Yamaha RS90NL Manual

SUPPLEMENTARY SERVICE MANUAL
RS90NL
RS90NRL
RS90RSL
RS90GTL
RS90MSL
LIT-12618-02-47 8GE-28197-10
PRINTED IN U.S.A.
2005.07 CR
(E)
YAMAHA MOTOR CO., LTD.
Cover_SMB.fm Page 1 Friday, July 22, 2005 8:54 AM

FOREWORD
This Supplementary Service Manual has been prepared to introduce new service and new data for
the RS90NL, RS90NRL, RS90RSL, RS90GTL, RS90MSL. For complete information, on service
procedures, it is necessary to use this Supplementary Service Manual together with following man-
ual:
RS90K, RS90RK, RSG90K, RS90MK, RST90K, RST90TFK SERVICE MANUAL:
8FJ-28197-10 (981096) (LIT-12618-02-38)
RS90NL, RS90NRL,
RS90RSL, RS90GTL, RS90MSL
SUPPLEMENTARY SERVICE MANUAL
©2005 by Yamaha Motor
Corporation, U.S.A.
1st Edition, July 2005
All rights reserved. Any reprinting or
unauthorized use without the written
permission of Yamaha Motor Corporation,
U.S.A. is expressly prohibited.
Printed in U.S.A.
P/N.LIT-12618-02-47

NOTICE
This manual was written by the Yamaha Motor Company primarily for use by Yamaha dealers and
their qualified mechanics. It is not possible to put an entire mechanic’s education into one manual,
so it is assumed that persons using this book to perform maintenance and repairs on Yamaha
snowmobiles have a basic understanding of the mechanical concepts and procedures inherent in
snowmobile repair. Without such knowledge, attempted repairs or service to this model may render
it unfit and/or unsafe to use.
This model has been designed and manufactured to perform within certain specifications in regard
to performance and emissions. Proper service with the correct tools is necessary to ensure that the
vehicle will operate as designed. If there is any question about a service procedure, it is imperative
that you contact a Yamaha dealer for any service information changes that apply to this model. This
policy is intended to provide the customer with the most satisfaction from his vehicle and to conform
to federal environmental quality objectives.
Yamaha Motor Company, Ltd. is continually striving to improve all models manufactured by
Yamaha. Modifications and significant changes in specifications or procedures will be forwarded to
all authorized Yamaha dealers and will, where applicable, appear in future editions of this manual.
HOW TO USE THIS MANUAL
Particularly important information is distinguished in this manual by the following notations:
The Safety Alert Symbol means ATTENTION! BE ALERT! YOUR SAFETY IS
INVOLVED!
Failure to follow WARNING instructions could result in severe injury or death to
the snowmobile operator, a bystander, or a person inspecting or repairing the
snowmobile.
A CAUTION indicates special precautions that must be taken to avoid damage
to the snowmobile.
A NOTE provides key information that can make procedures easier or clearer.
MANUAL FORMAT
All of the procedures in this manual are organized in a sequential, step-by-step format. The informa-
tion has been compiled to provide the mechanic with an easy to read, handy reference that contains
comprehensive explanations of all inspection, repair, assembly, and disassembly operations.
In this revised format, the condition of a faulty component will precede an arrow symbol and the
course of action required to correct the problem will follow the symbol, e.g.,
•Bearings
Pitting/damage →Replace.
EXPLODED DIAGRAM
Each chapter provides exploded diagrams before each disassembly section to facilitate correct dis-
assembly and assembly procedures.
WARNING
CAUTION:
NOTE:

ILLUSTRATED SYMBOLS
(Refer to the illustration)
Illustrated symbols 1to 9are designed as thumb
tabs to indicate the chapter’s number and content.
1General information
2Periodic inspection and adjustment
3Chassis
4Power train
5Engine
6Cooling system
7Carburetion
8Electrical
9Specifications
Illustrated symbols 0to Fare used to identify the
specifications which appear.
0 Filling fluid
ALubricant
BTightening
CWear limit, clearance
DEngine speed
ESpecial tool
FΩ, V, A
Illustrated symbols Gto Oin the exploded diagram
indicate grade of lubricant and location of lubrica-
tion point.
GApply locking agent (LOCTITE®)
HApply Yamabond No.5®
IApply engine oil
JApply gear oil
KApply molybdenum disulfide oil
LApply wheel bearing grease
MApply low-temperature lithium-soap base grease
NApply molybdenum disulfide grease
OUse new one
12
34
56
78
9
0 AB
CDE
FGH
IJK
LMN
O
GEN
INFO
INSP
ADJ
CHAS
POWR
TR
ENG
COOL
CARB
–+
ELEC
SPEC
T
R
.
.
LT
5
EGM
BLS M
New

INDEX
GENERAL INFORMATION GEN
INFO 1
PERIODIC INSPECTION AND
ADJUSTMENT INSP
ADJ 2
CHASSIS CHAS 3
POWER TRAIN POWR
TR 4
ENGINE ENG 5
COOLING SYSTEM COOL 6
CARBURETION CARB 7
ELECTRICAL ELEC 8
SPECIFICATIONS SPEC 9
–+

GENERAL INFORMATION
SPECIAL TOOLS .................................................1
FOR POWER TRAIN ......................................1
PERIODIC INSPECTION AND
ADJUSTMENT
INTRODUCTION...................................................2
PERIODIC MAINTENANCE CHART FOR THE
EMISSION CONTROL SYSTEM ..........................2
GENERAL MAINTENANCE AND
LUBRICATION CHART........................................3
CHASSIS ..............................................................5
BRAKE LEVER ADJUSTMENT
(RS90N/RS90NR/RS90RS/RS90GT).............5
LUBRICATION................................................5
TUNING ................................................................8
CARBURETOR TUNING ................................8
CLUTCH .......................................................14
GEAR SELECTION ......................................18
FRONT SUSPENSION .................................24
REAR SUSPENSION ...................................26
CHASSIS
STEERING..........................................................34
RS90N/RS90NR/RS90RS/RS90MS.............34
RS90GT ........................................................36
INSTALLATION ............................................38
SKI ......................................................................42
RS90N/RS90NR/RS90RS/RS90GT .............42
RS90MS........................................................43
FRONT SUSPENSION .......................................44
POWER TRAIN
PRIMARY SHEAVE AND DRIVE V-BELT .........46
DRIVE CHAIN HOUSING ...................................47
WITHOUT REVERSE MODEL .....................47
INSTALLATION ............................................49
WITH REVERSE MODEL.............................50
REMOVAL ....................................................53
INSTALLATION ............................................54
SECONDARY SHAFT ....................................... 56
INSTALLATION............................................ 56
SECONDARY SHAFT AND DRIVE CHAIN
HOUSING INSTALLATION.......................... 58
BRAKE .............................................................. 60
BRAKE CALIPER DISASSEMBLY .............. 63
BRAKE CALIPER INSTALLATION .............. 63
RS90N/RS90NR/RS90RS/RS90MS ............ 64
RS90GT ....................................................... 65
SLIDE RAIL SUSPENSION............................... 66
RS90N/RS90NR/RS90RS ........................... 66
RS90GT ....................................................... 72
RS90MS....................................................... 76
ASSEMBLY.................................................. 82
INSTALLATION............................................ 83
FRONT AXLE AND TRACK .............................. 86
INSTALLATION............................................ 87
ENGINE
SEAT AND FUEL TANK.................................... 88
RS90N/RS90NR/RS90RS/RS90GT ............ 88
RS90MS....................................................... 89
EXHAUST PIPE AND MUFFLER ...................... 90
RS90MS....................................................... 90
CARBURETION
CARBURETORS AND FUEL PUMP................. 92
SPECIFICATIONS
GENERAL SPECIFICATIONS........................... 94
MAINTENANCE SPECIFICATIONS.................. 97
ENGINE ....................................................... 97
POWER TRAIN.......................................... 102
CHASSIS ................................................... 106
ELECTRICAL ............................................. 108
HIGH ALTITUDE SETTINGS..................... 110
TIGHTENING TORQUE................................... 111
ENGINE ..................................................... 111
POWER TRAIN.......................................... 113
CHASSIS ................................................... 116
GENERAL TORQUE SPECIFICATIONS ........ 117
DEFINITION OF UNITS ................................... 117
CABLE ROUTING ........................................... 119

1
GEN
INFO
SPECIAL TOOLS
GENERAL INFORMATION
SPECIAL TOOLS
Some special tools are necessary for a completely accurate tune-up and
assembly. Using the correct special tool will help prevent damage that can
be caused by the use of improper tools or improvised techniques.
NOTE:
•Be sure to use the correct part number when ordering the tool, since the
part number may differ according to country.
•For USA and Canada, use part number starting with “YB-”, “YM-”, “YU-”,
“YS-”or “ACC-”.
•For others, use part number starting with “90890-”.
FOR POWER TRAIN
•Axle nut wrench (36 mm)
P/N: YM-37132
90890-01422
This tool is used for install the drive sprocket nut.
1

2
INSP
ADJ
PERIODIC INSPECTION AND ADJUSTMENT
INTRODUCTION
This chapter includes all information necessary to perform recommended inspections and adjustments. These
preventive maintenance procedures, if followed, will ensure more reliable machine operation and a longer ser-
vice life. In addition, the need for costly overhaul work will be greatly reduced. This information applies to
machines already in service as well as new machines that are being prepared for sale. All service technicians
should be familiar with this entire chapter.
PERIODIC MAINTENANCE CHART FOR THE EMISSION CONTROL SYSTEM
Item Remarks
Pre-opera-
tion check
(Daily)
Initial
1 month or
800 km
(500 mi)
(40 hr)
Every
Seasonally
or 4,000 km
(2,500 mi)
(200 hr)
Spark plugs
Check condition.
Adjust gap and clean.
Replace if necessary.
Valve clearance Check clearance.
Adjust clearance when engine is cold. Every 40,000 km (25,000 mi)
Crankcase breather system Check breather hose for cracks or damage.
Replace if necessary.
Fuel filter Check condition.
Replace if necessary.
Fuel line Check fuel hose for cracks or damage.
Replace if necessary.
Idle speed Check and adjust engine idle speed.
Carburetors Adjust the jets. Whenever operating condition (elevation/tem-
perature) is changed.
Adjust synchronization of carburetors.
Exhaust system Check for leakage.
Tighten or replace gasket if necessary.
INTRODUCTION/PERIODIC MAINTENANCE CHART FOR
THE EMISSION CONTROL SYSTEM

3
INSP
ADJ
GENERAL MAINTENANCE AND LUBRICATION CHART
GENERAL MAINTENANCE AND LUBRICATION CHART
Item Remarks
Pre-opera-
tion check
(Daily)
Initial
1 month or
800 km
(500 mi)
(40 hr)
Every
Seasonally
or 4,000 km
(2,500 mi)
(200 hr)
Engine oil Check oil level.
* Replace.
Engine oil filter cartridge Replace.
Every
20,000 km
(12,000 mi)
Fuel Check fuel level.
Engine coolant Check coolant level.
* Air bleed the cooling system if necessary.
Throttle lever (carburetor
side) Check throttle lever operation.
Throttle lever (handlebar
side)
Check operation.
* Repair if necessary.
Throttle override system
(T.O.R.S.)
Check operation.
* Repair if necessary.
Engine stop switch Check operation.
* Repair if necessary.
Drive guard Check for cracks, bends or damage.
* Replace if necessary.
V-belt Check for wear and damage.
Replace if necessary.
Drive track and idler wheels Check deflection, and for wear and damage.
* Adjust/replace if necessary.
Slide runners Check for wear and damage.
* Replace if necessary.
Brake and parking brake
Check operation and fluid leakage.
* Adjust free play and/or replace pads if necessary.
* Replace brake fluid. See NOTE on page 4.
Disc brake installation Check for slight free play.
Lubricate shaft with specified grease as required.
Every
1,600 km
(1,000 mi)
Drive chain oil Check oil level.
* Replace.
Drive chain Check deflection.
* Adjust if necessary.
Initial at 500 km (300 mi) and every 800 km
(500 mi) thereafter.
Skis and ski runners Check for wear and damage.
* Replace if necessary.
Steering system Check operation.
* Adjust toe-out if necessary.
Strap (RS90MS) Check for damage.
* Replace if necessary.
Lights Check operation.
Replace bulbs if necessary.
Battery Check condition.
Charge if necessary.
Primary and secondary
clutches
Check engagement and shift speed.
Adjust if necessary. Whenever operating elevation is changed.
Inspect sheaves for wear/damage.
Inspect weights/rollers and bushings for wear-for pri-
mary.
Inspect ramp shoes/bushings for wear-for secondary.
Replace if necessary.
Lubricate with specified grease.
2

4
INSP
ADJ
GENERAL MAINTENANCE AND LUBRICATION CHART
NOTE:
Brake system:
•After disassembling the master cylinder or caliper cylinder, always change the brake fluid. Regularly check
the brake fluid level and add fluid if necessary.
•Replace the oil seals of the master cylinder and caliper cylinder every two years.
•Replace the brake hose every four years, or if cracked or damaged.
Steering column bearing Lubricate with specified grease.
Ski and front suspension Lubricate with specified grease.
Suspension component Lubricate with specified grease.
Parking brake cable end and
lever end/throttle cable end
Lubricate with specified grease.
Check cable damage.
Replace if necessary.
Shroud latches Make sure that the shroud latches are hooked.
Fittings and fasteners Check tightness.
* Repair if necessary.
Tool kit and recommended
equipment Check for proper placement.
Item Remarks
Pre-opera-
tion check
(Daily)
Initial
1 month or
800 km
(500 mi)
(40 hr)
Every
Seasonally
or 4,000 km
(2,500 mi)
(200 hr)

5
INSP
ADJ
BRAKE LEVER ADJUSTMENT (RS90N/RS90NR/RS90RS/
RS90GT)/LUBRICATION
CHASSIS
BRAKE LEVER ADJUSTMENT
(RS90N/RS90NR/RS90RS/RS90GT)
1. Adjust:
•brake lever position a
Adjustment steps:
•While pushing the brake lever forward, loosen
the locknut 1.
•While pushing the brake lever forward, turn the
adjusting bolt 2in direction bor cuntil the
brake lever is in the desired position.
•Tighten the locknut.
CAUTION:
Be sure to tighten the locknut, as failing to do
so will cause poor brake performance.
a
1
2b
c
LUBRICATION
Brake lever, throttle lever and throttle cable end
1. Lubricate the brake lever pivot, throttle lever and
the ends of the throttle cables.
WARNING
Apply a dab of grease onto only the end of the
cables.
Do not grease the throttle cables.
They could freeze and cause a loss of control.
Recommended lubricant:
ESSO Beacon 325 Grease or
Aeroshell Grease #7A

6
INSP
ADJ
LUBRICATION
Front and rear suspension
1. Use a grease gun to inject grease into the nip-
ples 1and 2(Both side).
2. Apply grease 3.
ÈFront
ÉRear (RS90N/RS90NR/RS90RS)
ÊRear (RS90GT)
1Nipple
Recommended lubricant:
ESSO Beacon 325 Grease or
Aeroshell Grease #7A
1
È
È
112
É
21
1
2
Ê

7
INSP
ADJ
LUBRICATION
112
1
Ë
ËRear (RS90MS)
1Nipple

8
INSP
ADJ
TUNING
CARBURETOR TUNING
The carburetors are set at the factory to run at tem-
peratures of 0 °C ~ –20 °C (32 °F ~ –4 °F) at sea
level. If the machine is to be operated under condi-
tions other than those specified above, the carbure-
tors must be properly adjusted. Special care should
be taken in carburetor setting so that the pistons
will not be damaged or will not seize.
CAUTION:
Before performing the carburetor tuning, make
sure that the following items are set to specifi-
cation.
•Engine idle speed
•Throttle cable free play
•Carburetor synchronization
Carburetor tuning data
1. Standard specifications
ÈType CVK40
ÉManufacturer KEIHIN
ÊI.D. Mark 8ES1 00
ËMain jet (M.J.) #148
ÌPilot jet (P.J.) #45
ÍFloat height 16 mm (0.63 in)
ÎIdle speed 1,300 ~ 1,500 r/min
Mid-range and high speed tuning
Adjustments are normally not required, but may
sometimes be necessary, depending on tempera-
tures, altitude or both.
Mid-range speed and high speed tuning (from 1/4
to full-throttle) can be done by adjusting the main
jet.
CAUTION:
Never run the engine without the air filter case
installed. Severe engine damage may result.
1. Start the engine and operate the machine under
normal conditions to make sure that the engine
operates smoothly. Stop the engine.
2. Remove:
•Spark plugs
CARBURETOR TUNING

9
INSP
ADJ
CARBURETOR TUNING
3. Check:
•Spark plug insulator 1color
A medium to light tan color indicates normal
conditions.
Distinctly different color →Replace the main
jet.
4. The main jet should be adjusted on the basis of
the “Main jet selection chart”.
NOTE:
By checking the condition of the spark plugs, it is
easy to get some idea of the condition of the
engine. This may diagnose potential problems
before engine damage occurs.
High altitude tuning
Use the chart in CHAPTER 9 to select main jets
according to variations in elevation and tempera-
ture.
NOTE:
These jetting specifications are subject to change.
Consult the latest technical information from
Yamaha to be sure you have the most up-to-date
jetting specifications.
1Main jet
2Pilot jet

10
INSP
ADJ
CARBURETOR TUNING
Guide for carburetion

11
INSP
ADJ
CARBURETOR TUNING
AStandard main jet
BMain jet whose diameter is 10% smaller than stan-
dard
CMain jet whose diameter is 10% larger than standard
CAUTION:
If the air filter case is removed from the carbu-
retors, the change in pressure in the intake will
create a lean mixture that may cause severe
engine damage. The air filter case has no effect
on performance characteristics and must be
secured to the carburetors during carburetor
tuning and adjustment. Also, it must always be
in place when the engine is operated. Regularly
clean the air filter and keep it free from obstruc-
tions.
Low-speed tuning
The carburetors are built so that low speed tuning
can be done by adjusting the throttle stop screw 1.
CAUTION:
Never run the engine without the air filter case
installed. Severe engine damage may result.
1. Set the engine idle speed by turning the throttle
stop screw 1in (to increase engine speed) or
out (to decrease engine speed).
2. If low-speed performance is still poor at higher
elevations under extreme conditions, the stan-
dard pilot jets may need to be replaced. In this
way, the proper air/fuel mixture is obtained.
NOTE:
In this case, use a larger numbered pilot jet to
enrich the air/fuel mixture.
Standard pilot jet:
#45
Engine idle speed:
1,300 ~ 1,500 r/min

12
INSP
ADJ
CARBURETOR TUNING
Troubleshooting
Main jet selection chart
Spark plug color Diagnosis Remedy
Light tan or gray Carburetors are tuned prop-
erly.
Dry black or fluffy
deposits
Mixture is too rich. Replace the main jet with the next smaller size.
White or light gray Mixture is too lean. Replace the main jet with the next larger size.
White or gray insulator
with small black or
grayish brown spots
and electrodes having a
bluish-burnt appear-
ance
Mixture is too lean. The piston
is damaged or seized.
Replace the piston and spark plug.
Tune the carburetors again. Begin with low-speed
tuning.
Melted electrodes and
possibly a blistered
insulator
Metallic deposits on
insulator
Mixture is too lean. The spark
plug melted.
Check the piston for holes or seizure.
Check the cooling system, gasoline octane rating
and ignition timing. After replacing the spark plug
with a colder type, tune the carburetors again.
Begin with low-speed tuning.
Trouble Diagnosis Adjustment
Hard starting Insufficient fuel Add gasoline.
Excessive use of the starter or
choke
Return the starter lever to its seated position so
that the starter valve is fully closed.
Fuel passage is clogged or
frozen
•Check and, if necessary, clean the fuel tank air
vent, the fuel filter and all of the fuel passages.
•Check and, if necessary, clean the carburetor
air vents, fuel passages and the float valve.
•Clean the float chamber of any ice or water.
Overflow Adjust the fuel level.
Poor idling:
•Poor performance at
low speeds
•Poor acceleration
•Slow response to
throttle
•Engine tends to stall
Improper idling speed adjust-
ment
Adjust the engine idle speed.
Refer to “Low-speed tuning”.
Clogged bypass hole Clean the bypass hole.
Clogged or loose pilot jet •Remove the pilot jet, clean it with compressed
air and then install it.
•Make sure that the pilot jet is fully tightened.
Air leaking into the carburetor
joint
Retighten the clamp screws on the carburetor
joints.
Defective starter valve seat Clean or replace the starter valve seat.
Overflow Adjust the fuel level.
Poor performance at
mid-range speeds:
•Momentary slow
response to the throt-
tle
•Poor acceleration
Clogged or loose pilot jet •Remove the pilot jet, clean it with compressed
air, and then install it.
•Make sure that the pilot jet is fully tightened.
Lean mixture Overhaul the carburetors.

13
INSP
ADJ
CARBURETOR TUNING
Poor performance at
normal speeds:
•Excessive fuel con-
sumption
•Poor acceleration
Clogged air vent Remove the air vent hose and clean it.
Clogged or loose main jet •Remove the main jet, clean it with compressed
air, and then install it.
•Make sure that the main jet is fully tightened.
Overflow Check and, if necessary, clean the float and float
valve.
Poor performance at
high speeds:
•Power loss
•Poor acceleration
Starter valve is left open Return the starter lever to its seated position so
that the starter valve is fully closed.
Clogged air vent Remove and clean the air vent.
Clogged or loose main air jet •Remove the main jet, clean it with compressed
air, and then install it.
•Make sure that the main jet is fully tightened.
Clogged fuel line Clean or replace the fuel line.
Dirty fuel tank Clean the fuel tank.
Air leaks into the fuel line Tighten or replace the fuel line joint.
Low fuel pump performance Repair or replace the fuel pump.
Clogged fuel filter Replace the fuel filter.
Clogged intake Remove any obstructions (e.g., ice).
Abnormal combustion:
•Backfiring
Lean mixture Clean and adjust the carburetors.
Dirty carburetors Clean the carburetors.
Dirty or clogged fuel line Clean or replace the fuel line.
Overflow:
•Poor idling
•Poor performance at
low, mid-range, and
high speeds
•Excessive fuel con-
sumption
•Hard starting
•Power loss
•Poor acceleration
Clogged air vent Clean the air vent.
Clogged float valve •Disassemble and clean the float valve.
•Do not scratch the valve seat.
Scratched or unevenly worn
float valve or valve seat
•Clean or replace the float valve and valve seat.
•The valve seat and body must be replaced as a
set.
Broken float Replace the float.
Incorrect float level Check and, if necessary, replace the following
parts:
•Float tang
•Float (entire assembly)
•Arm pin
Trouble Diagnosis Adjustment

14
INSP
ADJ
CLUTCH
CLUTCH
High altitude
Specifications Model: RS90N
GGreen PPink
S Silver
ÈElevation ~ 800 m
(~ 2,500 ft)
600 ~ 1,400 m
(2,000 ~ 4,500 ft)
1,200 ~ 2,000 m
(4,000 ~ 6,500 ft)
1,800 ~ 2,600 m
(6,000 ~ 8,500 ft)
2,400 ~ 3,000 m
(8,000 ~ 10,000 ft)
ÉEngine idle speed 1,400 ± 100 r/min ←←←←
ÊEngagement r/min Approx. 3,600 r/min ←Approx. 3,700 r/min ←Approx. 3,800 r/min
ËShift r/min Approx. 8,500 r/min ←←←←
ÌMain jet -Refer to “HIGH ALTITUDE SETTINGS”in “MAINTENANCE SPECIFICATIONS”.
ÍPilot jet
ÎSecondary reduc-
tion ratio (number
of links)
21/40 (70 L) ←21/40 (68 L) 19/40 (68 L) ←
ÏPrimary sheave
spring 90501-582L2 ←←←←
ÐColor G-S-G ←←←←
ÑFree length 86.1 mm (3.39 in) ←←←←
ÒPreload 343 N (35 kg, 77 lb) ←←←←
ÓSpring rate
27.0 N/mm
(2.75 kg/mm,
154 lb/in)
←←←←
ÔWire diameter 5.8 mm (0.228 in) ←←←←
ÕOutside diameter 59.5 mm (2.34 in) ←←←←
ÖWeight (ID) 8ES-17605-00
(8ES00) ←←←←
×Weight rivet Steel 13.9 (OUT) Steel 13.3 (OUT) Steel 10.3 (OUT) Steel 10.3 (OUT) None (OUT)
Steel 13.9 (IN) Steel 13.3 (IN) Steel 10.3 (IN) Aluminum 10.3 (IN) None (IN)
ØWeight bushing VESPEL TP-8549 ←←←←
ÙRoller outer dia. 16.0 mm (0.63 in) ←←←←
ÚRoller bushing VESPEL TP-8549 ←←←←
ÛPri. clutch shim None ←←←←
ÜSecondary sheave
spring 90508-60012 ←←←←
ÝColor P ←←←←
ÞFree length 75 mm (2.95 in) ←←←←
ßPreload rate 60°(3-3)
1,211 kg ·mm/rad ←←←←
ÀWire diameter 6.0 mm (0.236 in) ←←←←
ÁOutside diameter 69.5 mm (2.74 in) ←←←←
+Sec. torque cam
angle 43°←←←←
,Sec. clutch shim 1.0 mm (0.04 in) ←←←←
