Zenoah G320RC User manual

Thank you for using ZENOAH ENGINE.
●Please read this Owner’s Manual thoroughly before operating and use the
engine correctly according to this Owner’s Manual.
(For safety reasons, please contact your sales dealer before operating this
engine if there is something that you do not understand.)
●This engine has been designed for the use of radio control car.
Please use this engine in conjunction with the manual for radio control car or
radio control equipment you are going to use.
●Any modification of the engine or any use of other applications is prohibited.
●The purchaser (user) shall bear all obligations and responsibilities stipulated
by law, local ordinance and the likes.
Husqvarna Zenoah Co., Ltd. shall bear no responsibility whatsoever.
115 64 99-26 (402)
OWNER'S MANUAL
Model: G320RC
Model code: 967289001

2

3
SPECIFICATIONS.....................................................4
SAFETY PRECAUTIONS..........................................5
FUELING SYSTEM ...................................................6
ENGINE STARTING..................................................8
OPERATION .............................................................9
MAINTENANCE ......................................................10
SPECIAL TOOLS ....................................................15
SERVICE GUIDE ....................................................16
TROUBLE SHOOTING ...........................................20
PARTS LIST............................................................22
WARRANTY............................................................26
CONTENTS

4
SPECIFICATIONS
Engine Type G320RC
Overall Size (L x W x H) 167 x 216 x 197mm
Weight 2.30kg
Displacement 31.8cm3
Clutch Engagement 6000rpm (STD Spring)
Carburetor Type WT-1107
Spark Plug NGK CMR7H
Spark Plug Gap 0.65mm
Rotating Direction Counter-Clockwise (View From PTO)

5
SAFETY PRECAUTIONS
●These safety precautions are to prevent you and those people in the
vicinity from incurring harm or damage. Make sure to observe these
precautions and constantly strive to ensure safety.
●Safe use of the engine is your personal obligation and responsibility.
Constantly take care to act with good judgment as you enjoy your
hobbies.
•The fuel is toxic. Do not let it get into your eyes or mouth. Store it in a
cool place, out of the reach of infants and children.
•Use of open flames around the fuel is strictly prohibited, because of
danger of fire.
•To prevent burns, make sure not to touch the engine while it is
operating or immediately after it has stopped.
•Do not run the motor in poorly ventilated places. Do not breathe the
exhaust, as it is a health hazard.
•Please wear clothing that facilitates your safety. Remove all scarves,

•Mix gasoline (octane over 95) and high grade 2 cycle engine oil (mixing use type;
JASO FC grade or ISO-L-EGC grade) at mixing ratio 25:1.
•The mixing ratio is according to the oil recommendation.
[ NOTE ]
1) Gasoline may contain maximum of 10% Ethanol (grain alcohol) or up to 15% MTBE
(Methyl tertiary-butyl ether).
Gasoline containing Methanol (Wood Alcohol) is NOT approved.
FUELING SYSTEM
6
SAFETY PRECAUTIONS
overly long sleeves, neckties and the like. Failure to do so could result
in injury.
•When mounting the engine to a model, make sure to follow the model’s
operating manual. If necessary, reinforce the engine mounting unit and
the peripheral parts.

7
FUELING SYSTEM
2) Gasoline is very flammable. Avoid smoking and any fires near fuel.
3) To prevent all possible problems on fueling system, make sure to use the fuel filter
which has more than 300 mesh or equivalent and gasoline proof rubber pipe or
equivalent.
Incorrect fuel filter may cause engine trouble like fuel passage stuffing in carburetor,
or piston surface scratching etc.
4) When fueling, make sure that no fuel touches the hot parts.
5) Assemble the fuel line so that it does not touch the hot parts. Also, check that there
is no fuel leakage due to cracks, or hardening.
6) The picture below shows the tank dimensions for use with the 1799-85400 PIPE
COMP.
Tank Dimensions

8
ENGINE STARTING
Fig.1
Choke
Lever
Open
Close
Throttle Lever
Fig.2
Fig.3
•Push the primer pump several times until overflown fuel
flows out. (Fig.1)
•Close the choke lever(Fig.2), and move the throttle
lever 1/4~1/3 open position.
•Pull the starter(knob) quickly until first firing noise.
(Fig.3)
•Open the choke(Fig.2), throttle idle~1/4 open
•Pull the starter quickly
•Operate engine for a few minutes for the warming up.
•In case of engine warm condition, choking may not be
necessary.
•Over choking may cause starting difficulty due to wet
spark plug.
In this case change spark plug or dry it, and remove
fuel rest in the cylinder by pulling starter.
IMPORTANT

9
OPERATION
•This engine is already tuned up to get high power and high speed, and needs correct
maintenance to keep such high performance.
•The details for operation may be described in the separate owners manual to be
issued by car manufacturer.
•Be sure to have the engine cool down for 30 seconds at idle speed after full throttle
running.

10
MAINTENANCE
1) MAINTENANCE CHART
Before Every Every
Items Action Use 25 hours 100 hours Note
Leakage, Check ✔
Damage/Crack
Idling Speed Check/Adjust ✔✔✔
Air-cleaner Check/Cleaning ✔✔ Replace if necessary
Spark Plug(gap) Check/Adjust ✔✔ ↑
Cylinder(barrel) Check/Cleaning ✔✔ ↑
Piston, Ring Check/Cleaning ✔✔ ↑
Muffler & Bolt Check/Cleaning ✔✔✔ ↑
Bearings Check/Cleaning ✔✔ ↑
Crank Shaft Check/Alignment ✔↑

2) SPECIFICATIONS AND TECHNICAL DATA
Items Unit G320RC Remarks
Bore x Stroke mm 38 x 28
Displacement cm331.8
Effective Compression Ratio 9.7
Type Walbro WT
Carburetor Venture(mm) ø13.5
Starting Recoil Starter
Type TCI
Ignition Timing BTDC 30°/8000rpm
Standard CMR7H NGK
CR8HIX
with Terminal Nut
Option(Hot Type) CMR6H ↑
Clutch Engagement Speed rpm 6000 STD Spring
No load max Speed rpm 20000
Idling Speed rpm 4000
Max. Net Power kW/rpm 2.40/13000
Max. Net Torque N.m/rpm 2.00/9000
Fuel Consumption g/kW·h 519
Carburetor H 1 7/8 ± 1/4
Standard setting L 1 3/8 ± 1/4
11
MAINTENANCE
↑
Option(For Race)
Spark Plug

12
MAINTENANCE
3) MAINTENANCE SPECIFICATIONS
G320RC
Items Standard Limit Measuring Device Remarks
Bore (mm) ø38 Plating damaged Eye Checking
Diameter (mm) ø37.97 ø37.87 Micro Meter
Piston Ring 1.01 1.11 Thickness Gauge
Groove width (mm)
Piston Pin Hole (mm) ø9.01 ø9.05 Cylinder Gauge
Clearance between
Piston and 0.03~0.06 0.15
Cylinder (mm)
Clearance between
Groove and 0.02~0.04 0.1 Thickness Gauge
Piston Ring (mm)
End Gap (mm) 0.1~0.2 0.5 Thickness Gauge
Width (mm) 0.98 0.93 Micro Meter
Piston Pin Diameter (mm) ø9 ø8.98 Micro Meter
Connecting Rod Small end (mm) ø12 ø12.05 Cylinder Gauge
Crankshaft Dia. at Main Bearing (mm) ø12 ø11.98 Micro Meter
Eccentricity (mm) — 0.07 Dial Gauge
Axial Play (mm) — 0.5 Thickness Gauge
Gritty orr
Main Bearing — —
Feels Flat Spot
At the skirt end and
the right angle to the
piston pin.
When inserted in
a new cylinder.
Piston
Cylinder
Piston
Ring
Micro Meter
Cylinder Gauge

13
MAINTENANCE
4) CARBURETOR
Items Standard Limit Measuring Device Remarks
Metering Lever set (mm) 1.65 ± 0.16 Vanier
Inlet Valve Opening Pressure (kg/cm2)1.3~2.3 Leak Tester
Inlet Valve Closing Pressure (kg/cm2)0.7~1.7 Leak Tester
5) IGNITION SYSTEM
Items Standard Limit Measuring Device Remarks
Spark Plug Air Gap (mm) 0.6~0.7 0.7 Thickness Gauge
Ignition Coil/Flywheel Air Gap (mm) 0.3 0.4 Thickness Gauge
Primary 0.7 — Volt Meter
Secondary 6100 — Volt Meter
Reading between
primary terminal and
iron core.
Reading between
sparking cord end and
iron core.
Coil
Resistance
(Ω)

6) TIGHTENING TORQUE
Items Screw Size Standard (N·m) Limit (N·m) Remarks
Carburetor M5 (P=0.8) 3.4 2.9~3.9
Apply Three Bond TB1342H
Insulator M5 (P=0.8) 4.4 3.9~4.9 (Low Strength) or equivalent
Case, Clutch M5 (P=0.8) 3.4 2.9~3.9
Clutch (Plate) M6 (P=1.0) 6.4 4.9~7.8
Clutch (Shoe) M6 (P=1.0) 6.4 4.9~7.8
Rotor M8 (P=1.0) 12.7 9.8~14.7
Cylinder M5 (P=0.8) 7.9 6.9~8.8
Crankcase M5 (P=0.8) 6.4 4.9~7.8
Spark Plug M10 (P=1.0) 10.8 8.8~12.8
Muffler M5 (P=0.8) 8.8 6.9~9.8
Muffler (Stay) M4 (P=0.7) 1.7 1.5~1.9
Fan Cover M5 (P=0.8) 3.4 2.9~3.9
Apply Three Bond TB1342H
Cylinder Cover M4 (P=0.7) 1.7 1.5~1.9 (Low Strength) or equivalent
Cover. TR M4 (P=0.7) 1.3 1.0~1.5
Ignition Coil M4 (P=0.7) 3.2 2.5~3.9
Starter Case M4 (P=0.7) 1.3 1.0~1.5
Tapping Screw TP 4.3 2.4 1.9~2.9
14
