FENDER ELIMINATOR KIT
070BG141200
Kawasaki Z125 Pro
5420 DANIELS STREET STE A, CHINO CA., 91710 · [phone] · [phone] · FACSIMILE [phone]
THIS PRODUCT IS NOT DOT APPROVED.
Yoshimura R&D of America, Inc. is not liable or responsible for any resulting event caused by the
installation of this product. Check with local laws and regulations for compliance prior to
installation and use. This product is not intended for use on public highways.
! !

No.
Item
Description
Qty.
1
14120-FEBKT
Fender Eliminator Bracket
1
2
070BG-LH-K
LED License Plate Light
1
3
070BG-LPF
License Plate Frame
1
4
14650-TSL-BKT
Left Turn Signal Bracket
1
5
14650-TSR-BKT
Right Turn Signal Bracket
1
6
M6X16BHS
6mm x 16mm Button Head Screw
2
7
M6X14BHS
6mm x 14mm Button Head Screw
2
8
M4X6BHS
4mm x 6mm Button Head Screw
2
9
6MMWASHER
6mm Washer
4
10
6MMLN
6mm Nylon Lock Nut
4
**
94785-01-ND
Butt Connectors
2
**
ZT-400
Cable Ties
3
**
17029
Yoshimura Sticker Sheet
1
Optional Parts
***
070BGUNVTBKT
Universal Turn Signal Bracket Kit
2
Assembly Diagram
** Not shown on diagram.
*** The Yoshimura Universal Turn Signal Bracket Kit is to be used with aftermarket stud-mounted turn signals and is sold separately.
1
2
3
5
6
7
4
8
9
10

1. Remove rider seat.
2. Locate and disconnect license plate light and
turn signal connectors.
3. While securely supporting the stock fender
assembly, remove the four bolts securing the
fender assembly to the subframe. Carefully
remove the stock fender assembly making sure
not to damage connectors in the process.
4. Remove left and right turn signals from the
stock fender assembly.
5. Cut the stock license plate light connector from
the stock fender assembly. Be sure to cut at
least a 6” section of wire from the connector.
Removal
Installation
1. Install (No. 2) 070BG-LH-K, license plate light
onto (No. 1) 14120-FEBKT, fender eliminator
bracket using (No. 8) M4X6BHS, 4mm screws.
2. Using the 94785-01-ND butt connectors
provided in the kit, connect the Yoshimura
license plate light wires to the stock license
plate light wires as follows:
Red -to- Red
Black -to- Black/Yellow
3. Secure and install (No. 1) 14120-FEBKT, fender
eliminator bracket to subframe using the stock
fender bolts.
4. Install stock rear turn signals onto (No. 4,5)
14650-TSL/R-BKT, left and right turn signal
brackets using the stock hardware.
5. Install (No. 4,5) 14650-TSL/R-BKT, left and right
turn signal brackets and (No. 3) 070BG-LPF,
license plate frame to (No. 1) 14120-FEBKT,
fender eliminator bracket using the (No. 6,7)
M6X16BHS and M6X14BHS, 6mm button head
screws and (No. 9,10) 6MMWASHER,
6MMLN, washer and nut as shown.
6. Route license plate light and turn signal wires
through the hole in (No. 1) 14120-FEBKT,
fender eliminator bracket and through the lower
rear cowl. Re-connect license plate light and
turn signal connectors.
7. Use the cable ties supplied in the kit to secure
license plate light and turn signal wires.
8. Re-install rider seat.
9. Check for proper function of license plate light
and turn signals and that all brackets and
components are secure prior to riding.
