Manager cards operation
1 Add user card(s)(In dual door mode, users can be only added to zone 1)
Read manager add card, Read Usercard .Read manager add card
Cards can be added continuously.
2 Delete user card(s)
Read manager delete card, Read User card .Read manager delete card
Cards can be deleted continuously.
User Operation
1.To unlock the lock by one card: Read valid card once, the lock will be unlocked.
7. Door Bell
Press the door bell button on the access control unit, the buzzer will sound ring back
tone, at the same time, the I box’s built-in door bell or the outer door bell will ring.
Remark: When the work mode is set in Auto Mode (Factory Default Mode), there will
be no ring back tone without the I Box.
Remark:
For users without card, must get ID number and initial PIN from the master. For Zone 1,
the first digit of PIN must be “1”, for Zone 2, the first digit of PIN must be “2”
For the card users with PIN “1234”, must use Reading card to change the PIN for the
first time.
6. To change the PIN of a PIN user
5. Toggle Mode
In normal mode, Every time a valid card/tag read or PIN input, the replay will operate,
for the pre-set replay pulse time.
Every time a valid card/tag read or PIN input in Toggle mode, the relay changes state,
which will not turn back until read card/tag or input PIN again.
4. To unlock the lock for multi cards: Read 2-10pcs valid cards (time interval can not
exceed 5s), the lock will be unlocked
Precondition: Set the door entry by card only, and set “2-10”for opening the door by
multi cards
2. To unlock the lock for card and PIN users
Read valid card once Input 4-6 digits PIN #, the lock will be unlocked.
3. To unlock the lock for card or PIN users
Or , the lock will be unlocked
Read valid card Input 4-6 digits PIN #
Or User ID number Input old PIN # Input new PIN # Input new PIN #
Read card Input old PIN #Input new PIN #Input new PIN #
Alarm
1. Anti Tamper Alarm
When the access control unit is disassembled illegally, the access control unit’s buzzer
and the external alarm will operate.
2. Door Status Switch
When connect with door status switch, if the door is opened illegal,theaccesscontrol
unit’s buzzer and the external alarm will operate.
3. Anti-duress alarm
When read zone 1 duress card / input 8digits duress PIN OR zone 2 duress card / input
8digits duress PIN, then press #, the corresponding lock will open, at the same time,
