Yowza Daytona Plus User manual

※TABLE OF CONTENTS
1. PRECAUTIONS．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P2
2. POWER REQUIREMENTS．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P3
3. BEFORE YOU BEGIN．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P4
4. SUPPLIED COMPONENTS / SUPPLIED HARDWARE．．．．．．．．．．．．．． P5~P6
5. PARTS LIST．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P7~P10
6. ASSEMBLY INSTRUCTIONS．．．．．．．．．．．．．．．．．．．．．．．．． P11~P17
7. EXPLODED DIAGRAM．．．．．．．．．．．．．．．．．．．．．．．．．．．．P18~P23
8. STABILIZER ADJUSTMENT．．．．．．．．．．．．．．．．．．．．．．．．．． ．P24
9. MAINTENANCE．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P25~P26
10. IMPORTANT STEPS．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P28
11. MUSCLE CHART．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．P29
12. STRETCHING ROUTINE．．．．．．．．．．．．．．．．．．．．．．．．．．．． P30
13. TROUBLESHOOTING．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P31
14. WARRANTY．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P32~P33
15. COMPUTER OPERATION．．．．．．．．．．．．．．．．．．．．．．．．． P34~P42
Yowza Technical Support
877-969-9240
Enter Serial Number: ________________________
Enter Original Sales Order # ________________________
Purchase Date: ______________

2
YOWZA DAYTONA PLUS TREADMILL
PRECAUTIONS
Precautions:
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and
information before operating the treadmill. It is the responsibility of the owner to ensure that all users of this treadmill are
adequately informed of all warnings and precautions.
Use the treadmill only as described in this manual.
Place on a level surface, with 6 feet (2 m) of clearance behind it. Do not place the treadmill on any surface that blocks air
openings. To protect the floor or carpet from damage, place a mat under the treadmill.
When choosing a location for the treadmill be sure that the location and position permit access to a plug.
Keep the treadmill indoors, away from moisture and dust. Do not put the treadmill in a garage or covered patio, or near
water.
Do not operate the treadmill where aerosol products are used or where oxygen is being administered.
Keep children under the age of 12 and pets away from the treadmill at all times.
The treadmill should not be used by persons weighing more than 350LBS (160 Kg).
Never allow more than one person on the treadmill at a time. Wear appropriate exercise clothing when using the treadmill.
Do not wear loose clothing that could become caught in the treadmill. Athletic support clothes are recommended for both
men and women. Always wear athletic shoes. Never use the treadmill with bare feet, wearing only stockings, or in
sandals.
When connecting the power cord, plug the power cord into a grounded circuit. No other appliance should be on the same
circuit.
Always straddle the belt and allow it to start moving before stepping onto the belt.
Always examine your treadmill before using to ensure all parts are in working order.
Allow the belt to fully stop before dismounting.
Never insert any object or body parts into any opening.
Follow the safety information in regards to plugging in your treadmill.
Keep the power cord away from the incline wheels and do not run the power cord underneath your treadmill. Do not
operate the treadmill with a damaged or frayed power cord.
Always unplug the treadmill before cleaning and/or servicing. Service to your treadmill should only be performed by an
authorized service representative, unless authorized and/or instructed by the manufacturer. Failure to follow these
instructions will void the treadmill warranty.
Never leave the treadmill unattended while it is running.
Use “safety key” when operating the treadmill and make sure the “safety key” is clipped to the users clothing.
The cell phone signal might interfere treadmill functions, keep the cell phone away from the motor hood.
Please Always put the safety key on “ON” position, and use the power switch to ON/OFF machine. “Safety Key” is
designed for emergency stop, and it is “NOT” for the power ON/OFF the treadmill.
Remove the “safety key” and store it in a safe place when the treadmill is not in use. Keep the “safety key” away from children.

http://www.yowzafitness.com/
3
POWER REQUIREMENTS
Power Requirements:
IMPROPER CONNECTION OF THE EQUIPMENT GROUNDING CONNECTOR CAN RESULT IN THE RISK OF AN ELECTRIC
SHOCK. CHECK WITH A QUALIFIED ELECTRICIAN OR SERVICE MAN IF YOU ARE IN DOUBT AS TO WHETHER THE
PRODUCT IS PROPERLY GROUNDED. DO NOT MODIFY THE PLUG PROVIDED WITH THE PRODUCT, IF IT WILL NOT FIT
THE OUTLET; HAVE A PROPER OUTLET INSTALLED BY A QUALIFIED ELECTRICIAN.
This treadmill can be seriously damaged by sudden voltage changes in your home’s electrical power. Voltage spikes, surges and
noise interference can result from weather conditions or from other appliances being turned on or off. To reduce the possibility of
treadmill damage, always use a surge protector (not included) with your treadmill.
Surge protectors can be purchased at most hardware stores. The manufacturer recommends a single outlet surge protector with a
UL 1449 rating as a Transient Voltage Surge Suppressor (TVSS) with a UL suppressed voltage rating of 400V or less and an
electrical rating 110VAC, 15 amps.
This treadmill must be grounded to reduce the risk of electrical shock. Grounding provides a path of least resistance for electric
current, should the treadmill malfunction. This treadmill is equipped with an electrical cord that has an equipment-grounding
conductor and a grounding plug. Always plug the power cord into a surge protector, and plug the surge protector into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
This product is for use on a nominal 110-volt circuit, and has a grounding plug that looks like the plug illustrated in the drawing
below.
GFCI outlets and GFCI Circuit Breakers are NOT recommended for use on this product. GFCI outlets and GFCI Circuit Breakers
may cause this equipment to function improperly.

4
YOWZA DAYTONA PLUS TREADMILL
BEFORE YOU BEGIN
Open the boxes:
Open the boxes of your new equipment. Inventory all parts included in the boxes, and compare them to the Supplied Components and
Supplied Hardware lists on pages 5-6 for a full count of the parts included. If you are missing any parts or have any questions contact us
directly.
Gather your tools:
Before you begin, make sure that you have gathered all the necessary tools you may require to assemble the unit properly. Having all of
the necessary equipment at hand will save time and make the assembly quick and hassle-free.
Clear your work area:
Make sure that you have cleared away a large enough space to properly assemble the unit. Make sure the space is free from anything
that may cause injury during assembly. After the unit is fully assembled, make sure there is a comfortable amount of free area around
the unit for unobstructed operation.
Invite a friend:
Some of the assembly steps may require heavy lifting. It is recommended that you obtain the assistance of another person when
assembling this product.
User Weight Limitation:
Please note that there is a weight limitation for this product. If you weigh more than 350LBS (Approx. 160 Kg). It is not recommended
that you use this product. Serious injury may occur if the user’s weight exceeds the limit shown here. This product is not intended to
support users whose weight exceeds this limit.
Care and maintenance:
The safety level can be maintained only if it is examined for damage and wear.
Replace any defective components immediately and stop all use of the equipment until repaired.
Always take care when mounting the equipment. Straddle the equipment by placing your feet on the straddle rails. Dismount from the
equipment only after all parts have stopped.
Always check the wear and tear components like pulley, belts, etc.…To prevent injury.
There is an emergency stop, in the form of a SAFETY KEY, to prevent injury; you can stop the treadmill immediately by actuating the
emergency stop for emergency dismount.

http://www.yowzafitness.com/
5
SUPPLIED COMPONENTS
This list identifies the major components you will use to assemble this product.
No.
Description
Qty.
A1
Main Frame Assembly
1
A2
Console Assembly
1
701
Upright Cover –LL
1
702
Upright Cover –LR
1
703
Upright Cover –RR
1
704
Upright Cover –RL
1
705
Upright Side Cover –Left
1
706
Upright Side Cover –Right
1
707
Wheel 65x25mm Set
2
708
Left Handlebar
1
709
Right Handlebar
1
710
Upright Lower Cap
2
725
I PAD Shelves
1
810
IWM Scale
1
E
Power Cord
1
G
Safety Key
1
I
MP3 Connection Wire
1
707
E
708
A1
709
A2
801
G
706
703
701 702 704 705
710
725
I

6
YOWZA DAYTONA PLUS TREADMILL
SUPPLIED HARDWARE
This list identifies the hardware you will use to assemble the product. To help distinguish between the various types of
screws and bolts, use the scale below to measure them and compare them to the sizes listed.
–––
No.
Description
Qty.
601
M8x25mm Allen Head CAP Bolt
2
602
M8x50mm Allen Head Bolt
4
604
4x15mm Screw
14
605
M10x45mm Bolt
2
606
10x22x2mm Spring Washer
2
608
M6x45mm Bolt
2
A
Screwdriver
1
C
6mm T-Type Allen Key
1
D
5mm Allen Key
1
F
4mm Allen Key
1
MILLIMETERS
601 602 604
605 606 608
F
AC D

http://www.yowzafitness.com/
7
PARTS LIST
Item No.
Description
Qty.
Part No.
DAYTONA-100
101
Base Frame
1
DAYTONA PLUS-101
102
Console Support Tube
1
DAYTONA PLUS-102
103
Elevation Support Tube
1
DAYTONA PLUS-103
104
Deck Frame
1
DAYTONA PLUS-104
105
Left Upright
1
DAYTONA PLUS -105
106
Right Upright
1
DAYTONA PLUS -106
107
Shock Locker Tube
1
DAYTONA PLUS -107
108
Left Handlebar
1
DAYTONA PLUS -108
109
Right Handlebar
1
DAYTONA PLUS -109
DAYTONA-200
201
Motor Holder
1
DAYTONA PLUS -201
202
Elevation Gear Sleeve
1
DAYTONA PLUS -202
203
Elevation Gear Sleeve Holder
1
DAYTONA PLUS -203
204
Power Switch Plate
1
DAYTONA PLUS -204
205
Front Roller
1
DAYTONA PLUS -205
206
Rear Roller
1
DAYTONA PLUS -206
207
Running Deck Support Tube
3
DAYTONA PLUS -207
208
Running Deck Support Tube Foam Grip
3
DAYTONA PLUS -208
211
Plastic Clamp Bracket
2
DAYTONA PLUS -211
212
Oilless bushing
4
DAYTONA PLUS -212
214
Compression spring
1
DAYTONA PLUS -214
217
Running Belt
1
DAYTONA PLUS -217
219
Running Deck
1
DAYTONA PLUS -219
221
Base Frame Fixed Plate
2
DAYTONA PLUS -221
222
Cushion M8X36X10
2
DAYTONA PLUS -222
DAYTONA-300
301
Rectangular Cushion 101X34X19.25-21.25
2
DAYTONA PLUS -301
302
Double Arc Shape Cushion 101x25x19.4
2
DAYTONA PLUS -302
304
Deck Rubber Cushion
2
DAYTONA PLUS -304
306
PU cushion
1
DAYTONA PLUS -306
308
Wheel OD: 25X100mm
2
DAYTONA PLUS -308
309
End Cap 40X40
2
DAYTONA PLUS -309
310
Plastic Clamp –Top
2
DAYTONA PLUS -310
311
Plastic Clamp - Bottom
2
DAYTONA PLUS -311
312
Deck Frame Side Cover –Left
1
DAYTONA PLUS -312
313
Deck Frame Side Cover –Right
1
DAYTONA PLUS -313
314
Console Housing –Top
1
DAYTONA PLUS -314
315
Console Housing –Bottom
1
DAYTONA PLUS -315
316
Wheel OD: 65x25mm
2
DAYTONA PLUS -316
317
Console PC board
1
DAYTONA PLUS -317
318
Speaker Cover –Left
1
DAYTONA PLUS -318

8
YOWZA DAYTONA PLUS TREADMILL
PARTS LIST
Item No.
Description
Qty.
Part No.
319
Speaker Cover –Right
1
DAYTONA PLUS-319
320
Side Rail End Cap –Left
1
DAYTONA PLUS-320
321
Side Rail End Cap –Right
1
DAYTONA PLUS-321
322
Elevation Support Tube Cover –Left
1
DAYTONA PLUS-322
323
Elevation Support Tube Cover –Right
1
DAYTONA PLUS-323
325
Vent Cover
1
DAYTONA PLUS-325
326
Motor Belly Pan
1
DAYTONA PLUS-326
327
Motor Hood
1
DAYTONA PLUS-327
328
Base Frame End Cap 48X121X30
2
DAYTONA PLUS-328
329
Elevation Support Tube Cap 19.4
2
DAYTONA PLUS-329
331
Handlebar End Cap
2
DAYTONA PLUS-331
332
Side Rail
2
DAYTONA PLUS-332
333
Level Adjuster M8X28.5
2
DAYTONA PLUS-333
334
Driving Belt 260J-7
1
DAYTONA PLUS-334
335
Wheel Bushing 22x19x12mm
4
DAYTONA PLUS-335
336
Running Deck Fixed Plate
10
DAYTONA PLUS-336
337
Power Plate Set
1
DAYTONA PLUS-337
340
Fan Bracket –Top
1
DAYTONA PLUS-340
341
Fan Bracket –Bottom
1
DAYTONA PLUS-341
342
Adjustable Vane
1
DAYTONA PLUS-342
343
Elevation Support Tube Axel
1
DAYTONA PLUS-343
344
Cushion Pad 18X35X2
1
DAYTONA PLUS-344
345
Washer 10X20X T1.5
2
DAYTONA PLUS-345
346
Cushion Pad 28X16-M8X12
2
DAYTONA PLUS-346
347
Round PVC Cushion M8X48
2
DAYTONA PLUS-347
351
Overlay
1
DAYTONA PLUS-351
DAYTONA-400
401
Hand Pulse Upper Cover –Left
1
DAYTONA PLUS-401
402
Hand Pulse Bottom Cover –Left
1
DAYTONA PLUS-402
403
Driving Motor
1
DAYTONA PLUS-403
404
Power Breaker
1
DAYTONA PLUS-404
405
Power Socket
1
DAYTONA PLUS-405
406
Power Switch
1
DAYTONA PLUS-406
407
Fan
1
DAYTONA PLUS-407
408
Elevation Motor
1
DAYTONA PLUS-408
409
Transformer
1
DAYTONA PLUS-409
410
3/8” Cable Tie
5
DAYTONA PLUS-410
411
5/16” Cable Tie
3
DAYTONA PLUS-411
412
USB+MP3 Docking Plate
1
DAYTONA PLUS-412
413
8pin Computer Wire - Upper
1
DAYTONA PLUS-413
414
8pin Computer Wire - Lower
1
DAYTONA PLUS-414
415
Safety Key Wire –Upper
1
DAYTONA PLUS-415
416
Safety Key Wire –Lower
1
DAYTONA PLUS-416
417
Connection Wire
1
DAYTONA PLUS-417
418
3C Power Wire
1
DAYTONA PLUS-418
419
3C Power Connection Wire
2
DAYTONA PLUS-419
420
Power Connection Wire
3
DAYTONA PLUS-420
421
Safety Key Connection Wire –Black
1
DAYTONA PLUS-421

http://www.yowzafitness.com/
9
PARTS LIST
LIST
Item No.
Description
Qty.
Part No.
422
Safety Key Connection Wire - Red
1
DAYTONA PLUS -422
423
Ground Wire
1
DAYTONA PLUS -423
424
Hand Pulse Sensor Wire
1
DAYTONA PLUS -424
425
1P Ground Wire
1
DAYTONA PLUS -425
426
Speaker
2
DAYTONA PLUS -426
428
Safety Key Base
1
DAYTONA PLUS -428
429
Control Board
1
DAYTONA PLUS -429
430
Elevation Board
1
DAYTONA PLUS -430
431
Circuit Board Mounting Spacer
6
DAYTONA PLUS -431
432
Hand Pulse Upper Cover –Right
1
DAYTONA PLUS -432
433
Hand Pulse Bottom Cover –Right
1
DAYTONA PLUS -433
434
Computer PC Board
1
DAYTONA PLUS -434
437
Receiver Wire
1
DAYTONA PLUS -436
439
Button PC Membrane
1
DAYTONA PLUS -439
440
Amplifier PC Board
1
DAYTONA PLUS -440
441
Amplifier volume control 3pin wire
1
DAYTONA PLUS -441
442
iPod dock connection 6pins wire
1
DAYTONA PLUS -442
443
Motion Control PC Board
1
DAYTONA PLUS -443
451
LED blue light buttom
1
DAYTONA PLUS -451
452
Digital Bluetooth Audio PC board
1
DAYTONA PLUS -452
DAYTONA-500
501
M10X120X47mm Carriage Bolt
1
DAYTONA PLUS -501
502
8x16x3mm Washer
2
DAYTONA PLUS -502
504
M8x20mm Allen Head Bolt
2
DAYTONA PLUS -504
505
M16x19-M16x22mm Bolt
1
DAYTONA PLUS -505
506
M16X24X10 Nut
1
DAYTONA PLUS -506
507
Plastic Washer
1
DAYTONA PLUS -507
508
20X49X5.5mm Washer
1
DAYTONA PLUS -508
510
M5X8mm Screw
2
DAYTONA PLUS -510
511
M10x35mm Allen Head Bolt
11
DAYTONA PLUS -511
513
M8x30mm Allen Head Bolt
2
DAYTONA PLUS -513
514
M10x40mm Allen Head Bolt
2
DAYTONA PLUS -514
516
M8x25mm Screw
4
DAYTONA PLUS -516
517
M6x15mm Screw
6
DAYTONA PLUS -517
518
M8x15mm Allen Head CAP Bolt
4
DAYTONA PLUS -518
519
M8x75mm Allen Head CAP Bolt
3
DAYTONA PLUS -519
520
M10x42mm Bolt
2
DAYTONA PLUS -520
522
M10X118X14mm Bolt
1
DAYTONA PLUS -522
523
M14x80mm Bolt
2
DAYTONA PLUS -523
524
3x12mm Screw
2
DAYTONA PLUS -524
525
4x15mm Screw
11
DAYTONA PLUS -525
526
4x19mm Screw
2
DAYTONA PLUS -526
527
4x8mm Screw
7
DAYTONA PLUS -527
529
4x12mm Screw
21
DAYTONA PLUS -529
530
4x19mm Screw
15
DAYTONA PLUS -530
531
4x12mm Screw
2
DAYTONA PLUS -531
532
M8 Nut
6
DAYTONA PLUS -532

10
YOWZA DAYTONA PLUS TREADMILL
PARTS LIST
Item No.
Description
Qty.
Part No.
533
M10 Nylon Nut
9
DAYTONA PLUS -533
534
M8 Nylon Nut
5
DAYTONA PLUS -534
535
10x22x2mm Washer
11
DAYTONA PLUS -535
536
6x13x1mm Washer
6
DAYTONA PLUS -536
537
8x16x1mm Washer
7
DAYTONA PLUS -537
538
10x16x2mm Washer
10
DAYTONA PLUS -538
539
6x10x1mm Spring Washer
6
DAYTONA PLUS -539
540
14X42X3mm Washer
2
DAYTONA PLUS -540
541
6mm Fixing Insert
2
DAYTONA PLUS -541
543
4x12mm Self Tapping Screw
4
DAYTONA PLUS -543
544
4x15mm Screw
2
DAYTONA PLUS -544
545
8x14x2mm Spring Washer
2
DAYTONA PLUS -545
547
6x20mm Bolt
1
DAYTONA PLUS -547
548
4x12x1mm Washer
2
DAYTONA PLUS -548
549
M5 Nut
3
DAYTONA PLUS -549
552
M5x10mm Screw
4
DAYTONA PLUS -552
555
6x8x8mm Plastic Washer
2
DAYTONA PLUS -555
556
4x12mm Screw
2
DAYTONA PLUS -556
557
17.2X22X1mm Washer
3
DAYTONA PLUS -557
DAYTONA-600
601
M8x25mm Allen Head CAP Bolt
2
DAYTONA PLUS -601
602
M8x50mm Allen Head Bolt
4
DAYTONA PLUS -602
604
4x15mm Screw
14
DAYTONA PLUS -604
605
M10x45mm Bolt
2
DAYTONA PLUS -605
606
10X16X2mm Spring Washer
2
DAYTONA PLUS -606
608
M6x45mm Bolt
2
DAYTONA PLUS -608
DAYTONA-700
701
Upright Cover –LL
1
DAYTONA PLUS -701
702
Upright Cover –LR
1
DAYTONA PLUS -702
703
Upright Cover –RR
1
DAYTONA PLUS -703
704
Upright Cover –RL
1
DAYTONA PLUS -704
705
Upright Side Cover –Left
1
DAYTONA PLUS -705
706
Upright Side Cover –Right
1
DAYTONA PLUS -706
708
Left Handlebar
1
DAYTONA PLUS -708
709
Right Handlebar
1
DAYTONA PLUS -709
710
Upright Lower Cap
2
DAYTONA PLUS -710
711
Motion Control PC Assembly
1
DAYTONA PLUS -711
725
Tablet Rack
1
DAYTONA PLUS -725
DAYTONA-800
801
IWM Scale
1
DAYTONA PLUS -801

http://www.yowzafitness.com/
11
OPEN BOX INSTRUCTION
(A) Remove your treadmill from the carton and place it on the floor in an open area.
(B) Remove the treadmill and all the components and hardware from the box.
(C) Check the quantities of all components and hardware with the component and hardware lists on pages 5-6.
(D) After verifying inventory if there is any missing parts please contact Yowza fitness at 877-969-9240.
.
9
3
7
5
8
1
2
6
CUT
CUT
CUT
CUT

12
YOWZA DAYTONA PLUS TREADMILL
STEP1
ASSEMBLY
STEP 1..Rotate the Uprights (105, 106) up, and secure using the M8x25mm Allen Head
CAP Bolt (601) to firm the upright, and then attach the Upright Lower Cap (710)
PLEASE CUT THE CABLE TIE AS SHOWN IN FIG-1 BEFORE YOU ASSEMBLE THE
UPRIGHT.
601
X2
601
601
106
105
101
C

http://www.yowzafitness.com/
13
STEP2
ASSEMBLY
STEP 2.. Attach the wheel to the base frame and secure using M10x45mm Bolt (605)
with 10X16X2 Spring Washer (606).
605
X2
606
X2
101
105
106
605 606
707
707 605
606
C

14
YOWZA DAYTONA PLUS TREADMILL
STEP3
ASSEMBLY
STEP 3-A.. Connect the 8pin Computer Wire - Upper (413) to 8pin Computer Wire -
Lower (414) and Safety Key Wire –Upper (415) to Safety Key Wire –Lower (416).
STEP 3-B.. Attach the Console Support Tube to the uprights and secure using
M6x45mm Bolt (608)
608
X2
102 608
608
105
106
416
415
413
414
F

http://www.yowzafitness.com/
15
STEP4
ASSEMBLY
STEP 4.. Attach the Left and Right Handlebar and secure using the M8x50mm Allen
Head Bolt (602)
602
X4
602
708
602 709
602
602
102
105
106
D

16
YOWZA DAYTONA PLUS TREADMILL
STEP5
ASSEMBLY
STEP 5.. Attach the Upright Cover (701, 702,705) to the left upright. Repeat the above procedure to assemble the right side.
315
703 706 704 705
701
702
STEP2
STEP1
STEP3
702
102
702
705
102
702
102
658
657
656
658
656
657
658
657
656

http://www.yowzafitness.com/
17
STEP6
ASSEMBLY
STEP 6.. Secure use the 4x15mm Screw (604) to firm the upright cover.
Place on your IWM scale in range of 3 meter and start to enjoy the exercise.
Your treadmill is now fully assembled.
604
X14
604
604
604
604
702 701
703
704
105
604
604
604
701
702

18
YOWZA DAYTONA PLUS TREADMILL
EXPLODED DIAGRAM - 01
428
604
604
525 531 525
531
604
525
531
525
604
315
530
706
525 433 524
524
402
401
209
705
541 209
701
702
331
527
102
527
552
407
426
341
549
342
318
319
703
704
340
426
317
531
314
432
108 109
527
527
530
711
541
711
324
330

http://www.yowzafitness.com/
19
EXPLODED DIAGRAM - 02
105
329
529
323
212
212
523
302
322
523
212
302
333
328
333
328
529
329
335
106
103
101
316
530
530
316
335
606
605
606 605
534
601
221
221
534 513
601
509
337
404
509
405
510
556
204
513
406
602
602
602
602
608
608
301
301
530
530
303
309

20
YOWZA DAYTONA PLUS TREADMILL
EXPLODED DIAGRAM - 03
516
336
320
543
217
332
332
516
535
511
538
538
538
511
538
321
219
