YEEUU S170 Operating instructions

YEEUU S170�Smart Lock
Installation and Operation Guide
( V1.0 )

Do not install the batteries before installing the lock!
Install and test the lock with the door open to avoid being
locked out.
Please follow the instructions in sequential order.
Please read all the instructions before contacting custom-
er support.
You must use 3 AAA Alkaline Batteries, do not use Lithium
or Rechargeable Batteries.
For after-sale services,
please contact with [e-mail].
Important Notes

What’s in the box
Front Lever x1
Cover Plate x2 Rear Cover x1 Connecting
Rod Bolt x2
Lever Screw x2
(M4 *8)
A-Screw x2
(M4 *25)
B-Screw x2
(M4 *40)
Key x3
Door Card x3 Screwdriver x1 GuideX1 Drill TemplateX1
C-Screw x2
(M4 *55)
Single Latch
Lock Body x1
Strike x1 Self-Tapping
Screw x4(M4 *20)
Back Lever x1 Spindle 80mm
x1 /100mm x1
Spring x1
Auxiliary Ring
x1

1
1
3
2
2
45
3
4
Front Lever Back Lever
Fingerprint Identification Area
Key Open Area
Password Area
5Battery Compartment Area
6Rear knob
Door Card Identification Area
6
Lock Parts

Technical Details
Item Weight 4.3lb
Product Dimensions
Access Modes
Storage
Front Lever — Φ60mm*H80.5mm
Back Lever — Φ60mm*H60.5mm
Material Front Lever — Zinc Alloy
Back Lever — Aluminum Alloy
Fingerprint, Password, Bluetooth,
NFC Devices, NFC Card, Keys, Remote
In-app management, Voice Control
100 Pcs of NFC Cards, fingerprints and
passwords
Batteries 3 AAA Alkaline Batteries (not included)
Battery Life 12 Months+
Color Matte Black
Waterproof Rate IP55
Working Temperature -4 °F ~ 158 °F (-20°C ~ 70°C）
Working Humidity 40%RH ~ 80%RH

Installation Guide
Please scan the QR Code above to watch our easy step by step
installation video, these steps will help with installation of S170
Smart Lock.
Or you can also visit: www.yeeuu.com/pages/s1-support -page.
1.1 Preparing the Door
Confirm the following dimensions.
· The thickness of the door is between 1-1/8"~2-61/64"
(30-75mm).
· The diameter of the hole is 1-7/8"(48mm).�
· The backset is either 2-3/8" or 2-3/4" (60mm or 70mm).
· The diameter of the hole in the door edge is 1" (25.5mm).�
1-1/8"~2-61/64"
(30mm~75mm)
1"(25.5mm)
1-7/8" (48mm)
2-3/8" OR 2-3/4"
(60mm OR 70mm)

Correct
Incorrect
Step 1. Optional: Remove your current lock.
If you are installing your Yeeuu S170 Smart Lock on a door
with an existing lock, please remove the current strike and
latch.
Step 2. Install the lock body.
Install the single latch lock body on the door, make sure the
latch angle faces the door jam.
Step 3. Install the strike.
Install the strike on the door frame, ensuring the strike will
match the latch.
1.2 Installing latch and strike

2. Optional: Affix the included front cover plate behind the
front lever if there is a gap due to a large bore hole.
Step 1. Install the front lever.
1. Place the 2 connecting rod bolts on the front lever, assem-
ble the front lever on the door, make sure the fingerprint area
is facing upwards.
Note: Make sure the latch
angle faces the door jam.
60mm
70mm
1.3 Installing the Lock

Step 2. Align the front and back lever.
1. Align the spindle with the slot in the latch , slide it into
the front lever.
2. Secure the rear cover with 2 screws, choose the A/B/C
screws according to the thickness of your door, do not
tighten the screws yet.
4. Insert the auxiliary ring into the hole, adjust the spindle
to the right direction.
5. Tighten the screws, take out the auxiliary ring.
3. Optional: Affix the included back cover plate behind
the rear cover if there is a gap due to a large bore hole.
Door Thickness Screw
B-Screw (M4 *40)
C-Screw (M4 *55)
1-3/16"~1-45/69"(30-45mm)
1-13/16"~2-23/64"(46-60mm)
2-13/32"~2-61/64"61-75mm
How to choose your screw:
A-Screw (M4 *25)

Step 3. Install the back lever.
1. Put the spring in the back cover, align the spindle and
insert it in.
2. Pull out the rear konb in the back lever, secure the back
lever with 2 lever screws.
3. Insert the the rear konb into the front lever. Twist the back
lever, see if can rotate neatly.
Insert the auxiliary ring to
adjust the spindle to the right
direction.
Place the spring into the
center hole of the back lever. Pull out the rear konb
to tighten the screws.

Step 4. Install the batteries.
1. Take off the cover on the front lever and the battery cover,
install 3 AAA alkaline batteries.
2. Wait for the LED light to turn on, put the battery cover
and the front cover back.
1.4 Testing the Lock
Twist the front lever, the latch should retract smoothly, if
it doesn't, please follow the instructions carefully and
repeat the installation.
Input any fingerprints, the LED light should blink green,
the lock can be opened.
Input the default password 123456 , the LED light
should blink green, the lock can be opened.
PLEASE NOTE: Please test the lock in DEFAULT MODE.

Use the Lock
2.1 Connect app
Make sure the lock is in Factory Default Mode. Search and
download “Yeeuu” in App Store (iOS) and Google Play
(Android).
Step 1
Sign in to your existing Yeeuu account, or create an
account by choosing “Register”.
Step 2
Turn on the Bluetooth on your smart phone, stay near the
lock (within 10 feet / 3 meters) and search the lock in the
App.
Step 3
Pair the New Deviceby tapping the “Add Device” or the “+”
button on the top right-hand corner.
Step 4
Choose “Add Manually” or “Auto Scan” , choose “Yeeuu S1
Smart Lock”, the lock will blink blue light and buzz when
paired.
Step 5

Password Touch board: 0-9, . ( is the confirm key. )
PLEASE NOTE: Make sure the Bluetooth on your smart
phone is on, and stay near the lock (within 10 feet / 3
meters).
Permanent password: 6-10 numbers, valid until you delete.
2.2 In-app set up
2.2.1 Fingerprint Setting
Step 1. Select the device on the “Home” page and go
to “ Set” page.
Step 1. Select the device on the “Home” page and go
to “ Set” page.
Step 2. Tap “Fingerprint Management” on the top
left-hand corner, and choose “ Add fingerprint”.
Step 3. Select the user you would like to add
fingerprint, and tap “ Start Collecting”.
Step 4. Put your finger on the identification area to
capture your fingerprints for 8 times.
2.2.2 Password Setting

Time-code password:
— One-time password
6-10 numbers, set the start and end time for one-time use.
— Periodic password
6-10 numbers, set a schedule time for routine visit.
Dynamic password
10 numbers, can be generated offline, valid within 5 minutes.
Anti-peep password
unlimited number + permanent password + up to 9 numb-
ers.
Step 2. Tap “Password Management” on the top
right-hand corner, and choose “ Add password”.
Step 3. Select the user you would like to add
permanent password, and set the password.
Step 1. Select the device on the “Home” page and go
to “ Set” page.
Step 2. Tap “NFC Card Management” on the
left-hand corner, and choose “ Add NFC Card”.
2.2.3 NFC Card Setting

PLEASE NOTE: In the Yeeuu App, 20 families can be
created. The family creator is who registers in Yeeuu
App originally, each “Family” can only have one “ Own-
er”.
Check the unusual attempts of the lock in “Alarm”.
2.3.1 Alarm Record
Check the lock and unlock records in “ Opening Record.”
2.3.2 Opening Record
2.3.3 Members
2.3 In-app Management
Step 3. Select the user you would like to add NFC
Card, and tap “ Start Collecting”.
Step 4. Put the card on the identification area ,
wait for the LED light to blink green and buzz.
Step 1. Select the device on the “Home” page and
click in.
Step 2. Tap “Click to Unlock” , and choose “
Confirm” to unlock.
2.2.4 Smart Phone Unlock

The “Owner” is the person who creates the “Family” , owns
the device and manages “Admin”, “Family Member” and
“Others”.
Select the device on the “Home” page and click “ ” on the
top right-hand corner.
Step 1
Step 2. Tap “Remove Device”----“Disconnect and wipe
data” , confirm the choice.
Step 2
Optional, after connected with H1 Wi-Fi bridge, you can
only add “Admin” or “ Family Member” to share the
permission to use the device.
PLEASE NOTE: All data will be erased if you reset S170
to FACTORY DEFAULT settings.
2.3.4 Reset the Lock
The “Admin” can control all lock settings, view alarm/open-
ing records, manage other members.
The “Family Member” has limited access towards the lock,
who can unlock via fingerprint, password, NFC card or App,
but has no permission to remove the device.
“Others” has limited access only when “Owner”, “Admin”,
“Family Member” share the permission to use the device.

After turn on the unlock status, the lock will stay unlocked
until you turn it off.
Turn On: +111+ +Admin Permanent Password(White
Light blink)+
Turn Off: +222+ +Admin Permanent Password (Green
Light blink)+
2.4.2 Unlock Status
Low battery status: Yellow light blink 2 times.
Operation Failed: Red light blink 2 times, buzz 2 times.
Error Lock: Red light blink 5 times.
2.4.1 Different lock status.
2.4 Lock Status

YEEUU S170 Smart Lock
Hangzhou Ujia Technology Co., Ltd.
