YOTRIO Target Howell FCS01154A User manual

Deep Seating Set Sofa
style # FCS01154A
dpci # 009000872
>>assembly instructions TM
Howell

Congratulations on your latest Target purchase.
Now what? Don't start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you'll be on your way to transforming your patio in no time.
Good luck – though we're confident you won't need it.
ATTENTION:
This Chair is not intended for use during any kind of inclement weather and the manufacturer is not,
and can not beheld responsible for any damages caused as a result of such weather. Weather-related
damage, or damage as a result of the Chair not being stored properly when not in use, is not the
responsibility of the manufacturer.
During extended periods of non-usage, off season, or in inclement weather (wind, rain, snow, hail,
sleet), freezing conditions and extreme heat, the Chair needs to be stored in a dry, sheltered place to
prolong the life and to avoid damage to the Chair.
2
IMPORTANT WARNING:
Unpack the box on a clean, soft, level surface and make sure all parts have been included.
To replace missing or damaged parts please call 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.

WARRANTY:
This Chair comes with a one year limited warranty against original manufacture defects. If you experience
trouble with your chair, please call the customer service number below.
3
Target Corporation
Toll Free at: 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.
Code: Yotrio 2019
before you begin
1. Check for damage or missing parts. Call to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
855-MYTGTHOME (855-698-4846)

table of contents
introduction
hardware
parts list
assembly
2-3
5
6
7-8
QUESTIONS?
4Please call 855-MYTGTHOME (855-698-4846) parts and service. For faster service, have th e style number and DPCI number ready when calling.

hardware
5
(Part F)×1
allen wrench
(Part D)×6
M6*25mm screw with washer
(Part E)×2
M6*30mm screw with washer

ITEM DESCRIPTION QUANTITY
1
A
6
chair bracket
Bchair base 1
A
B
C
Cmiddle leg 1

7
step 01:
ATTENTION: To avoid damage to your new patio furniture, please
use either the carton or another soft surface such as carpet as a
working surface to prevent product damage during assembly.
4. Attach the chair base (B) to the chair bracket (A) by lining up screw holes
on the chair base (B) with corresponding screw holes on the chair bracket (A).
5. Secure with M6*25 mm screw with washer (D) using allen wrench (F).
(Part D)×6
M6*25mm screw with washer
(Part F)×1
allen wrench
1. Place the chair bracket(A) upside down on a soft surface such as carpet.
1. 2.
(Part E)×2
M6*30mm screw with washer
2. Attach the middle leg (C) to the chair base(B) by lining up screw holes
on the middle leg (C) with corresponding screw holes on the chair base (B).
3. Secure with M6*30mm screw with washer (E) using allen wrench (F).
3.

step 02:
8
1. T ighten all the screws.
2. Turn the chair to upright position on a flat level surface.
Put the cushion on the chair.
You are now ready to enjoy your new chair.

9

TM
2019 Target. The Bullseye Design is a trademark of Target Brands Inc. All rights reserved.
