Yosin DP540 User manual

DP540 Digital Player Operating Manual
 


 



     
 





Front Panel Controls/Indicators Rear Plate Layout
Operational Flow Chart



Digital Player

 
    
Output Volume Control
Indicators of TRACK 1,2,3,4
a.Display the Track in PLAYING or RECORDING
b.Display the Item of PROGRAMMING
c.Display the Function of PROGRAMMING
TRACKButton
REC Indicator
Off: In PLAYING
On: In RECORDING or PROGRAMMING
Blinking: In WAITING MODE
RECButton





Power Adapter: 12VDC / 200mA
AUDIO IN: Input
AUDIO OUT: Output
8 ohm: Output
Telephone Interface: In/Output
External Trigger Switch





PLAYING
WAITING
MODE
RECORDING PROGRAMMING
REC
REC
TRACK
REC
REC
To change a track for playing
To select a track for RECORDING or
to select an item for PROGRAMMING
Means to press button untilall of indicators are blinking.
Means to press button quickly.
TRACK
To change function
TRACK
TRACK
REC

DP540 Digital Player Operating Manual
 


 

!!

Telephone
Earphone
ape, CD or PC
For inputting
recorded
Music/Message
For
monitoring
the input.
For directly
recording.


 



     

MOH port
of PBX MOH port of PBX
TRUNK port
of PBX
"4 tracks of DP540are availablefor recording up to4 message/music. Total recording time is 540seconds.
Recording
Input the recorded Message/Music from Tape/CD playeror PC to DP540 or use direct recording by telephone handset,the
procedures areas follows:
Step 1. As shown by Figure, connect theearphone, tape/CDplayer,
PC or phone set to DP540. Make sure REC indicator is
under off status. Otherwise, press RECto turn off the
REC indicator.
Step 2. Press RECuntil all of the indicators are blinking.
(REC Indicator blinking means waiting for further selection.)
Step 3. Press TRACKto select a track for recording.
(Blinking track indicator means what you have selected.)
Step 4. Press RECuntil all of the indicators are blinking.
(Track indicator will turn to stay on solidly.)
Step 5. Play the Tape/CD or PC or/and speak into the handset.
(When REC indicator turned to stay on solidly, it means
recording is started.)
Step 6. The recording will be auto-terminated while 1 second of
silence is detected. Orpress RECto complete the
recording and return to Playing.
(REC indictor turned off means under playing.)
"If you want to delete the recorded Message/Music,you must press RECimmediatelyafter step 4.
Connect the DP540 output to PBX
1.Connect power source to DP540 via adapter (included).
 Connect the DP540 "AUDIO OUT" Jack with the PBX MOH port.
Dial into PBX from CO line, let the called party hold the line and
then adjust the volume to proper position. If the volume is not
loud enough while in the maximum position, please connect the
"8 Ohm" output of DP540 with the PBX MOH port. If the PBX
uses CO line TRUNK port as MOH input, please connect the
TRUNK port to DP540 “Telephone Interface”.
Connection for recording
Connection for output
Don’t place the unit close to frequency generator (Power
supply, radio broadcast, … ) in 1 meter distance.

DP540 Digital Player Operating Manual
 
PROGRAMMING -- Item 1
Step 1. Make sure REC indicator is under off status. Otherwise, press RECto turn off the REC indicator.
Step 2. Press RECuntil all of the indicators are blinking. (REC Indicator will be blinking)
Step 3. Press TRACKto select the "Track1" Indicator. ("Track 1" Indicator willbe blinking)
Step 4. Press TRACKuntil all of the indicatorsare blinking. (RECindicator will be turned to stay onsolidly)
Step 5. Press TRACKto change the status of"Track 1,2,3" Indicators corresponding to the neededfunction.
Indicators
1234 Function of Playing

Single track with continuous playing. (Default, for MOH)



Single track with 1 time playing by trigger.



Single track with 2 times playing by trigger.





Single track with 3 times playing by trigger.


Multi-tracks insequence with continuous playing. (For MOH)




Multi-tracks insequence with 1 time playing by trigger.




Multi-tracks insequence with 2 times playing by trigger.






Multi-tracks insequence with 3 times playing by trigger.
Step 6. Press RECto complete theprogramming andreturn to Playing. (RECindictor willbe turned off.)
PROGRAMMING -- Item 2
Step 1. Make sure REC indicator is under off status. Otherwise, press RECto turn off the REC indicator.
Step 2. Press RECuntil all of the indicators are blinking. (REC Indicator will be blinking)
Step 3. Press TRACKto select the "Track2" Indicator. ("Track 2" Indicator willbe blinking)
Step 4. Press TRACKuntil all of the indicatorsare blinking. (RECindicator will be turned to stay onsolidly)
Step 5. Press TRACKto change the status of"Track 1,2,3" Indicators corresponding to the neededfunction.
Indicators
1234Recording Activated
by Audio Recording Terminated by Silence
 Yes (Default) Yes (Default)


 No Yes


 Yes No




 No No


Recording Prohibited
Step 6. Press RECto complete theprogramming andreturn to Playing. (REC indictor will be turned off)
"Anytime when you pressRECand TRACKsimultaneously until all of the indicators are blinking, the entire functions
of PROGRAMMING items will be reset to default. (Except for the status duringthe RECORDING)

Indicators: = ON, = OFF
"3 ways to trigger the playing:
a.By turning on the power.
b.By pressing TRACK
c.By External Trigger Switch.
"Pressing TRACKor
External Trigger Switch in
Single Track Playing will
change to next track.
"If the "Recording Activated by
Audio" function is disabled,
recording will begin immediately
while you switch to Recording.
"If the "Recording Terminated by
Silence" function is disabled, you
must press the REC to
complete the recording.

DP540 Digital Player Operating Manual
 
Application
Music / Message On-Hold
To inform callers about goods and services, reinforce the image of company, convey the desired information to callers as you
want. Turn passive waiting time to active promotionperiod.
Broadcast over public Place
To spread the message or music in public spaces such as Shopping mall, Museum, Airport, Corporate lobby, Casino,
Restaurant, Movie theater, Gas station and so on. For connection, justset DP540 to trigger playing mode, and connect “AUDIO
OUT” to the “AUX INPUT” of broadcastingsystem. Plugadapter of DP540 to atimer for the scheduled playing.
Play Advertising Messages In Store Promotion
DP540 is useful and ideal for Department store, Convenience store, Chain store, Retailer, and Grocery store in store
advertising or promotion. For connection, just set DP540 to trigger playing mode, and connect “AUDIO OUT” to the “AUX
INPUT” of broadcasting system.Advertising message will play when youpush the External Trigger Switchanytime.
Display In Exhibition
To perform the continuous and repeated product introduction in Trade show, Theme park, Just set DP540 to trigger playing
mode, and connect "8 ohm output" to a speaker. Product introducing message will play when the External Trigger Switch is
pushed anytime.
