 Printer (only MultiLab 4010P-1) . . . . . . . . . . . . . . . . . . . . . . . 83
12.1 Commissioning / switching the printer on or off . . . . . . . . . . . . 83
12.2 Operation / printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
12.3 Printer settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
12.4 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
12.4.1 Changing the roll of paper (thermal paper). . . . . . . . . . . 84
12.5 What to do if... / printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
13 Maintenance, cleaning, disposal. . . . . . . . . . . . . . . . . . . . . . 86
13.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
13.1.1 General maintenance activities . . . . . . . . . . . . . . . . . . . 86
13.1.2 Replacing the batteries. . . . . . . . . . . . . . . . . . . . . . . . . . 86
13.2 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
13.3 Packing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
13.4 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Contents MultiLab 4010-1
6ba76141e03 03/2014
14 What to do if.... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
14.1 pH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
14.2 Dissolved oxygen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
14.3 Conductivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
14.4 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
15 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
15.1 Measuring ranges, resolution, accuracy . . . . . . . . . . . . . . . . . 92
15.2 General data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
16 Firmware update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
16.1 Firmware update for the meter MultiLab 4010-1 . . . . . . . . . . . 94
16.2 Firmware-Update for IDS Sensors. . . . . . . . . . . . . . . . . . . . . . 95
17 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
18 Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
19 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
19.1 Oxygen solubility table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
19.2 DO% Calibration values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
20 Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
20.1 Ordering & Technical Support . . . . . . . . . . . . . . . . . . . . . . . . 105
20.2 Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

MultiLab 4010-1 Overview
ba76141e03 03/2014 7
1 Overview
1.1 MultiLab 4010-1 meter
The compact, digital precision meter MultiLab 4010-1 enables you to carry out
pH measurements, ORP measurements, conductivity measurements and dis-
solved oxygen (D.O.) measurements quickly and reliably.
The MultiLab 4010-1 provides the maximum degree of operating comfort, reli-
ability and measuring certainty for all applications.
The MultiLab 4010-1 supports you in your work with the following functions:
Automatic sensor recognition
CMC (continuous measurement control)
QSC (sensor quality control)
Electronic access control
Data transmission via the USB interface (USB-B).
1 Keypad
2 Display
3 Connectors
1
2
3
4010-1

Overview MultiLab 4010-1
8ba76141e03 03/2014
1.2 MultiLab 4010P-1 meter with integrated printer
The integrated printer of the MultiLab 4010P-1 enables to document measure-
ments according to GLP requirements.
1.3 Sensors
A measuring system ready to measure consists of the MultiLab 4010-1 meter
and a suitable sensor.
Suitable sensors are IDS pH sensors, IDS ORP sensors, IDS conductivity
sensors and IDS D.O. sensors.
1.3.1 IDS sensors
IDS sensors
support the automatic sensor recognition
show only the settings relevant to the specific sensor in the setting menu
process signals in the sensor digitally so that precise and interference-free
measurements are enabled even with long cables
facilitate to assign a sensor to a measured parameter with differently colored
couplings
The information concerning the printer of the MultiLab 4010P-1 is
given in a separate chapter (see section 12 PRINTER (ONLY
MULTILAB 4010P-1), page 83).
1 Keypad
2 Display
3 Socket field
4Printer
5 Control panel of the printer
1
2
3
4
5
4010 -1P

MultiLab 4010-1 Overview
ba76141e03 03/2014 9
have quick-lock couplings with which to fix the sensors to the meter.
Sensor data from
IDS sensors
IDS sensors transmit the following sensor data to the meter:
SENSOR ID
– Sensor name
– Sensor series number
Calibration data
Measurement settings
The calibration data are updated in the IDS sensor after each calibration proce-
dure. A message is displayed while the data are being updated in the sensor.
1.3.2 Automatic sensor recognition
The automatic sensor recognition for IDS sensors allows
to operate an IDS sensor with different meters without recalibrating
to assign measurement data to an IDS sensor
– Measurement datasets are always stored and output with the sensor
name and sensor series number.
to assign calibration data to an IDS sensor
– Calibration data and calibration history are always stored and output with
the sensor name and sensor series number.
to hide menus automatically that do not concern this sensor
To be able to use the automatic sensor recognition, a meter that supports the
automatic sensor recognition (e.g. MultiLab 4010-1) and a digital IDS sensor
are required.
In digital IDS sensors, sensor data are stored that clearly identify the sensor.
The sensor data are automatically taken over by the meter.
In the measured value display, you can display the sensor name
and series number of the selected sensor with the [Info] softkey.
You can then display further sensor data stored in the sensor with
the [More] softkey (see section 4.1.5 SENSOR INFO, page 18).

Overview MultiLab 4010-1
10 ba76141e03 03/2014

MultiLab 4010-1 Safety
ba76141e03 03/2014 11
2 Safety
2.1 Safety information
2.1.1 Safety information in the operating manual
This operating manual provides important information on the safe operation of
the meter. Read this operating manual thoroughly and make yourself familiar
with the meter before putting it into operation or working with it. The operating
manual must be kept in the vicinity of the meter so you can always find the infor-
mation you need.
Important safety instructions are highlighted in this operating manual. They are
indicated by the warning symbol (triangle) in the left column. The signal word
(e.g. "Caution") indicates the level of danger:
NOTE
indicates a possibly dangerous situation where goods might be damaged
if the actions mentioned are not taken.
2.1.2 Safety signs on the meter
Note all labels, information signs and safety symbols on the meter and in the
battery compartment. A warning symbol (triangle) without text refers to safety
information in this operating manual.
2.1.3 Further documents providing safety information
The following documents provide additional information, which you should
observe for your safety when working with the measuring system:
• Operating manuals of sensors and other accessories
• Safety datasheets of calibration or maintenance accessories (such as buffer
solutions, electrolyte solutions, etc.)
WARNING
indicates a possibly dangerous situation that can lead to seri-
ous (irreversible) injury or death if the safety instruction is not
followed.
CAUTION
indicates a possibly dangerous situation that can lead to
slight (reversible) injury if the safety instruction is not fol-
lowed.

Safety MultiLab 4010-1
12 ba76141e03 03/2014
2.2 Safe operation
2.2.1 Authorized use
The authorized use of the meter consists exclusively of the measurement of the
pH, ORP, conductivity and dissolved oxygen in a laboratory environment.
Only the operation and running of the meter according to the instructions and
technical specifications given in this operating manual is authorized (see
section 15 TECHNICAL DATA, page 92).
Any other use is considered unauthorized.
2.2.2 Requirements for safe operation
Note the following points for safe operation:
• The meter may only be operated according to the authorized use specified
above.
• The meter may only be supplied with power by the energy sources
mentioned in this operating manual.
• The meter may only be operated under the environmental conditions
mentioned in this operating manual.
• The meter may only be opened if this is explicitly described in this operating
manual (example: Inserting the batteries).
2.2.3 Unauthorized use
The meter must not be put into operation if:
• it is visibly damaged (e.g. after being transported)
• it was stored under adverse conditions for a lengthy period of time (storing
conditions, see section 15 TECHNICAL DATA, page 92).

MultiLab 4010-1 Commissioning
ba76141e03 03/2014 13
3 Commissioning
3.1 Scope of delivery
Meter MultiLab 4010-1 / MultiLab 4010P-1
4 batteries 1.5 V Mignon type AA
Power pack
USB cable (A plug on mini B plug)
Stand
Stand holder
Comprehensive operating manual
Short instructions
CD-ROM with
– USB drivers
– comprehensive operating manual
– software MultiLab User
– software MultiLab Importer
3.2 Power supply
The MultiLab 4010-1 is supplied with power in the following ways:
Mains operation with the supplied power pack
Battery operation (4 batteries, 1.5 V Mignon type AA)
USB operation via a connected USB-B cable
3.3 Initial commissioning
Perform the following activities:
Insert the supplied batteries
For mains operation: Connect the power pack
If necessary, mount the stand
Switch on the meter (see section 4.2 SWITCHING ON THE METER, page 19)
Set the date and time (see section 4.5.5 EXAMPLE 2 ON NAVIGATION: SETTING
THE DATE AND TIME, page 26)

Commissioning MultiLab 4010-1
14 ba76141e03 03/2014
3.3.1 Inserting the batteries
You can operate the meter either with normal batteries or with
rechargeable batteries (Ni-MH). In order to charge the batteries, an
external charging device is required.
1. Open the battery compartment (1) on the underside of the
meter.
1 Battery compartment
CAUTION
Make sure that the poles of the batteries are positioned cor-
rectly.
The ±signs on the batteries must correspond to the ± signs in
the battery compartment.
2. Place four batteries (type Mignon AA) in the battery compartment.
3. Close the battery compartment (1).
4. Set the date and time
(see section 4.5.5 EXAMPLE 2 ON NAVIGATION: SETTING THE DATE AND TIME,
page 26).
1

MultiLab 4010-1 Commissioning
ba76141e03 03/2014 15
3.3.2 Connecting the power pack
3.3.3 Mounting the stand
The stand base can be mounted at the right side of the meter.
CAUTION
The line voltage at the operating site must lie within the input
voltage range of the original power pack (see section 15.2
GENERAL DATA, page 92).
CAUTION
Use original power packs only (see section 15.2 GENERAL DATA,
page 92).
1. Connect the plug of the power pack to the socket for the power pack on
the MultiLab 4010-1.
2. Connect the original power pack to an easily accessible power outlet.
1
2

Operation MultiLab 4010-1
16 ba76141e03 03/2014
4Operation
4.1 General operating principles
4.1.1 Keypad
In this operating manual, keys are indicated by brackets <..>.
The key symbol (e.g. <MENU/ENTER>) generally indicates a short keystroke
(press and release) in this operating manual. A long keystroke (press and hold
for approx. 2 sec) is indicated by the underscore behind the key symbol (e.g.
<MENU/ENTER__>).
<F1>:
<F1__>:
<F2>:
<F2__>:
Softkeys providing situation dependent functions, e.g.:
<F1>/[Info]: View information on a sensor
<On/Off>: Switches the meter on or off
<M>: Selects the measured parameter / Quits the settings
<CAL>:
<CAL__>:
Calls up the calibration procedure
Displays the calibration data
<STO>:
<STO__>:
Saves a measured value manually
Opens the menu for the automatic save function
<RCL>:
<RCL__>:
Displays the manually stored measured values
Displays the automatically stored measured values
<><>:
<__><__>:
Menu control, navigation
Increments, decrements values
Increments, decrements values continuously
<MENU/ENTER>:
<MENU/ENTER__>:
Opens the menu for measurement settings / confirms
entries
Opens the menu for system settings
<AR> Freezes the measured value (HOLD function)
Switches the AutoRead measurement on or off
F1
F2
STOSTO
RCL
ARAR

MultiLab 4010-1 Operation
ba76141e03 03/2014 17
4.1.2 Display
Example (pH):
4.1.3 Status information (meter)
1 Status information (sensor)
2 Measured value
3 Measured parameter
4 Continuous measurement control (CMC function)
5 Sensor symbol (calibration evaluation, calibration interval)
6 Measured temperature (with unit)
7 Status information (meter)
8 Softkeys and date + time
AR Stability control (AutoRead) is active
HOLD Measured value is frozen (<AR> key)
Batteries are almost empty
Data are automatically output to the USB-B interface at
intervals
3
2
1
4
5
6
8
HOLD AR
7
AutoCal TEC
Info 03.04.2013
08:00 USB output
YSI

Operation MultiLab 4010-1
18 ba76141e03 03/2014
4.1.4 Instrument connectors
4.1.5 Sensor info
You can display the current sensor data and sensor settings of a connected
sensor at any time. The sensor data are available in the measured value
display with the <F1>/[Info] softkey.
1 IDS sensors: (pH, ORP, conductivity, D.O.)
2 USB B (device) interface
3 Stirrer (ProOBOD)
4 Service interface
5 Power pack
CAUTION
Only connect sensors to the meter that cannot return any volt-
ages or currents that are not allowed (> SELV and > current
circuit with current limiting).
YSI IDS sensors and IDS adapters meet these requirements.
1. In the measured value display:
Display the sensor data (sensor name, series number) with [<F1>Info].
1345
2
25.0
7.007
pH
°C
0
14
01.02.2014
08:00
Info USB output

MultiLab 4010-1 Operation
ba76141e03 03/2014 19
4.2 Switching on the meter
2. Display further sensor data (settings) with <F1>/[More].
1. Switch the meter on with <On/Off>.
The meter performs a self-test.
2. Connect the sensor.
The meter is ready to measure.
25.0
7.007
pH
°C
0
14
More 03.04.2013
08:00
4110
B09250001
pH resolution 0.001
mV resolution 0.1
Buffer YSI
Calibration interval 7d
Unit for slope mV/pH
QSC: off
Software-Version V 1.00
4110
B092500013
03.04.2013
08:00
Back
25.0
7.007
pH
°C
0
14
01.02.2014
08:00
Info USB output

Operation MultiLab 4010-1
20 ba76141e03 03/2014
4.3 Switching off the meter
4.4 Login with a user name
After activation of the user administration by the administrator (software
MultiLab User, on the enclosed CD-ROM), measurements
are only possible after login with a user name. The user
name is documented with the measured values and in records.
All user names entered by the administrator are listed in the User name menu.
The administrator determines for each user whether or not a
password is required for the login to the meter.
If the Password menu item is grayed out, no password is required for
the login.
If the user administration function is activated, the Login dialog
appears after the meter is switched on (see section 4.4 LOGIN WITH
AUSER NAME, page 20).
The user administration function is not active in the delivery condi-
tion.
1. Switch the meter off with <On/Off>.
1. Switch the meter on with <On/Off>.
The Login dialog appears.
2. Using <><>, select the menu item, User name and confirm with
<MENU/ENTER>.
The user name is highlighted.
3. Using <><>, select a user name and confirm with <MENU/
ENTER>.
User name Admin
Password ####
Change password
Login
03.04.2013
08:00
