Zephyr AK0720 Installation guide

WWW.ZEPHYRONLINE.COM
SEP20.0101
Stainless Steel Duct Cover
AK1720 - 30”
AK1726 - 36”
AK1722 - 42”
Use, Care, and Installation Guide
AK1728 - 48”
AK1724 - 54”
AK0720 - 30”
AK0726 - 36”
AK0722 - 42”
AK0728 - 48”
AK0724 - 54”
AK0736BS - 36”
AK0742BS - 42”
AK0748BS - 48”
AK0754BS - 54”

2Stainless Steel Duct Cover Use, Care, and Installation Guide
DUCT COVER
ACCESSORY

3
Stainless Steel Duct Cover Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Contents
Page
List of Materials................................................................................... 3
Specications ..................................................................................... 4
Installation Instructions....................................................................... 5
Maintenance ....................................................................................... 6
Contact Us ......................................................................................... 6
List of Materials
Parts Supplied
Quantity Part
1 Center panel
2 Side panels
12 Philips head metal screws
If any parts are missing, please call 1.888.880.8368 for replacements.

4Stainless Steel Duct Cover Use, Care, and Installation Guide
DUCT COVER
ACCESSORY
Specications
30”, 36”, 42”, 48”, 54”
Make sure bottom screw holes are face down on top of range hood.
24”
11”
1”
12”
14” (AK07xxBS only)
AK072x and AK172x
►The AK072x and AK172x stainless steel duct covers are compatible with the following models: AK70,
AK73, AK74, and AK75.
►AK072x duct covers have a 12” height, and AK172x duct covers have a 24” height.
►The total assembled depth is 12”.
AK07xxBS
►The AK07xxBS stainless steel duct cover is compatible specifically with AK78.
►AK07xxBS duct covers have a 12” height.
►The total assembled depth is 15”.

5
Stainless Steel Duct Cover Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
1. Line up screw holes and attach the left and right side panels to the center with screws provided
(FIG. A).
2. Place assembled duct cover on top of the hood. Make sure the screw holes of the center panel are
facing down and line up with the holes on top of the hood.
3. Attach the duct cover to the top by securing the rest of the screws to it from within the inside of
the hood (FIG. B).
Line up screw holes
FIG. A
FIG. B

6Stainless Steel Duct Cover Use, Care, and Installation Guide
DUCT COVER
ACCESSORY
Maintenance
►Cleaning the duct cover should be done frequently to preserve the life of the stainless steel.
Cleaning should typically be done once or twice a month depending on your cooking habits.
►When cleaning, use a non-abrasive cleaner. Do not use “orange” cleaner. Abrasive cleaners may
scratch the surface and discolor the stainless steel.
►You may also polish the stainless steel by using stainless steel polish. Make sure when polishing to
go along with the grain of the duct cover.
Contact Us
To order parts, visit us online at http://store.zephyronline.com or call us at 1.888.880.8368.
Zephyr Ventilation
2277 Harbor Bay Parkway
Alameda, CA 94502
