SAFETY PRECAUTIONS
MAINTENANCE AND REPAIR
• When lifting parts or assemblies, make sure all slings, chains, or cables are correctly fastened, and that the
load being lifted is balanced. Make sure the crane, cables, and chains have the capacity to support the
weight of the load.
• Do not lift heavy parts by hand, use a lifting mechanism.
• Wear safety glasses.
• DISCONNECT THE BATTERY CONNECTOR before doing any maintenance or repair on electric lift trucks.
Disconnect the battery ground cable on internal combustion lift trucks.
• Always use correct blocks to prevent the unit from rolling or falling. See HOW TO PUT THE LIFT TRUCK
ON BLOCKS in the Operating Manual or the Periodic Maintenance section.
• Keep the unit clean and the working area clean and orderly.
• Use the correct tools for the job.
• Keep the tools clean and in good condition.
• Always use APPROVED parts when making repairs. Replacement parts must meet or exceed the
specifications of the original equipment manufacturer.
• Make sure all nuts, bolts, snap rings, and other fastening devices are removed before using force to
remove parts.
• Always fasten a DO NOT OPERATE tag to the controls of the unit when making repairs, or if the unit needs
repairs.
• Be sure to follow the WARNING and CAUTION notes in the instructions.
• Gasoline, Liquid Petroleum Gas (LPG), Compressed Natural Gas (CNG), and Diesel fuel are flammable.
Be sure to follow the necessary safety precautions when handling these fuels and when working on these
fuel systems.
• Batteries generate flammable gas when they are being charged. Keep fire and sparks away from the area.
Make sure the area is well ventilated.
NOTE: The following symbols and words indicate safety information in this man-
ual:
WARNING
Indicates a hazardous situation which, if not avoided, could result in death
or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor
or moderate injury and property damage.
On the lift truck, the WARNING symbol and word are on orange back-
ground. The CAUTION symbol and word are on yellow background.

©2018 Yale Materials Handling Corp.
TABLE OF CONTENTS
General ..................................................................................................................................................................... 1
Threaded Fasteners ..............................................................................................................................................1
Nomenclature, Threads ........................................................................................................................................ 1
Strength Identification ........................................................................................................................................... 2
Cotter (Split) Pins ..................................................................................................................................................3
Fastener Torque Tables ........................................................................................................................................ 8
Conversion Table ................................................................................................................................................ 10
This section is for the following models:
Table of Contents
i

General
THREADED FASTENERS
Threaded fasteners, like bolts, nuts, capscrews, and
studs, are made to specifications that describe the
mechanical strength and hardness of the fastener. A
fastener used in a design application is selected
according to its specifications. Yale® Company buys
parts from many countries. Parts that are purchased
must be to Yale® Company standards. There are
several standards used by these countries in the
manufacture of threaded fasteners. Many of these
fasteners are similar, but cannot be used as a direct
replacement. To make sure that you have the correct
fastener, order fasteners and parts through the Yale®
Parts Depot.
Service persons must use replacement fasteners that
have the same specifications. Fasteners made to each
specification have identification marks for that
specification. This specification is commonly called
"Grade" for SAE standards and "property class" for
metric standards. This section describes the
identification of some common fasteners.
The metric system used by Yale® Company is
described as SI (Le Systeme d'Unites or the
International System of units, also called SI in all
languages). The SI System of measurement is
described in ISO Standard 1000, 1973. A conversion
table of common measurements is shown in Table 7.
NOMENCLATURE, THREADS
The thread design is specified by a series of numbers
and letters for inch and metric fasteners. See Figure 1.
The diameter of the shank of the fastener is shown
first in the series [M12 = 12 mm, M20 = 20 mm (1/2 =
1/2 in., 3/4 = 3/4 in.)].
The number of threads per inch is normally not shown
for inch nomenclature and only the UNC (Unified
National Coarse) or UNF (Unified National Fine) is
shown. This number of threads per inch is not shown
because a UNC or UNF fastener has a standard
number of threads per inch for a specific diameter.
Metric fasteners show the number of threads per
millimeter.
The length of the shank is often indicated as part of
the description of a fastener. This length is shown in
inches for inch fasteners and in millimeters for metric
fasteners.
A capscrew will have the following description:
Metric Inch
M12 × 1.75 × 50 1/2 × 13 UNC × 1-1/2
A B C A B C D
A = Thread Size A = Shank Diameter
B = Pitch B = Number of Threads Per
Unit of Length
C = Length C = type of Thread
D = Shank Length
8000 YRM 0231 General
1

Figure 1. Thread Design
STRENGTH IDENTIFICATION
CAUTION
When fasteners must be replaced, the new
fasteners must be of the same strength or greater
than the original fasteners. The new fasteners
must also be the correct size.
NOTE: Identification marks are according to bolt
strength. The higher the number or the increase in the
number of marks indicates increased bolt strength.
The most common property classes for metric
fasteners are 8.8 and 10.9. The property class is
marked with a number on the head of the capscrew or
on a nut. Property classes less than 8.8 are often not
marked. Grades for inch bolts go from 2 to 8. Grade 2
fasteners normally do not have any marks. The
following tables show the marks that identify the
grades and property classes for different fasteners.
General 8000 YRM 0231
2

COTTER (SPLIT) PINS
Cotter (split) pins are used in many applications on
your forklift. They are typically used to retain parts
such as pins and nuts. Cotter (split) pins are typically
not used as load-bearing members. Service personnel
must use new cotter (split) pins. Do not reuse a cotter
(split) pin. Replacement cotter (split) pin must be of the
correct size. See Table 8.
The legs of a cotter (split) pin are bent for the following
reasons:
•To retain the cotter (split) pin in the part
•To provide clearance between the cotter pin
legs and other parts or members. One or both
cotter (split) pin legs must be bent to provide a
minimum 90° angle between the legs. See
Figure 2.
Figure 2. Minimum Angle Between Cotter Pin Legs
Unless otherwise specified, the legs of chain anchor
cotter (split) pins are to be bent against the pin. See
Figure 3.
1. COTTER PIN
Figure 3. Cotter (Split) Pins Used On Mast Chain
Anchors
8000 YRM 0231 General
3

Table 1. Bolts and Screws
General 8000 YRM 0231
4

Table 2. Studs and Nuts
8000 YRM 0231 General
5

Table 3. Torque Nuts
General 8000 YRM 0231
6

Table 4. Torque Nuts With Nylon Insert
8000 YRM 0231 General
7

FASTENER TORQUE TABLES
Table 5. Torque Values for Metric Fasteners*
Size and Pitch Property Class 5.81Grade 8.82Grade 10.93
N•m lbf ft N•m lbf ft N•m lbf ft
M3 × 0.5 M3.5 × 0.6 M4 ×
0.7 M5 × 0.8 M6 × 1
0.62 0.97
1.44 2.91
4.94
0.5 0.7 1.1
2.1 3.6
0.99 1.55
2.30 4.65
7.90
0.7 1.1 2.1
3.6 6
1.34 2.11
3.13 6.33
10.8
1.0 1.6 2.3
4.7 8
M8 × 1.25 M8 × 1 M10 ×
1.5 M10 × 1.25
12.0 12.8
23.8 25.1
9 9 18 19 19.2 20.5
38.0 40.1
14 15 28 30 26.1 27.9
52 55
19 21 38 41
M12 × 1.75 M12 × 1.25
M14 × 2 M14 × 1.5
41.4 45.3
66 72
31 33 49 53 66 72 105
115
49 53 77 85 90 98 145
155
66 72 105
115
M16 × 2 M16 × 1.5 M20 ×
2.5 M20 × 1.5
105 110 200
225
77 81 150
165
165 175
320 355
122 130
235 260
225 240
435 485
165 175
320 360
M24 × 3 M24 × 2 M27 × 3
M27 × 2
345 375
505 550
255 275
370 405
555 605
810 875
410 445
600 645
755 820
1,100 1,190
560 605
810 880
M30 × 3.5 M30 × 3 M30 ×
2 M33 × 3.5 M33 × 2
690 715
765 940
1,030
510 530
565 695
760
1,100 1,140
1,220 1,500
1,640
810 840
900 1,100
1,210
1,500 1,550
1,660 2,040
2,240
1,100 1,140
1,230 1,510
1,660
M36 × 4 M36 × 3 M39 × 4
M39 × 3
1,200 1,280
1,560 1,640
885 945
1,150 1,210
1,930 2,040
2,490 2,630
1,430 1,510
1,840 1,940
2,620 2,780
3,390 3,570
1,940 2,050
2,500 2,640
M42 × 4.5 M42 × 3 M45 ×
4.5 M45 × 3 M48 × 5 M48
× 3
1,930 2,070
2,410 2,580
2,900 3,160
1,430 1,530
1,780 1,910
2,140 2,330
3,080 3,320
3,850 4,120
4,630 5,040
2,280 2,450
2,840 3,040
3,420 3,720
4,200 4,510
5,240 5,610
6,300 6,860
3,100 3,330
3,870 4,140
4,650 5,060
* Unless otherwise specified 1 Approximately equal to Grade 2 2 Approximately equal to Grade 5 3
Approximately equal to Grade 8
Table 6. Torque Values for Inch Fasteners*
Size and Pitch
Grade 21Grade 52Grade 83
lbf ft N•m lbf ft N•m lbf ft N•m
1/4 1/4 20 UNC 28
UNF
4 5 6 6 6 7 9 10 9 10 12 14
5/16 5/16 18 UNC 24
UNF
8 9 11 13 13 14 18 20 18 20 25 28
3/8 3/8 16 UNC 24
UNF
15 17 20 23 23 26 31 36 33 37 44 50
7/16 7/16 14 UNC 20
UNF
24 27 33 36 37 41 50 56 52 58 71 79
* Unless otherwise specified 1 Approximately equal to metric Property Class 5.8 2 Approximately equal to metric
Property Class 8.8 3 Approximately equal to metric Property Class 10.9
General 8000 YRM 0231
8

Table 6. Torque Values for Inch Fasteners* (Continued)
Size and Pitch
Grade 21Grade 52Grade 83
lbf ft N•m lbf ft N•m lbf ft N•m
1/2 1/2 13 UNC 20
UNF
37 41 50 56 57 85 77 115 80 90 110 120
9/16 9/16 12 UNC 18
UNF
53 59 72 80 82 91 110 125 115 130 155 175
5/8 5/8 11 UNC 18
UNF
73 83 99 110 115 130 155 175 160 180 215 245
3/4 3/4 10 UNC 16
UNF
130 145 175
195
200 225 270 300 280 315 380 425
7/8 7/8 9 UNC 14
UNF
125 140 170
185
320 355 435 480 455 500 615 680
1 1 8 UNC 14
UNF
185 210 255
285
485 540 655 735 680 765 925 1,040
1-1/8 1-1/8 7 UNC 12
UNF
265 300 360
405
595 670 805 905 965 1,080 1,310 1,470
1-1/4 1-1/4 7 UNC 12
UNF
375 415 510
565
840 930 1,140 1,260 1,360 1,500 1,850 2,050
1-3/8 1-3/8 6 UNC 12
UNF
490 560 665
760
1,100 1,250 1,490 1,700 1,780 2,040 2,420 2,760
1-1/2 1-1/2 6 UNC 12
UNF
650 735 885
995
1,460 1,650 1,980 2,230 2,370 2,670 3,210 3,620
* Unless otherwise specified 1 Approximately equal to metric Property Class 5.8 2 Approximately equal to metric
Property Class 8.8 3 Approximately equal to metric Property Class 10.9
8000 YRM 0231 General
9

CONVERSION TABLE
Table 7. Conversion Table for Metric and English units
Multiply By To Get Multiply By To Get
Area
inches 2 (in. 2) × 6.452 = centimeters 2 (cm 2) centimeters 2 (cm 2) × 0.155 = inches 2 (in. 2)
feet 2 (ft 2) × 0.093 = meters 2 (m 2) meters 2 (m 2) × 10.764 = feet 2 (ft 2)
Linear
inches (in.) × 25.4 = millimeters (mm) millimeter (mm) × 0.039 = inches (in.)
feet (ft) × 0.305 = meters (m) meter (m) × 3.281 = feet (ft)
yards (yd) × 0.914 = meters (m) meter (m) × 1.094 = yards (yd)
miles (mi) × 1.609 = kilometers (km) kilometer (km) × 0.621 = miles (mi)
Mass
ounces (oz) × 28.35 = grams (g) grams (g) × 0.035 = ounces (oz)
pounds (lb) × 0.454 = kilograms (kg) kilograms (kg) × 2.205 = pounds (lb)
tons (2,000 lb) × 907.18 = kilograms (kg) kilograms (kg) × 0.001 = tons (2,000 lb)
tons (2,000 lb) × 0.907 = metric ton (t) metric ton (t) × 1.102 = tons (2,000 lb)
Power
horsepower (hp) × 0.746 = kilowatts (kW) kilowatts (kW) × 1.34 = horsepower (hp)
Pressure
pounds/in. 2 (psi) × 6.895 = kilopascal (kPa) kilopascals (kPa) × 0.145 = pounds/in. 2 (psi)
pounds/in. 2 (psi) × 0.007 = megapascal (MPa) megapascals (MPa) × 145.04 = pounds/in. 2 (psi)
Temperature
(°Fahrenheit−32) × 0.56 = °Celsius (C) (°Celsius × 1.8) +32 = °Fahrenheit
Torque
pound inches (lbf in.) × 0.113 = Newton meter (N•m) Newton meter (N•m) × 8.851 = pound inches (lb f in.)
pound feet (lbf ft) × 1.356 = Newton meter (N•m) Newton meter (N•m) × 0.738 = pound feet (lb f ft)
Velocity
miles/hour (mph) × 1.609 = kilometer/hour (km/h) kilometer/hr (km/h) × 0.621 = miles/hour (mph)
Volume
inches 3 (in. 3) × 16.387 = centimeters 3 (cm 3) centimeters 3 (cm 3) × 0.061 = inches 3 (in. 3)
inches 3 (in. 3) × 0.016 = liters (l) liters (l) × 61.024 = inches 3 (in. 3)
quarts, U.S. (qt) × 0.946 = liters (l) liters (l) × 1.057 = quarts, U.S. (qt)
quarts, U.S. (qt) × 0.83 = quarts, Imp. (qt) quarts, Imp. (qt) × 1.205 = quarts, U.S. (qt)
gallons, U.S. (gal) × 3.785 = liters (l) liters (l) × 0.264 = gallons, U.S. (gal)
gallons, U.S. (gal) × 0.83 = gallons, Imp. (gal) gallons, Imp. (gal) × 1.205 = gallons, U.S. (gal)
ounces (oz) × 29.57 = milliliters (ml) milliliters (ml) × 0.034 = ounces (oz)
General 8000 YRM 0231
10

Table 8. Cotter Pin Dimensional Data
Nominal
Size A
Shank Diameter A Head Dia. B Length of Extended
Prong C
Recommended Hole Size
max min min max min min max
1.00 mm
(0.031 in.)
0.90 mm
(0.035 in.)
0.70 mm
(0.028 in.)
1.50 mm
(0.060 in.)
1.52 mm
(0.060 in.)
0.25 mm
(0.01 in.)
0.91 mm
(0.036 in.)
1.37 mm
(0.054 in.)
1.60 mm
(0.047 in.)
1.20 mm
(0.048 in.)
0.90 mm
(0.035 in.)
1.50 mm
(0.060 in.)
2.54 mm
(0.10 in.)
0.51 mm
(0.02 in.)
1.50 mm
(0.059 in.)
1.78 mm
(0.070 in.)
2.00 mm
(0.062 in.)
1.50 mm
(0.060 in.)
1.30 mm
(0.051 in.)
2.40 mm
(0.094 in.)
2.54 mm
(0.10 in.)
0.76 mm
(0.03 in.)
1.90 mm
(0.075 in.)
2.18 mm
(0.086 in.)
2.50 mm
(0.094 in.)
2.30 mm
(0.091 in.)
2.10 mm
(0.083 in.)
4.00 mm
(0.158 in.)
2.54 mm
(0.10 in.)
1.00 mm
(0.04 in.)
2.41 mm
(0.095 in.)
2.95 mm
(0.116 in.)
3.20 mm
(0.125 in.)
3.00 mm
(0.120 in.)
2.70 mm
(0.106 in.)
5.10 mm
(0.201 in.)
3.30 mm
(0.13 in.)
1.52 mm
(0.06 in.)
3.12 mm
(0.123 in.)
3.76 mm
(0.148 in.)
4.00 mm
(0.156 in.)
3.80 mm
(0.150 in.)
3.50 mm
(0.138 in.)
6.50 mm
(0.256 in.)
4.06 mm
(0.16 in.)
1.78 mm
(0.07 in.)
3.94 mm
(0.155 in.)
4.55 mm
(0.179 in.)
5.00 mm
(0.188 in.)
4.60 mm
(0.181 in.)
4.40 mm
(0.172 in.)
8.00 mm
(0.315 in.)
4.06 mm
(0.16 in.)
2.03 mm
(0.08 in.)
4.93 mm
(0.194 in.)
5.33 mm
(0.210 in.)
6.30 mm
(0.250 in.)
5.90 mm
(0.232 in.)
5.60 mm
(0.220 in.)
10.3 mm
(0.406 in.)
4.06 mm
(0.16 in.)
2.03 mm
(0.08 in.)
6.22 mm
(0.245 in.)
6.96 mm
(0.274 in.)
8.00 mm
(0.312 in.)
7.50 mm
(0.295 in.)
7.00 mm
(0.275 in.)
13.1 mm
(0.516 in.)
4.06 mm
(0.16 in.)
2.03 mm
(0.08 in.)
7.85 mm
(0.309 in.)
8.28 mm
(0.326 in.)
9.50 mm
(0.375 in.)
9.50 mm
(0.374 in.)
8.40 mm
(0.329 in.)
16.6 mm
(0.654 in.)
6.35 mm
(0.25 in.)
4.06 mm
(0.16 in.)
9.45 mm
(0.372 in.)
9.73 mm
(0.383 in.)
13.0 mm
(0.500 in.)
12.4 mm
(0.488 in.)
11.9 mm
(0.467 in.)
21.7 mm
(0.854 in.)
6.35 mm
(0.25 in.)
3.05 mm
(0.12 in.)
12.62 mm
(0.497 in.)
13.21 mm
(0.520 in.)
16.0 mm
(0.625 in.)
15.4 mm
(0.606 in.)
15.0 mm
(0.590 in.)
27.0 mm
(1.063 in.)
8.89 mm
(0.35 in.)
3.05 mm
(0.12 in.)
15.80 mm
(0.622 in.)
16.28 mm
(0.641 in.)
8000 YRM 0231 General
11

Table 9. Cotter Pin Dimensional Data
Nominal
Length L
Length Range Nominal Size - Part Numbers
max min
1.00 mm
(0.031 in.)
1.60 mm
(0.047 in.)
2.00 mm
(0.062 in.)
2.50 mm
(0.094 in.)
3.20 mm
(0.125 in.)
6.35 mm
(0.250 in.)
7.10 mm
(0.280 in.)
5.50 mm
(0.217 in.)
0221870 0221875
9.525 mm
(0.375 in.)
10.5 mm
(0.413 in.)
8.80 mm
(0.345 in.)
0221871 0221876
12.7 mm
(0.500 in.)
13.5 mm
(0.530 in.)
11.5 mm
(0.453 in.)
0221872 0221877 0015200 0015211 0015221
19.05 mm
(0.750 in.)
20.5 mm
(0.807 in.)
18.3 mm
(0.720 in.)
0221873 0221878 0015201 0015212 0015222
25.4 mm
(1.000 in.)
26.9 mm
(1.060 in.)
23.9 mm
(0.940 in.)
0221874 0221879 0015202 0015213 0015223
31.75 mm
(1.250 in.)
33.3 mm
(1.310 in.)
29.2 mm
(1.150 in.)
0015203 0015216 0015224
38.1 mm
(1.500 in.)
40.9 mm
(1.610 in.)
36.6 mm
(1.440 in.)
0015204 0015217 0015225
44.45 mm
(1.750 in.)
46.0 mm
(1.810 in.)
42.9 mm
(1.690 in.)
0015205 0015218 0015226
50.8 mm
(2.000 in.)
52.3 mm
(2.060 in.)
49.3 mm
(1.940 in.)
0015206 0015219 0015227
57.15 mm
(2.250 in.)
58.7 mm
(2.310 in.)
55.1 mm
(2.170 in.)
0015220 0056997
63.5 mm
(2.500 in.)
65.0 mm
(2.560 in.)
62.0 mm
(2.440 in.)
0221894 0015229
69.85 mm
(2.750 in.)
72.1 mm
(2.840 in.)
68.3 mm
(2.690 in.)
0015230
76.2 mm
(3.000 in.)
81.3 mm
(3.200 in.)
74.7 mm
(2.940 in.)
0015279
88.9 mm
(3.500 in.)
91.4 mm
(3.600 in.)
87.4 mm
(3.440 in.)
General 8000 YRM 0231
12

Table 9. Cotter Pin Dimensional Data (Continued)
Nominal
Length L
Length Range Nominal Size - Part Numbers
max min
1.00 mm
(0.031 in.)
1.60 mm
(0.047 in.)
2.00 mm
(0.062 in.)
2.50 mm
(0.094 in.)
3.20 mm
(0.125 in.)
101.6 mm
(4.000 in.)
113.3 mm
(4.460 in.)
98.8 mm
(3.890 in.)
127.0 mm
(5.000 in.)
128.5 mm
(5.060 in.)
123.7 mm
(4.870 in.)
152.4 mm
(6.000 in.)
153.9 mm
(3.060 in.)
5.460 mm
(138.7 in.)
Table 10. Cotter Pin Dimensional Data
Nominal
Length L
Length Range Nominal Size - Part Numbers
max min
4.00 mm
(0.156 in.)
5.00 mm
(0.188 in.)
6.30 mm
(0.250 in.)
8.00 mm
(0.312 in.)
9.52 mm
(0.375 in.)
6.35 mm
(0.250 in.)
7.10 mm
(0.280 in.)
5.50 mm
(0.217 in.)
9.525 mm
(0.375 in.)
10.5 mm
(0.413 in.)
8.80 mm
(0.345 in.)
12.7 mm
(0.500 in.)
13.5 mm
(0.530 in.)
11.5 mm
(0.453 in.)
19.05 mm
(0.750 in.)
20.5 mm
(0.807 in.)
18.3 mm
(0.720 in.)
0015232 0015241
8000 YRM 0231 General
13

Table 10. Cotter Pin Dimensional Data (Continued)
Nominal
Length L
Length Range Nominal Size - Part Numbers
max min
4.00 mm
(0.156 in.)
5.00 mm
(0.188 in.)
6.30 mm
(0.250 in.)
8.00 mm
(0.312 in.)
9.52 mm
(0.375 in.)
25.4 mm
(1.000 in.)
26.9 mm
(1.060 in.)
23.9 mm
(0.940 in.)
0015233 0015242 0015251 0015261
31.75 mm
(1.250 in.)
33.3 mm
(1.310 in.)
29.2 mm
(1.150 in.)
0015234 0015243 0015252 0015262 0221884
38.1 mm
(1.500 in.)
40.9 mm
(1.610 in.)
36.6 mm
(1.440 in.)
0015235 0015244 0015253 0015263 0221885
44.45 mm
(1.750 in.)
46.0 mm
(1.810 in.)
42.9 mm
(1.690 in.)
0015236 0015245 0015254 0015264 0221886
50.8 mm
(2.000 in.)
52.3 mm
(2.060 in.)
49.3 mm
(1.940 in.)
0015237 0015246 0015255 0015265 0015271
57.15 mm
(2.250 in.)
58.7 mm
(2.310 in.)
55.1 mm
(2.170 in.)
0015238 0015247 0015256 0221880 0221887
63.5 mm
(2.500 in.)
65.0 mm
(2.560 in.)
62.0 mm
(2.440 in.)
0015240 0015248 0015257 0221881 0015273
69.85 mm
(2.750 in.)
72.1 mm
(2.840 in.)
68.3 mm
(2.690 in.)
0015280 0015249 0015258 0221882 0015286
76.2 mm
(3.000 in.)
81.3 mm
(3.200 in.)
74.7 mm
(2.940 in.)
0015283 0015250 0015259 0015267 0015272
88.9 mm
(3.500 in.)
91.4 mm
(3.600 in.)
87.4 mm
(3.440 in.)
0015239 0015284 0015266 0015274
101.6 mm
(4.000 in.)
113.3 mm
(4.460 in.)
98.8 mm
(3.890 in.)
0015301 0015260 0128754 0015275
127.0 mm
(5.000 in.)
128.5 mm
(5.060 in.)
123.7 mm
(4.870 in.)
0221883 0015277
152.4 mm
(6.000 in.)
153.9 mm
(3.060 in.)
5.460 mm
(138.7 in.)
0221888
General 8000 YRM 0231
14

Table 11. Cotter Pin Dimensional Data
Nominal Length L Length Range Nominal Size - Part Numbers
max min 13.0 mm (0.500 in.) 16.00 mm (0.625 in.)
19.05 mm (0.750 in.) 20.5 mm (0.807 in.) 18.3 mm (0.720 in.)
25.4 mm (1.00 in.) 26.9 mm (1.060 in.) 23.9 mm (0.940 in.)
31.75 mm (1.250 in.) 33.3 mm (1.310 in.) 29.2 mm (1.150 in.)
38.1 mm (1.500 in.) 40.9 mm (1.610 in.) 36.6 mm (1.440 in.)
44.45 mm (1.750 in.) 46.0 mm (1.810 in.) 42.9 mm (1.690 in.) 0221889
50.8 mm (2.000 in.) 52.3 mm (2.060 in.) 49.3 mm (1.940 in.) 0221890
57.15 mm (2.250 in.) 58.7 mm (2.310 in.) 55.1 mm (2.170 in.) 0221891
63.5 mm (2.500 in.) 65.0 mm (2.560 in.) 62.0 mm (2.440 in.) 0221892
69.85 mm (2.750 in.) 72.1 mm (2.840 in.) 68.3 mm (2.690 in.) 0221893 0221895
76.2 mm (3.000 in.) 81.3 mm (3.200 in.) 74.7 mm (2.940 in.) 0015291 0221896
88.9 mm (3.500 in.) 91.4 mm (3.600 in.) 87.4 mm (3.440 in.) 0015292 0221897
101.6 mm (4.000 in.) 113.3 mm (4.460 in.) 98.8 mm (3.890 in.) 0015293 0221898
127.0 mm (5.000 in.) 128.5 mm (5.060 in.) 123.7 mm (4.870 in.) 0015295 0221899
152.4 mm (6.000 in.) 153.9 mm (3.060 in.) 138.7 mm (5.460 in.) 0015297 0221900
8000 YRM 0231 General
15

NOTES
16
