Xylem e-IXP Manual

e-IXP, e-IXPC, e-IXPF
Pumps according to chemistry standards
Additional Installation, Operation
and Maintenance Instructions
Applicare qui l’adesivo con il codice a barre
Apply the adhesive bar code nameplate here

en – Original Instructions
2 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
Table of Contents
1Introduction and Safety ............................................................................................................................................ 5
1.1 Introduction ...................................................................................................................................................... 5
1.2 Hazard levels and safety symbols.................................................................................................................... 5
1.3 User safety ........................................................................................................................................................ 6
1.4 Protection of the environment......................................................................................................................... 7
1.5 Spare parts........................................................................................................................................................ 7
2Handling and Storage............................................................................................................................................... 8
2.1 Unit inspection upon delivery.......................................................................................................................... 8
2.1.1 Package inspection ...................................................................................................................................... 8
2.1.2 Unpacking and inspection of the unit ......................................................................................................... 8
2.2 Guidelines for transport................................................................................................................................... 8
2.2.1 Handling of the packed unit using a forklift truck....................................................................................... 9
2.2.2 Lifting with a crane ....................................................................................................................................... 9
2.3 Storage ........................................................................................................................................................... 11
2.3.1 Storage of the packed unit ........................................................................................................................11
2.3.2 Long-term storage of the unit....................................................................................................................11
2.3.3 Return..........................................................................................................................................................11
3Description of the Product ..................................................................................................................................... 12
3.1 Features .......................................................................................................................................................... 12
3.2 Data plates...................................................................................................................................................... 13
3.3 Identification code .........................................................................................................................................13
3.4 Part names ......................................................................................................................................................14
4Installation ...............................................................................................................................................................15
4.1 General precautions.......................................................................................................................................15
4.2 Mechanical installation................................................................................................................................... 15
4.2.1 Precautions ................................................................................................................................................. 15
4.2.2 Installation area .......................................................................................................................................... 15
4.2.3 Installation on concrete foundation........................................................................................................... 15
4.2.4 Frame installation....................................................................................................................................... 17
4.3 Hydraulic connection ..................................................................................................................................... 17
4.3.1 Precautions ................................................................................................................................................. 17
4.3.2 Guidelines for the hydraulic system .......................................................................................................... 17
4.3.3 Auxiliary Connections ................................................................................................................................18
4.4 Alignment of the motor-pump coupling.......................................................................................................18
4.4.1 Disassembling the protections .................................................................................................................. 19
4.4.2 Checking the coupling alignment .............................................................................................................19
4.4.3 Installing the protections ...........................................................................................................................20

en – Original Instructions
e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions 3
4.5 OptimyzeTM connection .................................................................................................................................21
4.6 Electrical connection......................................................................................................................................21
4.6.1 Precautions ................................................................................................................................................. 21
4.6.2 Guidelines for electrical connection..........................................................................................................22
4.6.3 Guidelines for the control panel................................................................................................................ 22
4.6.4 Motor connection....................................................................................................................................... 22
4.6.5 Overload protection...................................................................................................................................23
4.6.6 Operation with frequency converter .........................................................................................................23
5Use and Operation.................................................................................................................................................. 24
5.1 Precautions .....................................................................................................................................................24
5.2 Lubrication......................................................................................................................................................25
5.3 Checking the rotation direction.....................................................................................................................25
5.4 Start-up ...........................................................................................................................................................25
5.5 Stopping .........................................................................................................................................................25
6Maintenance............................................................................................................................................................26
6.1 Precautions .....................................................................................................................................................26
6.2 Periodic maintenance .................................................................................................................................... 27
6.2.1 Grease top up.............................................................................................................................................28
6.2.2 Replacing the grease .................................................................................................................................28
6.2.3 Changing the oil .........................................................................................................................................28
6.3 Long periods of inactivity............................................................................................................................... 29
6.4 Spare parts ordering ......................................................................................................................................29
7Troubleshooting...................................................................................................................................................... 30
7.1 Precautions .....................................................................................................................................................30
7.2 The unit does not start ...................................................................................................................................30
7.3 The differential protection device (RCD) has tripped ..................................................................................30
7.4 The unit produces excessive noise and/or vibrations ..................................................................................30
7.5 The thermal overload protection triggers or the fuses trip.......................................................................... 31
7.6 The thermal overload protection triggers..................................................................................................... 31
7.7 The motor becomes excessively hot ............................................................................................................. 31
7.8 Little or no hydraulic performance ................................................................................................................31
7.9 When switched off, the unit turns in the opposite direction ........................................................................32
7.10 The unit starts and stops too frequently........................................................................................................ 32
7.11 The unit does not stop ...................................................................................................................................32
7.12 The unit is leaking at the mechanical seal..................................................................................................... 32
7.13 The frequency converter is in error mode or turned off...............................................................................32
8Technical Information ............................................................................................................................................. 33
8.1 Operating environment .................................................................................................................................33
8.2 Temperature of pumped liquid .....................................................................................................................33
8.3 Maximum operating pressure .......................................................................................................................34
8.4 Maximum number of starts per hour.............................................................................................................34
8.5 Electrical specifications.................................................................................................................................. 35

en – Original Instructions
4 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
8.6 Sound pressure .............................................................................................................................................. 35
8.7 Forces and torques applicable to the ports..................................................................................................36
8.8 Construction and maintenance data ............................................................................................................. 37
9Disposal...................................................................................................................................................................38
9.1 Precautions .....................................................................................................................................................38
9.2 WEEE 2012/19/EU (50 Hz) ............................................................................................................................ 38
10 Declarations........................................................................................................................................................39
10.1 Electric pump unit ..........................................................................................................................................39
10.2 Pump...............................................................................................................................................................40
11 Warranty .............................................................................................................................................................41
11.1 Information ..................................................................................................................................................... 41

en – Original Instructions
e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions 5
1Introduction and Safety
1.1 Introduction
Purpose of this manual
This manual provides information on how to do the following in the correct manner:
•Installation
•Operation
•Maintenance.
CAUTION:
This manual is an integral part of the unit. Be sure to read and understand the manual before
installing the unit and putting it to use. The manual
must always be made available to the user,
stored in the proximity of the unit, and well kept.
Supplementary instructions
The instructions and warnings of this manual apply to the standard unit as described in the sale
documentation. Special version pumps may be supplied with supplementary instruction
manuals. For situations not considered in the manual or in the commercial documentation,
contact Xylem or the Authorised Distributor.
1.2 Hazard levels and safety symbols
Before using the unit, the user must read, understand and comply with the indications of the
danger warnings in order to avoid the following risks:
•Injuries and health hazards
•Damage to the product
•Unit malfunction.
Hazard levels
Hazard level
Indication
DANGER:
It identifies a dangerous situation which, if not avoided, causes
serious injury, or even death.
WARNING:
It identifies a dangerous situation which, if not avoided, may cause
serious injury, or even death.
CAUTION:
It identifies a dangerous situation which, if not avoided, may cause
small or medium level injuries.
NOTE:
It identifies a situation which, if not avoided, may cause damage to
property but not to people.

en – Original Instructions
6 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
Complementary symbols
Symbol
Description
Electrical hazard
Hot surface hazard
Danger, pressurized system
Potentially explosive atmosphere hazard
Do not use flammable liquids
Do not use corrosive liquids
Read the instruction manual
1.3 User safety
Strictly comply with current health and safety regulations.
Qualified personnel
This unit must be used only by qualified users. Qualified users are people able to recognise
the risks and avoid hazards during installation, use and maintenance of the unit.
Inexperienced users
WARNING:
•
For EU countries: this product may be used by children aged 8 years and above and
persons with reduced physical, sensory or mental capabilities, or who lack experience and
knowledge, provided that they are being supervised and have been instructed on how to
use it safely, and understand the hazards involved. Children must not play with the product.
Cleaning and maintenance must not be carried out by children without supervision.
•
For countries outside the EU: this product is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or who lack experience and
knowledge, unless they are being supervised and have been instructed on how to use it by
a person responsible for their safety. Children should be supervised to ensure that they do
not play with the product.

en – Original Instructions
e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions 7
1.4 Protection of the environment
Disposal of packaging and product
Comply with the current regulations on sorted waste disposal.
Leaking of fluid
If the unit contains lubricating fluid, take appropriate measures to prevent the dispersion of
leaks into the environment.
Sites exposed to ionizing radiations
WARNING: Ionizing radiation hazard
If the unit has been exposed to ionizing radiations, implement the necessary safety measures
for the protection of people. If the unit needs to be dispatched, inform th
e carrier and the
recipient accordingly, so that appropriate safety measures can be put in place.
1.5 Spare parts
WARNING:
Replace all worn or faulty components with original spare parts, to prevent unit malfunction
and personal injury, as well as the
warranty from becoming null and void.
Identify the spare parts with the product codes directly on the site www.lowara.com/spark.
Contact Xylem or the Authorised Distributor for technical information.

en – Original Instructions
8 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
2Handling and Storage
2.1 Unit inspection upon delivery
2.1.1 Package inspection
1. Check that quantity, descriptions and product codes match the order.
2. Check the packaging for any damage or missing components.
3. In case of immediately detectable damage or missing parts:
•Accept the goods with reserve, indicating any findings on the transport document, or
•Reject the goods, indicating the reason on the transport document.
In both cases, promptly contact Xylem or the Authorised Distributor from whom the
product was purchased.
2.1.2 Unpacking and inspection of the unit
CAUTION: Cut and abrasion hazard
Always wear personal protective equipment.
1. Remove the packaging.
2. Ensure sorting of all packaging materials in accordance with the applicable regulations.
3. Release the unit by removing the screws and/or cutting the straps, if fitted.
4. Check the unit for integrity and to make sure that there are no missing components.
5. In case of damage or missing components, promptly contact Xylem or the Authorised
Distributor.
2.2 Guidelines for transport
Precautions
WARNING: Crushing hazard
The u
nit and components are heavy: risk of crushing.
WARNING:
Always wear personal protective equipment.
WARNING:
Check the gross weight marked on the packaging.
WARNING:
Handle the unit in compliance with the current regulations on "manual load handling", to avoid
undesirable ergonomic conditions causing risks of back
-spine injury.

en – Original Instructions
e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions 9
2.2.1 Handling of the packed unit using a forklift truck
The Figure shows the types of packaging and the lifting points.
1. Cardboard box with wooden base
2. Wooden crate
2.2.2 Lifting with a crane
WARNING:
Use ropes, chains and/or slings (hereinafter referred to as "ropes"), hooks and/or clasps
(hereinafter referred to as "hooks"), shackles or eyebolts that comply with the applicable
directives and are suitable for use.
WARNING:
It is forbidden to use the shaft end and/or the motor eyebolts to move the unit.
NOTE:
Make sure that the harnessing does not hit and/or damage the unit.
WARNING:
Lift and handle the unit slowly to avoid stability issues.
WARNING:
During handling, make sure to avoid injury to people and animals, and/or damage to property.
12

en – Original Instructions
10 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
Preparing the unit for lifting
1. Depending on the model:
•Attach the shackles to the eyelets, if any, and attach the ropes to the shackles, or
•Use the ropes to make a tie harness.
The figure shows how to harness and lift the different models.
2. Fix the ropes to the crane.
3. Lift the crane and tension the ropes without lifting the unit.
Lifting and positioning
1. Lift and move the unit slowly
2. Set the unit down slowly.
3. Depending on the model:
•Release the ropes from the shackles, or
•Release the harness.

en – Original Instructions
e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions 11
2.3 Storage
Precautions
WARNING:
In the case of liquids that are excessively hot or cold, pay attention to the risk of injury.
WARNING:
Make sure that the drained
liquid cannot cause damage or injuries.
WARNING:
It is prohibited to dispose of lubricant liquids and other hazardous substances in the
environment.
2.3.1 Storage of the packed unit
The unit must be stored:
•In a covered and dry place
•Away from heat sources
•Protected from dirt
•Protected from vibrations
•At an ambient temperature between -5°C and +40°C (23°F and 140°F), and relative
humidity between 5% and 95%.
NOTE:
Do not place heavy loads on top of the unit.
NOTE:
Protect the unit from collisions.
2.3.2 Long-term storage of the unit
1. Correctly empty the unit.
2. Close the suction and discharge ports with caps or flanges.
3. Follow the same instructions for the storage of the packed unit.
Note
This operation is essential in environments with cold temperatures. Otherwise, any residual
liquid in the unit could have an adverse effect on its condition and performance.
For more information on long-term storage contact the Xylem sales company or Authorised
Distributor.
2.3.3 Return
1. Correctly empty the unit.
2. Wash and clean the unit, especially if used to process harmful, explosive, hot or potentially
hazardous liquids.
3. Neutralize the unit further and blow with inert gas without water to dry it, in case of liquids
the residues of which can cause corrosion damage due to moisture, or can ignite on contact
with oxygen.
4. Please attach a completed release statement to the unit. Indicate the safety and
decontamination measures implemented.

en – Original Instructions
12 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
3Description of the Product
3.1 Features
The product is a single-stage end suction pump in back pull-out configuration with bearing
support, compliant with EN 22858 and ISO 2858.
The product can be supplied as a pump unit (pump with electric motor), or as a pump only.
Intended use
•Water supply
•Water transfer and circulation
•Process cooling and heating
•Cooling and heating in industrial buildings
•Industrial liquid transfer
•Boiler supply
•Remote heating and cogeneration
•Filtration and ultra-filtration systems
•Filtration in treatment systems
•Washers
•Galvanic processes and painting systems
•Cleaning of tanks and cisterns
•Mixing of liquids
•Water movement in water parks.
Observe the operating limits in Technical Information on page 33.
DANGER: Potentially explosive atmosphere hazard
It is prohibited to start the unit in environments with potentially explosive
atmospheres or with combustible dusts.
Pumped liquids
•Water
•Sea water
•Salt water
•Demineralized water
•Hot water
•Acids
•Brine
•Petrochemical products
•Chlorides
•Heat transfer fluids
•Oils
•Solvents
•Detergents
•Condensation.
DANGER:
It is prohibited to use this unit to pump flammable and/or explosive liquids.

en – Original Instructions
e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions 13
3.2 Data plates
1. Pump or pump unit type
2. Maximum operating pressure
3. Maximum liquid operating temperature
4. Full impeller diameter (non-trimmed impellers only)
5. Manufacturing date + serial number
6. Product code
7. Weight
8. Flow rate range
9. Minimum liquid operating temperature
10. Head range
11. Rotation speed
12. Reduced impeller diameter (trimmed impellers only)
13. Pump unit absorbed power
14. Minimum efficiency index
15. Hydraulic efficiency at the best efficiency point
3.3 Identification code
1. Series name
2. Size from 40-25-160 to 300-250-315
3. Impeller with full [A], reduced [B, C or D], standard [ ] or special [X] diameter
4. Motor power in kWx10 or impeller diameter in mm (bare shaft pump only)
5. Lowara motor [P, L], WEG [W], ABB [A], or other manufacturer's [X]
6. 2-pole [2], 4-pole [4] or 6-pole [6] motor
7. Frequency 50 Hz [5] or 60 Hz [6]
8. Operating pressure standard, discharge side, PN 16 bar [B], PN 25 bar [C], class 150 [R] or class 300 [S]
9. Pump body made of cast ductile iron [D], stainless steel [N], duplex [R], super duplex [T], super-austenitic stainless
steel [U] or other material [X]
10. Impeller made of stainless steel [N], duplex [R], super duplex [T], super-austenitic stainless steel [U] or other
material [X]
11. Mechanical seal made of SiC/Carbon/EPDM [4], SiC/Carbon/EPDM hot water [6], SiC/Carbon/FKM [2],
SiC/SiC/EPDM [Z], SiC/SiC/FKM [W] or other material [X]
12. Type of mechanical seal
13. Bearing support lubricated with grease [G] or oil [O]
XIP_M0003_A_sc
123456
8 9 10 11 12 13 14 157
XIP_M0004_A_sc
I X P 20 0 - 1 5 0 - 3 1 5 A 3 2 2 W 2 5 B D N 2 S 1 G
12
4 5
6 8
91 2 3 7
10
11 13

en – Original Instructions
14 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
3.4 Part names
1. Discharge body
2. Bolt
3. Lifting ring
4. Shaft seal ring
5. Bearing support
6. Shaft seal ring
7. Shaft
8. Coupling key
9. Bearing cover
10. Support foot
11. Cap
12. Impeller
13. Wear ring
14. Coupling key
15. Impeller locking nut
16. Plug
17. O-ring
18. Cap
19. O-ring
20. Seal
21. Cover
22. Mechanical seal
23. Shaft sleeve
24. Bearing cover
6
8
7
23
4
5
1
11
12
14
15
16
18
17
13
19 20 21
22 23
24
9
10
XIP_M0005_A_sc

en – Original Instructions
e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions 15
4Installation
4.1 General precautions
Before starting, make sure that the safety instructions shown in Introduction and Safety on
page 5 have been fully read and understood.
WARNING:
All the hydraulic and electrical connections must be completed by a technician possessing the
technical
-professional requirements outlined in the current regulations.
WARNING:
Always wear personal protective equipment.
WARNING:
Always use suitable working tools.
4.2 Mechanical installation
4.2.1 Precautions
WARNING: Risk of injury due to improper floor installation
Install the unit on a
concrete or metal foundation base sufficiently strong to ensure permanent
and rigid support, suitable for the size and weight of the unit and as flat and even as possible.
4.2.2 Installation area
1. Follow the provisions in Operating environment on page 33.
2. Place the unit in a raised position in relation to the floor.
3. Check that the air clearance between the wall and the motor fan grid is:
•≥ 100 mm (4 in), to ensure suitable ventilation
•≥ 300 mm (12 in), to allow inspection and removal of the motor.
4. Make sure that any leaks will not cause flooding to the installation area or submerge the
unit.
Permitted positions
Only install the unit in the horizontal position.
4.2.3 Installation on concrete foundation
Foundation requirements
•The concrete must have a compression resistance of C12/15 and meet the requirements of
exposure class XC1 according to EN 206-1
•Sizes must be appropriate for the sizes of the unit support plate
•The foundation weight must be ≥ 1.5 times the unit weight (≥ 5 times the weight of the unit
if a quieter operation is required)
•The surface should be as flat and level as possible.

en – Original Instructions
16 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
Installation
The figure shows the position of the levelling shims depending on the distance of the tie rods.
1. Unit
2. Levelling thickness
3. Tie rod
1. Drill the tie rod holes in accordance with the quantity, diameter and centre distances shown
in the technical catalogue.
2. Insert the tie rods into the holes and secure them with chemical anchors.
3. Remove the caps of the suction and discharge ports.
4. Place the unit on the foundation by inserting the tie rods into the holes in the plate.
5. Level the unit with a spirit level on the shaft and discharge port: the maximum permitted
tolerance is 0.2 mm/m (0.0024 in/ft).
6. Align the suction and discharge ports to their piping.
7. If necessary, insert levelling shims between the plate and the foundation: If the distance
between the tie rods is ≥ 800 mm (31 in), insert additional shims in the middle of the plate.
8. Tighten the nuts on the tie rods evenly and fully.
Nut
Torque, Nm (lbf·in)
M12
60 (44)
M16
120 (89)
M20
200 (148)
M24
350 (258)
M27
530 (391)
Reducing vibrations
The engine and the flow of liquids in the piping can generate vibrations, which may be
amplified
from the possible incorrect installation of the unit and the piping. See Hydraulic connection on
page 17.
≤ 800 mm (31 in)
> 800 mm (31 in)
1
2
2
3
3
2
2
3
1
3
2
XIP_M0006_A_sc

en – Original Instructions
e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions 17
4.2.4 Frame installation
•The frame must be rigid and must not vibrate during operation
•The pump and motor feet support bases must be as level as possible
•Position the pump and the motor at a distance that allows the coupling to be fitted
•Ensure a gap of 4-6 mm (0.16-0.24 in) between the frame and the motor to allow for vertical
adjustment in case of replacement.
•Make sure that pump and motor are securely attached to the frame.
4.3 Hydraulic connection
4.3.1 Precautions
WARNING:
Piping must be sized to ensure safety at the maximum operating pressure.
WARNING: Danger of hot and/or toxic liquid escaping from non-sealed piping system
connections
Support the piping system independently to prevent them from weighing on the unit. Secure
the piping system to the unit ports making sure to comply with the permitted forces and
torques. Install appropriate gaskets between the unit and the piping system.
WARNING: Hot surface hazard
If the temperature exceeds 60°C (140°F), isolate the unit before touching it.
NOTE:
When carrying out welding activities never use the unit for grounding: risk of pitting damage
to the bearings.
4.3.2 Guidelines for the hydraulic system
1. Support the piping system independently to prevent them from weighing on the unit.
2. Remove any welding residues, deposits and impurities in the pipes that could damage the
unit; install a filter if necessary.
3. To reduce the transmission of vibrations between the unit and the system and vice versa,
install:
•anti-vibration joints on the suction and discharge sides of the unit
•dampers between the unit and the surface on which it is installed.
4. In order to reduce flow resistance, the pipe on the suction side must be:
•As short and as straight as possible
•For the section connected to the unit, straight and without bottlenecks, covering a
length equal to at least six times the diameter of the suction port
•Wider than the suction port; if necessary, install an eccentric reducer that is horizontal on
top
•Without bends; if this cannot be avoided, bends of a radius as wide as possible
•Without traps and 'goosenecks'
•With valves with a low specific flow resistance.
5. Install a check valve on the discharge side to prevent the liquid from flowing back into the
pump unit when this is at standstill.
6. Install a pressure gauge (or a vacuum pressure gauge, in case of suction lift installation) on
the suction side, and a pressure gauge on the discharge side, for checking the actual
operating pressure of the pump unit.

en – Original Instructions
18 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
7. To exclude the unit from the system for the purpose of maintenance, install:
•An on-off valve on the suction side
•An on-off valve on the discharge side, downstream the check valve and pressure gauge,
also useful for regulating the flow rate.
8. In case of suction lift installation, the suction pipe must have an increasing slope towards
the unit exceeding 2%; to avoid air pockets.
4.3.3 Auxiliary Connections
NOTE:
Unused or incorrectly used connections may cause malfunction and damage to the unit.
1. Suction port
2. Discharge port
3. Greasing unit M8 nipple
4. Greasing unit M8 nipple
5. G 1/2” drain
6. G 1/4" recirculation outlet (optional)
7. G 1/4” suction pressure port
8. G 1/4" discharge pressure port
9. G 1/2” drain
4.4 Alignment of the motor-pump coupling
NOTE:
Check the alignment of the motor
-pump coupling after the mechanical installation and
hydraulic connection of the unit.
XIP_M0008_A_sc
8
6
1
4
3
5
2
9
7

en – Original Instructions
e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions 19
4.4.1 Disassembling the protections
1. Top fastener
2. Top coupling protection
3. Bottom fastener
4. Side fasteners
5. Bottom coupling protection
6. Adjustment ring
1. Unscrew the side fasteners.
2. Unscrew the top fastener.
3. Remove the top protection.
4. Unscrew the bottom fastener.
5. Remove the bottom protection.
6. Open and lift the adjustment ring.
4.4.2 Checking the coupling alignment
Figure 1: Standard coupling
Figure 2: Coupling with spacer
1. Ruler
2. Thickness gauge
See Figure 1 or Figure 2, depending on the type of coupling.
1. Place a ruler on the half-couplings.
2. Measure the distances at the points shown in the figure.
3. Turn the coupling by hand a little and repeat the measurement.
4. Repeat step 3 several times: the radial alignment is correct if the distances in relation to the
corresponding axes are the same at all points.
5. Check the distance between the half couplings with a feeler gauge.
6. Turn the coupling by hand a little and check the distance again.
7. Repeat step 6 several times: the axial alignment is correct if the distances are the same at all
points.
XIP_M0010_A_sc
5
26 1
43
XIP_M0013_A_sc
1
2
XIP_M0017_A_sc
12

en – Original Instructions
20 e-IXP, e-IXPC, e-IXPF series – Additional Installation, Operation and Maintenance Instructions
NOTE:
The radial and axial deviations
between the half couplings must not exceed the values
indicated by the manufacturer. Refer to the motor
-pump coupling instruction manuals for
more information.
The figure shows the correct alignment of the coupling.
4.4.3 Installing the protections
1. Top fastener
2. Top coupling protection
3. Bottom fastener
4. Side fasteners
5. Bottom coupling protection
6. Adjustment ring
7. Bearing cover
8. Coupling
9. Motor
1. Reinstall the bottom protection by screwing the bottom fastener.
2. Insert the ring with the slot facing down and press it against the motor in the axial direction.
3. Reinstall the top protection and screw the top and side fasteners.
XIP_M0011_A_sc
XIP_M0012_A_sc
21
4
3 5
6
78
9
