York E*BA-F018 THRU 060 Quick start guide

036-21318-002 Rev. A (0106)
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
SPLIT-SYSTEM
HEAT PUMPS
10 SEER
MODELS:
E*BA-F018 THRU 060
(1.5 THRU 5 NOMINAL TONS, 1 PH)
E*BA-(T,W)036 THRU 090
(3 THRU 7.5 NOMINAL TONS, 3 PH)
MODELS: 018 - 060 (1 PH)
MODELS: 036-048 (3 PH)
MODELS: 060, 090 (3 PH)
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at www.york.com for the most
up-to-date technical information.
Additional rating information can be found at
www.ariprimenet.org.
TECHNICAL
GUIDE
TECHNICAL
GUIDE
U
NI
T
A
R
Y
HE
A
T
P
U
M
P
T
E
Q
U
I
P
M
E
N
R
S
EC
T
I
O
N
S
A
T
I
O
N
E
RT
I
F
I
C
C
OF
D
ST
A
N
D
A
R
I
A
R
2
4
0
M
A
NU
F
A
CT
U
R
E
R
C
E
R
T
I
F
I
E
D
C
L
Y
OM
P
I
N
G
T
O
A
R
IA
S
LISTED
This product was manufactured
in a plant whose quality system
is certified/registered as being
in conformity with ISO 9001.
Certification applies only
when the complete
system is listed
with ARI.
DESCRIPTION
The 10 SEER Series heat pumps is the outdoor part of a ver-
satile system of heat pumps. It is designed to be custom-
matched with one of UPG’s complete line of evaporator sec-
tions, with each serving a specific function. Matching Air Han-
dlers are available for upflow, downflow, or horizontal
applications to provide a complete system. Electric Heaters
are available, if required. Add-On coils are available for use
with upflow, downflow, or horizontal furnaces and air han-
dlers.
WARRANTY
Single Phase Units:
5-year limited parts warranty.
5-year limited compressor warranty.
Three Phase Units:
1-year limited parts warranty.
5-year limited compressor warranty.
FEATURES
•QUALITY COILS - The coil is constructed of copper tube and
aluminum fins.
•COIL PROTECTION - Coils are protected from damage by a
polymer mesh applied between the coil face, and a PVC
coated steel coil guard.
•PROTECTED COMPRESSOR - The compressor is internally
protected against high pressure and temperature. This is
accomplished by the simultaneous operation of high pressure
relief valve and a temperature sensor which protects the com-
pressor if undesirable operating conditions occur. A liquid line
filter-drier further protects the compressor.
•DURABLE FINISH - Cabinet is made of pre-painted steel.
The pre-treated flat galvanized steel provides a better paint to
steel bond, which resists corrosion and rust creep. Special
primer formulas and matted-textured finish insure less fading
when exposed to sunlight.
•LOWER INSTALLED COST - Installation time and costs are
reduced by easy power and control wiring connections. Dis-
charge line heat exchanger knockouts are provided, if
required. Available in sweat connect models only. The unit
contains enough refrigerant for matching indoor coils and 15
feet of interconnecting piping. The small base dimension
means less space is required on the ground or roof.
•TOP DISCHARGE - The warm air from the top mounted fan is
blown up away from the structure and any landscaping. This
allows compact location on multi-unit applications.
•LOW OPERATING SOUND LEVEL - The upward air flow car-
ries the normal operating noise away from the living area. The
rigid top panel effectively isolates any motor sound. Isolator
mounted compressor and the rippled fins of the condenser
coil muffle the normal fan motor and compressor operating
sounds.
•LOW MAINTENANCE - Long life permanently lubricated
motor-bearings need no annual servicing.
•EASY SERVICE ACCESS - Fully exposed refrigerant con-
nections, a single panel covering the electrical controls, and
the molex plug in the control box connecting the condenser
fan make for easy servicing of the unit.
•SECURED SERVICE VALVES - Secured re-usable service
valves are provided on both the liquid and vapor sweat con-
nections for ease of evacuating and charging.
•U.L. and C.U.L. listed - approved for outdoor application.
Certified in accordance with the Unitary Small Equipment certifi-
cation program, which is based on ARI Standard 210/240.

036-21318-002 Rev. A (0106)
2Unitary Products Group
Physical and Electrical Data - 1 Phase
MODEL EBBA-F018S EBBA-F024S EABA-F030S EABA-F036S EABA-F042S EBBA-F048S EABA-F060S
Unit Supply Voltage 208/230 – 1 – 60
Normal Voltage Range 1187 to 252
Minimum Circuit Ampacity 11.8 14.9 19.0 23 28.5 31.7 40.7
Max. Overcurrent Device Amps 220 25 30 40 40 55 60
Compressor Type 3Recip Recip Recip Recip Recip ScrollBScrollC
Compressor Amps Rated Load 9.0 11.5 14.1 17.3 21.7 24.3 31.5
Locked Rotor 48 60 73 94 105 140 169
Crankcase Heater Yes Yes Yes Yes Yes No No
Fan Motor Amps Rated Load 0.5 0.5 1.4 1.4 1.3 1.3 1.3
Fan Diameter Inches 18 18 18 18 22 22 22
Fan Motor Rated HP 1/12 1/12 1/4 1/4 1/4 1/4 1/4 Nominal RPM 1,100 1,100 1,100 1,100 850 850 850
Nominal CFM 1,850 1,850 2,750 2,750 3,150 3,350 3,350
Coil Face Area Sq. Ft. 9.15 12.58 12.58 12.58 15.72 19.65 23.58 RowsDeep 1111111
Fin / Inches 13 13 14 14 13 13 13
Liquid Line OD 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line OD 3/4 3/4 3/4 3/4 3/4 7/8 7/8
Unit Charge (Lbs. - Oz.) 44 - 14 5 - 0 4 - 8 5 - 12 6 - 9 8 - 3 9 - 8
Charge Per Foot, Oz. 0.68 0.68 0.68 0.68 0.68 0.70 0.70
Operating Weight Lbs. 131 141 154 159 172 204 217
Physical and Electrical Data - 3 Phase
MODEL EABA-
T036S EBBA- T048S EABA- T060S EABA- T090S EABA- W036S EBBA- W048S EABA- W060S EABA- W090S
Unit Supply Voltage 208/230-3-60 460 - 3 - 60
Normal Voltage Range 1187 to 252 432 to 504
Minimum Circuit Ampacity 15.0 18.9 24.5 40.6 8.0 10.1 12.0 20.7
Max. Qvercurrent Device Amps 225 30 40 60 15 15 20 35
Compressor Type3Inertia ScrollBScrollCScrollCInertia ScrollBScrollCScrollC
Compressor Amps Rated Load 10.9 14.1 18.6 28.8 5.8 7.0 9.0 14.7
Locked Rotor 78 125 128 195 40 55 63 95
Crankcase Heater Yes No No No Yes No No No
Fan Motor Amps Rated Load 1.4 1.3 1.3 4.6 .8 .7 .8 2.3
Fan Diameter Inches 18 22 24 24 18 22 24 24
Fan Motor Rated HP 1/4 1/4 1/4 3/4 1/4 1/5 1/4 3/4
Nominal RPM 1,100 850 850 1100 1,100 825 850 1100
Nominal CFM 2,750 3,500 3,100 5000 2,750 3,500 3,100 5000
Coil Face Area Sq. Ft. 12.58 19.65 18.00 22.5 12.58 19.65 18.00 22.5
RowsDeep 11221122
Fin / Inches 14 13 14 16 14 13 14 16
Liquid Line OD 3/8 3/8 3/8 1/2 3/8 3/8 3/8 1/2
Vapor Line OD 3/4 7/8 7/8 1-1/8 3/4 7/8 7/8 1-1/8
Unit Charge (Lbs. - Oz.) 45 - 12 8 - 3 11 - 3 16 5 - 12 8 - 3 11 - 3 16
Charge Per Foot, Oz. .68 .70 .70 1.26 .68 .70 .70 1.26
Operating Weight Lbs. 178 232 243 354 178 232 243 354
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker.
3. All scrolls listed with a superscript “B” are Bristol scrolls. All scrolls listed with a superscript “C” are Copeland scrolls.
4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than
15 feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.

036-21318-002 Rev. A (0106)
Unitary Products Group 3
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaportor and for 15 feet of intercon-
necting line tubing.
2. Verify the orifice size and additional charge required for specific evaportor coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.
4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for
evaportor + adder for line set.
5. If the orifice in the evaportor was changed, verify the evaportor nameplate has been marked with the correct orifice size.
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase
Outdoor Unit EBBA-F018S EBBA-F024S EABA-F030S EABA-F036S EABA-F042S EBBA-F048S EABA-F060S
Unit Orifice (s) 151,53 59,61 67, 69 67, 69, 71 75,78,81 81,84,87 87
Factory R-22 Charge, lbs-oz 4 - 14 5 - 0 4 - 8 5 - 12 6 - 9 8 - 3 9 - 8
Indoor Coil Coil Orifice 2System Orifice - Additional Charge, Oz
G2FD024S(H)17 61 53 + 12 59 + 9 — — — — —
G2FD030S(H)17 65 — 61 + 9 67 + 17 — — — —
G2FD035S(H)14 65 — 61 + 9 67 + 17 — — — —
G2FD036S(H)17/21 75 — — — 69 + 2 — — —
G2FD042S(H)21 78 — — — 71 + 7 — — —
G2FD046S(H)17 78 — — — 71 + 7 81 + 8 — —
G2FD048S(H)21/24 84 — — — — 81 + 15 87 + 6 —
G2FD060S(H)24 90 — — — — — 84 + 4 7033+ 1
G1HD024 59 53 + 13 59 + 9 — — — — —
G1HD036 69 — — 67 + 22 69 + 4 — — —
G1HD048 81 — — — — 81 + 10 84 + 6 -
G1HD060 93 — — — — — 84 + 0 7033+ 1
G1FA/G1UA024S14/17 59 53 + 10 — — — — — —
G1FA/G1UA030S14 65 — 59 + 10 — — — — —
G1FA/G1UA036S14 73 — - 67 + 17 — — — —
G1FA/G1UA03617/21 73 — 61 + 9 67 + 15 — — — —
G1FA/G1UA048S21/24 84 — — — 71 + 12 81 + 13 84 + 3 —
G1FA/G1UA060S24 90 — — — — — 84 + 4 7033+ 1
G1NA030S17H 57 53 + 0 59 + 0 69 + 0 — — — —
G1NA030S21B 57 53 + 0 59 + 0 69 + 0 — — — —
G1NA036S17L 71 — — — 67 + 7 — — —
G1NA048S21D 78 — — — 67 + 7 75 + 0 81 + 8 —
G1NA048S24P 78 — — — — 75 + 0 81 + 8 —
G1NA060S24T 87 — — — — — — 87 + 0
G1NF024SOF 63 — 59 + 04—————
G1NF036SOF 67 — — 69 + 0467 + 74———
G1NF048SOF 78 — — — — 75 + 0484 + 44—
G1NF060SOF 87 — — — — — — 87 + 04
F2RP/F2FP018 53 51 + 10 — — — — — —
F2RP/F2FP024 61 51 + 21 59 + 9 — — — — —
F2RP/F2FP030 65 — — 69 + 19 — — — —
F2RP/F2FP036 75 — — 69 + 23 71 + 4 — — —
F2RP/F2FP042 78 — — — 71 + 7 81 + 8 — —
F2FP048 84 — — — — 81 + 15 84 + 0 —
F2FP060 90 — — — — — 87 + 4 7033+ 1
FOOTNOTES:
1. These orifices are packed in the customer packet of each outdoor unit.
2. These orifices are factory mounted in the flow control device of each indoor coil.
3. TXV kit must be used with these coils to obtain system performance. (701,702,703 indicates 1TV07 ...series).
4. Systems matched with furnaces or air handlers not equipped with blower-off delays, may require blower Time Delay Kit #2FD0670224.

036-21318-002 Rev. A (0106)
4Unitary Products Group
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaportor and for 15 feet of intercon-
necting line tubing.
2. Verify the orifice size and additional charge required for specific evaportor coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.
4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for
evaportor + adder for line set.
5. If the orifice in the evaportor was changed, verify the evaportor nameplate has been marked with the correct orifice size.
Additional R-22 Charge / Orifice Size for Various Matched Systems - 3 Phase
Outdoor Unit EABA-(T,W)036S EBBA-(T,W)048S EABA-(T,W)060S EABA-(T,W)090S
Unit Orifice (s) 171, 75 81, 84, 87 99 —
Factory R-22 Charge, lbs-oz 5 - 12 8 - 3 11 - 3 16.0
Indoor Coil Coil Orifice 2System Orifice = Additional Charge, Oz
G1NA036S17L 67 71 + 7 — — —
G1NA048S21D 67 71 + 7 81 + 8 — —
G1NA048S24P 78 — 81 + 8 — —
G1UA048S21 84 81 + 13 84 + 3 — —
G1UA060S24 90 — 84 + 4 99 + 0 —
G1FA048S21 84 81 + 13 84 + 3 —
G1FA060S24 90 — 84 + 4 99 + 0 —
G2FD042(S,H)21 78 81 + 8 — — —
G2FD048(S,H)21/24 84 — 87 + 6 — —
G2FD060(S,H)24 90 — 84 + 4 99 + 0 —
F3EH090A33 TXV———
TXV3+ 0
FOOTNOTES:
1. These orifices are packed in the instruction/warranty packet of each outdoor unit.
2. These orifices are factory mounted in the flow control device of each indoor coil.
3. A TXV is factory mounted in the coil or air handler.

036-21318-002 Rev. A (0106)
Unitary Products Group 5
- = Not applicable
COOLING CAPACITY - With Air Handler Coils
UNIT MODEL
AIR HANDLER COIL1
MODEL
COOLING
MODEL ELECTRIC 2
HEAT KW WRATED
CFM NET MBH SEER W/O TXV SEER
WITH TXV3EER
TOTAL SENS.
1 PH 10 SEER HP WITH N-AH / G2FD
EBBA-F018S N1AHB0806 2,5,8,10 17 G2FD024(S,H)17 650 17.8 12.8 10.10 - 8.95
EBBA-F024S N1AHB0806 2,5,8,10 17 G2FD030(S,H)17 840 22.6 16.2 10.00 - 9.30
EABA-F030S N1AHB1206 5,8,10,15,19 17 G2FD030(S,H)17 1000 28.0 19.6 10.00 - 9.10
EABA-F036S N1AHB1206 5,8,10,15,19 17 G2FD036(S,H)17 1250 33.6 24.9 10.00 - 8.80
EABA-F042S N1AHC1606 5,8,10,15,20 21 G2FD048(S,H)21 1400 40.0 29.6 10.10 - 9.15
EBBA-F048S N1AHC1606 5,8,10,15,20 21 G2FD048(S,H)21 1600 45.5 33.7 10.00 - 9.45 N1AHD2006 8,10,15,20,25,30 24 G2FD048(S,H)24 1600 45.5 33.7 10.00 - 9.45
N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24 1600 46.5 34.4 10.20 - 9.60
EABA-F060S N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24 1800 54.5 39.2 - 10.00 8.95
3 PH 10 SEER HP WITH N-AH / G2FD
EABA-(T,W)036S N1AHC1646 10,15 21 G2FD042(S,H)21 1250 34.2 25.3 10.00 - 8.95
EBBA-(T,W)048S) N1AHC1646 10,15 21 G2FD048(S,H)21 1600 45.5 33.7 10.00 - 9.45
N1AHD2046 10,15,29 24 G2FD048(S,H)24 1600 45.5 33.7 10.00 - 9.45
EABA-(T,W)060S N1AHD2046 10,15,29 24 G2FD060(S,H)24 1700 57.0 41.0 10.00 - 9.80
1 PH 10 SEER HP / F2RP / RC / FP / FC
EBBA-F018S F2RP/FP018 2,5,8 18 - 600 17.0 12.3 10.00 - 8.90
F2RP/FP024 5,8,10 18 - 650 17.8 12.4 10.00 - 8.95
EBBA-F024S F2RP/FP024 5,8,10 18 - 800 22.0 16.5 10.00 - 9.30
F2RP/FP030 5,8,10,15 18 - 840 22.6 16.8 10.00 - 9.40
EABA-F030S F2RP/FP030 5,8,10,15 18 - 1000 28.4 21.0 10.00 - 9.20
F2RP/FP036 5,8,10,15,19 21 - 1000 29.0 20.9 10.00 - 9.40
EABA-F036S F2RP/FP036 5,8,10,15,19 21 - 1250 34.0 24.9 10.00 - 9.00
F2RP/FP042 5,8,10,15 21 - 1250 34.0 24.9 10.00 - 9.00
EABA-F042S F2RP/FP042 5,8,10,15 21 - 1400 39.0 28.4 10.00 - 8.90
F2FP048 5,8,10,15,20,25 24 - 1400 39.5 28.8 10.00 - 9.15
EBBA-F048S F2FP048 5,8,10,15,20,25 24 - 1600 45.0 33.5 10.00 - 9.40
F2FP060 5,8,10,15,20,25 24 - 1600 46.5 34.4 10.00 - 9.60
EABA-F060S F2FP060 5,8,10,15,20,25 24 - 1850 54.0 40.5 - 10.00 8.60
3 PH 10 SEER HP / F2RP / RC / FP / FC4,5
EABA-(T,W)036S) F2RP/FP036 5,8,10,15,19 21 - 1250 34.0 24.9 10.00 - 9.00
F2RP/FP042 5,8,10,15 21 - 1250 34.0 25.6 10.00 - 9.00
EBBA-(T,W)048S F2FP048 5,8,10,15,20,25 24 - 1600 45.0 33.5 10.00 - 9.40
F2FP060 5,8,10,15,20,25 24 - 1600 46.5 34.4 10.00 - 9.60
EABA-(T,W)060S) F2FP060 5,8,10,15,20,25 24 - 1700 56.0 40.0 10.00 - 9.40
3 PH 10 SEER HP / FHP
EABA-(T,W)090S FCEH090 10,16,26,36 25-1/8 - 3000 91.0 87.4 - - 9.50
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
KW includes compressor, outdoor fan and indoor blower motor watts. Add-on coils include 365 watts/1000 CFM for blower motor.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power input
in watt-hours during the same period.
1. G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Single phase units require single phase 2HK heaters.
3. TXV = Use 1TV700 Series Kit.
4. To meet R=4.2 insulation requirements, substitute F2FP for F2RP, and F2FC for F2RC. models. All ratings remain the same.
5. FG8, FG9, and FL8 furnaces and F2RP / F2RC air handlers have B.O.D. standard.

036-21318-002 Rev. A (0106)
6Unitary Products Group
COOLING CAPACITY - Upflow, Downflow, & Horizontal Furnaces and Coils
UNIT MODEL FURNACE** COIL
MODEL
COOLING
CFM RANGE
(MIN.-MAX.) WRATED CFM NET MBH SEER W/O TXV SEER + TXV1
+ TDR* EER
TOTAL SENS.
EBBA-F018S 575
725
14,17 G1FA024S14,17 650 17.6 12.7 10.00 - 8.85
14 G1FA030S14 650 17.8 12.9 10.10 - 8.95
- G1HD024 650 18.0 12.9 10.10 - 9.00
17 G1NA030S17H 650 18.0 13.5 10.00 - 9.20
21 G1NA030S21B 650 18.0 13.5 10.00 - 9.20
14,17 G1UA024S14,17 650 17.6 12.7 10.00 - 8.85
14 G1UA030S14 650 17.8 12.9 10.10 - 8.95
14,17 G2FD024(S,H)14,17 650 17.8 12.8 10.10 - 8.95
EBBA-F024S 750
950
14 G1FA030S14 830 22.2 16.4 10.00 - 9.25
17,21 G1FA036S17,21 840 22.6 16.2 10.00 - 9.30
- G1HD024 800 22.2 16.4 10.00 - 9.35
17 G1NA030S17H 850 23.0 16.1 10.00 - 9.50
21 G1NA030S21B 850 23.0 16.1 10.00 - 9.50
14 G1UA030S14 830 22.2 16.4 10.00 - 9.25
17,21 G1UA036S17,21 840 22.6 16.2 10.00 - 9.30
14,17 G2FD024(S,H)14,17 800 22.0 15.8 10.00 - 9.30
17 G2FD030(S,H)17 840 22.6 16.2 10.00 - 9.30
14 G2FD035(S,H)14 840 22.6 16.2 10.00 - 9.30
EABA-F030S 875
1125
14 G1FA036S14 1000 28.4 20.6 10.00 - 9.10
17,21 G1FA036S17,21 1000 28.0 20.2 10.00 - 9.10
- G1HD036 1000 28.4 21.0 10.10 - 9.20
17 G1NA030S17H 1050 29.0 20.6 10.00 - 9.40
21 G1NA030S21B 1050 29.0 20.6 10.00 - 9.40
14 G1UA036S14 1000 28.4 20.6 10.00 - 9.10
17,21 G1UA036S17,21 1000 28.0 19.6 10.00 - 9.10
17 G2FD030(S,H)17 1000 28.0 19.6 10.00 - 9.10
14 G2FD035(S,H)14 1000 28.0 19.6 10.00 - 9.10
17 G2FD036(S,H)17 1025 28.4 19.9 10.10 - 9.20
21 G2FD036(S,H)21 1000 28.6 19.9 10.15 - 9.25
EABA-F036S 1100
1400
21,24 G1FA048S21 1250 34.4 24.7 10.00 - 9.05
- G1HD036 1200 33.4 24.7 10.00 - 8.85
- G1HD048 1200 35.2 26.0 10.00 - 9.10
17 G1NA036S17L 1250 35.0 26.2 10.00 - 9.00
21 G1NA048S21D 1250 35.0 26.2 10.00 - 8.95
21,24 G1UA048S21 1250 34.4 24.7 10.00 - 9.05
17 G2FD036(S,H)17 1250 33.6 24.9 10.00 - 8.80
21 G2FD036(S,H)21 1200 34.0 24.5 10.00 - 9.05
21 G2FD042(S,H)21 1250 34.2 25.3 10.00 - 8.95
17 G2FD046(S,H)17 1250 34.6 25.6 10.00 - 9.05
EABA-(T,W)036S) 1100
1400
21,24 G1FA048S21 1250 34.4 24.7 10.00 - 9.05
17 G1NA036S17L 1250 35.0 26.2 10.00 - 9.00
21 G1NA048S21D 1250 35.0 26.2 10.00 - 8.95
21,24 G1UA048S21 1250 34.4 24.7 10.00 - 9.05
21 G2FD042S21 1250 34.2 25.3 10.00 - 8.95
EABA-F042S 1225
1575
21,24 G1FA048S21 1400 39.5 28.4 10.00 - 9.20
- G1HD048 1400 39.5 32.9 10.00 - 9.10
21 G1NA048S21D 1400 40.5 28.6 10.00 - 9.50
21,24 G1UA048S21 1400 39.5 28.4 10.00 - 9.20
21 G2FD042(S,H)21 1400 39.0 28.9 10.00 - 9.05
17 G2FD046(S,H)17 1400 39.5 29.3 10.00 - 9.10
21,24 G2FD048(S,H)21,24 1400 40.0 29.6 10.10 - 9.15
24 G2FD060(S,H)24 1450 40.0 29.6 10.20 - 9.30
For Notes see Page 5.

036-21318-002 Rev. A (0106)
Unitary Products Group 7
* Requires a 2FD Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric
power input during the same period.
— = Not Applicable.
EBBA-F048S 1400
1800
21,24 G1FA048S21 1600 44.5 33.1 10.00 - 9.30
21,24 G1FA060S21,24 1600 46.5 34.4 10.20 - 9.60
- G1HD048 1600 44.5 33.1 10.00 - 9.30
- G1HD060 1600 46.0 34.1 10.10 - 9.55
21 G1NA048S21D 1600 43.5 32.2 10.00 - 9.25
21,24 G1UA048S21 1600 44.5 33.1 10.00 - 9.30
21,24 G1UA060S21,24 1600 46.5 34.4 10.20 - 9.60
21,24 G2FD048(S,H)21,24 1600 45.5 33.7 10.00 - 9.45
24 G2FD060(S,H)24 1600 46.0 34.0 10.20 - 9.60
EBBA-(T,W)048S) 1400
1800
21,24 G1FA048S21 1600 45.5 32.7 10.00 - 9.30
21 G1NA048S21D 1600 45.0 31.2 10.00 - 9.50
21,24 G1UA048S21 1600 45.5 32.7 10.00 - 9.30
21,24 G2FD048(S,H)21,24 1600 45.5 33.7 10.00 - 9.40
EABA-F060S 1600
2100
21,24 G1FA060S21,24 1800 54.5 39.2 - 10.00 8.90
- G1HD060 2000 54.5 33.9 - 10.00 8.80
24 G1NA060S24T 1850 53.5 35.5 10.00 - 9.00
21,24 G1UA060S21,24 1800 54.5 39.2 - 10.00 8.90
24 G2FD060(S,H)24 1800 54.5 39.2 - 10.00 8.90
EABA-(T,W)060S 1600
2100
21,24 G1FA060S21,24 1700 57.0 41.0 10.00 - 9.80
21,24 G1UA060S21,24 1700 57.0 41.0 10.00 - 9.80
24 G2FD060(S,H)24 1700 57.0 41.0 10.00 - 9.80
1. TXV = Use 1TV700 Series Kit.
COOLING CAPACITY - Upflow, Downflow, & Horizontal Furnaces and Coils (Continued)
UNIT MODEL FURNACE** COIL
MODEL
COOLING
CFM RANGE
(MIN.-MAX.) WRATED CFM NET MBH SEER W/O TXV SEER + TXV1
+ TDR* EER
TOTAL SENS.
HEATING PERFORMANCE - With Air Handler
UNIT
MODEL* COIL1
MODEL
ARI HEATING2OUTDOOR TEMP3
47°F17°F HSPF -3°F7°F17°F27°F37°F47°F57°F
MBH COP MBH COP STD MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW
EBBA-F018S F2RP/F2FP018 17.0 2.96 9.1 1.78 6.80 6.2 1.43 7.4 1.46 9.1 1.50 11.2 1.61 14.0 1.62 17.0 1.68 18.2 1.75
F2RP/F2FP024 17.0 3.00 10.6 2.06 7.00 7.2 1.44 8.6 1.47 10.6 1.52 13.0 1.63 14.0 1.59 17.0 1.66 18.2 1.73
EBBA-F024S F2RP/F2FP024 22.0 3.20 11.5 1.88 7.00 7.5 1.56 9.3 1.66 11.5 1.78 13.0 1.87 19.4 1.91 22.0 2.00 24.8 2.08
F2RP/F2FP030 24.0 3.16 14.0 2.06 7.30 7.7 1.52 9.6 1.62 14.0 1.74 13.4 1.83 19.8 1.90 24.0 2.00 25.4 2.07
EABA-F030S F2RP/F2FP030 28.8 3.10 16.2 2.00 7.20 10.5 1.99 13.5 2.19 16.2 2.26 19.6 2.46 25.3 2.59 28.8 2.72 33.0 2.86
F2RP/F2FP036 29.0 3.10 18.0 2.22 7.40 11.6 2.11 15.0 2.32 18.0 2.39 19.8 2.47 25.5 2.61 29.0 2.74 33.2 2.88
EABA-F036S F2RP/F2FP036 34.0 3.00 20.4 2.16 7.20 15.5 2.40 15.6 2.54 20.4 2.80 24.9 3.03 29.9 3.20 34.0 3.32 38.5 3.50
F2RP/F2FP042 34.0 3.00 20.4 2.14 7.20 11.3 2.41 15.9 2.67 20.4 2.79 25.7 3.11 31.0 3.44 34.0 3.32 38.5 3.50
EABA(T,W)036S F2RP/F2FP036 34.0 3.00 20.4 2.16 7.20 15.5 2.40 15.6 2.54 20.4 2.80 24.9 3.03 29.9 3.20 34.0 3.32 38.5 3.50
EABA-F042S F2RP/F2FP042 39.0 3.18 23.4 2.06 7.40 13.0 3.15 18.2 3.24 23.4 3.33 27.0 3.28 30.6 3.23 39.0 3.59 44.2 3.68
F2FP048 39.5 3.30 23.4 2.12 7.40 12.4 2.97 17.9 3.10 23.4 3.23 28.9 3.37 32.5 3.39 39.5 3.51 47.5 3.64
EBBA-F048S F2FP048 45.5 3.18 30.4 2.38 7.5 20.1 3.42 25.3 3.57 30.4 3.73 35.5 3.85 38.8 3.98 45.5 4.16 53.1 4.40
F2FP060 46.0 3.24 30.4 2.38 7.5 21.3 3.44 25.3 3.63 30.4 3.75 35.9 3.84 39.2 3.97 46.0 4.16 53.6 4.40
EBBA-(T,W)048S) F2FP048 47.0 3.08 31.4 2.32 7.50 20.8 3.64 26.1 3.80 31.4 3.97 36.7 4.13 40.1 4.27 47.0 4.47 54.6 4.71
EABA-F060S F2FP060 57.0 3.04 37.4 2.22 7.50 24.3 4.59 30.9 4.76 37.4 4.94 44.0 5.11 48.6 5.25 57.0 5.50 67.0 5.79
EABA-(T,W)060S F2FP060 58.5 3.12 39.0 2.34 7.60 26.0 4.48 32.5 4.68 39.0 4.88 42.1 4.98 45.1 5.07 58.5 5.49 65.0 5.70
EABA(T,W)090S F2EH090 83.0 3.00 54.0 2.15 -- 34.7 7.15 44.3 7.34 54.0 7.53 55.0 7.57 55.9 7.60 83.0 8.11 92.7 8.30
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and no supplemental
electric heat operation.
3. Integrated heating capacities include the effect of defrost cycles in the temperature range where they occur.

036-21318-002 Rev. A (0106)
8Unitary Products Group
HEATING PERFORMANCE - With Furnace Coils
UNIT
MODEL* COIL1
MODEL
ARI HEATING2OUTDOOR TEMP3
47°F17°FHSP
F-3°F7°F17°F27°F37°F47°F57°F
MBH COP MBH COP STD MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW
EBBA-F018S
G2FD024(S,H)14,17 17.0 3.02 10.6 2.06 7.0 6.4 1.41 8.5 1.46 10.6 1.51 12.7 1.56 14.8 1.60 17.0 1.65 20.3 1.69
G1HD024 17.23.0410.62.06 7.0 6.2 1.41 8.4 1.4610.61.5112.41.5914.31.6717.21.6619.41.71
G1NA030S17H 17.2 2.96 10.6 2.06 7.1 6.2 1.38 8.4 1.44 10.6 1.51 12.4 1.55 14.3 1.59 17.2 1.70 19.4 1.77
G1NA030S21B 17.2 2.96 10.6 2.06 7.1 6.2 1.38 8.4 1.44 10.6 1.51 12.4 1.55 14.3 1.59 17.2 1.70 19.4 1.77
G1UA024S14,17 16.8 2.95 10.6 2.02 6.9 6.4 1.44 8.5 1.49 10.6 1.54 12.7 1.59 14.8 1.64 16.8 1.67 20.3 1.80
G1FA024S14,17 16.8 2.95 10.6 2.02 6.9 6.4 1.44 8.5 1.49 10.6 1.54 12.7 1.59 14.8 1.64 16.8 1.67 20.3 1.80
EBBA-F024S
G2FD035(S,H)14 22.6 3.28 11.9 2.00 7.3 4.7 1.55 8.3 1.65 11.9 1.74 15.5 1.84 19.1 1.93 22.6 2.02 27.3 2.18
G2FD030(S,H)17 22.6 3.28 11.9 2.00 7.3 4.7 1.55 8.3 1.65 11.9 1.74 15.5 1.84 19.1 1.93 22.6 2.02 27.3 2.18
G2FD024(S,H)14,17 22.4 3.20 11.6 2.00 7.1 4.4 1.46 8.0 1.58 11.6 1.70 15.2 1.82 18.8 1.94 22.4 2.05 27.1 2.23
G1HD024 22.4 3.24 11.8 2.00 7.1 4.7 1.53 8.2 1.63 11.8 1.73 15.4 1.83 18.9 1.93 22.3 2.02 27.3 2.18
G1NA030S17H 23.4 3.28 13.3 2.10 7.4 6.1 1.63 9.5 1.72 13.0 1.81 16.0 1.92 19.0 2.03 23.4 2.09 26.9 2.18
G1NA030S21B 23.4 3.28 13.3 2.10 7.4 6.1 1.63 9.5 1.72 13.0 1.81 16.0 1.92 19.0 2.03 23.4 2.09 26.9 2.18
G1UA030S14 22.4 3.20 11.6 2.00 7.1 4.4 1.46 8.0 1.58 11.6 1.70 15.2 1.82 18.8 1.94 22.4 2.05 27.1 2.23
G1UA036S17,21 22.6 3.28 11.9 2.00 7.3 4.7 1.55 8.3 1.65 11.9 1.74 15.5 1.84 19.1 1.93 22.6 2.02 27.3 2.18
G1FA030S14 22.4 3.20 11.6 2.00 7.1 4.4 1.46 8.0 1.58 11.6 1.70 15.2 1.82 18.8 1.94 22.4 2.05 27.1 2.23
G1FA036S17,21 22.6 3.28 11.9 2.00 7.3 4.7 1.55 8.3 1.65 11.9 1.74 15.5 1.84 19.1 1.93 22.6 2.02 27.3 2.18
EABA-F030S
G2FD030(S,H)14,17 29.0 3.08 18.0 2.20 7.4 9.4 2.08 13.7 2.24 18.0 2.40 22.3 2.56 26.9 2.71 29.0 2.76 34.6 2.98
G2FD035(S,H)14 29.0 3.08 18.0 2.20 7.4 9.4 2.08 13.7 2.24 18.0 2.40 22.3 2.56 26.9 2.71 29.0 2.76 34.6 2.98
G2FD036(S,H)14 29.2 3.10 18.2 2.20 7.4 10.9 2.20 14.5 2.31 18.2 2.42 21.3 2.56 24.3 2.69 29.2 2.76 32.9 2.87
G2FD036(S,H)21 29.4 3.10 18.0 2.20 7.4 10.4 2.14 14.2 2.27 18.0 2.40 21.2 2.54 24.3 2.68 29.4 2.78 33.2 2.91
G1HD036 29.4 3.10 18.0 2.20 7.4 9.7 2.09 13.8 2.24 18.0 2.40 22.2 2.55 26.7 2.71 29.4 2.78 33.1 2.94
G1NA030S17H 29.0 3.06 18.0 2.22 7.4 10.7 2.11 14.3 2.24 18.0 2.38 21.5 2.50 25.0 2.62 29.0 2.78 32.7 2.91
G1NA030S21B 29.0 3.06 18.0 2.22 7.4 10.7 2.11 14.3 2.24 18.0 2.38 21.5 2.50 25.0 2.62 29.0 2.78 32.7 2.91
G1UA03614 29.2 3.10 18.2 2.22 7.4 11.4 2.21 14.8 2.31 18.2 2.40 20.4 2.43 22.6 2.46 28.4 2.68 31.8 2.78
G1UA036S17,21 29.03.0818.02.20 7.4 9.4 2.0813.72.2418.02.4022.32.5626.92.7129.02.7634.62.98
EABA-F036S
G2FD036(S,H)17 34.0 3.02 20.2 2.16 7.2 11.3 2.37 15.7 2.55 20.2 2.74 24.7 2.93 29.5 3.13 34.0 3.30 40.5 3.48
G2FD036(S,H)21 33.4 2.92 19.8 2.12 7.0 11.0 2.33 15.4 2.53 19.8 2.74 24.2 2.94 28.9 3.16 33.4 3.34 39.8 3.55
G2FD042(S,H)21 34.0 3.00 20.2 2.14 7.2 11.3 2.40 15.7 2.58 20.2 2.77 24.7 2.94 29.5 3.15 34.0 3.32 40.5 3.50
G2FD046(S,H)17 33.6 3.00 20.0 2.14 7.2 10.9 2.38 15.5 2.56 20.0 2.74 23.8 2.91 27.6 3.08 33.6 3.28 38.1 3.46
G1HD036 34.03.0320.22.14 7.2 11.22.3915.72.5720.22.7524.72.9329.53.1234.03.2940.53.47
G1HD048 34.23.0620.42.18 7.2 11.22.3915.82.5620.42.7424.22.9828.13.2134.23.2838.83.45
G1NA036S17L 35.0 3.20 22.0 2.26 7.6 13.3 2.62 17.7 2.74 22.0 2.85 23.3 2.71 24.5 2.57 35.0 3.21 39.3 3.32
G1NA048S21D 35.0 3.20 22.0 2.26 7.6 13.3 2.62 17.7 2.74 22.0 2.85 23.3 2.71 24.5 2.57 35.0 3.21 39.3 3.32
G1UA048S21 34.03.0020.22.14 7.2 11.32.4015.72.5820.22.7724.72.9529.53.1534.03.3240.53.50
G1FA048S21 34.0 3.00 20.2 2.14 7.2 11.3 2.40 15.7 2.58 20.2 2.77 24.7 2.95 29.5 3.15 34.0 3.32 40.5 3.50
EABA-(T,W)036S
G2FD042(S,H)21 34.0 3.00 20.2 2.14 7.2 11.3 2.40 15.7 2.58 20.2 2.77 24.7 2.94 29.5 3.15 34.0 3.32 40.5 3.50
G1NA036S17L 35.0 3.20 22.0 2.26 7.6 13.3 2.62 17.7 2.74 22.0 2.85 23.3 2.71 24.5 2.57 35.0 3.21 39.3 3.32
G1NA048S21D 35.0 3.20 22.0 2.26 7.6 13.3 2.62 17.7 2.74 22.0 2.85 23.3 2.71 24.5 2.57 35.0 3.21 39.3 3.32
G1UA048S21 34.03.0020.22.14 7.2 11.32.4015.72.5820.22.7724.72.9529.53.1534.03.3240.53.50
G1FA048S21 34.0 3.00 20.2 2.14 7.2 11.3 2.40 15.7 2.58 20.2 2.77 24.7 2.95 29.5 3.15 34.0 3.32 40.5 3.50
EABA-F042S
G2FD042(S,H)21 39.0 3.22 23.4 2.08 7.4 13.0 3.13 18.2 3.21 23.4 3.30 27.7 3.35 32.1 3.40 39.0 3.55 44.2 3.63
G2FD046(S,H)17 39.0 3.24 23.4 2.08 7.4 13.0 3.14 18.2 3.22 23.4 3.30 27.7 3.35 32.1 3.41 39.0 3.53 44.2 3.60
G2FD048(S,H)21,24 39.5 3.34 23.4 2.10 7.4 12.4 3.04 17.9 3.15 23.4 3.27 28.9 3.38 34.9 3.46 39.5 3.47 46.8 3.66
G1HD048 39.03.2423.42.10 7.4 11.82.9617.63.1123.43.2729.23.4233.13.4339.03.5247.83.82
G1NA048S21D 40.5 3.26 23.4 2.10 7.4 12.0 3.02 17.7 3.14 23.4 3.27 27.0 3.30 30.5 3.33 40.5 3.64 46.2 3.77
G1NA048S24P 40.5 3.26 23.4 2.10 7.4 12.0 3.02 17.7 3.14 23.4 3.27 27.0 3.30 30.5 3.33 40.5 3.64 46.2 3.77
G1UA048S21 39.03.2423.42.10 7.4 11.82.9717.63.1223.43.2729.23.4135.63.5339.03.5246.13.75
G1FA048S21 39.0 3.24 23.4 2.10 7.4 11.8 2.97 17.6 3.12 23.4 3.27 29.2 3.41 35.6 3.53 39.0 3.52 46.1 3.75
EBBA-F048S
G2FD048(S,H)21,24 47.0 3.02 31.2 2.32 7.5 21.0 3.56 26.1 3.75 31.2 3.94 36.3 4.13 40.1 4.32 47.0 4.56 54.1 4.59
G2FD060(S,H)24 47.0 3.00 31.2 2.30 7.5 21.0 3.60 26.1 3.79 31.2 3.98 36.3 4.17 42.0 4.39 47.0 4.59 54.1 4.61
G1HD048 47.03.0031.22.30 7.5 20.93.6026.13.7931.23.9836.34.1742.04.4147.04.5953.94.63
G1HD060 47.03.0031.22.30 7.5 20.73.5625.93.7731.23.9835.64.2140.04.4547.04.5952.34.80
G1NA048S21D 47.0 2.96 31.2 2.30 7.5 20.7 3.52 25.9 3.75 31.2 3.98 35.2 4.13 39.2 4.29 47.0 4.65 52.3 4.88
G1NA048S24P 47.0 2.96 31.2 2.30 7.5 20.7 3.52 25.9 3.75 31.2 3.98 35.2 4.13 39.2 4.29 47.0 4.65 52.3 4.88
G1UA048S21 47.03.0031.22.30 7.5 20.93.6026.13.7931.23.9836.34.1642.04.3947.04.5954.04.61
G1UA060S21,24 47.0 3.00 31.2 2.30 7.5 21.0 3.60 26.1 3.79 31.2 3.98 36.3 4.17 42.0 4.39 47.0 4.59 54.1 4.61
G1FA048S21 47.0 3.00 31.2 2.30 7.5 20.9 3.60 26.1 3.79 31.2 3.98 36.3 4.16 42.0 4.39 47.0 4.59 54.0 4.61
G1FA060S21,24 47.03.0031.22.30 7.5 21.03.6026.13.7931.23.9836.34.1742.04.3947.04.5954.14.61
For Notes see Page 7.

036-21318-002 Rev. A (0106)
Unitary Products Group 9
COP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric
power input during the same period.
— = Not Applicable.
ACCESSORIES
Refer to Price Manual for specific model numbers.
Start Assist Kit (2SA067*)
Blower Time Delay - Available to increase efficiency when
installed. Installs on indoor section and maintains blower for
approximately one minute after cooling thermostat has been
satisfied.
Hard Start Kits - Provides required starting torque for use
with Thermal Expansion Valve Kit.
Low Temperature Cutout (2LT06700224) - Prevents heat
pump operation below -10°F ambient temperature.
Compressor Blanket - Designed to further reduce the nor-
mal operating sound.
Add-on Fossil Fuel Control - Interface controls for use with
gas, oil furnaces and the heat pump system are available.
Thermal Expansion Valve Kit - 1TV0700 Series TXV kit
used to improve system performance.
Outdoor Thermostat (2TD06700124) - Provides additional
staging of supplemental electric heat.
Room Thermostats - A wide selection of matching
thermostats is available to provide features required for
any installation.
2H/1C, manual change-over electronic non-programmable
thermostat.
3H/2C, non-programmable digital thermostat.
3H/2C, auto/manual changeover, electronic programmable,
7-day, hardwire thermostat.
* For the most current accessory information, refer to the
price book or consult factroy.
SOUND RATINGS*
*Rated in accordance with ARI Standard 270.
All dimensions are in inches. They are subject to change without
notice. Certified dimensions will be provided upon request.
EBBA-(T,W)048S
G2FD048(S,H)21,24 47.0 3.02 31.2 2.32 7.5 21.0 3.56 26.1 3.75 31.2 3.94 36.3 4.13 40.1 4.32 47.0 4.56 54.1 4.59
G1NA048S21D 47.0 2.96 31.2 2.30 7.5 20.7 3.52 25.9 3.75 31.2 3.98 35.2 4.13 39.2 4.29 47.0 4.65 52.3 4.88
G1UA048S21 47.03.0031.22.30 7.5 20.93.6026.13.7931.23.9836.34.1642.04.3947.04.5954.04.61
G1FA048S21 47.0 3.00 31.2 2.30 7.5 20.9 3.60 26.1 3.79 31.2 3.98 36.3 4.16 42.0 4.39 47.0 4.59 54.0 4.61
EABA-F060S
G2FD060(S,H)24 56.5 3.10 37.0 2.30 7.5 24.1 4.30 30.6 4.51 37.0 4.71 43.4 4.92 48.2 5.09 56.5 5.34 65.9 5.59
G1HD060 57.0 3.10 37.0 2.30 7.5 24.0 4.30 30.5 4.51 37.0 4.71 43.5 4.92 48.3 5.10 57.0 5.37 66.1 5.55
G1NA060S24T 58.03.1637.02.38 7.5 23.04.0130.04.2837.04.5640.94.6944.84.8258.05.3865.05.65
G1UA060S21,24 56.5 3.10 37.0 2.30 7.5 24.1 4.30 30.6 4.51 37.0 4.71 43.4 4.92 48.2 5.09 56.5 5.34 65.9 5.59
G1FA060S21,24 56.53.1037.02.30 7.5 24.14.3030.64.5137.04.7143.44.9248.25.0956.55.3465.95.59
EABA-(T,W)060S G2FD060(S,H)24 58.0 3.20 38.5 2.40 7.7 25.5 4.29 32.0 4.50 3.9 4.70 42.1 4.91 45.7 5.11 58.0 5.31 64.5 5.51 G1UA060S24 58.0 3.20 38.5 2.40 7.7 25.5 4.29 32.0 4.50 3.9 4.70 42.1 4.91 45.7 5.11 58.0 5.31 64.5 5.51
G1FA060S24 58.0 3.20 38.5 2.40 7.7 25.5 4.29 32.0 4.50 3.9 4.70 42.1 4.91 45.7 5.11 58.0 5.31 64.5 5.51
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and no supplemental electric
heat operation.
3. Integrated heating capacities include the effect of defrost cycles in the temperature range where they occur.
HEATING PERFORMANCE - With Furnace Coils (Continued)
UNIT
MODEL* COIL1
MODEL
ARI HEATING2OUTDOOR TEMP3
47°F17°FHSP
F-3°F7°F17°F27°F37°F47°F57°F
MBH COP MBH COP STD MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW MBH KW
UNIT
MODEL SOUND RATINGS DECIBELS
018 80
024 80
030 80
036 82
042 82
048 77
060 82
DIMENSIONS - 1 PHASE
UNIT
MODEL DIMENSIONS (INCHES)
REFRIGERANT
CONNECTION
LINE SIZE
A1
1. Including fan guard.
B C Liquid Vapor
018 19 35 23
3/8” 3/4”
024 25 35 23
030 25 35 23
036 25 35 23
042 27 37 27
048 33 37 27 7/8”
060 39 37 27
DIMENSIONS - 3 PHASE
UNIT
MODEL DIMENSIONS (INCHES)
REFRIGERANT
CONNECTION
LINE SIZE
A1
1. Including fan guard.
B C Liquid Vapor
036 25 35 23 3/8” 3/4”
048 33 37 27 7/8”
060 26 43 32 7/8”
090 32 43 32 1/2” 1-1/8”
C
B
A

036-21318-002 Rev. A (0106)
10 Unitary Products Group
TYPICAL INSTALLATION
TYPICAL FIELD WIRING - 1 PH
MINIMUM 24” SERVICE ACCESS
CLEARANCE ON ONE SIDE
60” OVERHEAD
CLEARANCE
10” CLEARANCE
COIL AREA
WEATHERPROOF
DISCONNECT
SWITCH
THERMOSTAT TO FURNACE OR
AIR HANDLER
TERMINAL BLOCK
NEC CLASS 1 WIRING
NEC CLASS 2 WIRING
TO INDOOR COIL
SEAL OPENING(S) WITH
PERMAGUM OR EQUIVALENT
CONTROL ACCESS PANEL
NOTE: ALL OUTDOOR WIRING
MUST BE WEATHERPROOF.
THERMOSTAT INDOOR UNIT
OUTDOOR UNIT
LOW VOLTAGE TERMINAL BLOCK
IN AIR HANDLER WITH ELECTRIC HEAT
3,4
DEFROST
CONTROL
1FIELD
INSTALLED
JUMPER
DEHUMIDIFICATION CONTROL CONNECTION
(Humidistat* Jumper must be removed)
GND.
SCREW
CONTACTOR
T2 T1
L2 L1
M
R
LorX
Y
O
W
G
T2
E2
RR
YY
O
O
W2 W
W1
CC
X/L
G
W1
BK
GND.
LUG
CIRCUIT
BREAKER***
POWER WIRING
24V CONTROL WIRING
(NEC CLASS 2)
JUMPER TERMINALS E AND W TO HEAT
ON FIRST STAGE DURING EMERGENCY HEAT.
1
2
TERMINAL NOT USED ON ALL THERMOSTATS. POWER WIRING
208/230-1-60
230-1-50
3CHECK THE LOW VOLTAGE TERMINAL BLOCK ON THE INDOOR UNIT FOR THE ACTUAL ARRANGEMENT OF THE TERMINALS.
4CONNECT POWER WIRING TO TERMINAL BLOCK 3TB ON UNITS WITHOUT ELECTRIC HEAT OR CIRCUIT BREAKER.
BorC
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
RED
BLK
YEL
ORG
BRN
PUR
WHT
CC
GRY
/66
5GRAY FOR USE WITH OPTIONAL OUTDOOR THERMOSTAT KITS.
5

036-21318-002 Rev. A (0106)
Unitary Products Group 11
TYPICAL FIELD WIRING - 3 PH (036 - 060)
TYPICAL FIELD WIRING - 3 PH (090)
THERMOSTAT INDOOR UNIT
OUTDOOR UNIT
LOW VOLTAGE TERMINAL BLOCK
IN AIR HANDLER WITH ELECTRIC HEAT
3,4
DEFROST
CONTROL
1FIELD
INSTALLED
JUMPER
GND.
SCREW
CONTACTOR
T2 T1
L2 L1
M
R
LorX
Y
O
W
G
T2
E2
RR
YY
O
O
W2 W
W1
C
X
G
W1
GND.
LUG
POWER WIRING
24V CONTROL WIRING
(NEC CLASS 2)
JUMPER TERMINALS E AND W TOHEAT
ON FIRST STAGE DURING EMERGENCY HEAT.
1
2
TERMINAL NOT USED ON ALL THERMOSTATS.
POWER WIRING
208/230-3-60
460-3-50
3CHECK THE LOW VOLTAGE TERMINAL BLOCK ON THE INDOOR UNIT FOR THE ACTUAL ARRANGEMENT OF THE TERMINALS.
4CONNECT POWER WIRING TO TERMINAL BLOCK 3TB ON UNITS WITHOUT ELECTRIC HEAT OR CIRCUIT BREAKER.
BorC
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
RED
BLK
YEL
ORG
BRN
PUR
WHT /66
5GRAY FOR USE WITH OPTIONAL OUTDOOR THERMOSTAT KITS.
BorC
POWER
SUPPLY
208/230-3-60
460-3-50
T3
L3
CC
GRY
5
THERMOSTAT INDOOR UNIT
OUTDOOR UNIT
LOW VOLTAGE TERMINAL BLOCK
IN AIR HANDLER WITH ELECTRIC HEAT
3,4
DEFROST
CONTROL
1FIELD
INSTALLED
JUMPER
GND.
SCREW
CONTACTOR
T2 T1
L2 L1
M
R
X
Y
O
W
G
T2
E2
RR
YY
O
O
WW
W1
C
X
53
G
GND.
LUG
POWER WIRING
24V CONTROL WIRING
(NEC CLASS 2)
JUMPER TERMINALS E AND W TOHEAT
ON FIRST STAGE DURING EMERGENCY HEAT.
1
2
TERMINAL NOT USED ON ALL THERMOSTATS.
POWER WIRING
208/230-3-60
460-3-50
3
CHECK THE LOW VOLTAGE TERMINAL BLOCK ON THE INDOOR UNIT FOR THE ACTUAL ARRANGEMENT OF THE TERMINALS.
4CONNECT POWER WIRING TO TERMINAL BLOCK 3TB ON UNITS WITHOUT ELECTRIC HEAT OR CIRCUIT BREAKER.
BorC
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
RED
BLK
YEL
ORG
BRN
PUR
WHT /66
C
POWER
SUPPLY
208/230-3-60
460-3-50
T3
L3
X
60
60
5FIELD
INSTALLED
JUMPER
3
TERMINAL NOT USED ON ALL THERMOSTATS.
5REQUIRED ON ALL ELECTRIC HEAT

036-21318-002 Rev. A (0106)
12 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EBBA-F018S
INDOOR COIL MODEL NO. F2RP/F2FP018
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 500 650 800
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75 T.C. 20.8 18.3 15.1 22.4 19.4 16.0 23.1 20.0 16.6 S.C. 11.7 11.0 9.8 13.8 12.7 11.5 15.5 14.2 12.8
KW 1.71 1.91 1.83 1.73 1.94 1.86 1.76 1.98 1.88
85 T.C. 19.4 17.2 14.5 20.5 18.2 15.5 21.1 18.7 16.0 S.C. 11.4 10.8 10.0 13.4 12.5 11.7 15.0 14.0 13.0
KW 1.78 1.90 1.92 1.80 1.93 1.95 1.83 1.96 1.97
95 T.C. 17.9 16.1 13.8 18.7 17.0 15.0 19.0 17.5 15.5 S.C. 11.2 10.5 10.2 13.0 12.3 11.9 14.5 13.8 13.3
KW 1.85 1.89 2.02 1.87 1.92 2.04 1.89 1.94 2.06
105 T.C. 15.5 14.9 12.5 16.3 15.7 13.3 16.6 16.3 13.8 S.C. 10.5 10.0 9.3 12.3 11.9 11.0 13.8 13.4 12.4
KW 2.08 1.99 2.02 2.11 2.02 2.04 2.13 2.04 2.06
115 T.C. 13.0 13.8 11.2 13.9 14.5 11.7 14.3 15.0 12.0 S.C. 9.8 9.5 8.4 11.7 11.6 10.1 13.1 13.1 11.5
KW 2.32 2.09 2.03 2.35 2.12 2.05 2.36 2.13 2.07
125 T.C. 10.5 12.6 9.8 11.6 13.3 10.0 11.9 13.8 10.3 S.C. 9.2 9.0 7.5 11.0 11.2 9.3 12.4 12.7 10.5
KW 2.56 2.19 2.04 2.59 2.22 2.06 2.60 2.23 2.07
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHB0806 G2FD024(S,H)17 1.05 1.04 1.04
F2RP/F2FP024 1.05 1.01 1.04
G1FA024S14,17 1.04 1.03 1.04
G1FA030S14 1.05 1.05 1.04
G1HD024 1.06 1.05 1.05
G1NA030S17H 1.06 1.10 1.02
G1NA030S21B 1.06 1.10 1.02
G1UA024S14,17 1.04 1.03 1.04
G1UA030S14 1.05 1.05 1.04
G2FD024(S,H)14,17 1.05 1.04 1.04

036-21318-002 Rev. A (0106)
Unitary Products Group 13
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EBBA-F024S
INDOOR COIL MODEL NO. F2RP/F2FP030
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 650 850 1050
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75 T.C. 26.6 24.3 22.4 20.0 27.0 24.7 22.7 20.3 27.1 24.8 22.8 20.9 S.C. 15.7 15.7 15.0 15.8 16.4 16.4 15.8 16.6 16.8 16.8 16.2 17.4
KW 2.20 2.12 2.06 1.97 2.21 2.13 2.07 1.99 2.21 2.14 2.08 2.01
85 T.C. 25.7 23.5 21.5 19.4 26.1 23.8 21.9 19.8 26.2 23.9 22.0 20.0 S.C. 15.8 15.8 15.1 16.1 16.7 16.7 16.0 17.0 17.1 17.1 16.5 17.4
KW 2.35 2.25 2.18 2.11 2.37 2.27 2.19 2.12 2.37 2.27 2.20 2.12
95 T.C. 23.9 21.7 20.1 17.9 24.2 22.0 20.4 18.2 24.3 22.1 20.5 18.6 S.C. 15.5 15.4 15.0 15.5 16.5 16.5 15.9 16.6 17.0 17.0 16.4 17.1
KW 2.50 2.40 2.30 2.21 2.51 2.41 2.33 2.22 2.52 2.42 2.34 2.25
105 T.C. 21.7 19.7 18.2 16.4 21.9 20.1 18.5 16.8 22.1 20.2 18.6 17.0 S.C. 15.0 15.0 14.3 15.1 16.1 16.2 15.2 15.5 16.7 16.6 15.6 15.7
KW 2.64 2.51 2.42 2.32 2.65 2.53 2.44 2.35 2.66 2.53 2.45 2.37
115 T.C. 19.5 17.8 16.3 14.8 19.8 18.1 16.7 15.2 19.9 18.1 17.0 15.4 S.C. 14.4 14.3 13.6 13.7 15.5 15.4 14.5 14.1 15.9 15.8 14.7 14.2
KW 2.74 2.61 2.51 2.41 2.76 2.62 2.54 2.45 2.77 2.64 2.56 2.46
125 T.C. 17.3 15.9 14.5 13.2 17.7 16.1 15.0 13.6 17.7 16.0 15.3 13.8 S.C. 13.8 13.6 12.9 12.2 14.9 14.6 13.7 12.7 15.1 15.0 13.7 12.7
KW 2.84 2.72 2.61 2.50 2.87 2.72 2.65 2.55 2.88 2.74 2.68 2.55
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHB0806 G2FD030(S,H)17 1.00 0.96 1.01
F2RP/F2FP024 0.97 0.98 0.98
G1FA030S14 0.98 0.98 1.00
G1FA036S17,21 1.00 0.96 1.01
G1HD024 0.98 0.98 0.99
G1NA030S17H 1.02 0.96 1.01
G1NA030S21B 1.02 0.96 1.01
G1UA030S14 0.98 0.98 1.00
G1UA036S17,21 1.00 0.96 1.01
G2FD024(S,H)14,17 0.97 0.94 0.98
G2FD030(S,H)17 1.00 0.96 1.01
G2FD035(S,H)14 1.00 0.96 1.01

036-21318-002 Rev. A (0106)
14 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABA-F030S
INDOOR COIL MODEL NO. F2RP/F2FP036
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 850 1050 1250
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75 T.C. 27.1 27.3 26.5 28.3 28.3 28.6 28.8 29.1 29.7 S.C. 19.7 19.9 19.1 20.9 20.9 21.2 21.4 21.7 22.3
KW 2.77 2.75 2.71 2.79 2.74 2.72 2.79 2.75 2.72
85 T.C. 27.3 26.9 26.9 29.1 28.4 27.9 30.0 29.8 29.3 S.C. 19.9 19.5 19.5 21.7 21.0 20.5 22.6 22.4 21.9
KW 2.95 2.90 2.86 2.98 2.91 2.87 2.99 2.93 2.88
95 T.C. 27.6 26.5 27.2 29.8 28.4 27.2 31.2 30.4 28.9 S.C. 20.2 19.1 19.8 22.4 21.0 19.8 23.8 23.0 21.5
KW 3.13 3.06 3.01 3.16 3.09 3.03 3.18 3.12 3.05
105 T.C. 26.6 25.6 25.4 29.0 27.7 26.5 30.6 29.6 28.2 S.C. 19.2 18.2 18.0 21.6 20.3 19.1 23.2 22.2 20.8
KW 3.29 3.22 3.15 3.32 3.25 3.18 3.34 3.28 3.20
115 T.C. 25.5 24.7 23.5 28.1 27.0 25.8 30.0 28.8 27.6 S.C. 18.1 17.3 16.1 20.7 19.6 18.4 22.6 21.4 20.2
KW 3.44 3.38 3.29 3.47 3.41 3.33 3.50 3.44 3.35
125 T.C. 24.5 23.9 21.7 27.3 26.4 25.0 29.4 28.0 26.9 S.C. 17.1 16.5 14.3 19.9 19.0 17.6 22.0 20.6 19.5
KW 3.60 3.53 3.43 3.63 3.56 3.48 3.66 3.59 3.50
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHB1206 G2FD030(S,H)17 0.97 0.94 1.00
F2RP/F2FP030 0.98 1.00 1.00
G1FA036S14 0.98 0.99 1.01
G1FA036S17,21 0.97 0.97 1.00
G1HD036 0.98 1.00 1.00
G1NA030S17H 1.00 0.99 1.00
G1NA030S21B 1.00 0.99 1.00
G1UA036S14 0.98 0.99 1.01
G1UA036S17,21 0.97 0.94 1.00
G2FD030(S,H)17 0.97 0.94 1.00
G2FD035(S,H)14 0.97 0.94 1.00
G2FD036(S,H)17 0.98 0.95 1.00
G2FD036(S,H)21 0.99 0.95 1.00

036-21318-002 Rev. A (0106)
Unitary Products Group 15
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
1 Phase 3 Phase
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABA-F036S, EABA-(T,W)036S)
INDOOR COIL MODEL NO. F2RP/F2FP036
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1000 1250 1400
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75 T.C. 38.1 35.0 32.5 29.4 38.6 35.5 32.9 29.9 38.8 35.7 33.2 30.2 S.C. 22.9 22.9 22.1 23.6 24.1 24.2 23.4 24.8 24.9 24.9 24.1 25.5
KW 3.15 3.08 3.02 2.94 3.16 3.10 3.03 2.96 3.17 3.10 3.04 2.97
85 T.C. 37.6 34.6 32.0 28.9 38.1 35.1 32.7 29.4 38.3 35.3 33.0 29.7 S.C. 23.3 23.4 22.6 23.9 24.8 24.9 24.1 25.3 25.7 25.7 25.0 26.1
KW 3.39 3.30 3.22 3.12 3.40 3.32 3.24 3.14 3.41 3.33 3.25 3.15
95 T.C. 36.2 33.3 30.9 27.7 36.7 33.7 31.4 28.3 36.8 34.0 31.6 28.6 S.C. 23.3 23.3 22.6 23.7 24.9 24.9 24.0 25.4 25.8 25.9 24.9 26.2
KW 3.71 3.60 3.51 3.38 3.72 3.62 3.53 3.40 3.74 3.64 3.55 3.42
105 T.C. 34.4 31.5 29.2 26.3 34.7 32.0 29.6 26.8 35.0 32.2 29.9 27.3 S.C. 22.9 22.9 22.1 23.3 24.5 24.5 23.5 24.7 25.6 25.5 24.6 25.5
KW 4.03 3.90 3.79 3.63 4.06 3.93 3.82 3.67 4.06 3.94 3.82 3.71
115 T.C. 32.2 29.6 27.4 24.7 32.6 30.0 27.8 25.5 32.8 30.2 28.1 25.8 S.C. 22.2 22.2 21.4 22.4 23.9 23.8 22.9 23.8 24.8 24.8 23.8 24.1
KW 4.34 4.19 4.05 3.88 4.37 4.22 4.09 3.93 4.38 4.24 4.10 3.96
125 T.C. 30.0 27.7 25.6 23.1 30.5 28.0 26.0 24.2 30.6 28.2 26.3 24.3 S.C. 21.5 21.5 20.6 21.5 23.3 23.1 22.2 22.9 24.0 24.1 23.1 22.7
KW 4.65 4.48 4.31 4.13 4.68 4.51 4.36 4.19 4.70 4.54 4.38 4.21
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHB1206 G2FD036(S,H)17 0.99 1.00 1.01
F2RP/F2FP042 1.00 1.00 1.00
G1FA048S21 1.01 0.99 1.01
G1HD036 0.98 0.99 1.00
G1HD048 1.04 1.04 1.02
G1NA036S17L 1.03 1.05 1.03
G1NA048S21D 1.03 1.05 1.04
G1UA048S21 1.01 0.99 1.01
G2FD036(S,H)17 0.99 1.00 1.01
G2FD036(S,H)21 1.00 0.98 0.99
G2FD042(S,H)21 1.01 1.02 1.01
G2FD046(S,H)17 1.02 1.03 1.01
Air Handler Coil T.C. S.C. KW
N1AHC1646 G2FD042(S,H)21 1.01 1.02 1.01
F2RP/F2FP042 1.00 1.00 1.00
G1FA048S21 1.01 0.99 1.01
G1NA036S17L 1.03 1.05 1.03
G1NA048S21D 1.03 1.05 1.04
G1UA048S21 1.01 0.99 1.01
G2FD042(S,H)21 1.01 1.02 1.01

036-21318-002 Rev. A (0106)
16 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABA-F042S
INDOOR COIL MODEL NO. F2RP/F2FP042
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1200 1400 1600
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75 T.C. 44.8 42.1 38.8 45.8 43.0 40.4 46.2 43.5 40.9 S.C. 27.9 28.4 27.4 29.9 29.7 29.5 30.8 30.8 30.9
KW 3.74 3.69 3.63 3.76 3.71 3.66 3.78 3.73 3.67
85 T.C. 42.9 39.6 35.7 43.9 41.0 37.1 44.4 41.3 37.9 S.C. 27.7 27.4 26.0 29.7 29.3 28.1 30.7 30.7 29.8
KW 3.96 4.02 3.79 3.99 4.05 3.83 4.01 4.07 3.85
95 T.C. 41.1 37.1 32.7 42.0 39.0 33.9 42.5 39.1 34.9 S.C. 27.5 26.4 24.7 29.5 28.8 26.8 30.7 30.6 28.6
KW 4.18 4.35 3.95 4.22 4.38 4.00 4.24 4.41 4.03
105 T.C. 37.6 33.7 29.9 38.6 35.0 30.9 39.3 35.4 31.6 S.C. 26.3 24.9 23.4 28.4 27.2 25.4 30.1 29.0 27.2
KW 4.38 4.39 4.12 4.42 4.42 4.16 4.45 4.46 4.19
115 T.C. 34.2 30.2 27.1 35.2 31.0 27.8 36.0 31.8 28.3 S.C. 25.0 23.4 22.1 27.3 25.7 24.1 29.4 27.5 25.7
KW 4.58 4.42 4.28 4.62 4.47 4.32 4.66 4.50 4.35
125 T.C. 30.8 26.8 24.3 31.7 27.0 24.7 32.8 28.1 24.9 S.C. 23.8 21.9 20.9 26.2 24.1 22.8 28.7 25.9 24.2
KW 4.77 4.46 4.45 4.82 4.51 4.48 4.86 4.55 4.50
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHC1606 G2FD048(S,H)21 1.03 1.04 1.00
F2FP048 1.01 1.01 0.99
G1FA048S21 1.01 1.00 0.98
G1HD048 1.01 1.16 0.99
G1NA048S21D 1.04 1.01 0.97
G1UA048S21 1.01 1.00 0.98
G2FD042(S,H)21 1.00 1.02 0.98
G2FD046(S,H)17 1.01 1.03 0.99
G2FD048(S,H)21,24 1.03 1.04 1.00
G2FD060(S,H)24 1.03 1.04 0.98

036-21318-002 Rev. A (0106)
Unitary Products Group 17
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
1 Phase 3 Phase
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EBBA-F048S, EBBA-(T,W)048S
INDOOR COIL MODEL NO. F2FP048
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1300 1450 1550
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75 T.C. 52.3 48.3 45.0 40.6 53.0 49.0 45.7 41.3 53.4 49.4 46.1 41.9 S.C. 32.5 32.8 31.7 33.5 34.0 34.3 33.2 35.1 35.0 35.2 34.1 36.3
KW 4.14 4.07 4.02 3.95 4.16 4.08 4.04 3.97 4.17 4.09 4.05 3.97
85 T.C. 50.9 47.0 43.7 39.4 51.5 47.6 44.4 40.3 51.9 48.0 44.7 40.6 S.C. 32.4 32.6 31.6 33.3 34.0 34.2 33.2 35.1 35.2 35.4 34.2 36.2
KW 4.44 4.36 4.30 4.22 4.46 4.38 4.32 4.24 4.47 4.38 4.33 4.25
95 T.C. 48.8 45.0 41.8 37.9 49.2 45.5 42.4 38.4 49.6 45.8 42.7 38.7 S.C. 32.0 32.2 31.2 32.9 33.6 33.8 32.9 34.5 34.9 35.1 33.8 35.6
KW 4.87 4.79 4.73 4.64 4.90 4.81 4.74 4.66 4.91 4.81 4.76 4.67
105 T.C. 46.1 42.5 39.5 35.8 46.6 43.0 40.1 36.3 46.4 43.3 40.4 36.7 S.C. 31.0 31.1 30.1 32.0 32.9 32.9 31.9 33.7 33.8 34.3 32.9 35.1
KW 5.37 5.28 5.22 5.12 5.38 5.30 5.22 5.14 5.34 5.30 5.24 5.14
115 T.C. 43.2 39.9 37.0 33.5 43.6 40.3 37.6 34.2 43.8 40.6 37.9 35.0 S.C. 29.9 30.2 29.2 30.7 31.8 32.1 30.8 32.8 32.9 33.1 31.8 34.5
KW 5.90 5.80 5.74 5.66 5.90 5.80 5.76 5.66 5.92 5.83 5.78 5.68
125 T.C. 40.3 37.3 34.6 31.2 40.6 37.6 35.0 32.1 41.2 37.9 35.3 33.3 S.C. 28.8 29.3 28.2 29.4 30.7 31.3 29.7 31.9 32.0 31.9 30.8 33.9
KW 6.43 6.32 6.27 6.20 6.42 6.30 6.31 6.18 6.50 6.36 6.31 6.22
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHC1606 G2FD048(S,H)21 1.00 1.00 0.97
N1AHD2006 G2FD048(S,H)24 1.00 1.00 0.97
N1AHD2006 G2FD060(S,H)24 1.03 1.03 1.01
F2FP060 1.02 1.01 1.02
G1FA048S21 1.00 0.97 0.98
G1FA060S21,24 1.01 1.01 0.97
G1HD048 0.98 0.98 0.96
G1HD060 1.00 1.00 0.96
G1NA048S21D 0.99 0.93 0.95
G1UA048S21 1.00 0.97 0.98
G1UA060S21,24 1.01 1.01 0.97
G2FD048(S,H)21,24 1.00 1.00 0.97
G2FD060(S,H)24 1.01 1.01 0.96
Air Handler Coil T.C. S.C. KW
N1AHC1646 G2FD048(S,H)21 1.00 1.00 0.97
N1AHD2046 G2FD048(S,H)24 1.00 1.00 0.97
F2FP060 1.02 1.01 1.02
G1FA048S21 1.00 0.97 0.98
G1NA048S21D 0.99 0.93 0.95
G1UA048S21 1.00 0.97 0.98
G2FD048(S,H)21,24 1.00 1.00 0.97

036-21318-002 Rev. A (0106)
18 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABA-F060S
INDOOR COIL MODEL NO. F2FP060
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1550 1750 1950
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75 T.C. 62.6 57.9 53.9 48.8 63.6 58.8 54.9 49.7 64.1 59.4 55.4 50.3 S.C. 39.7 40.1 38.8 41.2 42.3 42.6 41.3 43.6 44.0 44.4 43.0 45.4
KW 5.15 5.08 5.03 4.94 5.16 5.09 5.05 4.96 5.17 5.10 5.06 4.98
85 T.C. 60.0 55.5 51.8 46.7 61.0 56.4 52.7 47.7 61.4 56.8 53.2 48.3 S.C. 38.8 39.1 38.0 40.1 41.3 41.6 40.3 42.5 42.8 43.2 42.0 44.4
KW 5.61 5.54 5.48 5.39 5.63 5.55 5.51 5.41 5.64 5.57 5.53 5.42
95 T.C. 57.7 53.3 49.6 44.8 58.4 54.0 50.3 45.7 58.8 54.4 51.1 46.3 S.C. 38.0 38.3 37.1 39.1 40.2 40.5 39.3 41.4 41.9 42.2 41.1 43.3
KW 6.33 6.25 6.20 6.09 6.35 6.28 6.22 6.11 6.36 6.29 6.23 6.12
105 T.C. 55.1 50.9 47.4 42.8 55.6 51.5 48.2 43.6 56.0 51.8 48.7 44.1 S.C. 37.1 37.4 36.1 38.0 39.3 39.5 38.5 40.5 40.9 41.1 40.1 42.2
KW 7.16 7.08 7.02 6.90 7.19 7.11 7.04 6.93 7.20 7.13 7.06 6.94
115 T.C. 52.0 48.1 44.8 40.4 52.5 48.6 45.6 41.2 52.9 49.2 46.0 41.8 S.C. 35.6 36.0 34.8 36.8 38.0 38.3 37.3 39.3 39.7 40.4 38.8 40.9
KW 8.13 8.02 7.95 7.82 8.14 8.04 7.97 7.84 8.15 8.05 7.99 7.86
125 T.C. 48.9 45.3 42.1 38.0 49.4 45.7 42.9 38.8 49.8 46.6 43.2 39.5 S.C. 34.2 34.7 33.6 35.5 36.7 37.1 36.2 38.1 38.5 39.7 37.4 39.6
KW 9.10 8.96 8.89 8.74 9.09 8.97 8.91 8.76 9.10 8.97 8.93 8.79
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHD2006 G2FD060(S,H)24 1.01 0.97 0.97
G1FA060S21,24 1.01 0.97 0.98
G1HD060 1.01 0.84 0.99
G1NA060S24T 0.99 0.88 0.95
G1UA060S21,24 1.01 0.97 0.98
G2FD060(S,H)24 1.01 0.97 0.98

036-21318-002 Rev. A (0106)
Unitary Products Group 19
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABA-(T,W)060S)
INDOOR COIL MODEL NO. G2FD060(S,H)24
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1600 1800 2000
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 71 67 63 71 67 63 71 67 63
65 T.C. 63.0 61.1 60.7 62.9 60.9 61.1 62.9 60.6 61.4 S.C. 39.6 39.7 40.3 41.6 41.5 42.2 43.7 43.3 44.1
KW 3.71 3.66 3.68 3.71 3.66 3.67 3.71 3.67 3.67
75 T.C. 62.3 59.8 57.9 62.5 60.0 58.5 62.6 60.1 59.0 S.C. 39.6 39.3 39.1 41.8 41.3 41.1 43.9 43.3 43.1
KW 4.20 4.14 4.12 4.21 4.15 4.13 4.21 4.16 4.13
85 T.C. 61.7 58.5 55.1 62.0 59.1 55.9 62.3 59.6 56.6 S.C. 39.6 38.9 38.0 41.9 41.1 40.1 44.2 43.3 42.2
KW 4.70 4.63 4.57 4.71 4.64 4.58 4.72 4.65 4.60
95 T.C. 61.0 57.2 52.3 61.5 58.2 53.3 62.0 59.1 54.2 S.C. 39.6 38.5 36.8 42.0 40.9 39.0 44.4 43.3 41.2
KW 5.19 5.11 5.01 5.21 5.13 5.04 5.22 5.14 5.06
105 T.C. 58.3 53.9 49.1 59.1 54.7 49.9 60.0 55.6 50.7 S.C. 38.5 37.2 35.4 41.0 39.6 37.6 43.6 41.9 39.8
KW 5.78 5.67 5.55 5.80 5.69 5.57 5.82 5.71 5.60
115 T.C. 55.5 50.5 45.9 56.8 51.3 46.5 58.0 52.1 47.1 S.C. 37.4 35.9 34.0 40.1 38.2 36.2 42.7 40.5 38.3
KW 6.36 6.22 6.08 6.39 6.25 6.11 6.41 6.27 6.13
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHD2046 G2FD060(S,H)24 1.00 1.00 1.00
F2FP060 G1FA060S21,24 0.98 0.98 1.02
G1FA060S21,24 1.00 1.00 1.00
G1UA060S21,24 1.00 1.00 1.00

036-21318-002 Rev. A (0106)
20 Unitary Products Group
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABA-(T,W)090S
INDOOR COIL MODEL NO. FCEH090
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 2400 3000 3600
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75 T.C. 103.9 94.3 88.5 107.3 98.0 92.1 110.6 101.8 95.7 S.C. 86.2 82.8 81.1 95.3 91.5 89.1 104.4 100.3 97.2
K.W 8.13 8.14 7.84 8.22 8.18 7.94 8.30 8.22 8.03
85 T.C. 99.6 91.2 85.5 103.1 94.6 88.8 106.5 98.0 92.1 S.C. 84.1 80.9 79.0 93.4 89.5 87.2 102.8 98.1 95.4
K.W 8.91 8.83 8.61 8.98 8.89 8.69 9.06 8.94 8.78
95 T.C. 95.3 88.2 82.4 98.8 91.2 85.5 102.3 94.2 88.6 S.C. 82.0 79.0 76.8 91.6 87.4 85.2 101.1 95.8 93.6
K.W 9.68 9.53 9.38 9.75 9.60 9.45 9.82 9.66 9.53
105 T.C. 91.1 84.2 78.6 94.4 86.9 81.5 97.6 89.5 84.5 S.C. 79.4 76.8 74.6 89.0 85.0 82.9 98.7 93.3 91.1
K.W 10.62 10.47 10.33 10.70 10.55 10.40 10.78 10.63 10.46
115 T.C. 86.9 80.2 74.7 89.9 82.5 77.6 92.9 84.8 80.5 S.C. 76.7 74.6 72.5 86.5 82.7 80.5 96.3 90.8 88.5
K.W 11.55 11.41 11.29 11.64 11.50 11.34 11.74 11.60 11.40
125 T.C. 82.7 76.2 70.8 85.4 78.2 73.6 88.1 80.1 76.4 S.C. 74.1 72.4 70.3 84.0 80.4 78.2 93.8 88.3 86.0
K.W 12.48 12.35 12.24 12.59 12.46 12.29 12.69 12.57 12.33
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
