Yaesu FTM-3200DR User manual

C4FM/FM
VHF DIGITAL/ANALOG TRANSCEIVER
Operating Manual
VOL
DIAL
SQL
TXPO D W M W
SETUP
REV D /A V / MM H z

2
Contents
FTM-3200DR Operating Manual
FTM-3200DR Quick Reference Guide ..................... 3
Introduction ............................................................... 4
Features of this radio ............................................... 4
Accessories & Options ............................................ 5
Supplied Accessories .............................................. 5
Optional Accessories ............................................... 5
Installation ................................................................. 6
Connecting the Microphone ..................................... 6
Connecting the Antenna .......................................... 6
Mobile Installation .................................................... 7
Power connection ................................................. 8
Base Station Installation .......................................... 9
AC Power Supplies ............................................... 9
Front Panel Controls & Switches .......................... 10
Front Panel ............................................................ 10
Microphone Switches ............................................. 12
Microphone (MH-48A6JA) ..................................... 12
[P1] button (SQL OFF) ........................................ 12
[P2] button (HOME) ............................................ 12
[P3] button (CD SRCH)....................................... 12
[P4] button (WX CH/T.CALL) .............................. 12
Rear Panel Connectors .......................................... 13
Rear Panel ............................................................. 13
Basic Operation ...................................................... 14
Turning the Transceiver ON and OFF ................... 14
Inputting the call sign ............................................. 14
Adjusting the Audio Volume Level ......................... 14
Adjusting the Squelch Setting ................................ 14
Frequency Navigation ............................................ 15
Using the Dial ..................................................... 15
Using the MH-48A6JA Microphone..................... 15
Channel Step Selection ......................................... 15
Selecting the communication mode ....................... 16
Setting the transmission mode
when using the AMS function ....... 17
Transmission ......................................................... 18
Adjusting the transmit power .............................. 19
Lock Feature .......................................................... 19
Advanced Operation .............................................. 20
Repeater Operation ............................................... 20
Checking the Repeater Uplink (Input)
Frequency ..... 20
Weather Broadcast Reception ............................... 21
Severe Weather Alert Feature ............................ 21
CTCSS Operation .................................................. 22
Tone Search........................................................ 22
DCS Operation ...................................................... 22
DCS Search ........................................................ 23
EPCS (Enhanced Paging & Code Squelch)
Operation .... 23
Split Tone Operation .............................................. 23
DTMF Operation .................................................... 23
Memory Operation .................................................. 24
Memory Storage .................................................... 24
Split Memory ....................................................... 24
Naming a Memory Channel ................................ 24
Memory Only Mode ............................................ 24
Memory Recall ....................................................... 25
Memory Recall from the Microphone Keypad..... 25
Moving Memory Data to the VFO ....................... 25
Masking Memories ................................................ 26
Unmasking Memories ......................................... 26
HOME Channel Memory ....................................... 26
Changing the frequency of the home channel .... 26
Scanning ................................................................. 27
Basic Scanner Operation ....................................... 27
Scan Resume Options ........................................ 27
Memory Skip Scanning ....................................... 27
Preferential Memory Scan .................................. 27
Programmable Memory Scan (PMS) .................. 27
Priority Channel Scanning (Dual Watch) ............ 27
GM Function ............................................................ 28
What is the GM (Group Monitor) Function? ........... 28
Displaying all the stations using the
GM function ..... 28
Reset Procedure/Clone .......................................... 29
Reset Procedure .................................................... 29
Microprocessor Resetting ................................... 29
Set Mode Resetting ............................................ 29
Clone ..................................................................... 29
Miscellaneous Settings .......................................... 30
Programming the Key Assignments ...................... 30
Keyboard Beeper ................................................... 30
Display Brightness ................................................. 30
Time-Out-Timer (TOT) ........................................... 30
Automatic Power Off (APO) ................................... 30
Busy Channel Lock-Out (BCLO) ........................... 30
TX Deviation Level ................................................ 30
MIC Gain Setting ................................................... 30
Displaying the Supply Voltage ............................... 31
Displaying the Temperature ................................... 31
Band Edge Beeper ................................................ 31
Setup (Menu) Mode ................................................ 32
Maintenance ............................................................ 35
Care and maintenance .......................................... 35
Replacing the fuse ................................................. 35
Replacing the fuse of the
DC power supply cable ........... 35
Specifications ......................................................... 36

3FTM-3200DR Operating Manual
FTM-3200DR Quick Reference Guide
VOL
DIAL
SQL
TXPO D W M W
SETUP
RE V D / A V / MM H z
P3
P2
7
1
4
8
2
0
5
9
B
A
C
D
3
6
P4
DTMF MICROPHONE
MH-48
ABC
JKL
TUV
GHI
PQRS
DEF
MNO
WXYZ
MIC
Power Switch
Press and hold for one second.
Frequency DIAL Knob
Selects the operating Frequency.
VOL Knob
Adjusts the audio
volume level.
Microphone
Transmission Switch
Speak into the microphone in
a normal voice level while
pressing this switch.

4FTM-3200DR Operating Manual
Introduction
Features of this radio
144 MHz mobile radio, equipped with a C4FM digital communication modem
65 Watts of power output, with selection of three power levels for every operating situ-
ation
Clear audio and data communication is achieved using the digital modem functions
Expanded receiver coverage: 136-174 MHz
Keyboard entry of operating frequencies from the microphone
220 memories (199 “basic” memory channels, 10 sets of band-edge memory chan-
nels, and one “Home” channel) which can store repeater shifts, odd repeater shifts,
CTCSS/DCS tones, and 8-character Alpha-Numeric labels for easy channel recogni-
tion
10 NOAA Weather Broadcast Channels, with Weather Alert and a Volume Control for
the Weather Alert tone
Built-in CTCSS and DCS Encoder/Decoder circuits
Extensive Menu system, which allows customization of a number of transceiver perfor-
mance characteristics
Equipped with the GM (Group Monitor) function.
Additional features include a transmit Time-Out-Timer (TOT), Automatic Power-Off (APO),
and Automatic Repeater Shift (ARS). Also included is an RF Squelch circuit that allows
the owner to set the squelch to open at a programmed setting of the S-Meter, thus reduc-
ing guesswork in setting the squelch threshold.
Congratulations on your purchase of the FTM-3200DR! Whether this is your first rig, or if
Yaesu equipment is already the backbone of your station, the Yaesu organization is com-
mitted to ensuring your enjoyment of this high-performance transceiver. It should provide
you with many years of satisfying operation. Our dealer network and technical support
personnel stand behind every product we sell, and we invite you to contact us should you
require technical advice or assistance.
We recommend that you read this manual in its entirety prior to installing the FTM-
3200DR, so that you fully understand the capabilities of your new transceiver.

5FTM-3200DR Operating Manual
Accessories & Options
Supplied Accessories
DTMF Microphone
MH-48A6JA
Mobile Mounting Bracket
(Attachment screw set)
DC power cable w/Fuse
Operating Manual
Safty Guide
Warranty Card
Spare fuse (25 A) USB cable
Optional Accessories
MH-42C6J Microphone
MH-48A6JA DTMF Microphone
MEK-2 Mic Extension Kit
MLS-100 High-Power External Speaker
MLS-200-M10 High-Power External Speaker
FP-1023 AC Power Supply (USA market only)
FP-1030A AC Power Supply

6FTM-3200DR Operating Manual
Installation
Connecting the Microphone
Connect the supplied MH-48A6JA microphone to the FTM-3200DR.
Plug the microphone connector into the MIC jack on the front panel until it clicks.
Note: When disconnecting the microphone, pull the cable while pressing the connector
latch.
P3
P2
7
1
4
8
2
0
5
9
B
A
C
D
3
6
P4
DTMF MICROPHO NE
MH-48
ABC
JKL
TUV
GHI
PQRS
DEF
MNO
WXYZ
MIC
Connector
Microphone
Connecting the Antenna
Connect the coaxial cable to the body.
Plug the coaxial cable jack into the ANT terminal on the rear panel of the body, then rotate
and tighten it.
Rear panel
Coaxial cable plug

7
Installation
FTM-3200DR Operating Manual
Mobile Installation
The FTM-3200DR must only be installed in vehicles having a 13.8 Volt negative ground
electrical system. Mount the transceiver where the display, controls, and microphone are
easily accessible, using the supplied mounting bracket.
The transceiver may be installed in almost any location, but should not be positioned
near a heating vent nor anywhere where it might interfere with driving (either visually or
mechanically).
Make sure to provide plenty of space on all sides of the transceiver so that air can flow
freely around the radio’s case. Refer to the diagrams showing proper installation proce-
dures.

8
Installation
FTM-3200DR Operating Manual
Power connection
To minimize voltage drop and avoid blowing the vehicle’s fuses, connect the supplied
DC power cable directly to the battery terminals. Do not attempt to defeat or bypass the
DC cable fuse - it is there to protect you, your transceiver, and your vehicle’s electrical
system.
Warning!
Never apply AC power to the power cable of the FTM-3200DR, nor DC voltage
greater than 15.8 Volts. When replacing the fuse, only use a 25-A fuse. Failure
to observe these safety precautions will void the Limited Warranty on this
product.
Before connecting the transceiver, check the voltage at the battery terminals while rev-
ving the engine. If the voltage exceeds 15 Volts, adjust the vehicle’s voltage regulator
before proceeding with installation.
Connect the RED power cable lead to the POSITIVE (+) battery terminal, and the
BLACK power cable lead to the NEGATIVE (–) terminal. If you need to extend the
power cable, use #12 AWG or larger insulated, stranded copper wire. Solder the splice
connections carefully, and wrap the connections thoroughly with insulating electrical
tape.
Before connecting the cable to the transceiver, verify the voltage and polarity at the
voltage at the transceiver end of the DC cable, using a DC voltmeter. Now connect the
transceiver to the DC cable.
Rear panel
Power cable
(DC 13.8 V)
Black
DC power supply
cable (supplied)
DC 12 V battery
Fuse holder
Red
Warning!
• Do not use a DC power supply cable other than the one that is supplied or
specified.
• Do not place anything on the DC power supply cable or step on it.
• Do not use the DC power supply cable with the fuse holder cut off.
• Do not reverse the polarity (positive and negative) when connecting the
battery.

9
Installation
FTM-3200DR Operating Manual
Base Station Installation
The FTM-3200DR is ideal for base station use as well as in mobile installations. The
FTM-3200DR is specifically designed to integrate into your station easily, using the fol-
lowing information as a reference.
AC Power Supplies
Operation of the FTM-3200DR from an AC line requires a power source capable of pro-
viding at least 20 Amps continuously at 13.8 Volts DC. The FP-1023 (USA market only)
and FP-1030A AC Power Supplies are available from your Yaesu dealer to satisfy these
requirements. Other well-regulated power supplies may be used as well, if they meet the
above voltage and current specifications.
Use the DC power cable supplied with the transceiver to make the power connection to
the power supply. Connect the RED power cable lead to the POSITIVE (+) power supply
terminal, and connect the BLACK power cable lead to the NEGATIVE (–) power supply
terminal.
Rear panel
Power cable
(DC 13.8 V)
Black
Direct current
power supply
AC power
outlet
DC power supply
cable (supplied)
Red
Fuse holder

10 FTM-3200DR Operating Manual
Front Panel Controls & Switches
Front Panel
VOL
DIAL
SQL
TXPO D W M W
SETUP
REV D/A V / MM H z
VOL knob
Turning the knob clockwise increases the volume, whereas turning it counterclock-
wise decreases the volume.
Mode/Status indicator
Indicates the transmission/reception status with a two-color combination on the upper
and lower portions of the mode/status indicator.
Communication status Upper portion Lower portion
Receiving analog audio Green Green
Transmitting analog audio Red Red
Receiving digital audio Green Blue
Transmitting digital audio Red Blue
Receiving digital data Green White
Transmitting digital data Red White
Receiving signals with unmatched
audio or data conditions Green Blink in Blue
• Receiving signals with unmatched tone frequency or DCS code.
• Receiving analog audio in digital mode.
• Receiving signals with unmatched SQL code in digital mode.
• Receiving a signal level less than the RF Squelch S-meter level setting.
DIAL Knob
• Allows setting the operating band frequency.
Turning clockwise increases the frequency, whereas turning counterclockwise de-
creases the frequency.
• Allows selecting the desired items for setup, memory registration, group monitoring
operation, etc.
MIC Jack
Connect the provided microphone cable.
