Yakima K979 User manual

1/13
23-13-979-Rev7
Please Recycle
Kia KX5, Steel Roof, 5dr SUV 16+ CN 75 kg (165 lb) 100 kg (220 lb)
Kia Sportage, Steel Roof, 5dr SUV 16-18 EU,ZA 75 kg (165 lb) 100 kg (220 lb)
Kia Sportage, Steel Roof, 5dr SUV 16-Jul 18 AU, NZ 75 kg (165 lb) 100 kg (220 lb)
Kia Sportage, Steel Roof, 5dr SUV 18-21 EU 75 kg (165 lb) 100 kg (220 lb)
Kia Sportage, Steel Roof, 5dr SUV 18+ ZA 75 kg (165 lb) 100 kg (220 lb)
Kia Sportage, Steel Roof, 5dr SUV Aug 18-Sep 21 AU, NZ 75 kg (165 lb) 100 kg (220 lb)
Kia Sportage, Glass Roof,5dr SUV 16+ CN 75 kg (165 lb) 75 kg (165 lb)
Kia Sportage, Glass Roof,5dr SUV 16-18 EU,ZA 75 kg (165 lb) 75 kg (165 lb)
Kia Sportage, Glass Roof,5dr SUV 16-Jul 18 AU, NZ 75 kg (165 lb) 75 kg (165 lb)
Kia Sportage, Glass Roof,5dr SUV 18-21 EU 75 kg (165 lb) 75 kg (165 lb)
Kia Sportage, Glass Roof,5dr SUV 18+ ZA 75 kg (165 lb) 75 kg (165 lb)
Kia Sportage, Glass Roof,5dr SUV Aug 18-Sep 21 AU, NZ 75 kg (165 lb) 75 kg (165 lb)
F T S HD
THD
K979 Instructions
++ =
kg (lb)
MAX
ALWAYS REFER TO OUR WEBSITE FOR THE LATEST VERSION OF INSTRUCTIONS.
BESUCHEN SIE IMMER UNSERE WEBSITES, UM DIE NEUESTE VERSION DER ANWEISUNGEN ZU ERHALTEN.
CONSULTE NUESTRAS PÁGINAS WEB PARA VER LA ÚLTIMA VERSIÓN DE LAS INSTRUCCIONES.
RÉFÉREZ VOUS TOUJOURS À NOS SITES INTERNET POUR CONSULTER LA DERNIÈRE VERSION DES INSTRUCTIONS.
DEN NYESTE VERSJONEN AV INSTRUKSJONENE ER ALLTID TILGJENGELIG PÅ VÅRE NETTSIDER.
CONSULTE SEMPRE OS NOSSOS WEBSITES PARA OBTER A MAIS RECENTE VERSÃO DAS INSTRUÇÕES.
АКТУАЛЬНАЯ ВЕРСИЯ ИНСТРУКЦИИ ДОСТУПНА НА НАШЕМ САЙТЕ.
FARE SEMPRE RIFERIMENTO AI NOSTRI SITI WEB PER L’ULTIMA VERSIONE DELLE ISTRUZIONI.
ZAWSZE SPRAWDZAJ NASZĄSTRONĘINTERNETOWĄ,ABY UZYSKAĆNAJNOWSZĄWERSJĘINSTRUKCJI.
NEJNOVĚJŠÍ VERZI POKYNŮVŽDY NAJDETE NA NAŠÍ WEBOVÉ STRÁNCE.
POSLEDNÚ VERZIU POKYNOV VŽDY NÁJDETE NA NAŠICH WEBOVÝCH STRÁNKACH.
RAADPLEEG ALTIJD ONZE WEBSITES VOOR DE MEEST RECENTE VERSIE VAN DE INSTRUCTIES.
SE ALLTID VÅRA WEBBPLATSER FÖR DEN SENASTE VERSIONEN AV INSTRUKTIONERNA.
DEN NYESTE VERSION AF VEJLEDNINGERNE ER ALTID TILGÆNGELIG PÅ VORES HJEMMESIDER.
ОСТАННЯ ВЕРСІЯ ІНСТРУКЦІЇ ЗАВЖДИ ДОСТУПНА НА НАШОМУ САЙТІ.
KATSO AINA VERKKOSIVUSTOILTAMME UUSIN VERSIO OHJEISTA.
EN
DE
ES
FR
NO
PT
RU
IT
PL
CS
SK
NL
SV
DK
UA
FI
MAX kg (lb)

2/13
23-13-979-Rev7
Please Recycle
8 mm (3/8”) x1
4.9 mm (2/8”) x1
2 mm (1/8”) x1
x2 x2
5 mm (2/8”) x1
5 mm (2/8”) x8
CONTENTS • INHALT • CONTENIDO • CONTENU • INNHOLD • CONTEÚDO • СОДЕРЖАНИЕ • CONTENUTO
ZAWARTOŚĆ • OBSAH • OBSAH • INHOUD • INNEHÅLL • INDHOLD • ЗМІСТ • SISÄLLYS
ATTENTION • ACHTUNG • ATENCIÓN • ATTENTION • OPPMERKSOMHET • ATENÇÃO • ВНИМАНИЕ • ATTENZIONE
UWAGA • UPOZORNĚNÍ • UPOZORNENIE • LET OP • UPPMÄRKSAMHET • OPMÆRKSOMHED • УВАГА • HUOMIO
FLUSH (F) THROUGH (T) HEAVY DUTY (HD) STANDARD (S)
T
FSHD THD
COMPATIBLE WITH • KOMPATIBEL MIT • COMPATIBLE CON • COMPATIBLE AVEC • KOMPATIBEL MED
• COMPATÍVEL COM • СОВМЕСТИМ С• COMPATIBLE CON • KOMPATYBILNY Z • KOMPATIBILNÍ S
• KOMPATIBILNÉ S • COMPATIBLE MET • KOMPATIBEL MED • KOMPATIBEL MED • СУМІСНИЙ З•
YHTEENSOPIVA
TRIM HD (THD)

3/13
23-13-979-Rev7
Please Recycle
!14
2
1
x4
!
2
x8
3
x8
10
10
10 mm (3/8”)
ATTENTION • ACHTUNG • ATENCIÓN • ATTENTION • OPPMERKSOMHET • ATENÇÃO • ВНИМАНИЕ • ATTENZIONE
UWAGA • UPOZORNĚNÍ • UPOZORNENIE • LET OP • UPPMÄRKSAMHET • OPMÆRKSOMHED • УВАГА • HUOMIO
REQUIRED • ERFORDERLICH • REQUERIDOS • OBLIGATOIRE • NØDVENDIG • NECESSÁRIO •
ОБЯЗАТЕЛЬНО • OBBLIGATORIO • POTRZEBY • NEVYHNUTELNÉ • NEVYHNUTNÉ • NODIG
• NÖDVÄNDIG • PÅKRÆVET • ПОТРІБНА • EDELLYTETÄÄN

4/13
23-13-979-Rev7
Please Recycle
4.9 mm (2/8”)
4
x8
5
x2
6
x8
7
x8 x8
8

5/13
23-13-979-Rev7
Please Recycle
8 mm (3/8”)
9
x8 x4
11
x2
12
13
x8
x8
4 Nm
(35 lb-in)
10

6/13
23-13-979-Rev7
Please Recycle
14 15
x4 x4
T
F
HD
S
THD
x10
a
HD/S
F/T

7/13
23-13-979-Rev7
Please Recycle
16 17
x4 x8
25
b
19
x4 x4
18

8/13
23-13-979-Rev7
Please Recycle
c
3 Nm
(27 lb-in)
20 21
22 23
x2 x2
x4 x4
!
1 Nm
(9 lb-in)
24
1 Nm
(9 lb-in)
x4
x4
x4
25

9/13
23-13-979-Rev7
Please Recycle
13
24
26
xx-xx-xx
FR = 00-04-381
= 00-04-382
= 00-04-383
= 00-04-384
FL
RR
RL
FR
FL
RR
RL
PLACEMENT • PLATZIERUNG • COLOCACIÓN • MONTAGE • PLASSERING • COLOCAÇÃO • РАЗМЕЩЕНИЕ • MONTAGGIO
UMIESZCZENIE • UMÍSTĚNÍ • UMIESTNENIE • PLAATSING • PLACERING • PLACERING • РОЗМІЩЕННЯ • SIJOITTAA
xxxxxxxxxx
FR = A744
= A743
= A744
= A743
FL
RR
RL

10/13
23-13-979-Rev7
Please Recycle
27
1
2
X
X
A
B
12AB
Kia KX5, Steel Roof, 5dr SUV 16+ CN X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Steel Roof,5dr SUV 16-18 EU,ZA X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Steel Roof,5dr SUV 16-Jul 18 AU, NZ X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Steel Roof,5dr SUV 18-21 EU X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Steel Roof,5dr SUV 18+ ZA X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Steel Roof,5dr SUV Aug 18-Sep
21
AU, NZ X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Glass Roof, 5dr SUV 16+ CN X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Glass Roof, 5dr SUV 16-18 EU, ZA X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Glass Roof, 5dr SUV 16-Jul 18 AU, NZ X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Glass Roof, 5dr SUV 18-21 EU X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Glass Roof, 5dr SUV 18+ ZA X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
Kia Sportage,Glass Roof, 5dr SUV Aug 18-Sep
21
AU, NZ X = 915 mm (36”) X = 876 mm (34 1/2”) A = 10 mm (3/8”) B = 840 mm (33 1/8”)
PRESS
F
PRESS
T
PRESS
HD
THD
S
T
FT
T
T
HD T
S
T
THD
xx
xx
==
==
==
==
