YOTRIO TRELLIS User manual

THEASSEMBLYINSTRUCTION
OF
TRELLISGAZEBO
"WARNING:KEEPALLFLAMEAND HEATSOURCESAWAYFROMTHISGAZEBO
FABRIC. ThisGazeboismadewithfabricthatmeetsCPAI 84specificationsforflame
resistance.Itisnotfireproof.Thefabricwillburnifleftincontinuouscontactwithanyflame
source.Theapplicationofanyforeignsubstancetothegazebofabricmayrenderthe
flame-resistantpropertiesineffective."
YotrioCorporation
4550 SanPabloAve, SuiteB,Emeryville, CA94608.
CountryofOriginal:China
Code#:Yotrio2009

1-866-905-4107
MONDAY-FRIDAY 9:00 AM TO 5:30 PM PST

Step 2: AssembleBeamA1withA2byusing M6X15 (H1)bolts. See figure 1 &2.
Insert eavesB2and B2intothe assembled Beam(A1&A2)through the
assembled beamtrack. See figure3. ScreweavesB2and B3byusing M6X12
(H4)Bolts. See figure 4.
B1&B2
STEP02
B1&B2
A2
A2
B1
A1&A2
A1
H4
A1&A2
A1
H1
B2
Step 1: AssemblePanelFI withPanelF2byusing M6X30 (H3)bolts. Put plastic
capson. Repeat this step 3times.
F2
F1
F1&F2
H3
H2

Step 4: Connect all 4assembled beams(B1&B2)at eachcornerbyusing M6X12
(H4)bolts. See figure6. Repeat this step forall 4 corners.
Step 3: Placethe assembled Beam(A1&A2)and Eves(B1&B2)on top of the
Panels (F1&F2)and fastened byusing M6X30 (H3)bolts. See figure 5.
Repeat this step 3times.
A1&A2
B1&B2
H4
Fig. 6
Fig. 5
H3
F1&F2

Step 6: Assemblethe long canopysupport tubesD1withD3bypressing the push
pinon tube (D1). See figure8. Repeat this step 3 times.
Step 5: Insert the 4short canopysupport tubes(D4)intothe short canopyHUB
(P). Makesuretolock theminplacebyusing pushpinon the tubes. See
figure7.
Fig. 7
D3
Fig. 8
D4
D4
D3
P
D4 P
D1
D1
D4
D4

Step 8: Placethe assembled HUB(P)on the assembled HUB(N). Make sure to
connect HUB(N)withHUB(P)byusing the pushpinon the support canopy
tubes(D3withD3). See figure 10
Step 7: Insert the assembled 4long canopysupport tubes(D1&D3)and short
canopysupport tube (D2)intothe Large HUB(N). Makesuretolock themin place
byusing stretchbutton on the tubes. See figure9.Then screwthe lantern hook(J)
underneathHUB(N). See Figure 10.
D1&D3
STEP08
Fig. 9
D4
N
N
D1&D3
Fig.11
D3
D2
Fig.10
D2
D2
G1
N
D1&D3
D1&D3
D2

Fig.12
Step 10: Placethe small canopycover(M2)overthe top of the assembled short
HUB(P)and pull the canopy'scornerpocket at the end of short support tube (D4).
See figure13. Repeat this step 3times.
Step 9: Fastened the canopysupport tube (D1)withthe assembled Beam(A1&A2)
at eachcornerbyusing M6X15 (H1)bolts. Placethe plastic caps. See figure 11.
Repeat this step 3times. Then fastened the short canopysupporttube (D2)with
the assembled Beam(A1&A2)at the middlesection byusing M6X15 (H1)bolts.
See figure12. Placethe plastic caps. Repeat this step 3 times.
D2
A1&A2
H1
Fig.13
M2
D4
D1
H1
A1&A2
Fig.11

Step 11: Placethe large canopycover(M3)overthe top of the assembled HUB
(N), then insert the canopyfitting tube (C)at the end of the large canopycover
(M3). See figure14. Repeat this step 3times.Fix the large canopycover(M3)on
the assembled beam(A1&A2)byusing M6X15 (H1)bolts. See figure 15. Repeat
this step 5timeson eachside of the Gazebo.
Step 12: Toassemblethe Sun Panel: Onthe top of the pane insert the 2 piecesof
the sun panelfit tube (D5)through fromeitherend (M1). At the bottomof the sun
panel(M1), insert the sun panelfit tube (D7&D6)through the end.See figure 16
&17. Repeat this step on forthe second sun panel.
STEP12
D7
Fig.16
D5
D7
M1
M1
M1
Fig.17
D6
D6
D5
M3
CFig.14
M3
Fig.15

Step 13:
A. Insert the sun panelhooks (G3)on the assembled beam(A1&A2)-each
beamshouldhave4. See figure 19.
B. Placethe assembled sun panelfit tube (D)withthe assembled sun panel
(M1)on the hooks (G3). See figure 18.
C. Toprevent the sun panelfrombeing blownbythe wind: fix the sun panelfit
tubes(D7&D6)together. See figure20. And tiethe rope tothe small hooks
at the bottomof assembled panels (F1&F2). See figure 22.
D. Tohide the sun panel(M1). Roll the sun panel(M1)on the hook(G3)and tie
the rope tothe hooks. See figure 21.
E. You can install the sun panelon anyside of the Gazebo you like byfollowing
the abovesteps.
M1
M1
A1&A2
M1
D5
D7
G3
Fig.18
A1&A2
Fig.20
D6 F1&F2
M1
Fig.19
G3
G3
M1
Fig.22
Fig.21
A1&A2

Step 14: See lanternassembly instructionsattached. Placelantern hooks (G2)and
along side the support tubesribs(D1)then hang the chain(G4)along side the mid
post of the Gazebo. See figure23.
Step 15: Assemblethe ground fitting bracket (Q)at the end of the assembled panel
byusing M6X15 (H1)bolts. See figure25. Repeat this step 7times.Once finish
Insert ground spikes(J)through the ground fitting bracket toplace the Gazebo
firmly on the ground. See figure 26.
Q
H1
Fig.25
STEP15
J
Q
Fig.26
EG2
G4
G1
Fig.23

Attention:
1, Candlesarenot provided and need tobe purchased separately.
2, NEVERleavelit candlesunattended atanytime.
3, When the laternis inusewithalit candlechildren arenot to playaround
the gazebo and must haveadult supervision.
4, The Lanternsarenot toy'sand need tobe handled byadultsonly.
5, Toavoiddamage toyourlanternand gazebo the candleinyourlantern
must not exceed the dimensionsof 1.5"diameterand 1.75"height.

AA
Step 1: Placepanels AStand and makethemclosed bybolt. please see
the Fig.1.
Fig. 1
Step 2: AssemblebottomCtoPanelAbyusing BoltsD. Repeat this step
3times. Pleasesee the Fig. 2.
Fig. 2.

D
B
B
D
A
A
Step 3: AssembleTop coverBtoPanelAbyusing BoltsD. Repeat this
step 3times. Pleasesee the Fig . 2.
