YOTRIO Target Howell FCS01151AST User manual

Howell
Glove Sling Deep Seating Set
style # FCS01151AST
dpci # 009000870
>>assembly instructions

Congratulations on your latest Target purchase.
Now what? Don't start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you'll be on your way to transforming your patio in no time.
Good luck – though we're confident you won't need it.
ATTENTION:
This Chair is not intended for use during any kind of inclement weather and the manufacturer is not,
and can not be, held responsible for any damages caused as a result of such weather. Weather-related
damage, or damage as a result of the Chair not being stored properly when not in use, is not the
responsibility of the manufacturer.
During extended periods of non-usage, off season, or in inclement weather (wind, rain, snow, hail,
sleet), freezing conditions and extreme heat, the Chair needs to be stored in a dry, sheltered place to
prolong the life and to avoid damage to the Chair.
2
IMPORTANT WARNING:
Unpack the box on a clean, soft, level surface and make sure all parts have been included.
To replace missing or damaged parts please call 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.

WARRANTY:
This Chair comes with a one year limited warranty against original manufacture defects. If you experience
trouble with your chair, please call the customer service number below.
3
Target Corporation
Toll Free at: 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.
Code: Yotrio 2019
before you begin
1. Check for damage or missing parts. Call to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
855-MYTGTHOME (855-698-4846)

table of contents
introduction
hardware
parts list
assembly
2-3
5
6
7-10
QUESTIONS?
4Please call 855-MYTGTHOME (855-698-4846) parts and service. For faster service, have th e style number and DPCI number ready when calling.

hardware
5
(Part E)×8
M6*25mm screw with washer
(Part G)×1 (Part H)×2
Allen wrench Clip
(Part F)×4
M6*30mm screw with washer

ITEM DESCRIPTION QUANTITY
chair base 2
1
1
1
1
A
B
C
D
6
chair bracket 1
chair bracket 2
chair base 1
A
D

7
step 01:
Do not completely tighten screws until all screws are started.
1. Place the chair bracket 1 (A) upside down on a soft surface such as carpet.
2. Attach chair base1 (B) to the chair bracket 1 (A) by lining up the screw holes
chair bracket 1 (A).
3. Secure with M6*25mm screw with washer (E) and M6*30 mm screw with washer (F) .
(G).
on the end of chair base 1(B) with the corresponding screw holes on the
(Part E)×8
M6*25mm screw with washer
(Part F)×4
M6*30mm screw with washer
(Part G)×1 (Part H)×2
Allen wrench Clip
tighten using allen wrench

8
step 02:
Do not completely tighten screws until all screws are started.
1. Place the chair bracket 2(C) upside down on a soft surface such as carpet.
2. Attach chair base2 (D) to the chair bracket 2(C) by lining up the screw holes
on the end of chair base 2(D) with the corresponding screw holes on the chair
3. Secure with M6*25mm screw with washer (E) and M6*30 mm screw with washer (F).
tighten using allen wrench (G).
bracket 2 (C).
(Part E)×8
M6*25mm screw with washer
(Part F)×4
M6*30mm screw with washer
(Part G)×1 (Part H)×2
Allen wrench Clip

9
step 03:
Do not completely tighten screws until all screws are started.
1. Place the chair bracket 1(A) and chair bracket 2 (C) upside down on a soft surface such as carpet.
2. Attach chair base1 (B) to the chair base 2(D).
3.Use the clip (H) to connect the chair base 1(B) and the chair base2 (D).
D
D
B
H
(Part E)×8
M6*25mm screw with washer
(Part F)×4
M6*30mm screw with washer
(Part G)×1 (Part H)×2
Allen wrench Clip

step 04:
10
2. Return chair to upright position.
3. Put the cushion on the chair.
1. Tighted all the screws.
You are now ready to enjoy your new chair.

11

TM
T9102 arget. The Bullseye Design is a trademark of Target Brands Inc. All rights reserved.
