YOUYANG SLL Series Manual

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 1/21
OPERATION & MAINTENANCE
MANUAL
SLL- LED : UNSERVICEABLE AREA LIGHT(LED)
YOUYANG AIRPORT LIGHTING EQUIPMENT INC.

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 2/21
REVISION RECORD
This Revision Record of Manual is written in below Table and we supply new
updated Manual with product.
This Manual can be revised anytime for better improvement of products and its
Revision contents are made by company production process regulation and will
give to customers as newly updated Hard copy and Soft copy by CD.
This Manual not including content for discontinued parts and products.
REVISION RECORD
REVISION NO
CONTENTS
DATE
SIGN
Rev 0
FIRST MADE
2009-12-22

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 3/21
목차
1. General
1.1Knowledge before Operation(use)
1.2Cautions for Safety
1.3Quality guaranty
2. Product specification
3. Installation
4. Maintenance & Repair Procedure
5. Transportation & Storage
6. Drawings & Part List

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 4/21
1. General
1.1 Knowledge before use
Please read carefully this Manual with below Caution before use and use correctly.
If you do not understand and have any questions, please contact with below
department and make best Installation, Operation and Maintenance after sufficient
knowledge from us.
Please transfer this Manual to person in charge of end user and maintenance person
and Duty maintenance manager.
Please store this Manual where can see easy by person in charge always and use
anytime when required.
Company:
YOUYANG AIRPORT LIGHTING EQUIPMENT INC. KOREA
Department:
Quality Assurance Team
Tel:
[phone]
Fax:
[phone]
E - Mail
[e-mail]

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 5/21
1.2 Cautions for Safety
Keep this Caution to use products at safely and correctly to prevent before any
troubles and dangerous cases are occurred.
Use this product function as sufficiently and safely after carefully reading of this
Manual.
The Caution means as below 2 kinds:
WARNING
When user do violate this Introduction of Manual, it
cause serious injury and death to user.
NOTICE
When user do violate this Manual introduction, it
cause light injury to user and made products
troubles.

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 6/21
WARNING
1. If the product is watered, do not repair it. This will make electrical shock to user.
2. Do not use when a Cable is peeled off and damaged. This will make Electrical shock to
user.
3. Do make sure to fix the equipment after installation work.
NOTICE
1. Please keep the product away from water and dust. Otherwise this will make defect on
the product.
2. Please use all parts matching to right capacity. Otherwise this will make defect on the
product.
3. Please do no change the inner wiring of the product. Otherwise this will make defect
on the product.
4. Please do maintain and operate the work by trained technician. If non-qualified user
does these works, it makes defect and trouble on the product.

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 7/21
1.3 QUALITY GUARANTY
The product guaranty under this manual applied is 2 years after supply to site. The
consumable parts are excluded from guaranty period.
The troubles caused by products defects will be free of charge during guaranty period,
but, user mistakes and mis-use will be charged.
PRODUCT GUARANTY RANGE
Div.
A/S charge
Guaranty & support period
Product
defect
free A/S
2 years after arrival on site
charge A/S
10 years after arrival on site
User defect
Free A/S
Non
Charge A/S
10 years after arrival on site

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 8/21
2. PRODUCT SPECIFICATION
2.1 UAL : UNSERVICEABLE AREA LIGHT
No
Item
Specification
In compliance with
1
Environment
al Property
Operating
temperature
-40 ～+60℃
FAA: AC 150/5345-46C
Storage
temperature
-55 ～+55℃
FAA: AC 150/5345-46C
Precipitation
Exposure to rain, snow, ice, and standing
water
FAA: AC 150/5345-46C
Salt fog
Exposure to a corrosive salt atmosphere
FAA: AC 150/5345-46C
Temperature
shock
Exposure of the hot light fixture to cold
water spray
FAA: AC 150/5345-46C
Wind Velocity
Exposure to wind velocities of 300 not
FAA: AC 150/5345-46C
2
Electrical
Property
In put power
6.6A series circuit
FAA: AC 150/5345-46C
Power
consumption
45W
-
Lamp
Halogen lamp
-
Lamp type
GY-9.5
-
Lamp
specification
6.6A 45W * 1EA
-
Lamp life
＞1,000 hour
-
3
Photometric
Property
Light color
Blue
IEC 61827
Main beam
angle
Vertical horizontal
0°~ 6°360°
IEC 61827
Min. intensity
＞2 cd
IEC 61827
Chromaticity
x : 0.1536 y : 0.0983 *
ICAO, Annex 14, fig
A1.1
4
Mechanical
Property
Installation
height
300mm. Maximum
FAA: AC 150/5345-46C
Weight
2 kg
-
Size
150 X 150 X 315 mm
-

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 9/21
No
Item
Specification
In compliance with
Frangibility of
coupling
Breakable under 230kg pressure on 30cm
from breakable points
FAA : AC 150/5345-46
C
Wind Velocity
300Not
`
Surface
Treatment
Treatment
powder electrostatic painting
-
Color
Aviation yellow
FAA: AC 150/5345-46C
7
Composition
Body
Aluminum die-casting (ALD 6)
-
Dome lens
Glass (Blue)
-
Lamp socket
GY-9.5
-
2 pole plug
L- 823, Style 1.
FAA: AC 150/5345-26C
2.3.1 ELC-TEDL: ELEVATED OMNIDIRECTIONAL LOW INTENSITY LIGHT(외형도)

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 10/21
3. INSTALLATION
3.1 General
The light is supplied at a condition of assembled and tested by YOUYANG.
The Light product is supplied under KS, ICAO and FAA regulation requirement and Light
capacity, color and intensity can be decided with user to meet with airfield site
condition.
The Light installation method is complied with ICAO and FAA installation requirements.
Please see below procedure.
3.2 JIG & TOOLS for INSTALLATION
The Jig & Tools for installation work must be prepared and refer below list.
Jig for line arrangement with optical device
Torque Wrench
Ring spanner set
“L”type wrench set
Silicon grease
Driver
Other necessary tools.
3.3 CHECK POINTS before INSTALLATION
The Deep base (box) or Shallow base(box) must be installed before Light to be
installed as requirement as below.
The Light position is met with KS, ICAO, FAA and MAK Requirement?
The base box arrangement is met with requirement?

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 11/21
3.4 LIGHT INSTALLATION
Light is installed on earth with anchors and refer to below procedure.
3.4.1 SHALLOW BASE INSTALLATION
Light Installation Procedure
1) Mark bolts’right position of light on concrete floor.
2) Make 4 holes with concrete drill hammer.
3) Lay down light on the right position of 4 holes.
4) Drive 1/2”anchors into the holes of light and concrete floor.
5) Set the direction of light and fix it with bolts of coupling.
1
Light
2
Anchor Bolt(1/2”*100L)
3
Concrete

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 12/21
< NOTE >
-. To fasten bolts should be used by torque wrench.
(Torque Pressure: 30 N.m)
4. MAINTENANCE and REPAIR PROCEDURE
4.1 CHECK PERIOD and CHECK POINTS
This Precaution, Maintenance and Repair works are very important for Aircraft safety
operation. The below check points are recommended by FAA for Elevated type Light.
PRECAUTION & MAINTENANCE CHECK POINTS
CHECK POINT( ITEMS)
DAYLY
WEEKLY
MONTHLY
HALF
YEARLY
YEARLY
EMERGENCY
LIGHT LAMP ON
●
WEED&GRASS REMOVAL AROUND
LIGHT
●
LENS BROKEN CHECK AND CLEAN
●
LIGHT ARRANGEMENT & BEAM
DIRECTION
●
LIGHT & SOCKET CLAENING
●
LIGHT INSTALLATION HIGHT
●
INSIDE WATER
●
RUST & PAINT REMOVAL
●
LIGHT BROKEN
●
CABLE INSUATION
●

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 13/21
ALL PACKING & SEALING
●
SNOW & ICE REMOVAL
●
4.2 TROUBLE SHOOTING
Please follow up as below action for trouble shooting.
*Do change assembly of light at site and then, troubled light must be repaired at
maintenance shop to prevent runway shut-down time.
TROUBLE & ACTION
TROUBLE
REASON
ACTION
No Lighting
- Lamp Fault
- Replace lamp
- Lamp is not connected to
power.
- Check wiring and connector
connection status.
- Power drive part fault
- Replace power drive assembly
No Lighting
- No charged battery
- Replace batteries and check
solar cell.
- Solar cell’s voltage fault
- Replace solar cell
Brightness seems dimmer
than other same light.
- Lamp Fault
- Replace lamp
- Battery voltage fault
- Replace batteries
- Power drive fault
- Replace power drive
- Light angle fault
- Re-assemble it to right angle
Water penetration
- Water inlet inside of light body
- Replace packing of light cover
- Water inlet into Optical part
- Replace lens o-ring

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 14/21
4.3 REPAIR WORK METHOD
4.3.1 LAMP ASSEMBLY REPLACEMENT
1) TOOL & MATERIAL
TOOL
MATERIAL
1. Screwdriver
2. Flat head screwdriver
1. LED Assembly
2) WORK METHOD
NO
WORK METHOD
1
-. Power off the light
1. Lens, 2. Solar Cell, 3. Coupling 4. Base Plate
2
-. Un-fasten 4 bolts with screwdriver and open
the cover.
-. Separate LED Module and LED Module
Connector.
1
2
3
1
2
4

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 15/21
3
-. Un-fasten 4 bolts fixing lens by screwdriver.
4
-. Un-fasten bolts fixing lamp assembly by
screwdriver.
5
-. This photo shows that faulty LED Assembly is
separated from light.
6
Re-assembly
-. Assemble a new LED Assembly in revert of dis-
assembly order.
<NOTE>
1. Do not re-use O-ring and packing. (In a case of inevitable situation to
reuse them, please check the defective or not.)
2. Do work Lamp replacement wearing soft globes.
(Do not touch lamp by bare hands.)

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 16/21
4.3.2 BATTERY REPLACEMENT
1) TOOL AND MATERIAL
TOOL
MATERIAL
1. Screwdriver
1. BATTERY
2) WORK METHOD
NO
WORK METHOD
1
-. Un-fasten round headed bolts with
screwdriver.
1. Optical Assembly, 2. Power Assembly
3. Round headed bolt
2
-. Un-fasten 4 round headed bolts and
open Power box cover.
1. Power Box Cover, 2. Round headed bolt
3. Battery 4. Power Assembly
3
-. Un-fasten 2 bolts fixing battery with
screwdriver.
-. Take away battery fixing plate.
-. Replace a new battery.
NOTE: When replacing battery, watch out
not to change polarity.
-. Assembly work is revert of dis-assembly
order.
NOTE: Do not re-use O-Ring and Packing.
In inevitable situation, check any defects on them or not.

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 17/21
4.3.3 POWER ASSEMBLY REPLACEMENT
1) TOOL AND MATERIAL
TOOL
MATERIAL
1. Screwdriver
1. Power assembly
2) WORK METHOD
NO
WORK METHOD
1
-. Un-fasten round headed bolts with
screwdriver.
1. Optical Assembly, 2. Power Assembly
3. Round headed bolt
2
-. Un-fasten 4 round headed bolts and
open Power Box Cover.
1. Power Box Cover, 2. Round headed
bolt 3. Battery 4. Power Assebly
3
-. Take away all kinds of connector.
-. Un-fasten bolts fixing power assembly
with screwdriver.
-. Take away a failed power assembly..
4
-. Assembly a new power assembly in
revert of disassembly order.

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 18/21
4.3.4 COUPLING REPLACEMENT
1) TOOL AND MATERIAL
TOOL
MATERIAL
1. SPANNER(13mm)
1. COUPLING
2) WROK METHOD
NO
WORK METHOD
1
-. When replacing broken coupling, un-
fasten 2 hexagon bolts with spanner
(13mm).
-. Take the broken coupling away from
Light.
-. Take coupling away from plate as well.
-. Assemble a new coupling into plate.
-. Assemble light into coupling.
-. Fix the light with spanner.
NOTE : When fixing the light, watch out not
to be bent out of main beam direction.
5.운송 및보관
5.1 STORAGE
1) All Lights are supplied by each packing box and each box has name plate and
indicated box content at outside of box.
2) All light must be stored at dry condition without dust in the room.
5.2 2 Storage Atmosphere condition
1) Place : Dry and No dust place
2) Temperature : - 55~ +70 °C
3) Humidity : below than 90%

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 19/21
5.3 TRANSPORTATION
1) Arrange as low load box to be upper side and heavy load box to be lower side.
2) Marking at outside of big box when several small boxes input in big box what is
content in big box.
3) When transportation, the container, selves and boxes can be used.
4) Make a protection action for box contents from dust when container is opened.
5) The general regulation must be kept when transportation is made by air and sea
shipment and shall be followed with International transportation regulation.
6. Drawing and Part List
6.1 SLL-UAL : UNSERVICEABLE AREA LIGHT
Part List

OPERATING & MAINTENANCE MANUAL MODEL : SLL series
유양산전주식회사페이지 20/21
No
Part of name
quantity
Ordering NO
1
Optical Assembly
1
1-1
Globe
1
1-2
O-Ring
1
1-3
Upper cover
1
1-4
O-Ring
1
1-5
Upper Cover support
1
1-6
Bolt
4
1-7
Bolt
2
1-8
spring washer
2
1-9
Lamp support
1
1-10
LED PCB
1
1-11
LED Lens
1
1-12
Bolt
2
1-13
spring washer
2
1-14
Bolt
4
1-15
Bolt
2
2
Body assembly
1
2-1
Bolt
3
2-2
Body support
1
2-3
Photovoltaic arrays
1
2-4
Power supply assembly
1
2-5
Bolt
2
2-6
Cable gland set
1
2-7
Power supply support
1
2-8
Blind rivet
3
2-9
Lower pipe
1
2-10
Photovoltaic arrays angle bracket
2
2-11
Bolt
4
2-12
packing
1
2-13
Power supply box
1
2-14
Bolt
4
3
Coupling assembly
1
3-1
Coupling
1
3-2
Baseplate
1
