ZEAL'N LIFE SP-01A User manual

Product manual
Steam Mop Cleaner
SP-01A

IMPORTANT SAFETY INSTRUCTIONS
Contents
3
Product part name..........................................................4
Parts list............................................................................5
Complete machine installation steps...........................6
Attachment Installation Steps........................................7
Use steam mop................................................................9
Product standard............................................................12
Trouble removal..............................................................13
Guarantee.........................................................................14
After-sales service..........................................................15
Please read this instruction carefully before using the product and
keep it for reference.
BEFORE USING IT. BE SURE TO READ ALL THE INSTRUCTIONS BELOW CAREFULLY.
WHEN USING YOUR VACUUM CLEANER. ALWAYS FOLLOW THE INSTRUCTIONS BELOW.
■ ONLY WITHIN THE SCOPE OF THE MACHINE.
■ IF THE BLACK CHARGER OR THE MACHINE HAS BEEN REPORTED DESTROYED, IN ORDER TO AVOID DAMAGE.
IT MUST BE REPLACED OR REPAIRED BY THE MANUFACTURER OR ITS SERVICE AGENT OR BY A SIMILARLY
QUALIFIED PERSON.
■ THIS PRODUCT MAY ONLY BE GIVEN TO CHILDREN 8 YEARS OF AGE OR OLDER UNDER THE FOLLOWING
CIRCUMSTANCES. WEAK AND SICKLY PEOPLE WHO LACK THE RELEVANT KNOWLEDGE AND EXPERIENCE TO
USE, THEY HAVE THE APPROPRIATE GUARDIAN PERMISSION OR GET THE APPROPRIATE INFORMATION ABOUT
THE SAFE USE OF THE PRODUCT AND UNDERSTAND THE CORRESPONDING HAZARDS. CHILDREN MAY NOT PLAY
WITH MACHINES. CHILDREN MAY USE THIS PRODUCT ONLY UNDER THE SUPERVISION OF THEIR GUARDIAN.
■TO AVOID THE RISK OF ELECTRIC SHOCK, DO NOT FLOOD ANY PART OF THE PRODUCT INTO WATER OR
LIQUID.
■ THE PRODUCT WAS DAMAGED WHEN. TO AVOID ELECTRIC SHOCK, DO NOT DISASSEMBLE OR ATTEMPT TO
REPAIR THE PRODUCT. THE PRODUCT SHALL BE RETURNED FOR REPAIR. UNPROFESSIONAL DISASSEMBLY MAY
RESULT IN ELECTRIC SHOCK DURING USE.
■ PLEASE NOTE THAT WHEN USING THIS PRODUCT NEAR CHILDREN, DO NOT LEAVE WHEN USING THIS
PRODUCT. KEEP HAIR, LOOSE CLOTHING, FINGERS OR ANY PART OF YOUR BODY AWAY FROM THE MAIN
SUCTION.
■ THIS PRODUCT SHOULD NOT ABSORB COMBUSTIBLE ASHES OR FLAMMABLE LIQUIDS, SUCH AS GASOLINE,
OR BE USED WHERE POSSIBLE.
■ DO NOT SMOKE ANYTHING THAT IS BURNING OR SMOKING, SUCH AS CIGARETTES, MATCHES OR ASHES..
■ PLEASE PAY MORE ATTENTION TO YOUR FEET WHEN USING THIS PRODUCT ON THE STAIRS.
■ DUST CUP IS NOT INSTALLED ON THE MAIN MACHINE, DO NOT USE THIS PRODUCT.
■ THIS PRODUCT IS FOR HOUSEHOLD USE ONLY. FOLLOW ALL THE INSTRUCTIONS IN THE MANUAL.
■ DO NOT CHARGE THE PRODUCT WHEN YOU ARE AWAY FOR A LONG TIME. UNPLUG THE CHARGER FROM THE
SOCKET WHEN NOT IN USE.
■ THIS PRODUCT IS NOT A TOY. PLEASE PAY MORE ATTENTION WHEN USING IT NEAR CHILDREN'S PETS AND
PLANTS.
■ ONLY USE THE PRODUCT AS SHOWN IN THE INSTRUCTIONS. ONLY USE THE ORIGINAL ACCESSORIES.
■WHEN CHARGING, DO NOT PLUG THE CHARGER INTO THE SOCKET AFTER CONNECTING THE MACHINE. PLUG
THE CHARGER INTO THE SOCKET BEFORE PLUGGING IT INTO THE PRODUCT. THIS OPERATION CAN EXTEND THE
SERVICE LIFE OF THE PRODUCT.
■ DUST BUCKET IS BLOCKED BY DUST DO NOT USE, PLEASE OFTEN CLEAN DUST BUCKET DUST, HAIR TO
REDUCE THE WIND VOLUME.
■ PLEASE USE THIS PRODUCT IN BRIGHT PLACES.
■ PLACE THE END OF THE STRAW FLAT AWAY FROM YOUR FACE AND BODY.
■ THIS PRODUCT CAN ONLY BE USED ON A DRY SURFACE.
■ IMPROPER USE OF VOLTAGE CAN LEAD TO MOTOR DAMAGE AND USER INJURY. THE CORRECT VOLTAGE HAS
BEEN DISPLAYED ON THE NAMEPLATE.
WARNING:
TO REDUCE THE RISK OF INJURY DURING MOVEMENT, PULL OUT THE HEAD BEFORE MOVING.
TO REDUCE THE RISK OF ELECTRIC SHOCK - ALWAYS UNPLUG THE CHARGER BEFORE USE.
IN ORDER TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT USE IN THE OUTDOORS OR WET GROUND.

4 5
VERTICAL STEAM
OUT BUTTON
HANDLE RELEASE BUTTON
配件清单产品部件名称
HAND SHANK
INDICATOR LIGHT
HOLD OUT THE STEAM BUTTON
MASTER SWITCH
Parts listProduct part name
POWER CORD HOOK
HOST MACHINE
RADIATOR CAP
CONNECTOR*1
FLAT BRUSH*1
ROUND BRUSH*1
SCRAPER*1
ELBOW NOZZLE*1
STEAM BRUSH*1
MOP*2

Complete machine installation steps
Complete machine installation
Attachment Installation Steps
6 7
Attachment connection
1. When connecting the handle with the installation
of the host, please hold the host with your left hand
as shown in the right picture, and insert the handle
part into the hole at the top of the host with your
right hand until the sound of "click" is heard, and
the installation is completed.
2. The installation of the floor brush and the host
machine align the floor brush with the adapter
mouth of the host machine, and push up hard until
you hear the sound of "crack" locking.
Attachment Installation Steps

Use a steam mop
8 9
Attachment Installation Steps
First, the back of the hook alignment,
in the rotary press load
1. When using this product for the first time, take off the water tank and fill it with
water.
2. Then insert the plug into the socket, press the switch button at the back of the
machine, and the indicator light will light up, indicating that the circuit is closed. Wait
15-20 seconds for preheating, then press the button on the handle to mop the floor.

Matters needing attention
1110
Use a steam mop
3. When using accessories, press the button at the connection between the handle and
the whole machine to take the handle off
4. Then connect the installation connector with the same method as the ground brush.
5. Then connect the attachment you want to use to the connection header.
6. After the power is switched on, the indicator lights up and waits for 15-20 seconds for
preheating. Press the handheld steam release button to use
1. After each use. It is recommended that the mop be removed and cleaned and dried.
2. Please pour out the water in the tank when not in use for a long time.
3. Do not touch the brush and air outlet with your hands to avoid scalding.
4. Do not clean the host machine directly with water.
5. Do not allow children to use the product. Do not allow children to approach when using
the product.

Product standard
Technical specifications
Trouble Removal
1312
Nominal voltage： 110V-120V
Model Number: SP-01A
320ml
30ml/min
Rated power：
Water tank capacity：
Quantity of steam：
1500W
Trouble Removal
1. Not working: Check whether the socket is powered on and the switch behind the host.
Whether to turn on, the indicator light is on, that is the working state.
2. No steam: Check whether the water tank is filled.
Check if the water tank is in place.
Check that the handle is installed in place.

Warranty instructions
1514
After-sales service
Product warranty card
Maintenance record
The user's name
Failure description and
replacement of accessories Maintenance date Maintenance staff
1
2
3
4
Correspondence address
Contact phone number
Product name and model
Product purchase channels
Product Purchase Date
1. The company's products from the date of purchase of consumers (consumers valid
purchase invoice shall prevail), to provide you with warranty services.
2. Within the warranty period, you will receive free warranty service for any damage caused
by manufacturing process or components when the products are confirmed to be in normal
use by the maintenance personnel of our company.
Service policy/Prompt message/technical support
Service policy: This product is strictly in accordance with the provisions of commodity repair
and return liability, to provide consumers who buy this product with three guarantees of
service.
Please note that any of the following circumstances do not fall within the scope of the three
guarantees:
1. Beyond the validity period of three packets;
2. Damage caused by failure to use, repair or keep the product in accordance with the
instructions;
3. Damage caused by repair and demolition by unauthorized service provider;
4. There are no valid three packets of vouchers and valid invoices (can prove the product
within the three packets of validity except);
5. Unauthorized alteration of three packets of certificates;
6. The product model or number of the three packets of certificates is not consistent with
the actual product;
7. Damage caused by force Majeure;
