YOTRIO LORENA User manual

THEASSEMBLYINSTRUCTION
OF
LORENAGAZEBO
"WARNING:KEEPALLFLAMEAND HEATSOURCESAWAYFROMTHISGAZEBO
FABRIC. ThisGazeboismadewithfabricthatmeetsCPAI 84specificationsforflame
resistance.Itisnotfireproof.Thefabricwillburnifleftincontinuouscontactwithanyflame
source.Theapplicationofanyforeignsubstancetothegazebofabricmayrenderthe
flame-resistantpropertiesineffective."
YotrioCorporation
4550 SanPabloAve, SuiteB,Emeryville, CA94608.
CountryofOriginal:China
Code#:Yotrio2009

1-866-905-4107
MONDAY-FRIDAY 9:00 AM TO 5:30 PM PST

1
The AssemblyInstruction ofLorenaGazebo
A 6PCS Pillar
B 6PCS Beam
C 6PCS
Long Support
Tube
D 6PCS
ShortSupport
Tube
E 1PC Top Hub
F 12PCS Tube
Connector
G 6PCS FootCap
H 6PCS CornerShelf
I 12PCS
Corner
Supporter
J 36PCS M6*15 Bolt
K 24PCS M6*32 Bolt
L 6PCS
M6*30
Bolt

2
M 12PCS
M6*22
Bolt
N 1PC
Small Fabric
Cover
O 1PC
LargeFabric
Cover
P 48PCS PlasticRing
Q 6PCS
Mosquito
Netting
R 12PCS Ground Spike
S 1PC Lantern
Screw Driver Wrench

3
Step1:
a. FixPillar(A)withCornerShelf(H)byM6X32(K)Bolts,butdo nottightenthem.InsertBeam(B)oneachsideof
CornerShelf(H)thentightenthembyusingM6X32(K)Boltsalreadyinplace. Repeatthisstep5timestoforma
hexagon. See figure1.
Note:TheBeam(B)mustbeplacedwiththe4holesalongsideitfacingtheground tohangthemosquitonetting.
b. PlacetheFoot Cap(G)on thebaseof Pillar(A)usingM6X15 (J)Bolts. See figure2.
Step2:
a.PlacetheShortSupportTube(D)ontopoftheLongSupportTube(C)andscrewtheTubeConnecters(F)then
fastenedtogetherateithersidebyusingM6X22 (M) Bolts. See Figure3.
b.InserttheLongSupport Tube(C)intothepipesoftheTop Hub (E).
c.FixtheShort SupportTube(D)tothetopend of theTop Hub(E)byusing M6X22(M)Bolts.See Figure4.
②
Fig. 1
Fig. 2
Fig. 3
M
Fig. 4
A
A
A
A

4
Step3:
PlaceeachCornerSupporter(I)on theassembledPillarand Beam(A+B)and screwinbyusing M6X15 (J)Bolts. See
Figure5and6.
Step4:
BringtheassembledCanopySupport Structureatstep2(C+D)on TopHub (E)and insert theeachend of Long Support
Tube(C)intothepipeof eachCornerShelf(H).See Figure7.
③
④
Fig. 5
Fig. 6
Fig. 7

5
Step5:
a. PlaceLargeCanopyCover(O)overtheLong SupportTubes(C)butdont extend it.
b.PlaceSmallFabricCover(N)ontop oftheShortSupportTubes(D).Fullyextend inalldirectionsthentightentogether
withtheSmallNetting.See Figure8.
c.Fullyextend theLargeFabricCover(O)inalldirectionstoincludetheCornerShelf(H).See Figure9.
Step6:
a. Hang theMosquitoNetting(Q)tothelowerend oftheBeam(B)byusingthePlasticRings(P).See Figure10.
b. InserttheGroundSpikes(R)throughtheFoot Cap(G)and hammeredintokeepGazebo inplace. See Figure11.
⑥
Fig. 8
Fig. 9
Fig. 10
Fig. 11

6
Step7:
PlacetheLanternonthehooklocatedatthebottomof theTopHub(E).See Figure12.
⑦
Step8:Toinstallthecandleonthelantern:
a.Turnthelanternbaseclockwise.
b. Removethebase.
c.Insert alitcandle1.5”in.dimensionsby1.75”in.heightonthecandlebase.
d.Insertitback inplaceandsecurebyturningthelanternbasecounterclockwise.
⑧
Fig. 12
A B C D

7
IMPORTANTNOTICE:
Candlesarenot providedand need tobe purchaseseparately. NEVERleavelit candles
unattended at ANYtime.Whenthelanternisinusewithalit candlechildrenarenottoplay
around the Gazebo andmust haveadult supervision.
The Lanternisnot atoyandshouldbe handledbyan adult only.Toavoiddamage toyour
lanternandGazebo the candleinyourlanternshouldnotexceed the 1.5”in.dimensionsby
1.75”in.height.
