York R-410A Quick start guide

®
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
333495-YTG-C-0908
TECHNICAL GUIDE Description
These York® Affinity™ packaged heat pumps are designed for
outdoor installation. Only utility and duct connections are
required at the point of installation.
Field-installed electric heater accessories are available to
provide electric heat, if required.
R-410A
AFFINITY™ SERIES
BHX AND BHZ MODELS
2 - 5 TON
60 Hertz
Tested in accordance with:
ISO 9001
Certified Quality
Management System

333495-YTG-C-0908
2Johnson Controls Unitary Products
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Component Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Heat Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features and Benefits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Guide Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Physical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Capacity Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Sound Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Component Location
Heat Pump
Direct Drive Condenser
Fan Motor
Highly Efficient Enhanced Copper
Tube/Aluminum Fin
Indoor Coil
Highly Efficient Enhanced Copper
Tube/Aluminum Fin
Outdoor Coil
Decorative Protective
Coil Guard
Direct Drive Blower Motor With
Slide-Out Blower Assembly
Heavy Gauge
Removable Base Rails
High-Efficiency Compressor
Rigidly Mounted
Long-Lasting
Powder Paint Finish
Low Voltage
Terminal Block
High Voltage
Terminal Block
Back And Bottom
Return Air and Supply
Air Duct Opening

333495-YTG-C-0908
Johnson Controls Unitary Products 3
Nomenclature
Heat Pump
Features and Benefits
Standard Features
•Operating Efficiency - All heat pump units provide
operating efficiencies of 13 to 15 SEER and 7.7 to 8.0
HSPF. All efficiencies exceed legislated minimum levels.
•On Site Flexibility - All model sizes share a common,
compact design cabinet in a single footprint. The installer
has the flexibility of setting one curb and placing the
proper tonnage unit on that curb after the internal load has
been determined. Field convertible duct connections from
side shot to down shot allows the installer to have greater
flexibility with less inventory.
•Lower Installation Cost - Installation time and costs are
reduced by easy power and control wiring connections.
The small base dimension means less space is required
on the ground or roof, plus, the installer can fit this unit
between the wheel wells of full size pick-up truck.
• All units are completely wired, charged with R-410A and
tested prior to shipment. Unique test stations using a new
state of the art computerized process system are used to
insure product quality. Refrigerant charge and component
part numbers are verified via computers at assembly. Vital
run test statistics such as system pressure, motor
currents, air velocity and temperature, unit vibration, and
gas system safeties are monitored and recorded by the
system to insure unit performance.
• Equal size, side supply and return duct connections
allows easy hook-up of ducts to match low crawl spaces
without transition pieces.
•Utility Connections Made Easy - Electric utility
knockouts are provided through the bottom as well as the
side of the unit. Utility connections can be made quickly
and with a minimum amount of field labor. A field supplied
and field installed electrical disconnect switch must be
installed.
•Convertible Airflow Design - The bottom duct openings
are covered when they leave the factory ready to be used
for a side supply/side return application. If a bottom
supply/bottom return application is desired, you simply
remove the two panels from the bottom of the unit and
place them in the side supply/side return duct openings.
No panel cutting is required and no accessory panel is
necessary. Convertible airflow design allows maximum
field flexibility and minimum inventory.
•Condensate Pan - A non-corrosive, long-lasting, water-
tight pan is positioned below the evaporator coil to collect
and drain all condensate. Less collection of stagnate
condensate will build-up. The condensate pan conforms
to ASHRAE 62-89 standards (Ventilation for Acceptable
Indoor Air Quality).
•Condensate Drain - The 3/4 inch NPTF connection is
rigidly mounted to assure proper fit and leak tight seal.
•Durable Finish - With a heavy duty cabinet made of
powder-painted, galvanized steel the neutral color blends
into surrounding areas. The powdered paint provides a
better paint to steel bond, which resists corrosion and rust
creep. The special primer formulas and glossy finish
insures less fading when exposed to sunlight and offers a
more attractive on site appearance. This paint finish
meets ASTM-B117 standards for 1000 hours salt spray
rating. The highest in the industry.
•Full Perimeter Base Rails - The easily removable base
rails provide a solid foundation for the entire unit and
protects the unit during shipment. The rails provide fork lift
access from all sides, and rigging holes are also provided
so that an overhead crane can be used to place the units
on a roof. On applications where the unit is placed on a
pad, the base will keep the unit off the pad to deter
corrosion. On applications where height is limited, the inch
high base rails may be removed on location.
B 1 024 06
A
HZ
Product Category
B = Single Package Heat Pumps
(Air Cooled)
Product Generation
1 = New or Current Design
2 = 2nd Generation
Factory Installed Electric Heat
A = No Electric Heat Installed
Product Identifier
HZ = R-410A 13 SEER
HX = R-410A 15 SEER
024 = 24,000 BTUH
030 = 30,000 BTUH
036 = 36,000 BTUH
Voltage Code
06 = 208/230-1-60
25 = 208/230-3-60
46 = 460-3-60
042 = 42,000 BTUH
048 = 48,000 BTUH
060 = 60,000 BTUH
Nominal Cooling Capacity (MBH)

333495-YTG-C-0908
4Johnson Controls Unitary Products
•More Attractive Appearance - A single piece Water
Shed top cover containing a top discharge condenser fan
arrangement requires less square footage on installation
and provides a wider variety of installations. The one
piece design adds greater water integrity. Rounded
corners with water drip edges add to the attractive
appearance. The cabinet panels have a non-fibrous
insulation that will not release insulation fibers into
conditioned area.
•Top Discharge - The top discharge condenser fan does
not disrupt neighboring areas or dry-out vegetation
surrounding the unit. The warm air from the top mounted
fan is blown up away from the structure and any
landscaping. This allows compact location on multi-unit
applications.
•Condenser Coil Grille - A multi-piece totally enclosed,
rigidly mounted condenser coil grille provides protection
from objects after installation and provides protection
during transit.
•Low Operating Sound Level - The upward air flow
carries the normal operating noise up and away from the
living area. The rigid top panel effectively isolates any
motor sound. Isolator mounted compressor and the
rippled fins of the condenser coil muffle the normal fan
motor and compressor operating sounds. The unique
formed base pan also aids in sound alterations with it's
Super-Structure design. This design strategically places
embossments in the pan for optimum strength and rigidity.
•Fan System - All models operate over a wide range of
design conditions with an electrically commutated fan
motor. These units easily match all types of applications
and provide greater on site flexibility to match comfort
requirement. The cooling speed is factory set and can be
field adjusted to a second speed. The heating speed is
factory set to maintain mid point rise at the units heating
input, but can be field adjusted. This allows maximum
comfort conditions.
•Simple Control Circuit - A low voltage printed circuit
board contains a diagnostic indicator light and a low
voltage terminal strip. An additional set of pin connectors
is also provided to simplify the field interface of external
controls. Mate-n-lock plug connectors are used. The
electrical control box is not located in the compressor
compartment. The controls are mounted on a Control-Tilt
control panel to allow the access cover to be removed for
trouble shooting and maintenance without affecting the
normal system operating pressures. All wiring internal to
the unit is color/number coded.
•Protected Compressor - The compressor is internally
protected against high pressure and temperature. This is
accomplished by the simultaneous operation of high
pressure relief valve and a temperature sensor which
protect the compressor if undesirable operating conditions
occur.
•Pressure Switches - High pressure and low pressure/
loss of charge switches standard in all units. When
abnormal conditions are sensed through the pressure
switches, the unit will lock out preventing any further
operation until reset or problem is corrected.
•Exclusive Coil Design - Grooved copper tubes and
enhanced aluminum fin construction improves heat
transfer for maximum efficiency and durability.
•Low Maintenance - Long life, permanently lubricated
condenser and evaporator fan motor bearings need no
annual maintenance adding greater reliability to the unit.
Blower assembly can be easily cleaned by the unique
Slip- Track slide-out blower assembly.
•Secured Service Access Ports - Protected, externally
mounted, re-usable service access ports are provided on
both the high and low lines for ease of evacuating and
charging the system. No final field mounting required.
•Easy Service Access - A large, single panel covers the
electrical and gas controls makes servicing easy. The
blower compartment has an additional large panel with a
built-in handle tab. Removing this panel will allow the
blower assembly to slide-out for easy removal for
maintenance and ease of trouble shooting.
•Replacement Parts - The installer requires no special
training to replace any of the components of these units
and does not need to maintain an inventory of unique
parts.
•System Integration - Each unit has the internal ability to
integrate an electronic air cleaner or humidifier to work in
conjunction with the base unit.
Field Installed Accessories
•Economizer Down Discharge/Supply Kit - Modulating
integrated economizer provides simultaneous operation
between the mechanical cooling and economizer
operation. Independent blade design insures proper
control and less than 1% leak rate. Includes hood and
mesh bird screen filter integrated into the hood, dry bulb
sensor and relief damper. Separate field accessories of
single enthalpy and dual enthalpy are also available. A
built-in barometric relief of 25% is provided.
•Single Enthalpy Sensor - Sensor replaces dry bulb
sensor standard in economizer kit. Provides improved
economizer operation by sensing the dry bulb
temperature from outdoors plus the enthalpy content of
the outdoor air.
•Dual Enthalpy Sensor - Additional sensor to single
enthalpy sensor. Sensor senses both the return air
temperature dry bulb and humidity in conjunction with the
single enthalpy to determine the most economical mix.
Single Enthalpy sensor also required.
•Hail Guard Kit - Kit contains protective grilles made of
expanded aluminum with full perimeter frame. Sloped
hoods are also included to assure maximum protection.
•Anti Short Cycle Timer (BHZ Units Only) -
Automatically prevents the compressor from restarting for
5 minutes after cycled off.Not required if Thermostat

333495-YTG-C-0908
Johnson Controls Unitary Products 5
2ET07700224 and 2ET04700224 are used. Standard in
all BHX units.
•Filter/Frame Kit (Single Phase Only) - Kit contains the
necessary hardware to field install return air filters into the
base unit. Pre-cut filter racks and appropriate cleanable
standard size filters are shipped in one kit. The filter rack
is suitable for either 1" or 2" filters. (1" filter is supplied)
This kit is available for single phase horizontal or vertical
duct application only. Standard in all 3 Phase models.
•Motorized Fresh Air Damper - Designed for duct
mounted side supply/return and unit mounted down
supply/return applications. Damper capable of providing
0% through 50% of outdoor air (field supplied). Closes on
power loss, includes hood and screen assembly.
•Rectangle To Round Adapters - Kit includes one supply
and one return air rectangle to round duct adapter.
Adapters are preformed and designed to fit over current
duct openings on the base unit. Transition is from side
square duct opening to 14" round duct opening.
•Roof Curbs - NRCA approved curbs provide proper fit to
base unit for rooftop installations. Curbs are designed to
be assembled through hinge pins in each corner. Kit also
provides seal strip to assure a water tight seal. 8 and 14
inch high roof curbs are available.
•Manual Outdoor Damper - Provides 0% through 50%
outdoor air capability (field adjustable). Designed for duct
mounted side supply/return applications. Includes hood
and screen assembly.
•Wall Thermostat - The units are designed to operate with
24-volt electronic and electro-mechanical thermostats. All
units can operate with single stage heat/single stage cool
thermostats - with or without the economizer.
•Low Ambient Kit - Kit provides necessary hardware to
convert unit to operate in cooling cycle down to 0º F.
Standard unit operation 45º F.
•Transformer Kit - Kit provides necessary hardware to
provide single phase models from factory furnished 40 VA
transformer capability to 75 VA transformer capability.
(Required on installations with economizer or motorized
damper.)
Guide Specifications
General
Units shall be manufactured by York International Unitary
Products Group in an ISO 9001 certified facility. YORK’s
Affinity™ package units give you the flexibility and choices you
need in today’s market. These packaged heat pumps are
designed for outdoor installation. Only utility and duct
connections are required at the point of installation.
Description
Units shall be factory-assembled, single packaged, heat pump
units, designed for outdoor mounted installation. For SEER
ratings, refer to technical literature. They shall have built in,
equal size, field convertible duct connections for down
discharge supply/return or horizontal discharge supply/return.
The units shall be factory wired, piped, charged with R-410A
Refrigerant and factory tested prior to shipment. All unit wiring
shall be both numbered and color coded. All units shall be
manufactured in a facility certified to ISO 9001 standards, and
the cooling performance shall be rated in accordance with DOE
and ARI test procedures. The heating performance shall be
rated to DOE and GAMA test procedures. Units shall be CSA
listed and classified to ANSI Z21.47/CAN/CSA 2.3 standards
and UL 1995/CAN/CSA No. 236-M90 conditions.
Unit Cabinet
Unit cabinet shall be constructed of G90 galvanized steel, with
exterior surfaces coated with a non-chalking, powdered paint
finish, certified at 1000 hours salt spray test per ASTM-B117
standards. The unit top shall be a single piece “Water Shed”
design, with drip edges and no-seam corners to provide
optimum water integrity. Unit shall have a rigidly mounted
condenser coil guard to provide protection from objects and
personnel after installation. Indoor blower section shall be
insulated with up to 3/4” thick, aluminum, foil faced insulation,
fastened to prevent insulation from entering the air stream.
Cabinet panels shall be “large” size, easily removable for
servicing and maintenance, with built-in lift handles. Unit shall
be built on a formed, “Super-Structure” design base pan, with
embossments at critical points to add strength, rigidity and aid
in minimizing sound. Full perimeter base rails shall be provided
to assure reliable transit of equipment, overhead rigging, for
truck access and proper sealing on roof curb applications. Base
rails shall be removable, when required, to lower unit height.
Filters shall be furnished and be accessible through a
removable access door, sealed airtight. Units vertical discharge
and return duct configuration shall be designed to fit between
standard 24” O.C. beams without modification to building
structure, duct work and base unit. Condensate pan shall be
internally sloped and conform to ASHRAE 62-89 self-draining
standards, with 3/4” NPTI copper, ridged mount connection.
Indoor (Evaporator) Fan Assembly
Fan shall be direct drive design. Fan wheel shall be double-inlet
type with forward-curved blades, dynamically balanced to
operate smoothly throughout the entire range of operation.
Airflow design shall be constant air volume. Bearings shall be
sealed and permanently lubricated for longer life and no
maintenance. Fan assembly shall be “Slip Track” (slide-out)
design for easy removal and cleaning.
Outdoor (Condenser) Fan Assembly
The outdoor fan shall be of the direct-driven propeller type,
discharge air vertically, have aluminum blades riveted to
corrosion resistant steel spider bracket and shall be statically
balanced for smooth operation. The outdoor fan motor shall be
totally enclosed with permanently lubricated bearings and
internally protected against overload conditions.

333495-YTG-C-0908
6Johnson Controls Unitary Products
Refrigerant Components
Compressors:
a. Shall be fully hermetic type, direct drive, internally
protected with internal high-pressure relief and over
temperature protection. The hermetic motor shall be
suction gas cooled and have a voltage range of +/- 10%
of the unit nameplate voltage.
b. Shall have internal isolation and sound muffling to
minimize vibration and noise, and be externally isolated
on a dedicated, independent mounting.
Coils:
a. Evaporator and condenser coils shall have aluminum
plate fins mechanically bonded to seamless internally
enhanced copper tubes with all joints brazed.
b. Evaporator coil shall be of the direct expansion, blow
through design, while condenser coil shall be draw
through design.
Refrigerant Circuit and Refrigerant Safety Components shall
include:
a. Shall include independent fixed orifice expansion
devices.
b. Shall include filter/strainer to eliminate any foreign
matter.
Electric Heating Section
(Field Install Accessory)
An electric heating section, with nickel chromium elements,
shall be provided in a range of 5 thru 25 KW. The heating
section shall have a primary limit control(s) (automatic reset) to
prevent the heating element system from operating at an
excessive temperature. The Heating Section assembly shall
slide out of the unit for easy maintenance and service. Units
with Electric Heating Sections shall be wired for a single point
power supply with branch circuit fusing (where required).

333495-YTG-C-0908
Johnson Controls Unitary Products 7
Physical Data
BHZ024-060 Physical Data
Component Models
BHZ024 BHZ030 BHZ036 BHZ042 BHZ048 BHZ060
Nominal Tonnage 2.0 2.5 3.0 3.5 4.0 5.0
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu) 22.9 29.7 36.0 41.3 47.2 57.5
ARI net capacity (Btu) 22.8 29.2 33.6 40.5 45.5 56.0
EER 11.4 11.25 11.0 11.25 10.65 11.0
SEER 13 13 13 13 13 13
Nominal CFM 800 950 1100 1400 1450 1550
System power (KW) 2.0 2.6 3.1 3.6 4.1 5.10
Refrigerant type R410a R410a R410a R410a R410a R410a
Refrigerant charge (lb-oz) 6-0 7-4 9-6 12-0 10-10 11-8
ARI HEATING PERFORMANCE
47°F Capacity Rating (Mbh) 22.2 27.8 32.8 40.0 45.5 56.0
System Power (Kw/COP) 3.4 3.3 3.0 3.0 3.0 2.90
17°F Capacity Rating (Mbh) 11.5 14.6 19.2 23.2 27.4 33.0
System Power (Kw/COP) 2.0 2.0 2.3 2.3 2.2 2.0
HSPF (BTU/Watts-hr.) 7.7 7.7 7.7 7.7 7.7 7.7
DIMENSIONS (inches)
Length 49 1/8 49 1/8 49 1/8 49 1/8 49 1/8 49 1/8
Width 47 1/4 47 1/4 47 1/4 47 1/4 47 1/4 47 1/4
Height 33 1/2 33 1/2 33 1/2 41 1/2 41 1/2 41 1/2
OPERATING WT. (lbs.) 350 350 385 435 480 490
COMPRESSORS
Type Scroll 1-spd Scroll 1-spd Scroll 1-spd Scroll 1-spd Scroll 1-spd Scroll 1-spd
Quantity 1 1 1 1 1 1
CONDENSER COIL DATA
Face area (Sq. Ft.) 11.7 11.7 11.7 16.4 16.4 16.4
Rows 1 1 2 2 2 2
Fins per inch 20 20 20 20 20 20
Tube diameter (in.) 3/8 3/8 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced
Refrigerant control Orifice Orifice Orifice Orifice Orifice TXV
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 4.38 4.38 4.38 5.63 5.63 5.63
Rows 2 3 3 3 3 3
Fins per inch 15 13 15 15 16 16
Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced
Refrigerant control Orifice Orifice Orifice Orifice Orifice TXV
CONDENSER FAN DATA
Fan diameter (Inch) 22 22 22 22 22 22
Type Prop Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct Direct
No. speeds 1 1 1 1 1 1
Number of motors 1 1 1 1 1 1
Motor HP each 1/4 1/4 1/4 1/4 1/4 1/2
RPM 850 850 850 850 850 1100
Nominal total CFM 1800 1800 2400 2400 3000 3000
DIRECT DRIVE EVAP FAN DATA
Quantity 1 1 1 1 1 1
Fan Size (Inch) 10 x 8 10 x 8 11 x 10 11 x 10 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
No. speeds 5 5 5 5 5 5
Motor HP each 1/2 1/2 3/4 3/4 3/4 1
RPM Variable Variable Variable Variable Variable Variable
Frame size 48 48 48 48 48 48
FILTERS
Quantity - Size 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1

333495-YTG-C-0908
8Johnson Controls Unitary Products
BHX024-060 Physical Data
Component Models
BHX024 BHX036 BHX048 BHX060
Nominal Tonnage 2.0 3.0 4.0 5.0
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu) 24.9 35.3 49.2 58.8
ARI net capacity (Btu) 24.4 34.4 47.0 57.0
EER 12.0 11.5 11.3 11.0
SEER 16 15 15 14.5
Nominal CFM 800 1200 1600 1700
System power (KW) 2.0 3.0 4.2 5.2
Refrigerant type R410a R410a R410a R410a
Refrigerant charge (lb-oz) 7-10 10-4 12-4 12-0
ARI HEATING PERFORMANCE
47°F Capacity Rating (Mbh) 19.8 33.0 45.0 55.0
System Power (Kw/COP) 3.5 3.1 3.0 3.1
17°F Capacity Rating (Mbh) 11.1 18.9 27.2 32.4
System Power (Kw/COP) 2.1 2.0 2.1 2.1
HSPF (BTU/Watts-hr.) 8.0 8.0 8.0 8.0
DIMENSIONS (inches)
Length 49 1/8 49 1/8 49 1/8 49 1/8
Width 47 1/4 47 1/4 47 1/4 47 1/4
Height 33 1/2 33 1/2 41 1/2 41 1/2
OPERATING WT. (lbs.) 350 400 440 460
COMPRESSORS
Type Scroll 2-spd Scroll 2-spd Scroll 2-spd Scroll 2-spd
Quantity 1 1 1 1
CONDENSER COIL DATA
Face area (Sq. Ft.) 11.7 11.7 16.4 16.4
Rows 1 2 2 2
Fins per inch 20 20 20 20
Tube diameter (in.) 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced
Refrigerant control Orifice TXV TXV TXV
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 4.38 4.38 5.63 5.63
Rows 3 3 3 3
Fins per inch 15 15 16 16
Tube diameter 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV TXV
CONDENSER FAN DATA
Fan diameter (Inch) 22 22 22 22
Type Axial Axial Axial Axial
Drive type Direct Direct Direct Direct
No. speeds 2 1 2 2
Number of motors 1 1 1 1
MotorHPeach 1/3 1/4 1/3 1/3
RPM 850/1100 1100 900/1100 950/1100
Nominal total CFM 2400 2400 3000 3000
DIRECT DRIVE EVAP FAN DATA
Quantity 1 1 1 1
Fan Size (Inch) 10 x 8 11 x 10 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal Centrifugal
No. speeds 1 1 1 1
Motor HP each 1/2 3/4 3/4 1
RPM Variable Variable Variable Variable
Frame size 48 48 48 48
FILTERS
Quantity - Size 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1

333495-YTG-C-0908
Johnson Controls Unitary Products 9
BHZ and BHX Unit Limitations
Size
(Tons) Model Unit Voltage Unit Limitations
Applied Voltage Outdoor DB Temp
Min Max Max (°F)
024
(2.0) BHZ 208/230-1-60 187 252 125
BHX 208/230-1-60 187 252 115
030
(2.5) BHZ 208/230-1-60 187 252 125
208/230-3-60 187 252 125
460-3-60 432 504 125
036
(3.0)
BHZ 208/230-1-60 187 252 125 208/230-3-60 187 252 125
460-3-60 432 504 125
BHX 208/230-1-60 187 252 115 208/230-3-60 187 252 115
460-3-60 432 504 115
042
(3.5) BHZ 208/230-1-60 187 252 125
208/230-3-60 187 252 125
460-3-60 432 504 125
048
(4.0)
BHZ 208/230-1-60 187 252 125 208/230-3-60 187 252 125
460-3-60 432 504 125
BHX 208/230-1-60 187 252 115 208/230-3-60 187 252 115
460-3-60 432 504 115
060
(5.0)
BHZ 208/230-1-60 187 252 125 208/230-3-60 187 252 125
460-3-60 432 504 125
BHX 208/230-1-60 187 252 115 208/230-3-60 187 252 115
460-3-60 432 504 115

333495-YTG-C-0908
10 Johnson Controls Unitary Products
Capacity Performance
BHZ024-060 Cooling Capacities
BHZ024 (2.0 Ton)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
600
77 30.6 1.5 17.9 15.0 12.2 - - - 26.8 1.7 14.7 11.8 9.0 - - -
72 28.4 1.5 19.8 16.9 14.1 11.2 - - 25.5 1.7 18.2 15.3 12.5 9.6 - -
67 26.2 1.5 21.7 18.9 16.0 13.2 10.3 - 24.1 1.7 21.6 18.8 15.9 13.1 10.2 -
62 24.3 1.5 24.3 24.0 20.1 17.3 14.4 11.6 22.4 1.6 22.4 22.2 19.4 16.5 13.7 10.8
57 23.4 1.5 23.4 23.4 22.4 19.6 16.7 13.9 22.1 1.6 22.1 22.1 20.6 17.8 14.9 12.1
700
77 30.6 1.6 19.5 16.3 12.9 - - - 27.0 1.7 16.8 12.9 9.5 - - -
72 28.4 1.6 21.7 18.4 15.0 11.6 - - 25.6 1.7 19.9 16.5 13.2 9.8 - -
67 26.1 1.5 23.9 20.5 17.1 13.7 10.4 - 24.3 1.7 23.1 20.2 16.8 13.5 10.1 -
62 24.3 1.5 24.3 24.1 21.4 18.1 14.7 11.3 22.5 1.7 22.5 22.5 20.5 17.1 13.7 10.3
57 23.4 1.6 23.4 23.4 23.9 20.5 17.1 13.7 22.3 1.7 22.3 22.3 21.8 18.4 15.0 11.7
800
77 30.6 1.6 21.2 17.5 13.6 - - - 27.2 1.8 18.8 13.9 10.0 - - -
72 28.4 1.6 23.7 19.8 15.9 12.0 - - 25.8 1.8 21.6 17.7 13.9 10.0 - -
67 26.1 1.6 26.1 22.0 18.1 14.3 10.4 - 24.5 1.8 24.5 21.6 17.7 13.8 9.9 -
62 24.2 1.6 24.2 24.2 22.7 18.8 15.0 11.1 22.7 1.8 22.7 22.7 21.5 17.6 13.8 9.9
57 23.4 1.6 23.4 23.4 25.3 21.4 17.5 13.6 22.4 1.8 22.4 22.4 22.9 19.0 15.1 11.2
900
72 28.3 1.6 25.1 20.7 16.3 11.9 - - 26.0 1.9 23.2 18.7 14.3 9.9 - -
67 26.1 1.6 26.1 23.1 18.6 14.1 9.7 - 24.6 1.9 24.6 22.7 18.3 13.9 9.4 -
62 24.2 1.6 24.2 24.2 23.4 19.0 14.5 10.1 22.9 1.8 22.9 22.9 22.2 17.8 13.4 9.0
57 23.3 1.7 23.3 23.3 24.3 19.9 15.4 11.0 22.6 1.8 22.6 22.6 22.8 18.4 14.0 9.5
1000
72 28.3 1.7 26.6 21.6 16.7 11.7 - - 26.2 1.9 24.7 19.7 14.8 9.8 - -
67 26.1 1.7 26.1 24.1 19.0 14.0 9.0 - 24.8 1.9 24.8 23.8 18.9 13.9 8.9 -
62 24.2 1.7 24.2 24.2 24.0 19.1 14.1 9.1 23.0 1.9 23.0 23.0 22.9 18.0 13.0 8.0
57 23.3 1.7 23.3 23.3 23.3 18.3 13.4 8.4 22.7 1.9 22.7 22.7 22.7 17.8 12.8 7.8
95°F 105°F
600
77 23.0 1.8 11.5 8.7 5.8 - - - 22.8 2.1 11.8 9.0 6.1 - - -
72 22.5 1.8 16.5 13.7 10.8 8.0 - - 21.6 2.1 16.3 13.4 10.6 7.7 - -
67 22.1 1.8 21.6 18.7 15.9 13.0 10.2 - 20.4 2.1 20.1 17.9 15.0 12.2 9.3 -
62 20.5 1.8 20.5 20.5 18.7 15.8 12.9 10.1 19.0 2.0 19.0 19.0 17.3 14.5 11.6 8.8
57 20.8 1.8 20.8 20.8 18.8 16.0 13.1 10.3 19.4 2.0 19.4 19.4 17.2 14.3 11.5 8.6
700
77 23.3 1.9 14.0 9.5 6.1 - - - 23.0 2.2 14.9 10.0 6.4 - - -
72 22.9 1.9 18.1 14.7 11.3 8.0 - - 21.8 2.2 17.8 14.4 11.1 7.7 - -
67 22.4 1.9 22.2 19.9 16.6 13.2 9.8 - 20.5 2.1 20.4 18.9 15.7 12.4 9.0 -
62 20.8 1.9 20.8 20.8 19.5 16.1 12.8 9.4 19.1 2.1 19.1 19.1 18.2 14.8 11.4 8.1
57 21.1 1.8 21.1 21.1 19.7 16.3 12.9 9.6 19.6 2.1 19.6 19.6 18.0 14.6 11.3 7.9
800
77 23.7 2.0 16.4 10.2 6.4 - - - 23.2 2.3 18.0 11.0 6.7 - - -
72 23.3 2.0 19.6 15.7 11.8 7.9 - - 21.9 2.3 19.3 15.5 11.6 7.7 - -
67 22.8 2.0 22.8 21.2 17.3 13.4 9.5 - 20.7 2.2 20.7 19.9 16.4 12.6 8.7 -
62 21.1 2.0 21.1 21.1 20.3 16.4 12.6 8.7 19.3 2.2 19.3 19.3 19.0 15.1 11.2 7.3
57 21.5 1.9 21.5 21.5 20.5 16.6 12.7 8.8 19.7 2.2 19.7 19.7 18.8 15.0 11.1 7.2
900
72 23.6 2.1 21.2 16.8 12.3 7.9 - - 22.2 2.3 20.6 16.5 12.0 7.6 - -
67 23.2 2.1 23.2 22.4 18.0 13.6 9.2 - 21.0 2.3 21.0 20.5 17.1 12.7 8.3 -
62 21.5 2.1 21.5 21.5 21.1 16.6 12.2 7.8 19.5 2.3 19.5 19.5 19.4 14.9 10.5 6.1
57 21.8 2.0 21.8 21.8 21.3 16.9 12.5 8.0 20.0 2.3 20.0 20.0 19.5 15.1 10.7 6.2
1000
72 24.0 2.2 22.8 17.8 12.8 7.9 - - 22.4 2.4 21.8 17.5 12.5 7.5 - -
67 23.5 2.1 23.5 23.5 18.8 13.8 8.8 - 21.2 2.4 21.2 21.2 17.8 12.8 7.8 -
62 21.8 2.1 21.8 21.8 21.8 16.9 11.9 6.9 19.7 2.4 19.7 19.7 19.7 14.8 9.8 4.8
57 22.2 2.1 22.2 22.2 22.2 17.2 12.2 7.2 20.2 2.4 20.2 20.2 20.2 15.2 10.3 5.3

333495-YTG-C-0908
Johnson Controls Unitary Products 11
115°F 125°F
600
77 22.6 2.3 12.1 9.2 6.4 - - - 22.5 2.6 12.4 9.5 6.7 - - -
72 20.6 2.3 16.0 13.1 10.3 7.4 - - 19.7 2.5 15.7 12.8 10.0 7.1 - -
67 18.6 2.3 18.6 17.0 14.1 11.3 8.4 - 16.9 2.5 16.9 16.1 13.3 10.4 7.6 -
62 17.5 2.3 17.5 17.5 16.0 13.2 10.3 7.5 15.9 2.5 15.9 15.9 14.7 11.8 9.0 6.1
57 18.0 2.3 18.0 18.0 15.6 12.7 9.9 7.0 16.7 2.5 16.7 16.7 13.9 11.1 8.2 5.4
700
77 22.6 2.4 15.8 10.5 6.7 - - - 22.3 2.7 16.8 11.1 7.0 - - -
72 20.6 2.4 17.5 14.2 10.8 7.4 - - 19.5 2.7 17.3 13.9 10.5 7.2 - -
67 18.6 2.4 18.6 17.8 14.9 11.5 8.1 - 16.7 2.6 16.7 16.7 14.0 10.7 7.3 -
62 17.4 2.4 17.4 17.4 16.8 13.5 10.1 6.7 15.8 2.6 15.8 15.8 15.5 12.1 8.8 5.4
57 18.0 2.4 18.0 18.0 16.4 13.0 9.6 6.3 16.5 2.6 16.5 16.5 14.7 11.4 8.0 4.6
800
77 22.6 2.5 19.6 11.8 7.0 - - - 22.0 2.8 21.2 12.6 7.4 - - -
72 20.6 2.5 19.1 15.2 11.3 7.4 - - 19.3 2.8 18.9 15.0 11.1 7.2 - -
67 18.6 2.5 18.6 18.6 15.6 11.7 7.8 - 16.5 2.7 16.5 16.5 14.8 10.9 7.0 -
62 17.4 2.5 17.4 17.4 17.7 13.8 9.9 6.0 15.6 2.7 15.6 15.6 15.6 12.4 8.6 4.7
57 18.0 2.5 18.0 18.0 17.2 13.3 9.4 5.5 16.3 2.8 16.3 16.3 15.5 11.6 7.7 3.8
900
72 20.7 2.6 20.0 16.2 11.8 7.3 - - 19.3 2.9 19.3 15.9 11.5 7.0 - -
67 18.7 2.6 18.7 18.7 16.2 11.8 7.3 - 16.5 2.8 16.5 16.5 15.3 10.8 6.4 -
62 17.5 2.6 17.5 17.5 17.7 13.2 8.8 4.4 15.6 2.8 15.6 15.6 15.6 11.5 7.1 2.7
57 18.1 2.6 18.1 18.1 17.7 13.3 8.9 4.4 16.3 2.8 16.3 16.3 15.9 11.5 7.0 2.6
1000
72 20.9 2.7 20.9 17.1 12.2 7.2 - - 19.3 2.9 19.3 16.8 11.8 6.9 - -
67 18.9 2.7 18.9 18.9 16.8 11.8 6.8 - 16.5 2.9 16.5 16.5 15.8 10.8 5.8 -
62 17.7 2.6 17.7 17.7 17.7 12.7 7.7 2.8 15.6 2.9 15.6 15.6 15.6 10.6 5.6 0.7
57 18.2 2.6 18.2 18.2 18.2 13.3 8.3 3.3 16.3 2.9 16.3 16.3 16.3 11.3 6.4 1.4
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
BHZ024 (2.0 Ton) (Continued)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65

333495-YTG-C-0908
12 Johnson Controls Unitary Products
BHZ030 (2.5 Ton)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
750
77 36.3 2.1 19.3 15.7 12.2 - - - 36.0 2.3 17.9 14.3 10.7 - - -
72 34.1 2.0 22.6 19.1 15.5 11.9 - - 33.3 2.3 21.8 18.2 14.6 11.1 - -
67 31.8 1.9 26.0 22.4 18.9 15.3 11.7 - 30.6 2.2 25.6 22.1 18.5 15.0 11.4 -
62 30.1 1.8 30.1 28.1 24.6 21.0 17.4 13.9 27.8 2.2 27.8 26.4 22.8 19.3 15.7 12.1
57 28.2 1.8 28.2 27.9 24.3 20.8 17.2 13.6 27.3 2.2 27.3 26.7 23.1 19.6 16.0 12.4
875
77 37.6 2.3 21.4 17.7 13.5 - - - 36.6 2.4 20.5 16.0 11.8 - - -
72 35.2 2.2 25.7 21.5 17.2 13.0 - - 33.8 2.4 24.5 20.3 16.1 11.9 - -
67 32.8 2.1 29.9 25.2 21.0 16.8 12.6 - 31.1 2.4 28.6 24.6 20.4 16.2 12.0 -
62 31.0 1.9 31.0 30.0 27.3 23.1 18.9 14.7 28.2 2.3 28.2 27.5 25.2 21.0 16.7 12.5
57 29.2 2.0 29.2 29.0 27.1 22.8 18.6 14.4 27.7 2.3 27.7 27.4 25.5 21.3 17.1 12.9
1000
77 38.8 2.5 23.5 19.7 14.8 - - - 37.1 2.6 23.1 17.8 12.9 - - -
72 36.3 2.4 28.7 23.8 19.0 14.1 - - 34.3 2.5 27.3 22.5 17.6 12.8 - -
67 33.9 2.3 33.9 28.0 23.1 18.2 13.4 - 31.5 2.5 31.5 27.2 22.3 17.5 12.6 -
62 32.0 2.1 32.0 32.0 30.0 25.2 20.3 15.4 28.6 2.4 28.6 28.6 27.5 22.6 17.8 12.9
57 30.1 2.2 30.1 30.1 29.8 24.9 20.1 15.2 28.2 2.4 28.2 28.2 27.9 23.0 18.1 13.3
1125
72 36.7 2.5 31.3 25.8 20.3 14.7 - - 34.3 2.6 29.9 24.4 18.9 13.3 - -
67 34.2 2.4 34.2 31.3 24.7 19.1 13.6 - 31.5 2.6 31.5 29.3 23.9 18.4 12.8 -
62 32.3 2.2 32.3 32.3 31.3 25.8 20.2 14.7 28.6 2.5 28.6 28.6 28.0 22.5 17.0 11.4
57 30.4 2.3 30.4 30.4 30.3 24.7 19.2 13.7 28.1 2.5 28.1 28.1 28.0 22.4 16.9 11.4
1250
72 37.1 2.6 34.0 27.8 21.5 15.3 - - 34.3 2.8 32.5 26.3 20.1 13.9 - -
67 34.6 2.6 34.6 34.6 26.2 20.0 13.8 - 31.5 2.7 31.5 31.5 25.5 19.3 13.1 -
62 32.6 2.3 32.6 32.6 32.6 26.4 20.2 13.9 28.6 2.6 28.6 28.6 28.6 22.4 16.1 9.9
57 30.7 2.4 30.7 30.7 30.7 24.5 18.3 12.1 28.1 2.6 28.1 28.1 28.1 21.9 15.7 9.5
95°F 105°F
750
77 35.7 2.6 16.4 12.9 9.3 - - - 32.5 2.8 15.1 11.5 8.0 - - -
72 32.6 2.6 20.9 17.3 13.7 10.2 - - 29.5 2.8 19.7 16.2 12.6 9.1 - -
67 29.4 2.5 25.3 21.7 18.2 14.6 11.1 - 26.5 2.9 24.4 20.8 17.3 13.7 10.1 -
62 25.5 2.6 25.5 24.7 21.1 17.5 14.0 10.4 23.8 2.9 23.8 23.2 19.6 16.1 12.5 8.9
57 26.4 2.6 26.4 25.5 21.9 18.4 14.8 11.2 23.3 2.9 23.3 22.8 19.3 15.7 12.1 8.6
875
77 35.6 2.6 19.6 14.4 10.1 - - - 32.4 2.9 19.1 13.2 8.8 - - -
72 32.4 2.6 23.4 19.2 15.0 10.8 - - 29.5 2.9 22.3 18.1 13.9 9.6 - -
67 29.3 2.6 27.3 24.1 19.9 15.6 11.4 - 26.5 2.9 25.4 22.9 19.0 14.8 10.5 -
62 25.4 2.6 25.4 25.0 23.0 18.8 14.6 10.4 23.8 2.9 23.8 23.5 21.6 17.3 13.1 8.9
57 26.3 2.6 26.3 25.8 23.9 19.7 15.5 11.3 23.3 2.9 23.3 23.0 21.2 16.9 12.7 8.5
1000
77 35.4 2.6 22.8 15.9 11.0 - - - 32.4 2.9 23.2 14.9 9.5 - - -
72 32.3 2.6 26.0 21.1 16.3 11.4 - - 29.4 2.9 24.8 20.0 15.1 10.2 - -
67 29.2 2.6 29.2 26.4 21.5 16.7 11.8 - 26.5 2.9 26.5 25.1 20.7 15.8 10.9 -
62 25.3 2.6 25.3 25.3 25.0 20.1 15.3 10.4 23.8 2.9 23.8 23.8 23.5 18.6 13.8 8.9
57 26.2 2.6 26.2 26.2 26.0 21.1 16.2 11.4 23.3 2.9 23.3 23.3 23.0 18.2 13.3 8.5
1125
72 31.9 2.7 28.5 23.0 17.5 11.9 - - 30.2 3.0 27.5 22.0 16.5 10.9 - -
67 28.8 2.7 28.8 27.4 23.1 17.6 12.1 - 27.2 3.1 27.2 26.5 22.5 17.0 11.5 -
62 24.9 2.8 24.9 24.9 24.8 19.2 13.7 8.2 24.4 3.0 24.4 24.4 24.3 18.8 13.2 7.7
57 25.8 2.8 25.8 25.8 25.7 20.2 14.6 9.1 23.9 3.0 23.9 23.9 23.7 18.2 12.7 7.1
1250
72 31.4 2.9 31.1 24.9 18.7 12.5 - - 31.0 3.1 30.2 24.0 17.8 11.6 - -
67 28.4 2.9 28.4 28.4 24.7 18.5 12.3 - 27.9 3.2 27.9 27.9 24.4 18.2 12.0 -
62 24.6 2.9 24.6 24.6 24.6 18.3 12.1 5.9 25.1 3.2 25.1 25.1 25.1 18.9 12.7 6.5
57 25.5 2.9 25.5 25.5 25.5 19.2 13.0 6.8 24.4 3.2 24.4 24.4 24.4 18.2 12.0 5.8

333495-YTG-C-0908
Johnson Controls Unitary Products 13
115°F 125°F
750
77 29.2 3.1 13.8 10.2 6.7 - - - 26.0 3.3 12.5 8.9 5.3 - - -
72 26.4 3.1 18.6 15.1 11.5 7.9 - - 23.4 3.4 17.5 13.9 10.4 6.8 - -
67 23.7 3.2 23.5 19.9 16.3 12.8 9.2 - 20.8 3.5 20.8 19.0 15.4 11.8 8.3 -
62 22.1 3.1 22.1 21.7 18.1 14.6 11.0 7.4 20.5 3.4 20.5 20.2 16.6 13.1 9.5 5.9
57 20.2 3.1 20.2 20.2 16.6 13.0 9.5 5.9 17.2 3.4 17.2 17.2 13.9 10.4 6.8 3.2
875
77 29.3 3.1 18.7 12.0 7.4 - - - 26.2 3.4 18.2 10.9 6.0 - - -
72 26.5 3.2 21.1 16.9 12.7 8.5 - - 23.5 3.5 20.0 15.8 11.6 7.4 - -
67 23.7 3.3 23.6 21.8 18.1 13.9 9.6 - 20.9 3.6 20.9 20.7 17.2 13.0 8.8 -
62 22.2 3.2 22.2 22.0 20.1 15.8 11.6 7.4 20.6 3.5 20.6 20.5 18.6 14.3 10.1 5.9
57 20.3 3.2 20.3 20.2 18.4 14.2 9.9 5.7 17.3 3.5 17.3 17.3 15.6 11.4 7.2 2.9
1000
77 29.3 3.2 23.6 13.8 8.1 - - - 26.3 3.4 24.0 12.8 6.6 - - -
72 26.5 3.2 23.7 18.8 13.9 9.1 - - 23.7 3.6 22.5 17.6 12.8 7.9 - -
67 23.8 3.3 23.8 23.8 19.8 15.0 10.1 - 21.0 3.7 21.0 21.0 19.0 14.1 9.2 -
62 22.2 3.2 22.2 22.2 22.0 17.1 12.3 7.4 20.7 3.5 20.7 20.7 20.5 15.6 10.8 5.9
57 20.3 3.3 20.3 20.3 20.1 15.3 10.4 5.6 17.4 3.6 17.4 17.4 17.2 12.4 7.5 2.6
1125
72 28.6 3.3 26.5 21.0 15.4 9.9 - - 26.9 3.6 25.5 20.0 14.4 8.9 - -
67 25.6 3.4 25.6 25.6 21.9 16.4 10.9 - 24.0 3.7 24.0 24.0 21.3 15.8 10.3 -
62 23.9 3.3 23.9 23.9 23.8 18.3 12.7 7.2 23.5 3.6 23.5 23.5 23.3 17.8 12.3 6.7
57 21.9 3.3 21.9 21.9 21.8 16.2 10.7 5.2 19.9 3.6 19.9 19.9 19.8 14.3 8.8 3.2
1250
72 30.6 3.4 29.4 23.1 16.9 10.7 - - 30.2 3.6 28.5 22.3 16.1 9.8 - -
67 27.4 3.5 27.4 27.4 24.1 17.9 11.6 - 26.9 3.8 26.9 26.9 23.7 17.5 11.3 -
62 25.6 3.4 25.6 25.6 25.6 19.4 13.2 7.0 26.2 3.6 26.2 26.2 26.2 20.0 13.8 7.6
57 23.4 3.4 23.4 23.4 23.4 17.2 11.0 4.8 22.4 3.7 22.4 22.4 22.4 16.2 10.0 3.8
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
BHZ030 (2.5 Ton) (Continued)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65

333495-YTG-C-0908
14 Johnson Controls Unitary Products
BHZ036 (3.0 Ton)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
900
77 39.2 2.6 19.4 15.1 10.8 - - - 39.6 2.7 20.6 16.3 12.0 - - -
72 38.5 2.4 27.0 22.7 18.4 14.2 - - 37.6 2.6 27.1 22.8 18.5 14.2 - -
67 37.7 2.2 34.6 30.3 26.1 21.8 17.5 - 35.5 2.6 33.6 29.3 25.0 20.7 16.5 -
62 34.8 2.2 34.8 34.8 32.3 28.0 23.7 19.5 33.2 2.5 33.2 33.2 30.9 26.6 22.3 18.1
57 34.5 2.3 34.5 34.5 32.4 28.1 23.9 19.6 32.9 2.6 32.9 32.9 30.8 26.6 22.3 18.0
1050
77 40.4 2.6 22.9 16.8 11.8 - - - 40.3 2.8 24.8 17.9 12.9 - - -
72 39.6 2.5 30.1 25.0 20.0 14.9 - - 38.2 2.7 30.0 24.9 19.9 14.8 - -
67 38.8 2.3 37.2 33.3 28.2 23.2 18.1 - 36.1 2.6 35.1 31.9 26.9 21.8 16.7 -
62 35.8 2.3 35.8 35.8 35.0 29.9 24.8 19.8 33.8 2.6 33.8 33.8 33.2 28.1 23.0 18.0
57 35.5 2.3 35.5 35.5 35.1 30.0 25.0 19.9 33.5 2.6 33.5 33.5 33.1 28.1 23.0 17.9
1200
77 41.6 2.7 26.5 18.5 12.7 - - - 40.9 2.9 29.1 19.6 13.8 - - -
72 40.7 2.5 33.2 27.3 21.5 15.7 - - 38.8 2.8 32.9 27.1 21.2 15.4 - -
67 39.8 2.4 39.8 36.2 30.4 24.5 18.7 - 36.7 2.7 36.7 34.5 28.7 22.9 17.0 -
62 36.8 2.4 36.8 36.8 37.6 31.8 26.0 20.1 34.3 2.7 34.3 34.3 35.4 29.6 23.8 17.9
57 36.5 2.4 36.5 36.5 37.7 31.9 26.1 20.3 34.1 2.7 34.1 34.1 35.4 29.5 23.7 17.9
1350
72 41.2 2.6 36.3 29.4 22.8 16.1 - - 39.5 2.9 35.9 29.3 22.7 16.0 - -
67 40.3 2.4 40.3 38.5 32.1 25.5 18.9 - 37.3 2.8 37.3 36.2 30.6 24.0 17.3 -
62 37.3 2.4 37.3 37.3 37.7 31.0 24.4 17.7 34.9 2.7 34.9 34.9 35.4 28.8 22.1 15.5
57 36.9 2.5 36.9 36.9 37.5 30.9 24.3 17.6 34.6 2.8 34.6 34.6 35.3 28.6 22.0 15.3
1500
72 41.7 2.7 39.5 31.5 24.0 16.6 - - 40.1 3.0 39.0 31.5 24.1 16.6 - -
67 40.8 2.5 40.8 40.8 33.9 26.5 19.0 - 37.9 2.9 37.9 37.9 32.5 25.1 17.6 -
62 37.7 2.5 37.7 37.7 37.7 30.3 22.8 15.4 35.4 2.8 35.4 35.4 35.4 28.0 20.5 13.1
57 37.3 2.5 37.3 37.3 37.3 29.9 22.4 15.0 35.2 2.9 35.2 35.2 35.2 27.7 20.2 12.8
95°F 105°F
900
77 40.0 2.9 21.7 17.5 13.2 - - - 37.1 3.4 20.1 15.8 11.6 - - -
72 36.7 2.9 27.1 22.8 18.6 14.3 - - 33.6 3.4 25.5 21.3 17.0 12.7 - -
67 33.4 2.9 32.5 28.2 24.0 19.7 15.4 - 30.1 3.3 29.6 26.7 22.4 18.2 13.9 -
62 31.6 2.8 31.6 31.6 29.5 25.2 20.9 16.6 28.7 3.2 28.7 28.7 26.3 22.0 17.8 13.5
57 31.4 2.8 31.4 31.4 29.3 25.0 20.7 16.4 28.6 3.3 28.6 28.6 26.2 22.0 17.7 13.4
1050
77 40.2 3.0 26.7 19.1 14.0 - - - 37.4 3.5 26.1 18.3 12.4 - - -
72 36.8 3.0 29.9 24.8 19.8 14.7 - - 33.8 3.4 28.4 23.4 18.3 13.2 - -
67 33.5 3.0 33.1 30.6 25.5 20.4 15.4 - 30.3 3.4 30.1 28.4 24.2 19.1 14.1 -
62 31.7 2.9 31.7 31.7 31.3 26.3 21.2 16.2 28.9 3.3 28.9 28.9 28.3 23.3 18.2 13.2
57 31.5 2.9 31.5 31.5 31.1 26.1 21.0 16.0 28.8 3.3 28.8 28.8 28.3 23.2 18.1 13.1
1200
77 40.3 3.1 31.6 20.7 14.9 - - - 37.6 3.6 32.0 20.7 13.3 - - -
72 37.0 3.1 32.6 26.8 20.9 15.1 - - 34.1 3.5 31.3 25.4 19.6 13.8 - -
67 33.6 3.1 33.6 32.9 27.0 21.2 15.4 - 30.5 3.4 30.5 30.1 25.9 20.1 14.2 -
62 31.9 3.0 31.9 31.9 33.2 27.4 21.6 15.7 29.1 3.4 29.1 29.1 30.3 24.5 18.7 12.8
57 31.6 3.0 31.6 31.6 33.0 27.2 21.3 15.5 29.0 3.4 29.0 29.0 30.3 24.4 18.6 12.8
1350
72 37.7 3.2 35.6 29.2 22.5 15.9 - - 34.5 3.6 33.1 27.2 20.6 13.9 - -
67 34.3 3.2 34.3 33.9 29.1 22.4 15.8 - 30.9 3.5 30.9 30.7 27.1 20.5 13.9 -
62 32.5 3.1 32.5 32.5 33.2 26.6 19.9 13.3 29.5 3.5 29.5 29.5 30.1 23.5 16.8 10.2
57 32.3 3.1 32.3 32.3 33.0 26.3 19.7 13.1 29.4 3.5 29.4 29.4 30.0 23.4 16.7 10.1
1500
72 38.5 3.3 38.5 31.6 24.1 16.7 - - 35.0 3.7 35.0 29.0 21.5 14.1 - -
67 35.0 3.3 35.0 35.0 31.1 23.7 16.2 - 31.3 3.6 31.3 31.3 28.4 20.9 13.5 -
62 33.2 3.2 33.2 33.2 33.2 25.7 18.3 10.8 29.9 3.6 29.9 29.9 29.9 22.4 15.0 7.5
57 33.0 3.2 33.0 33.0 33.0 25.5 18.1 10.6 29.8 3.6 29.8 29.8 29.8 22.3 14.9 7.4

333495-YTG-C-0908
Johnson Controls Unitary Products 15
115°F 125°F
900
77 34.1 3.9 18.5 14.2 9.9 - - - 31.2 4.4 16.9 12.6 8.3 - - -
72 30.5 3.8 24.0 19.7 15.4 11.1 - - 27.3 4.3 22.4 18.1 13.8 9.6 - -
67 26.8 3.7 26.8 25.2 20.9 16.6 12.3 - 23.5 4.2 23.5 23.5 19.3 15.1 10.8 -
62 25.7 3.7 25.7 25.7 23.1 18.9 14.6 10.3 22.7 4.1 22.7 22.7 20.0 15.7 11.4 7.2
57 25.8 3.7 25.8 25.8 23.2 18.9 14.7 10.4 22.9 4.1 22.9 22.9 20.2 15.9 11.6 7.4
1050
77 34.5 4.0 25.5 17.5 10.9 - - - 31.7 4.4 24.9 16.7 9.3 - - -
72 30.8 3.9 27.0 21.9 16.8 11.8 - - 27.8 4.3 25.5 20.4 15.4 10.3 - -
67 27.1 3.8 27.1 26.3 22.8 17.8 12.7 - 23.9 4.2 23.9 23.9 21.5 16.4 11.4 -
62 26.0 3.7 26.0 26.0 25.3 20.2 15.2 10.1 23.1 4.2 23.1 23.1 22.3 17.2 12.2 7.1
57 26.1 3.7 26.1 26.1 25.4 20.3 15.3 10.2 23.3 4.2 23.3 23.3 22.5 17.4 12.4 7.3
1200
77 34.9 4.0 32.5 20.8 11.8 - - - 32.2 4.5 32.2 20.9 10.3 - - -
72 31.2 3.9 29.9 24.1 18.3 12.4 - - 28.3 4.3 28.3 22.8 16.9 11.1 - -
67 27.4 3.8 27.4 27.4 24.8 18.9 13.1 - 24.3 4.2 24.3 24.3 23.6 17.8 12.0 -
62 26.3 3.8 26.3 26.3 27.4 21.6 15.8 9.9 23.5 4.2 23.5 23.5 23.5 18.7 12.9 7.0
57 26.4 3.8 26.4 26.4 27.5 21.7 15.9 10.0 23.7 4.2 23.7 23.7 23.7 18.9 13.1 7.3
1350
72 31.3 4.0 30.7 25.2 18.6 12.0 - - 28.1 4.4 28.1 23.3 16.6 10.0 - -
67 27.5 3.9 27.5 27.5 25.2 18.6 11.9 - 24.1 4.3 24.1 24.1 23.3 16.6 10.0 -
62 26.4 3.9 26.4 26.4 27.0 20.3 13.7 7.1 23.4 4.3 23.4 23.4 23.4 17.2 10.6 4.0
57 26.5 3.9 26.5 26.5 27.1 20.4 13.8 7.1 23.6 4.3 23.6 23.6 23.6 17.5 10.8 4.2
1500
72 31.5 4.1 31.5 26.4 18.9 11.5 - - 27.9 4.5 27.9 23.8 16.3 8.9 - -
67 27.7 4.0 27.7 27.7 25.6 18.2 10.7 - 24.0 4.4 24.0 24.0 22.9 15.4 8.0 -
62 26.5 4.0 26.5 26.5 26.5 19.1 11.6 4.2 23.2 4.4 23.2 23.2 23.2 15.8 8.3 0.9
57 26.6 4.0 26.6 26.6 26.6 19.2 11.7 4.3 23.4 4.4 23.4 23.4 23.4 16.0 8.5 1.1
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
BHZ036 (3.0 Ton) (Continued)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65

333495-YTG-C-0908
16 Johnson Controls Unitary Products
BHZ042 (3.5 Ton)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1050
77 52.7 3.0 26.6 21.6 16.6 - - - 47.6 3.2 24.7 19.7 14.8 - - -
72 48.9 2.9 34.3 29.3 24.4 19.4 - - 44.4 3.2 32.7 27.7 22.7 17.7 - -
67 45.1 2.8 43.9 37.1 32.1 27.1 22.1 - 41.2 3.2 40.6 35.6 30.6 25.6 20.6 -
62 44.0 2.8 44.0 44.0 42.6 37.6 32.6 27.7 38.8 3.1 38.8 38.8 38.2 33.2 28.2 23.2
57 43.6 2.8 43.6 43.6 41.8 36.8 31.8 26.8 39.4 3.1 39.4 39.4 38.5 33.5 28.5 23.5
1225
77 52.5 2.9 29.9 22.9 17.0 - - - 48.4 3.2 28.7 21.1 15.2 - - -
72 48.7 2.9 36.7 30.8 24.9 19.0 - - 45.2 3.2 35.1 29.3 23.4 17.5 - -
67 44.9 2.8 44.3 38.7 32.8 26.9 21.0 - 41.9 3.2 41.6 37.4 31.5 25.6 19.7 -
62 43.9 2.8 43.9 43.9 42.3 36.4 30.5 24.6 39.5 3.1 39.5 39.5 39.3 33.4 27.5 21.6
57 43.5 2.8 43.5 43.5 42.6 36.7 30.8 24.9 40.1 3.1 40.1 40.1 39.6 33.7 27.9 22.0
1400
77 52.3 2.9 33.2 24.1 17.3 - - - 49.3 3.2 32.6 22.4 15.6 - - -
72 48.5 2.9 39.0 32.2 25.4 18.6 - - 45.9 3.2 37.6 30.8 24.0 17.2 - -
67 44.7 2.8 44.7 40.2 33.4 26.6 19.8 - 42.6 3.2 42.6 39.2 32.4 25.6 18.8 -
62 43.8 2.8 43.8 43.8 41.9 35.1 28.3 21.5 40.2 3.1 40.2 40.2 40.4 33.6 26.8 20.0
57 43.3 2.8 43.3 43.3 43.5 36.7 29.9 23.1 40.8 3.1 40.8 40.8 40.8 34.0 27.2 20.4
1575
72 48.4 3.1 41.4 33.7 25.9 18.2 - - 46.7 3.4 40.2 32.5 24.7 17.0 - -
67 44.5 3.0 44.5 41.9 34.1 26.4 18.6 - 43.3 3.3 43.3 41.1 33.3 25.6 17.8 -
62 43.7 3.0 43.7 43.7 42.7 35.0 27.3 19.5 40.9 3.3 40.9 40.9 41.0 33.2 25.5 17.7
57 43.2 3.0 43.2 43.2 43.5 35.8 28.1 20.3 41.5 3.3 41.5 41.5 41.5 33.7 26.0 18.2
1750
72 48.2 3.3 43.9 35.2 26.5 17.8 - - 47.5 3.5 42.8 34.1 25.4 16.7 - -
67 44.4 3.3 44.4 43.6 34.9 26.2 17.5 - 44.1 3.5 44.1 43.0 34.3 25.6 16.9 -
62 43.6 3.2 43.6 43.6 43.6 34.9 26.2 17.5 41.6 3.4 41.6 41.6 41.6 32.9 24.2 15.5
57 43.1 3.2 43.1 43.1 43.6 34.9 26.2 17.5 42.2 3.4 42.2 42.2 42.2 33.5 24.8 16.1
95°F 105°F
1050
77 42.5 3.5 22.9 17.9 12.9 - - - 39.6 3.8 22.3 17.3 12.3 - - -
72 39.9 3.5 31.0 26.0 21.0 16.0 - - 36.3 3.7 29.9 24.9 19.9 14.9 - -
67 37.3 3.5 37.3 34.1 29.1 24.1 19.2 - 33.0 3.7 33.0 31.4 27.4 22.4 17.4 -
62 33.7 3.4 33.7 33.7 33.7 28.7 23.7 18.8 30.6 3.6 30.6 30.6 30.6 25.6 20.6 15.6
57 35.2 3.4 35.2 35.2 35.2 30.2 25.3 20.3 31.9 3.7 31.9 31.9 31.9 26.9 21.9 16.9
1225
77 44.4 3.5 27.5 19.3 13.4 - - - 41.2 3.9 28.3 19.6 12.8 - - -
72 41.6 3.5 33.6 27.7 21.8 16.0 - - 37.7 3.9 32.4 26.5 20.6 14.7 - -
67 38.9 3.5 38.9 36.2 30.3 24.4 18.5 - 34.3 3.8 34.3 32.9 28.5 22.6 16.7 -
62 35.2 3.4 35.2 35.2 36.3 30.4 24.5 18.6 31.8 3.8 31.8 31.8 32.8 26.9 21.0 15.1
57 36.8 3.4 36.8 36.8 36.6 30.8 24.9 19.0 33.2 3.8 33.2 33.2 33.3 27.4 21.5 15.6
1400
77 46.2 3.5 32.1 20.7 13.9 - - - 42.7 4.0 34.3 21.9 13.3 - - -
72 43.4 3.5 36.3 29.5 22.7 15.9 - - 39.2 4.0 35.0 28.2 21.4 14.6 - -
67 40.5 3.6 40.5 38.2 31.4 24.6 17.8 - 35.6 3.9 35.6 34.5 29.5 22.7 15.9 -
62 36.6 3.5 36.6 36.6 38.9 32.1 25.3 18.5 33.0 3.9 33.0 33.0 35.0 28.2 21.4 14.6
57 38.3 3.5 38.3 38.3 38.1 31.3 24.5 17.6 34.4 3.9 34.4 34.4 34.7 27.9 21.1 14.2
1575
72 45.1 3.6 39.0 31.2 23.5 15.7 - - 40.6 4.0 37.2 29.9 22.1 14.4 - -
67 42.1 3.6 42.1 40.3 32.5 24.8 17.0 - 37.0 4.0 37.0 36.0 30.5 22.8 15.0 -
62 38.1 3.5 38.1 38.1 39.2 31.5 23.7 16.0 34.3 3.9 34.3 34.3 35.3 27.5 19.8 12.0
57 39.8 3.5 39.8 39.8 39.4 31.7 23.9 16.2 35.7 3.9 35.7 35.7 35.7 27.9 20.2 12.4
1750
72 46.8 3.7 41.7 33.0 24.3 15.6 - - 42.1 4.0 39.5 31.6 22.9 14.2 - -
67 43.7 3.7 43.7 42.4 33.7 25.0 16.3 - 38.3 4.0 38.3 37.6 31.5 22.8 14.1 -
62 39.6 3.6 39.6 39.6 39.6 30.9 22.2 13.5 35.5 3.9 35.5 35.5 35.5 26.8 18.1 9.4
57 41.3 3.6 41.3 41.3 40.8 32.1 23.4 14.7 37.0 4.0 37.0 37.0 36.7 28.0 19.3 10.6

333495-YTG-C-0908
Johnson Controls Unitary Products 17
115°F 125°F
1050
77 36.6 4.1 21.7 16.7 11.7 - - - 33.6 4.3 21.1 16.1 11.2 - - -
72 32.6 4.0 28.7 23.7 18.7 13.7 - - 29.0 4.3 27.5 22.6 17.6 12.6 - -
67 28.7 3.9 28.7 28.7 25.7 20.7 15.7 - 24.4 4.2 24.4 26.0 24.0 19.0 14.0 -
62 27.4 3.9 27.4 27.4 27.4 22.4 17.5 12.5 24.3 4.1 24.3 24.3 24.3 19.3 14.3 9.3
57 28.5 4.0 28.5 28.5 28.5 23.5 18.6 13.6 25.2 4.2 25.2 25.2 25.2 20.2 15.2 10.2
1225
77 37.9 4.3 29.2 19.9 12.2 - - - 34.7 4.6 30.0 20.1 11.5 - - -
72 33.8 4.2 31.2 25.3 19.4 13.5 - - 29.9 4.5 30.0 24.1 18.2 12.3 - -
67 29.7 4.1 29.7 29.7 26.6 20.7 14.8 - 25.1 4.4 25.1 26.5 24.8 18.9 13.0 -
62 28.4 4.1 28.4 28.4 29.3 23.4 17.5 11.6 25.0 4.4 25.0 25.0 25.8 19.9 14.0 8.1
57 29.6 4.1 29.6 29.6 29.9 24.0 18.1 12.2 26.0 4.5 26.0 26.0 26.5 20.6 14.7 8.8
1400
77 39.3 4.5 36.6 23.0 12.6 - - - 35.8 4.9 38.9 24.1 11.9 - - -
72 35.0 4.4 33.7 26.9 20.1 13.3 - - 30.8 4.8 32.4 25.6 18.8 12.0 - -
67 30.8 4.3 30.8 30.8 27.5 20.7 13.9 - 25.9 4.7 25.9 27.0 25.6 18.8 12.0 -
62 29.4 4.3 29.4 29.4 31.2 24.4 17.6 10.8 25.8 4.7 25.8 25.8 27.3 20.5 13.7 6.9
57 30.6 4.3 30.6 30.6 31.3 24.5 17.7 10.9 26.7 4.8 26.7 26.7 27.9 21.1 14.3 7.5
1575
72 36.2 4.4 35.5 28.5 20.7 13.0 - - 31.7 4.8 33.8 27.1 19.4 11.6 - -
67 31.8 4.3 31.8 31.8 28.5 20.7 13.0 - 26.6 4.7 26.6 27.5 26.4 18.7 10.9 -
62 30.4 4.3 30.4 30.4 31.3 23.5 15.8 8.0 26.5 4.6 26.5 26.5 27.3 19.6 11.8 4.1
57 31.6 4.3 31.6 31.6 32.0 24.2 16.5 8.7 27.5 4.7 27.5 27.5 28.2 20.5 12.7 5.0
1750
72 37.4 4.4 37.4 30.1 21.4 12.7 - - 32.6 4.7 35.2 28.7 20.0 11.3 - -
67 32.8 4.3 32.8 32.8 29.4 20.7 12.0 - 27.4 4.6 27.4 28.1 27.3 18.6 9.9 -
62 31.4 4.2 31.4 31.4 31.4 22.7 14.0 5.3 27.3 4.6 27.3 27.3 27.3 18.6 9.9 1.2
57 32.7 4.3 32.7 32.7 32.7 24.0 15.3 6.6 28.3 4.7 28.3 28.3 28.6 19.9 11.2 2.5
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
BHZ042 (3.5 Ton) (Continued)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65

333495-YTG-C-0908
18 Johnson Controls Unitary Products
BHZ048 (4.0 Ton)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1200
77 61.1 3.3 32.3 25.1 17.8 - - - 58.8 3.4 30.4 24.0 17.5 - - -
72 57.7 3.1 40.9 33.6 26.4 19.1 - - 54.5 3.3 38.7 32.2 25.7 19.3 - -
67 54.2 2.8 49.4 42.2 34.9 27.7 20.4 - 50.2 3.3 47.0 40.5 34.0 27.5 21.0 -
62 47.9 2.8 47.9 47.9 43.1 35.8 28.6 21.3 45.8 3.2 45.8 45.8 41.3 34.9 28.4 21.9
57 49.1 2.8 49.1 49.1 43.6 36.3 29.1 21.8 46.3 3.1 46.3 46.3 41.6 35.1 28.7 22.2
1400
77 61.0 3.5 34.3 26.4 18.9 - - - 58.6 3.6 34.2 25.5 18.4 - - -
72 57.6 3.2 43.0 35.5 28.0 20.5 - - 54.3 3.5 41.3 34.2 27.0 19.9 - -
67 54.2 2.9 51.8 44.6 37.1 29.5 22.0 - 50.0 3.5 48.4 42.8 35.7 28.6 21.4 -
62 47.9 2.9 47.9 47.9 45.7 38.2 30.7 23.2 45.7 3.4 45.7 45.7 43.4 36.3 29.2 22.0
57 49.1 3.0 49.1 49.1 46.2 38.7 31.2 23.7 46.2 3.3 46.2 46.2 43.7 36.6 29.5 22.3
1600
77 61.0 3.7 36.2 27.8 20.0 - - - 58.4 3.8 37.9 27.0 19.2 - - -
72 57.6 3.4 45.2 37.4 29.6 21.8 - - 54.1 3.7 43.9 36.1 28.3 20.5 - -
67 54.1 3.1 54.1 47.0 39.2 31.4 23.7 - 49.8 3.7 49.8 45.2 37.4 29.6 21.9 -
62 47.8 3.0 47.8 47.8 48.3 40.6 32.8 25.0 45.5 3.6 45.5 45.5 45.5 37.7 29.9 22.2
57 49.0 3.1 49.0 49.0 48.9 41.1 33.3 25.6 46.0 3.4 46.0 46.0 45.8 38.0 30.2 22.5
1800
72 57.6 3.8 48.6 39.9 31.3 22.7 - - 54.1 3.9 47.0 38.3 29.7 21.0 - -
67 54.2 3.5 54.2 50.6 41.4 32.8 24.2 - 49.8 3.9 49.8 47.5 39.2 30.6 21.9 -
62 47.9 3.4 47.9 47.9 48.1 39.5 30.9 22.2 45.5 3.8 45.5 45.5 45.5 36.8 28.2 19.5
57 49.1 3.5 49.1 49.1 49.0 40.4 31.7 23.1 45.9 3.6 45.9 45.9 45.9 37.2 28.6 19.9
2000
72 57.7 4.2 52.0 42.5 33.0 23.5 - - 54.0 4.2 50.0 40.5 31.0 21.5 - -
67 54.3 3.8 54.3 54.3 43.7 34.2 24.7 - 49.7 4.1 49.7 49.7 41.0 31.5 22.0 -
62 47.9 3.8 47.9 47.9 47.9 38.4 28.9 19.4 45.4 4.0 45.4 45.4 45.4 35.9 26.4 16.9
57 49.1 3.8 49.1 49.1 49.1 39.6 30.1 20.6 45.9 3.8 45.9 45.9 45.9 36.4 26.9 17.4
95°F 105°F
1200
77 56.5 3.4 28.5 22.8 17.1 - - - 51.7 3.8 27.8 22.1 16.4 - - -
72 51.3 3.6 36.5 30.8 25.1 19.4 - - 46.4 3.8 35.7 30.0 24.3 18.6 - -
67 46.1 3.8 44.5 38.8 33.1 27.4 21.7 - 41.0 3.9 40.2 37.4 32.2 26.5 20.8 -
62 43.7 3.6 43.7 43.7 39.6 33.9 28.2 22.5 39.6 3.8 39.6 39.6 37.3 31.6 25.9 20.2
57 43.5 3.3 43.5 43.5 39.7 34.0 28.3 22.6 39.5 3.6 39.5 39.5 37.4 31.7 26.0 20.2
1400
77 56.2 3.7 34.1 24.5 17.8 - - - 51.7 4.1 34.4 24.3 16.8 - - -
72 51.0 3.8 39.5 32.8 26.1 19.3 - - 46.3 4.2 38.3 31.6 24.8 18.1 - -
67 45.8 4.0 45.0 41.1 34.3 27.6 20.9 - 41.0 4.2 40.6 38.6 32.9 26.2 19.5 -
62 43.5 3.8 43.5 43.5 41.1 34.4 27.6 20.9 39.5 4.1 39.5 39.5 38.1 31.4 24.6 17.9
57 43.3 3.5 43.3 43.3 41.2 34.4 27.7 21.0 39.4 3.9 39.4 39.4 38.2 31.5 24.7 18.0
1600
77 55.8 3.9 39.7 26.2 18.4 - - - 51.6 4.5 41.0 26.5 17.1 - - -
72 50.6 4.1 42.6 34.8 27.0 19.3 - - 46.2 4.5 40.9 33.1 25.4 17.6 - -
67 45.5 4.3 45.5 43.4 35.6 27.8 20.1 - 40.9 4.5 40.9 39.8 33.6 25.9 18.1 -
62 43.2 4.1 43.2 43.2 42.6 34.9 27.1 19.3 39.4 4.4 39.4 39.4 38.9 31.2 23.4 15.6
57 43.0 3.8 43.0 43.0 42.7 34.9 27.2 19.4 39.4 4.2 39.4 39.4 39.0 31.2 23.5 15.7
1800
72 50.5 4.1 45.3 36.7 28.1 19.4 - - 46.3 4.6 43.1 35.0 26.2 17.5 - -
67 45.3 4.3 45.3 44.3 37.0 28.3 19.7 - 40.9 4.6 40.9 40.4 34.8 26.0 17.3 -
62 43.0 4.1 43.0 43.0 42.8 34.1 25.5 16.8 39.5 4.5 39.5 39.5 39.2 30.5 21.7 13.0
57 42.8 3.8 42.8 42.8 42.7 34.1 25.4 16.8 39.4 4.3 39.4 39.4 39.2 30.5 21.7 13.0
2000
72 50.3 4.2 48.1 38.6 29.1 19.6 - - 46.3 4.6 45.2 36.8 27.1 17.4 - -
67 45.2 4.4 45.2 45.2 38.3 28.8 19.3 - 41.0 4.7 41.0 41.0 35.9 26.2 16.5 -
62 42.9 4.2 42.9 42.9 42.9 33.4 23.9 14.4 39.5 4.5 39.5 39.5 39.5 29.8 20.1 10.4
57 42.7 3.8 42.7 42.7 42.7 33.2 23.7 14.2 39.4 4.4 39.4 39.4 39.4 29.7 20.0 10.3

333495-YTG-C-0908
Johnson Controls Unitary Products 19
115°F 125°F
1200
77 47.0 4.1 27.1 21.4 15.7 - - - 42.2 4.5 26.3 20.6 14.9 - - -
72 41.5 4.0 34.9 29.2 23.5 17.8 - - 36.5 4.3 34.1 28.4 22.7 17.0 - -
67 36.0 4.0 36.0 36.0 31.4 25.7 20.0 - 30.9 4.0 30.9 30.9 30.6 24.9 19.2 -
62 35.4 3.9 35.4 35.4 35.0 29.2 23.5 17.8 31.2 4.0 31.2 31.2 31.2 26.9 21.2 15.5
57 35.5 3.9 35.5 35.5 35.0 29.3 23.6 17.9 31.4 4.2 31.4 31.4 31.4 27.0 21.3 15.6
1400
77 47.1 4.6 34.7 24.0 15.7 - - - 42.6 5.0 34.9 23.8 14.7 - - -
72 41.6 4.5 37.1 30.4 23.6 16.9 - - 37.0 4.8 35.9 29.1 22.4 15.7 - -
67 36.1 4.4 36.1 36.1 31.5 24.8 18.0 - 31.3 4.6 31.3 31.3 30.1 23.4 16.6 -
62 35.5 4.3 35.5 35.5 35.1 28.4 21.6 14.9 31.6 4.6 31.6 31.6 31.6 25.3 18.6 11.9
57 35.6 4.3 35.6 35.6 35.2 28.5 21.7 15.0 31.8 4.7 31.8 31.8 31.8 25.5 18.7 12.0
1600
77 47.3 5.0 42.3 26.7 15.8 - - - 43.1 5.6 43.1 26.9 14.5 - - -
72 41.8 4.9 39.3 31.5 23.7 15.9 - - 37.4 5.3 37.4 29.8 22.1 14.3 - -
67 36.3 4.8 36.3 36.3 31.7 23.9 16.1 - 31.7 5.1 31.7 31.7 29.7 21.9 14.1 -
62 35.7 4.7 35.7 35.7 35.2 27.5 19.7 11.9 31.9 5.1 31.9 31.9 31.5 23.8 16.0 8.2
57 35.7 4.7 35.7 35.7 35.3 27.6 19.8 12.0 32.1 5.2 32.1 32.1 31.7 23.9 16.1 8.3
1800
72 42.1 5.0 40.8 33.3 24.4 15.6 - - 37.9 5.4 37.9 31.6 22.6 13.7 - -
67 36.5 4.9 36.5 36.5 32.6 23.8 14.9 - 32.1 5.2 32.1 32.1 30.4 21.5 12.5 -
62 35.9 4.8 35.9 35.9 35.7 26.8 18.0 9.1 32.4 5.2 32.4 32.4 32.2 23.2 14.2 5.3
57 36.0 4.8 36.0 36.0 35.8 26.9 18.1 9.2 32.5 5.3 32.5 32.5 32.3 23.3 14.4 5.4
2000
72 42.4 5.1 42.4 35.1 25.2 15.2 - - 38.4 5.5 38.4 33.3 23.2 13.0 - -
67 36.8 5.0 36.8 36.8 33.6 23.6 13.7 - 32.5 5.3 32.5 32.5 31.2 21.0 10.9 -
62 36.1 4.9 36.1 36.1 36.1 26.2 16.3 6.3 32.8 5.2 32.8 32.8 32.8 22.6 12.5 2.3
57 36.2 4.9 36.2 36.2 36.2 26.3 16.3 6.4 33.0 5.4 33.0 33.0 33.0 22.8 12.7 2.5
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
BHZ048 (4.0 Ton) (Continued)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65

333495-YTG-C-0908
20 Johnson Controls Unitary Products
BHZ060 (5.0 Ton)
Air on
Evaporator Coil Temperature of Air on Condenser Coil
Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh) Net
Capacity1
(MBh)
Total
Input
(kW)2
Sensible Capacity (MBh)
CFM WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1500
77 74.6 3.8 37.2 30.1 23.0 - - - 68.9 4.6 34.2 27.1 19.9 - - -
72 65.7 3.9 42.0 34.9 27.8 20.6 - - 62.7 4.6 42.6 35.5 28.4 21.3 - -
67 56.8 4.0 46.8 39.7 32.6 25.4 18.3 - 56.4 4.5 51.1 44.0 36.8 29.7 22.6 -
62 55.7 3.6 55.7 55.7 45.4 38.2 31.1 24.0 53.4 4.2 53.4 53.4 46.6 39.5 32.3 25.2
57 55.0 3.6 55.0 55.0 46.1 39.0 31.9 24.8 53.0 4.2 53.0 53.0 46.9 39.7 32.6 25.5
1750
77 76.7 4.1 41.6 33.6 25.1 - - - 70.0 4.8 39.3 29.6 21.1 - - -
72 67.6 4.2 47.6 39.2 30.7 22.3 - - 63.6 4.8 46.9 38.5 30.1 21.7 - -
67 58.5 4.4 53.5 44.8 36.4 27.9 19.5 - 57.3 4.7 54.6 47.5 39.0 30.6 22.2 -
62 57.3 3.9 57.3 57.3 50.3 41.8 33.4 25.0 54.2 4.4 54.2 54.2 49.4 41.0 32.6 24.1
57 56.7 3.9 56.7 56.7 51.0 42.6 34.2 25.8 53.7 4.4 53.7 53.7 49.7 41.3 32.8 24.4
2000
77 78.8 4.4 46.0 37.0 27.3 - - - 71.0 5.0 44.3 32.1 22.3 - - -
72 69.5 4.6 53.2 43.4 33.7 24.0 - - 64.6 5.0 51.2 41.5 31.8 22.1 - -
67 60.3 4.7 60.3 49.9 40.2 30.4 20.7 - 58.1 4.9 58.1 51.0 41.3 31.5 21.8 -
62 58.9 4.2 58.9 58.9 55.1 45.4 35.7 26.0 55.0 4.6 55.0 55.0 52.2 42.5 32.8 23.1
57 58.3 4.2 58.3 58.3 56.0 46.2 36.5 26.8 54.5 4.6 54.5 54.5 52.5 42.8 33.1 23.3
2250
72 73.2 4.5 60.4 49.3 38.2 27.1 - - 66.9 5.0 57.1 46.1 35.0 23.9 - -
67 63.6 4.6 63.6 58.0 45.8 34.7 23.6 - 60.2 4.9 60.2 56.5 45.4 34.3 23.3 -
62 62.1 4.2 62.1 62.1 60.2 49.1 38.0 27.0 57.0 4.7 57.0 57.0 55.6 44.5 33.5 22.4
57 61.4 4.1 61.4 61.4 60.3 49.2 38.1 27.0 56.5 4.6 56.5 56.5 55.5 44.4 33.4 22.3
2500
72 77.0 4.5 67.6 55.1 42.7 30.3 - - 69.2 5.1 63.0 50.6 38.2 25.8 - -
67 66.9 4.6 66.9 66.2 51.4 39.0 26.5 - 62.3 5.0 62.3 62.0 49.6 37.1 24.7 -
62 65.2 4.1 65.2 65.2 65.2 52.8 40.4 28.0 59.0 4.7 59.0 59.0 59.0 46.6 34.2 21.7
57 64.5 4.1 64.5 64.5 64.5 52.1 39.7 27.3 58.5 4.7 58.5 58.5 58.5 46.1 33.7 21.2
95°F 105°F
1500
77 63.3 5.5 31.1 24.0 16.9 - - - 57.8 5.8 29.5 22.4 15.3 - - -
72 59.7 5.2 43.2 36.1 29.0 21.9 - - 53.8 5.6 40.0 32.9 25.8 18.7 - -
67 56.1 4.9 55.3 48.2 41.1 34.0 26.8 - 49.8 5.4 49.4 43.4 36.3 29.1 22.0 -
62 51.2 4.9 51.2 51.2 47.8 40.7 33.6 26.4 45.7 5.3 45.7 45.7 43.6 36.5 29.4 22.2
57 50.9 4.9 50.9 50.9 47.6 40.5 33.3 26.2 46.5 5.3 46.5 46.5 42.1 34.9 27.8 20.7
1750
77 63.2 5.6 36.9 25.6 17.1 - - - 58.1 6.0 36.9 24.6 15.9 - - -
72 59.6 5.3 46.3 37.9 29.4 21.0 - - 54.1 5.8 43.7 35.2 26.8 18.4 - -
67 56.0 5.0 55.7 50.1 41.7 33.3 24.9 - 50.1 5.5 49.9 45.9 37.7 29.3 20.9 -
62 51.1 4.9 51.1 51.1 48.6 40.1 31.7 23.3 45.9 5.4 45.9 45.9 45.4 37.0 28.6 20.1
57 50.8 4.9 50.8 50.8 48.3 39.9 31.5 23.1 46.7 5.4 46.7 46.7 43.8 35.3 26.9 18.5
2000
77 63.2 5.7 42.6 27.1 17.4 - - - 58.4 6.1 44.2 26.8 16.5 - - -
72 59.6 5.4 49.3 39.6 29.9 20.2 - - 54.4 5.9 47.3 37.6 27.9 18.1 - -
67 56.0 5.1 56.0 52.1 42.3 32.6 22.9 - 50.3 5.7 50.3 48.4 39.2 29.5 19.7 -
62 51.1 5.0 51.1 51.1 49.3 39.6 29.9 20.1 46.2 5.5 46.2 46.2 47.2 37.5 27.8 18.0
57 50.8 5.0 50.8 50.8 49.1 39.3 29.6 19.9 47.0 5.5 47.0 47.0 45.4 35.7 26.0 16.3
2250
72 60.6 5.5 53.9 42.9 31.8 20.7 - - 55.6 6.0 51.3 40.6 29.5 18.4 - -
67 56.9 5.3 56.9 54.9 45.0 34.0 22.9 - 51.5 5.8 51.5 50.5 41.5 30.4 19.4 -
62 51.9 5.2 51.9 51.9 51.0 40.0 28.9 17.8 47.3 5.7 47.3 47.3 47.8 36.7 25.6 14.5
57 51.6 5.2 51.6 51.6 50.7 39.7 28.6 17.5 48.1 5.7 48.1 48.1 47.3 36.2 25.2 14.1
2500
72 61.5 5.7 58.5 46.1 33.7 21.3 - - 56.9 6.1 55.4 43.6 31.2 18.7 - -
67 57.8 5.4 57.8 57.8 47.7 35.3 22.9 - 52.7 5.9 52.7 52.7 43.8 31.4 19.0 -
62 52.8 5.3 52.8 52.8 52.8 40.3 27.9 15.5 48.3 5.8 48.3 48.3 48.3 35.9 23.5 11.1
57 52.4 5.3 52.4 52.4 52.4 40.0 27.6 15.2 49.2 5.8 49.2 49.2 49.2 36.8 24.3 11.9
