Yamaha A5000 Editor User manual

HAMAMATSU,JAPAN
1.57K-859 I Printed in Japan2000.01
CONTENTS
SPECIFICATIONS ................................................................................3
PANEL LAYOUT ..................................................................................4
CIRCUITBOARDLAYOUT ...................................................................5
BLOCKDIAGRAM ...............................................................................6
DISASSEMBLY PROCEDURE ............................................................7
LSIPINDESCRIPTION ......................................................................10
IC BLOCK DIAGRAM .........................................................................16
TEST PROGRAM ............................................................................. 19
ERROR MASSAGE ...........................................................................31
MIDIDATAFORMAT ..........................................................................32
MIDIIMPLEMENTATIONCHART........................................................43
PARTSLIST
OVERALLCIRCUITDIAGRAM
CIRCUITBOARDS
SERVICE MANUAL
SY 011491
A500019991210-229000
A400019991210-149000
PROFESSIONAL SAMPLER

A5000/A4000
IMPORTANT NOTICE
This manual has been provided for the use of authorized Yamaha Retailers and their service personnel. It has been
assumed that basic service procedures inherent to the industry, and more specifically Yamaha Products, are
already known and understood by the users, and have therefore not been restated.
WARNING: Failure to follow appropriate service and safety procedures when servicing this product may
result in personal injury, destruction of expensive components and failure of the product to per
form as specified. For these reasons, we advise all Yamaha product owners that all service
required should be performed by an authorized Yamaha Retailer or the appointed service
repre sentative.
IMPORTANT: This presentation or sale of this manual to any individual or firm does not constitute authoriza-
tion, certification, recognition of any applicable technical capabilities, or establish a principal-
agent relationship of any form.
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research
engineering, and service departments of Yamaha are continually striving to improve Yamaha products. Modifica-
tions are, therefor, inevitable and changes in specification sre subject to change without notice or obligation to
retrofit. Should any discrepancy appear to exist, please contact the distributor's Service Division.
WARNING: Static discharges can destroy expensive components. Discharge any static electricity your
body may have accumulated by grounding yourself to the ground buss in the unit (heavy gauge
black wires connect to this buss).
IMPORTANT: Turn the unit OFF during disassembly and parts replacement. Recheck all work before you
apply power to the unit.
WARNING: CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition, other electrical / electronic and / or
plastic (where applicable) components may also contain traces of chemicals found by the California Health and
Welfare Agency (and possibly other entities) to cause cancer and / or birth defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL / ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY
REASON WHAT SO EVER!
Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or
expose eyes to solder / flux vapor!
If you come in contact with solder or components located inside the enclosure of this product, wash your hands
before handling food.
WARNING
Components having special characteristics are marked and must be replaced with parts having specification equal to those
originally installed.

A5000/A4000
3
SPECIFICATION
Tone generation method
AWM2 tone generator
Maximum Polyphony
126 notes (64 notes on the A4000), 32 multi-timbre parts (16 parts on the A4000)
A/D conversion
20 bit 64-times oversampling
D/A conversion
24 bit 8-times oversampling
Digital I/O (only when AIEB1 I/O expansion board is installed)
Input/output DIGITAL connectors S/P-DIF (coaxial)
OPTICAL connectors S/P-DIF (optical)
Input frequency 48 kHz, 44.1 kHz, 32 kHz
Output frequency 44.1 kHz
Sampling frequency
Analog input 44.1, 22.05, 11.025 kHz, 5.5125 kHz (mono and stereo)
Digital input (only when AIEB1 I/O expansion board is installed)
48 kHz, 44.1 kHz, 32 kHz external synchronized recording
(stereo only)
1/2, 1/4 and 1/8 undersampling is supported
Internal sample memory capacity
Standard 4 Mbytes (installed on-board)
Maximum 128 Mbytes
(When four 32 Mbyte 72 pin SIMM modules are installed. The on-
board 4 Mbytes are unused only if memory has been expanded to the
maximum.)
Sampling time
Maximum sample length
32 Mbytes monaural
64 Mbytes stereo
Maximum sampling time (mono or stereo)
6 minutes 20 seconds (44.1 kHz)
12 minutes 40 seconds (22.05 kHz)
25 minutes 21 seconds (11.025 kHz)
50 minutes 43 seconds (5.5125 kHz)
Effects
6 effect blocks (3 on the A4000)
Total equalizer (4 bands)
Sample equalizer
Program
128 program
Sequencer
Real-time recording and playback
Front panel
POWER switch
INPUT L,R jacks (phone x 2)
REC VOLUME (L& R shared)
MASTER VOLUME (L&R shared, STEREO OUT & PHONES shared)
PHONES OUTPUT jack
Knobs (1 - 5)
Mode buttons (PLAY, EDIT, REC, DISK, UTILITY)
Function buttons (six buttons)
COMMAND/EXIT button
ASSIGNABLE button
AUDITION button
LCD (320 x 80 dot, LED backlight)
LCD contrast control
3.5" 2HD/2DD dual mode floppy disk drive
Rear panel
STEREO OUT L/MONO, R (phone jack x 2)
ASSIGNABLE OUT L, R (phone jack x 2)
MIDI IN-A/B, OUT, THRU-A/B (IN, OUT, THRU on the A4000)
SCSI (half-pitch, 50-pin)
Expansion board slot
Power supply connector (AC inlet)
Fan
Dimensions
Two-space rackmount unit
W 480 mm x D 461 mm x H 90 mm (18-7/8” x 18-1/8” x 3-9/16”)
Weight
8.0 kg (17l bs 10 oz)
Included items
Power cable x1
CD-ROM set
(See the separate “Guide for the Accompanying Disks” booklet)
FD x 4
Power Cable for Internal Hard Disk (long) x1
Power Cable for ZIP Drive (short) x 1
SCSI Cable for Internal Hard Disk x 1
IDE Cable for Internal Hard Disk x 1
Owner’s manual x1
Options (made by Yamaha)
AIEB1: I/O expansion board
Internal expansion devices (made by other manufacturers)
Expansion memory
(use a pair of identical-size 72pin SIMM modules of the following types)
Access time 70 ns or less
Bit Width x 32 (no parity) or x 36 bit (parity)
Fast Page or EDO, JEDEC standard.
Capacity 4 megabyte/8 megabyte/16 megabyte/32 megabyte
Internal hard disk drive (3.5 inch) performance requirements
Interface 50-pin SCSI or 40-pin IDE
Power supply +5V maximum840mA
+12 V maximum2400mA
Internal ZIP Drive
Interface 40-pin IDE (ATAPI)
Power supply +5V 0.8 A

A5000/A4000
4
PANEL LAYOUT
Front Panel
Rear Panel
1 AC inlet
2 Midi In-A, In-B, Out, Thru-A, Thru-B (A5000)
connectors / Midi In, Out, Thru (A4000) connectors
3 Assignable Out L, R jacks
4 Stereo Out L/Mono, R jacks
5 SCSI connector
6 Optical In, Out connectors
7 Digital In, Out connectors
8 Assignable Out jacks 1-6
1 Master Vol [Master Volume]
2 Rec Vol [Recording Volume]
3 Phones jack
4 Input L, Input R jacks
5 LCD Contrast
6 Display
7 Knobs 1-5
8 Mode buttons
9 Function buttons [F1]-[F6]
10 Command Exit button
11 Assignable button
12 Audition button
13 Floppy Disk Drive
14 Power switch

A5000/A4000
5
CIRCUIT BOARD LAYOUT

A5000/A4000
6
BLOCK DIAGRAM
28CA1-8815099

A5000/A4000
7
1. Top Cover
1-1 Remove the sixteen (16) screws marked [510] and slide the Top Cover to the back side. The top cover can be then
removed.
DISASSEMBLY PROCEDURE
2. Circuit Boards and Unit
After removing the top cover, remove the following screws. Each circuit board can then be removed.
Note: *1 Before removing the DM, remove the HDD Ass'y.
*2 Two for A4000.
*3 Before removing the FDD Ass'y and the PS cover Ass'y, remove the Push Rod.
*4 Before removing the PS and Fan Ass’y, remove the PS cover Ass’y.
(Fig.1)
Circuit Boards and Unit Ref.No. Screw Qty
HDDBracket
DM*1
FDD Bracket*3
PS Cover Ass'y
PS*4
Fan Ass’y*4
[220]
[120]
[130]
[140]
[150]
[190]
[90]
[100]
[30]
[50]
[60]
[L40]
[L50]
Bind Head Tapping Screw-B 3.0X6 MFZN2Y (EP600130) (fig.2)
Bind Head Tapping Screw-B 3.0X6 MFZN2Y (EP600130) (fig.3)
Bonding Head Screw-B 3.0X10 MFZN2BL (VQ049800)(fig.3)
Bind Head Tapping Screw-P 3.0X8 MFZN2BL (EP630220) (fig.3)
Pan Head Screw 2.5X6 SUS (VV342700)(fig.3)
Bind Head Tapping Screw-B 3.0X6 MFZN2Y (EP600130) (fig.2)
Bonding Head Screw-B 3.0X10 MFZN2BL (VQ049800)(fig.2)
Bind Head Tapping Screw-B 4.0X8 MFZN2BL (EG340190) (fig.2)
Bind Head Tapping Screw-B 3.0X6 MFZN2Y (EP600130) (fig.3)
Bind Head Tapping Screw-P 3.0X8 MFZN2BL (EP630220) (fig.2)
Bind Head Tapping Screw-B 4.0X8 MFZN2BL (EG340190) (fig.3)
Flat Head Screw 3.0X25 MFN133 (V4814400) (fig.3)
Hexagonal Nut 3.0 MFZN2Y (VA211900) (fig.3)
4
13
2
4(2)*2
2
4
3
2
7
2
1
4
4

A5000/A4000
8
3. Front Panel
3-1 Remove the knob marked [440], [450], [460].
3-2 Remove the three (3) screws marked [410]. And remove the Front Panel from the Lower Case Assembly.
(Fig.2)
(Fig.3)
(Fig.4)

A5000/A4000
9
4. Circuit Boards and Unit
After removing the front panel, remove the following screws. Each circuit board can then be removed.(Fig.5)
(Fig.5)
Ref.No. Screw Qty
JK
RE
VR
PNA
LCD
[S230]
[L170]
-
-
[L170]
[S140]
[S70]
[S110]
Hexagonal Nut 14X2 M12 (ES200210)
Bind Head Tapping-B 3.0X6 MFZN2Y (EP600130)
Washer
Nut
Bind Head Tapping-B 3.0X6 MFZN2Y (EP600130)
Bind Head Tapping-B 3.0X6 MFZN2Y (EP600130)
Cup Tapping Screw-B 3.0X6 MFZN2Y (V2644100)
Bind Head Tapping-B 3.0X6 MFZN2Y (EP600130)
3
2
5
5
2
4
4
4
Circuit Boards and Unit

A5000/A4000
10
LSI PIN DESCRIPTION
(IC507)TC203C760HF-002 (XS725A00) SWP30B (AWM Tone Generator coped with MEG) Standard Wave Processor
PIN
NO. NAME I/O FUNCTION PIN NO. NAME I/O FUNCTION
1Vss
(
Ground
)
121 VSS -
(
Ground
)
2 CA0 I 122 HMD0 I/O
3 CA1 I 123 HMD1 I/O
4 CA2 I 124 HMD2 I/O
5 CA3 I 125 HMD3 I/O
6 CA4 I 126 HMD4 I/O
7 CA5 I Address bus of internal re
g
ister 127 HMD5 I/O
8 CA6 I 128 HMD6 I/O Wave memor
y
data bus
(
Upper 16 bits
)
9 CA7 I 129 HMD7 I/O
10 CA8 I 130 HMD8 I/O
11 CA9 I 131 HMD9 I/O
12 CA10 I 132 HMD10 I/O
13 CA11 I 133 HMD11 I/O
14 VSS -
(
Ground
)
134 HMD12 I/O
15 CD0 I/O 135 HMD13 I/O
16 CD1 I/O 136 HMD14 I/O
17 CD2 I/O 137 HMD15 I/O
18 CD3 I/O 138 VSS -
(
Ground
)
19 CD4 I/O 139 HMA0 O
20 CD5 I/O 140 HMA1 O
21 CD6 I/O 141 HMA2 O
22 CD7 I/O 142 HMA3 O
23 CD8 I/O Data bus of internal re
g
ister 143 HMA4 O
24 CD9 I/O 144 HMA5 O
25 CD10 I/O 145 HMA6 O
26 CD11 I/O 146 HMA7 O
27 CD12 I/O 147 HMA8 O
28 CD13 I/O 148 HMA9 O
29 CD14 I/O 149 HMA10 O
30 VDD - (Power supply) 150 VDD - (Power supply)
31 VSS - (Ground) 151 VSS - (Ground)
32 CD15 I/O 152 HMA11 O
33 CSN I Chip select 153 HMA12 O Wave memor
y
address bus
34 WRN I Write strobe 154 HMA13 O
35 RDN I Read strobe 155 HMA14 O
36 VDD -
(
Power suppl
y)
156 HMA15 O
37 SYSH0 O 157 HMA16 O
38 SYSH1 O 158 HMA17 O
39 SYSH2 O 159 HMA18 O
40 SYSH3 O NSYS/LNSYS upper 16 bits output 160 HMA19 O
41 SYSH4 O 161 HMA20 O
42 SYSH5 O 162 HMA21 O
43 SYSH6 O 163 HMA22 O
44 SYSH7 O 164 HMA23 O
45 KONO0 O 165 HMA24 O
46 KONO1 O Ke
y
on data 166 VSS -
(
Ground
)
47 KONO2 O 167 MRASN O RAS when DRAM
(
s
)
is connected to wave memor
y
48 KONO3 O 168 MCASN O CAS when DRAM
(
s
)
is connected to wave memor
y
49 VSS -
(
Ground
)
169 MOEN O Wave memor
y
output enable
50 SYSL0 I/O 170 MWEN O Wave memor
y
write enable
51 SYSL1 I/O 171 VSS -
(
Ground
)
52 SYSL2 I/O 172 LMD0 I/O
53 SYSL3 I/O NSYS input/LNSYS output lower 8 bits 173 LMD1 I/O
54 SYSL4 I/O 174 LMD2 I/O
55 SYSL5 I/O 175 LMD3 I/O
56 SYSL6 I/O 176 LMD4 I/O
57 SYSL7 I/O 177 LMD5 I/O
58 KONI0 I 178 LMD6 I/O
59 KONI1 I Key on data input 179 LMD7 I/O Wave memory data bus (Lower 16 bits)
60 VDD - (Power supply) 180 VDD - (Power supply)
61 VSS - (Ground) 181 VSS - (Ground)
62 KONI2 I 182 LMD8 I/O
63 KONI3 I 183 LMD9 I/O
64 DAC0 O DAC output 184 LMD10 I/O
65 DAC1 O 185 LMD11 I/O
66 WCLK O DAC0/DAC1 word clock 186 LMD12 I/O
67 MELO0 O 187 LMD13 I/O
68 MELO1 O 188 LMD14 I/O
69 MELO2 O 189 LMD15 I/O
70 MELO3 O MEL wave data output 190 VSS -
(
Ground
)
71 MELO4 O 191 LMA0 O
72 MELO5 O 192 LMA1 O
73 MELO6 O 193 LMA2 O
74 MELO7 O 194 LMA3 O
75 VDD -
(
Power suppl
y)
195 LMA4 O
76 ADLR O ADC word clock 196 LMA5 O
77 MELI0 I 197 LMA6 O
78 MELI1 I 198 LMA7 O
79 MELI2 I 199 LMA8 O
80 MELI3 I MEL wave data input 200 LMA9 O
81 MELI4 I 201 LMA10 O
82 MELI5 I 202 LMA11 O
83 MELI6 I 203 VSS -
(
Ground
)
84 MELI7 I 204 LMA12 O
85 VSS -
(
Ground
)
205 LMA13 O Wave memor
y
address bus
(
Lower data memor
y)
86 RCASN O DRAM column address strobe
(
RAS si
g
nal
)
206 LMA14 O
87 RA8 O 207 LMA15 O
88 RA7 O 208 LMA16 O
89 RA6 O 209 LMA17 O
90 VDD - (Power supply) 210 VDD - (Power supply)
91 VSS - (Ground) 211 VSS - (Ground)
92 RA5 O DRAM address bus 212 LMA18 O
93 RA4 O 213 LMA19 O
94 RA3 O 214 LMA20 O
95 RA2 O 215 LMA21 O
96 RA1 O 216 LMA22 O
97 RA0 O 217 LMA23 O
98 RRASN O DRAM row address strobe
(
RAS si
g
nal
)
218 LMA24 O
99 RWEN O DARM write enable 219 VSS -
(
Ground
)
100 VSS -
(
Ground
)
220 SYO O S
y
nc.si
g
nal for master clock
101 RD7 I/O 221 SYOD O S
y
nc.si
g
nal for HCLK/QCLK
102 RD6 I/O 222 QCLK O 1/12 master clock
(
64Fs
)
103 RD5 I/O 223 HCLK O 1/6 master clock
(
128Fs
)
104 RD4 I/O 224 CK256 O 1/3 master clock
(
256Fs
)
105 RD3 I/O 225 SYSCLK O 1/2 master clock
(
384Fs
)
106 RD2 I/O 226 VDD -
(
Power suppl
y)
107 RD1 I/O 227 SYI I S
y
nc.clock
108 RD0 I/O 228 MCLKI I Master clock input
109 VSS -
(
Ground
)
229 MCLKO O Master clock output
110 RD17 I/O 230 VDD -
(
Power suppl
y)
111 RD16 I/O DRAM data bus 231 XIN I Cr
y
stal osc. input
112 RD15 I/O 232 XOUT O Cr
y
stal osc. output
113 RD14 I/O 233 VSS -
(
Ground
)
114 RD13 I/O 234 ICN I Initial clear
115 RD12 I/O 235 CHIP2 I 2 chips mode enable
116 RD11 I/O 236 SLAVE I Master/Slave select when 2 chipsmode
117 RD10 I/O 237 TESTON I
118 RD9 I/O 238 ACIN I Test pin
119 RD8 I/O 239 DCTEST I
120 VDD -
(
Power suppl
y)
240 VDD -
(
Power suppl
y)

A5000/A4000
11
D65611GB-039-3B (XS323A00) ENI
PIN
NO.
NAME I/O FUNCTION
PIN
NO.
NAME I/O FUNCTION
1
CLRN I
Clear Status 23
P3 I/O
2
E1A I
Rotary Encoder 1 Input A 24
P4 I/O
3
E1B I
Rotary Encoder 1 Input B 25
P5 I/O
4
E2A I
Rotary Encoder 2 Input A 26
P6 I/O
I/O Port
5
E2B I
Rotary Encoder 2 Input B 27
P7 I/O
6
E3A I
Rotary Encoder 3 Input A 28
D0 I/O
7
E3B I
Rotary Encoder 3 Input B 29
D1 I/O
8
E4A I
Rotary Encoder 4 Input A 30
GND -
Ground
9
E4B I
Rotary Encoder 4 Input B 31
D2 I/O
10
E5A I
Rotary Encoder 5 Input A 32
D3 I/O
CPU Data Bus
11
E5B I
Rotary Encoder 5 Input B 33
D4 I/O
12
E6A I
Rotary Encoder 6 Input A 34
GND -
Ground
13
E6B I
Rotary Encoder 6 Input B 35
D5 I/O
14
E7A I
Rotary Encoder 7 Input A 36
D6 I/O
CPU Data Bus
15
E7B I
Rotary Encoder 7 Input B 37
D7 I/O
16
VDD -
Power Supply 38
GND -
Ground
17
GND -
Ground 39
VDD -
Power Supply
18
E8A I
Rotary Encoder 8 Input A 40
A0 I
Address Bus
19
E8B I
Rotary Encoder 8 Input B 41
A1 I
Address Bus
20
P0 I/O
42
WRN I
Write Enable
21
P1 I/O
I/O Port 43
RDN I
Read Enable
22
P2 I/O
44
CSN I
Chip Select
D65621GF-028-3B9 (XS370A00) SMI
PIN
NO.
NAME I/O FUNCTION
PIN
NO.
NAME I/O FUNCTION
1
LMA24 I 41
VDD - Power Supply
2
LMA23 I 42
L1RAS2 O
RAS2 for LoMem SIMM 1
3
LMA22 I 43
L1RAS3 O
RAS3 for LoMem SIMM 1
4
LMA21 I Low Memory Address 44
GND - Ground
5
LMA20 I 45
HDRAS0 O
RAS for HiMem DRAM 0
6
LMA19 I 46
HDRAS1 O
RAS for HiMem DRAM 1
7
LMA18 I 47
GND - Ground
8
HMA24
I 48
VDD - Power Supply
9
HMA23
I High Memory Address 49
LDRAS0 O
RAS for LoMem DRAM 0
10
HMA22
I 50
LDRAS1 O
RAS for LoMem DRAM 1
11
HMA21
I 51
LMA1 I Low Memory Address
12
GND - Ground 52
LMA0 I
13
HMA20
I 53
GND - No.53
14
HMA19
I High Memory Address 54
LMA1X O
Low Memory Address Exchanged
15
HMA18
I 55
LMA0X O
16
RASN I Row Address Strobe 56
GND - Ground
17
H0RAS0
O
RAS0 for HiMem SIMM 0 57
VDD - Power Supply
18
H0RAS1
O
RAS1 for HiMem SIMM 0 58
HMA1 I High Memory Address
19
GND - Ground 59
HMA0 I
20
H0RAS2
O
RAS2 for HiMem SIMM 0 60
HMA1X O
High Memory Address Exchanged
21
H0RAS3
O
RAS3 for HiMem SIMM 0 61
HMA0X O
22
GND - Ground 62
D0 I Data Input
23
VDD - Power Supply 63
D1 I
24
L0RAS0
O
RAS0 for LoMem SIMM 0 64
GND - Ground
25
L0RAS1
O
RAS1 for LoMem SIMM 0 65
D2 I
26
GND - Ground 66
D3 I Data Input
27
L0RAS2
O
RAS2 for LoMem SIMM 0 67
D4 I
28
L0RAS3
O
RAS3 for LoMem SIMM 0 68
D5 I
29
GND - Ground 69
A2 I Address
30
VDD - Power Supply 70
WRN I Write
31
H1RAS0
O
RAS0 for HiMem SIMM 1 71
GND - Ground
32
H1RAS1
O
RAS1 for HiMem SIMM 1 72
VDD - Power Supply
33
GND - Ground 73
CSN I Chip Select
34
VDD - Power Supply 74
A0 I Address
35
H1RAS2
O
RAS2 for HiMem SIMM 1 75
A1 I
36
H1RAS3
O
RAS3 for HiMem SIMM 1 76
MCLK I Clock (37MHz)
37
GND - Ground 77
SYI I Sync Clock (48kHz)
38
L1RAS0
O
RAS0 for LoMem SIMM 1 78
HBANK O
HiMem Bank Select 01/23
39
L1RAS1
O
RAS1 for LoMem SIMM 1 79
LBANK O
LoMem Bank Select 01/23
40
GND -
Ground 80
REFRN O
RefreshTiming
(IC11)
(IC516)

A5000/A4000
12
D65636GF-104-3B9 (XS369A00) SPF
PIN
NO. NAME I/O FUNCTION PIN NO. NAME I/O FUNCTION
1 ICN I Initial Clear 41 SYNIO I Serial Input0 Sync Clock(48kHz)
2 VDD - Power Supply 42 VDD - Power Supply
3 GND - Ground 43 GND - Ground
4 D0 I/O Data Bus 44 DIN0 I Serial Input0 Data Input(1.6MHz)
5 D1 I/O 45 CK256I1 I Serial Input1 256fs Clock(12.8MHz)
6 GND - Ground 46 BCKI1 I Serial Input1 Bit Clock(3.2MHz)
7 D2 I/O Data Bus 47 SYNI1 I Serial Input1 Sync Clock(48kHz)
8 D3 I/O 48 DIN1 I Serial Input1 Data Input(1.6MHz)
9 GND - Ground 49 DAC256O O 256fs Clock for DAC(12.8MHz)
10 VDD - Power Supply 50 DAC64O O 256fs Clock for DAC(3.2MHz)
11 D4 I/O Data Bus 51 DACWCKO O Word Clock for DAC(48kHz)
12 D5 I/O 52 DACDTI I DAC Data Input(1.6MHz)
13 GND - Ground 53 DACDTO O DAC Data Output(1.6MHz)
14 D6 I/O Data Bus 54 VDD - Power Supply
15 D7 I/O 55 GND - Ground
16 A4 I Address 56 MONMELO O Monitor MEL Output(1.6MHz)
17 CSN I Chip Select 57 DIT128O O 128fs Clock for DIT(6.4MHz)
18 WRN I Write 58 DITWCKO O Word Clock for DIT(48kHz)
19 RDN I Read 59 MUTEI I Mute Request Input(from CPU)
20 DREQN O DMA Request 60 MUTENO O Mute Request Output(to DAC&DIT)
21 DACKN I DMA Acknowledge 61 ERRI I PLL Error Input(from DIR)
22 GND - Ground 62 GND - Ground
23 VDD - Power Supply 63 VDD - Power Supply
24 D8 I/O Data Bus 64 ERRIRQN O PLL Error IRQ
25 D9 I/O 65 TGRESN O TG Reset Signal
26 GND - Ground 66 P7 I/O
27 D10 I/O Data Bus 67 P6 I/O
28 D11 I/O 68 P5 I/O
29 GND - Ground 69 P4 I/O I/O Port
30 VDD - Power Supply 70 P3 I/O
31 D12 I/O Data Bus 71 P2 I/O
32 D13 I/O 72 P1 I/O
33 GND - Ground 73 P0 I/O
34 D14 I/O Data Bus 74 OCSN I Option Chip Select0
35 D15 I/O 75 ODACKN I Option DMA Acknowledge
36 A1 I 76 ODDIR I Option DMA Direction
37 A2 I Address 77 OBOEN O Option Bus Buffer Output Enable
38 A3 I 78 OBDIR O Option Bus Buffer Direction
39 CK256IO I Serial Input0 256fs Clock(12.8MHz) 79 CSOUTN O Chip Select Out at A4=1, A3=1
40 BCKIO I
Serial Input0 Bit Clock(3.2MHz) 80 ASSIGN O WritePulseOutatA4=1,A3=0,WR=0
(IC11)
PCM1800 (XU770A00) A/D Converter
PIN
NO.
NAME
I/O
FUNCTION
PIN
NO.
NAME
I/O
FUNCTION
1 VINL I Analog input (L ch.) 13 LRCK I/O Sampling clock input/ output
2 VREF1 Reference 1 decoupling cap. 14 BCK I/O Bit clock input/ output
3 REFCOM Reference decoupling common 15 DOUT O
Audio data output
4 VREF2 Reference 2 decoupling cap. 16 SYSCK I System clock input
5 VINR I Analog input (R ch.) 17 DGND Digital ground
6 RSTB I Reset input active “L” 18 VDD Power supply +5V
7 BYPAS I LCF bypass control 19 CINNR Anti-aliasing filter cap. (-) R ch.
8 FMT0 I Audio data format 0 20 CINPR Anti-aliasing filter cap. (+) R ch.
9 FMT1 I Audio data format 1 21 CINNL Anti-aliasing filter cap. (-) L ch.
10 MODE0 I Master/ Slave mode selection 0 22 CINPL Anti-aliasing filter cap. (+) L ch.
11 MODE1 I Master/ Slave mode selection 1 23 VCC Analog power supply
12 FSYNC I/O Frame sync. Input/ output 24 AGND Analog Ground
(IC807)

A5000/A4000
13
(IC9)
(IC8)
SED1335F0B (XQ595A00) LCDC (LCD Controller)
PIN
NO. NAME I/O
FUNCTION PIN
NO.
NAME I/O
FUNCTION
1
VA5 O
31
XD2 O
2
VA4 O
32
XD1 O
X driver data bus
3
VA3 O
VRAM address bus 33
XD0 O
4
VA2 O
34
XECL O
X driver enable chain clock
5
VA1 O
35
XSCL O
X driver shift clock
6
VA0 O
36
VSS -
Ground
7
VR/W O
VRAM write strobe 37
LP O
Latch pulse
8
/VCE O
VRAM chip enable 38
WF O
Frame signal
9
NC -
39
YDIS O
LCD power down
10
/RES I
Reset 40
YD O
Scan start pulse
11
NC -
41
YSCL O
Scan shift clock
12
NC -
42
VD7 I/O
13
/RD I
80: Read strobe, 68: E clock 43
VD6 I/O
14
/WR I
80: Write strobe, 68: Read/Write
44
VD5 I/O
15
SEL2 I
CPU 80/68 bus select 45
VD4 I/O
VRAM data bus
16
SEL1 I
46
VD3 I/O
17
OSC1 I
Clock 47
VD2 I/O
18
OSC2 O
48
VD1 I/O
19
/CS I
Chip select 49
VD0 I/O
20
A0 I
Data bus signal discrimination 50
VA15 O
21
VDD -
Power supply 51
VA14 O
22
D0 I/O
52
VA13 O
23
D1 I/O
53
VA12 O
24
D2 I/O
54
VA11 O
VRAM address bus
25
D3 I/O
55
VA10 O
26
D4 I/O
Data bus 56
VA9 O
27
D5 I/O
57
VA8 O
28
D6 I/O
58
VA7 O
29
D7 I/O
59
VA6 O
30
XD3 O
X driver data bus 60
NC -
HD63266F (XI939A00) FDC (Floppy Disk Controller)
PIN
NO. NAME I/O
FUNCTION PIN
NO.
NAME I/O
FUNCTION
1
8"//5" I
Data transmission speed 33
/TRKO I
Track 00 signal
2
XTALSET I
Clock select 34
/INDEX I
Index signal
3
/RESET I
Rest 35
/RDATA I
Read data input from FDD
4
E//RD I
Enable/Read 36
XTAL2
Clock
5
RW//WR I
Read/write/Write 37
EXTAL2
6
/CS I
Chip select 38
NC -
7
/DACK I
DMA acknowledge 39
XTAL1
Clock
8
RS0 I
Register select 40
EXTAL1
9
RS1 I
41
VSS4 -
Ground
10
VSS1 -
Ground 42
VSS5 -
11
VSS2 -
43
NC -
12
D0 I/O
44
VCC2 -
13
D1 I/O
45
VCC3 -
Power supply
14
D2 I/O
46
VCC4 -
15
D3 I/O
Data bus 47
/WGATE O
Write control
16
D4 I/O
48
/WDATA O
Write data to FDD
17
D5 I/O
49
VSS6 -
Ground
18
D6 I/O
50
/STEP O
Step signal to control head of FDD
19
D7 I/O
51
/HDIR O
Direction
20
/DREQ O
DMA request 52
/HLOAD O
Head load
21
/IRQ O
Interrupt request 53
/HSEL O
Head select
22
/DEND I
Data end 54
VSS7 -
Ground
23
VSS3 -
Ground 55
/DS0 O
24
1/2 EX1
56
/DS1 O
Drive select
25
VCC1 -
Power supply 57
/DS2 O
26
NUM1 I
58
/DS3 O
27
NUM3 I
59
VSS8 -
Ground
28
IFS I
Host interface select 60
/MON0 O
29
SFORM I
Format data 61
/MON1 O
Motor on
30
/INP I
Index pulse 62
/MON2 O
31
/READY I
Ready from FDD 63
/MON3 O
32
/WPRT I
Write control signal 64
VSS9 -
Ground

A5000/A4000
14
HD6437043AE00F (XW795A00) CPU
PIN
NO. NAME I/O FUNCTION PIN NO. NAME I/O FUNCTION
1 /WRHH O HH write 73 D15 I/O
2 DACK0 O DMA transfer strobe 74 D14 I/O Data bus
3 PA22 O Port A 75 D13 I/O
4 /CASHH O HH Column address strobe 76 D12 I/O
5 PE15 I/O Port E 77 VCC I Power suppl
y
6 VSS - Ground 78 D11 I/O Data bus
7 A0 O 79 VSS I Ground
8 A1 O 80 D10 I/O
9 A2 O Address bus 81 D9 I/O
10 A3 O 82 D8 I/O Data bus
11 A4 O 83 D7 I/O
12 VCC - Power suppl
y
84 D6 I/O
13 A5 O Address bus 85 VCC I Power suppl
y
14 VSS - Ground 86 D5 I/O Data bus
15 A6 O 87 VSS - Ground
16 A7 O 88 D4 I/O
17 A8 O 89 D3 I/O
18 A9 O 90 D2 I/O Data bus
19 A10 O 91 D1 I/O
20 A11 O Address bus 92 D0 I/O
21 A12 O 93 VSS - Ground
22 A13 O 94 XTAL I Cr
y
stal oscillator
23 A14 O 95 MD3 I Mode select 3
24 A15 O 96 EXTAL I Cr
y
stal oscillator
25 A16 O 97 MD2 I Mode select 2
26 VCC - Power suppl
y
98 NMI I Non-maskable interrupt
27 A17 O Address bus 99 VCC I Power suppl
y
28 VSS - Ground 100 PA16 I/O Port A
29 /CASHL O HL Column address strobe 101 /WAIT I/O Wait
30 PA19 I/O Port A 102 MD1 I Mode select 1
31 /RAS O Row address strobe 103 MD0 I Mode select 0
32 /CASL O Column address strobe (low) 104 PLLVCC I PLL power supply
33 PA18 I/O Port A 105 PLLCAP I PLL capacitor
34 /CASH O Column address strobe (high) 106 PLLVSS I PLL ground
35 VSS - Ground 107 CK I/O Clock
36 RDWR O DRAM read/write 108 /RES I Reset
37 A18 O 109 /DREQ0 I DMA transfer request
38 A19 O Address bus 110 DRAK0 I/O DMA transfer strobe
39 A20 O 111 /DREQ1 I/O DMA transfer request 1
40 VCC I Power supply 112 VCC I Power supply
41 A21 O Address bus 113 PE3 I/O
42 VSS I Ground 114 PE4 I/O Port E
43 /RD O Read 115 PE5 I/O
44 /WDTOVF O Watch dog timer overflow 116 PE6 I/O
45 D31 I/O Data bus 117 VSS - Ground
46 D30 I/O 118 PF0 I/O
47 /WRH O High write 119 PF1 I/O
48 /WRL O Low write 120 PF2 I/O Port F
49 /CS1 O Chip select 1 121 PF3 I/O
50 /CS0 O Chip select 0 122 PF4 I/O
51 /IRQ3 I Interrupt request 3 123 PF5 I/O
52 /IRQ2 I Interrupt request 2 124 AVSS I Analog ground
53 /CS3 O Chip select 3 125 PF6 I/O Port F
54 /CS2 O Chip select 2 126 PF7 I/O
55 VSS - Ground 127 AVREF I Analog reference voltage
56 D29 I/O 128 AVCC - Analog power supply
57 D28 I/O 129 VSS - Ground
58 D27 I/O Data bus 130 RxDO I Receive data
59 D26 I/O 131 PA1 I/O Part A
60 D25 I/O 132 /IRQ0 I Interrupt request 0
61 VSS - Ground 133 RxD1 I Receive data
62 D24 I/O Data bus 134 TXD1 I/O Transmit data
63 VCC - Power supply 135 VCC - Power supply
64 D23 I/O 136 IRQ1 I/O Interrupt request 1
65 D22 I/O 137 PE7 I/O
66 D21 I/O 138 PE8 I/O Port E
67 D20 I/O Data bus 139 PE9 I/O
68 D19 I/O 140 PE10 I/O
69 D18 I/O 141 VSS - Ground
70 D17 I/O 142 PE11 I/O
71 VSS - Ground 143 PE12 I/O Port E
72 D16 I/O Data bus 144 PE13 I/O
(IC1)

A5000/A4000
15
MB87034PF (XK851A00) SPC (SCSI Protocol Controller)
PIN
NO. NAME I/O
FUNCTION PIN
NO.
NAME I/O
FUNCTION
1
/RESET I
Reset 41
/CLK I
Clock
2
VSS -
Ground 42
VSS -
Ground
3
NC -
43
NC -
4
NC -
44
NC -
5
NC -
45
NC -
6
/DBP I/O
SCSI data bus 46
/I/O I/O
Data direction
7
VSS -
Ground 47
VSS -
Ground
8
/DB7 I/O
48
/REQ I/O
Request
9
/DB6 I/O
SCSI data bus 49
/C/D I/O
Command/Data
10
/DB5 I/O
50
/SEL I/O
Select
11
VDD -
Power supply 51
VDD -
Power supply
12
VSS -
Ground 52
VSS -
Ground
13
VSS -
53
VSS -
14
/DB4 I/O
54
/MSG I/O
Message
15
/DB3 I/O
SCSI data bus 55
/RST I/O
Reset
16
/DB2 I/O
56
/ACK I/O
Acknowledge for REQ
17
/DB1 I/O
57
/BSY I/O
Busy
18
VSS -
Ground 58
VSS -
Ground
19
/DB0 I/O
SCSI data bus 59
/ATN I/O
Attention condition
20
NC -
60
NC -
21
NC -
61
NC -
22
TEST -
62
INT2 O
Non-maskable interrupt request
23
VSS -
Ground 63
VSS -
Ground
24
DRESP I
Response signal for DREQ 64
/CS I
Chip select
25
DREQ O
Data transfer request 65
/WT I
Write strobe
26
HIN I
Output control of HDB0-7,HDBP
66
/WTG I
Data bus write control (to HDB0-7,HDBP)
27
HDB0 I/O
67
/RD I
Read strobe
28
HDB1 I/O
68
/RDG I
Output control for D0-7,DP
29
HDB2 I/O
Data bus 69
D0 I/O
30
HDB3 I/O
(MB87034 <->data memory) 70
D1 I/O
Data bus
31
HDB4 I/O
71
D2 I/O
(MB87034 <->internal register)
32
HDB5 I/O
72
D3 I/O
33
VDD -
Power supply 73
VDD -
Power supply
34
HDB6 I/O
74
D4 I/O
35
HDB7 I/O
Data bus 75
D5 I/O
36
HDBP I/O
76
D6 I/O
Data bus
37
A0 I
77
D7 I/O
38
A1 I
Resistor select 78
DP I/O
39
A2 I
79
DP0 O
Odd number parity of data bus
40
A3 I
80
INTR O
Interrupt request
(IC52)
(IC805)
PCM1716E (XU829A00) DAC (Digital to Analog Converter)
PIN
NO.
NAME
I/O
FUNCTION
PIN
NO.
NAME
I/O
FUNCTION
1
LRCK I
15
Vcc1 -
Analog power supply (+5V)
2
DATA I
Data input 16
VOUTL O
Lch, analog voltage output
3
BCK I
Bit clock 17
NC -
4
CLKO O
Clock input 18
EXTL O
Lch, analog output
5
XTI I
Clock input 19
AGND2L -
Analog ground
6
XTO O
Clock out 20
Vcc2L -
Analog power supply (+5V)
7
DGND -
Digital ground 21
/ZERO O
Zero data flag
8
VDD -
Digital power supply (+5V) 22
/RST I
Reset
9
Vcc2R -
Analog power supply (+5V) 23
/CS/IWO I
Chip select
10
AGND2R -
Analog ground 24
MODE I
Mode control select
(H: Software, L: Hardware)
11
EXTR O
Rch, analog output 25
/MUTE I
Mute control
12
NC -
26
MD/DM0 I
Mode control data/ De-emphasis select1
13
14
VOUTR
AGND1 O
-
Rch, analog voltage output
Analog ground 27
28
MC/DM1
ML/IIS I
I
Mode control BCK/ De-emphasis select2
Mode control Latch/ input format select

A5000/A4000
16
IC BLOCK DIAGRAM

A5000/A4000
17

A5000/A4000
18

A5000/A4000
19
TEST No. TEST TEST RESULTS
00 MIDI OK/NG
01 LCD ALL DOTS ON/OFF
02 LED/SWITCH LIT, OK/NG
03 ENCODER OK/NG
04 CPU(DRAM/EEPROM/DPRAM) OK/NG
05 WAVEMEMORY OK/NG
06 SIMM Displayed CAPACITY/NG ADDRESS (SIMM)
07 DRIVE 1SECTOR/DMA (SCSI) OK/NG
08 DRIVE 1SECTOR (IDE) OK/NG
09 FDINSERT/VERIFY OK/NG
10 128 (64)TONE/DSPRAM Listning (via DSP RAM)
11 STEREO OUT-L 1 kHz +/- 1 Hz, less than 2.0% distortion, -1 +/- 3 dBm
12 STEREO OUT-R 1 kHz +/- 1 Hz, less than 2.0% distortion, -1 +/- 3 dBm
13 ASSIGNABLE OUT-L 1 kHz +/- 1 Hz, less than 2.5% distortion, -1 +/- 3 dBm
14 ASSIGNABLE OUT-R 1 kHz +/- 1 Hz, less than 2.5% distortion, -1 +/- 3 dBm
15 REC IN (MIC)/SPF 1 kHz +/- 1.5 Hz, less than 3.0% distortion, -1 +/- 4 dBm
16 REC IN (LINE)/SPF 1 kHz +/- 1.5 Hz, less than 2.5% distortion, -1 +/- 4 dBm
17 MUTE Listning
18 ASSIGNABLE OUT-1 1 kHz +/- 1 Hz, less than 0.5% distortion, 0 +/- 3 dBm
19 ASSIGNABLE OUT-2 1 kHz +/- 1 Hz, less than 0.5% distortion, 0 +/- 3 dBm
20 ASSIGNABLE OUT-3 1 kHz +/- 1 Hz, less than 0.5% distortion, 0 +/- 3 dBm
21 ASSIGNABLE OUT-4 1 kHz +/- 1 Hz, less than 0.5% distortion, 0 +/- 3 dBm
22 ASSIGNABLE OUT-5 1 kHz +/- 1 Hz, less than 0.5% distortion, 0 +/- 3 dBm
23 ASSIGNABLE OUT-6 1 kHz +/- 1 Hz, less than 0.5% distortion, 0 +/- 3 dBm
24 DIGITAL & OPTICAL OUT Lintning, measuring
25 DIGITALIN 1 kHz +/- 5 Hz, less than 0.2% distortion, 17 +/- 4 dBm
26 OPTICAL IN 1 kHz +/- 5 Hz, less than 0.2% distortion, 17 +/- 4 dBm
27 mLAN I/F (26pin)
28 mLAN I/F (50pin)
50 CPU (DRAM/DPRAM) ALL OK/NG
51 WAVEMEMORYALL Displayed CAPACITY/NG ADDRESS
52 SIMMALL Displayed CAPACITY/NG ADDRESS
53 DRIVE 100MB VERIFY (SCSI) OK/NG
54 DRIVE 100MB VERIFY (IDE) OK/NG
55 DIGITALI/O OK/NG
56 OPTICALI/O OK/NG
90 SCSI TERM POWER Displayed CAPACITY +4.4 ~ 5.1 V
91 SCSI TERM SW Displayed CAPACITY SW ON: 2.85 +/- 0.5 V OFF: 0 +/- 0.5 V
92 REMAIN NOISE less than -70 dBm, PHONES: less than -62 dBm
93 POWER SUPPLYVOLTAGE 5.00 +/- 0.25 V
94 POWER ON MUTE less than 200 mVp-p, PHONES: less than 500 mVp-p
98 FACTORYSET
99 EXIT
TEST PROGRAM

A5000/A4000
20
A. TESTENTRY
The test program can be entered in either of the two ways.
1.Turn on the A5000/A4000 power switch while pressing the [F1]
and the [COMMAND] switches.
2.After turning on the A5000/A4000 power switch, wait a few
miniutesandwhile simultaneouslypressingthe[F1] andthe[COM-
MAND] switches, press the [F6] switch.
If the [ENC4] AUTO switch is pressed, the auto test can be started.
If the [ENC5] MANUAL switch is pressed, the manual test can be
started.
When the test mode is finished, execute the EXIT or stop the power
switch.
< Attention to the destroyed data >
According to the item 04, 07, 08, 09, 50, 53, 54, there’s a danger to
destroy and initialize the media (Memory and Disk) data placed in
the test. Save the back-up and execute.
EEPROM to be tested at the item 04 is memorized the institution of
the Master body but this cannnot be saved back-up to the media.If
the test is normally finished, the institution is kept. But if NG is on,
the institution isn’t guaranted.
Thesetest are displayed the“DESTRUCTIVE!”attheselectedscreen.
B. PROCEEDING THROUGHTHETEST
MANUALMODE
If the test mode is entered, the following screen is displayed.
If the test showed the [ENC5] STOP while the execution of the test,
the test is stopped.
If the [ENC4] AUTO is pushed, the test is automatically executed in
order of the test number.
If the test showed [ENC5] STOP while the execution of the test is
pushed, the test is stopped.
If the error is happened, the error is displayed and the test is stopped.
AUTOMODE
If the auto test is executed at the [ENC4] AUTO the test is executed
in order of the number.
If the test showed the [ENC5] STOP while the execution of the test
is pushed, the test is stopped.
If the error is happened, the error is displayed and the test is stopped.
If the [ENC5] GO switch is pushed, only the stopped item test is
executed.
Proceeding through the test when the NG is judged
Accordingto each ofthe test,if the NGis judged,proceed the follow-
ing tests.
If the [ENC5] switch is pushed, the selected present test is executed
again.
If the [ASSIGNABLE] switch is pushed, the next test (of the se-
lected present test) is selected and the item test is displayed.
If the [COMMAND] switch is pushed, the last test (of the selected
presetnt test) is selected and the item test is displayed.
ENC1 ENC2 ENC3 ENC4 ENC5
Displayed Test Version
Displayed Program Version
Displayed
Mode
Item Test
Displayed Attention and
Excutive button
NOW EXCUTING ...
The test is proceeded to use the [ENC4], [ENC5], [COMMAND]
and [ASSIGNABLE].
If the [ASSIGNABLE] switch is pushed, the next test (of the se-
lected present test) is selected and the item test is displayed.
If the [COMMAND] switch is pushed, the last test (of the selected
present test) is selected and the item test is displayed.
(If the [ENC1] switch is turned, the item test is selected.)
If the [ENC5] GO switch is pushed, the selected present test is
executed.
While executing, the next letters is displayed.
Measuring instruments: oscilloscope, level meter(with a JIS-C
filter), distortion meter, AD converter,
oscillator
Jigs: MIDI cable, optional extension board
00:MIDI AUTO MANUAL
A5000TESTPROGRAMVER x.xx
MST:Vx.xx SLV:x.xx BOOT:xx xx xx
TESTMODE= MANUAL
00:MIDI
DESTRUCTIVE! AUTO MANUAL
