Zephyr ZRC-7000 Installation guide

Use, Care, and Installation Guide
www.zephyronline.com
Model number:
Serial Number:
Date of Purchase:
Sales Dealer:
JUN08.0201 © Zephyr Corporation
Tempest I Recirculating Kit
ZRC-7000
ZRC-7036
ZRC-7042
READ AND SAVE THESE INSTRUCTIONS

www.zephyronline.com

1
LIST OF MATERIALS....................................................... 2
INSTALLATION
Speci cations ............................................................... 3
Mounting the Diverter Box....................................... 4
Mounting the Filters and Brackets ....................... 5
LIST OF PARTS AND ACCESSORIES .............................. 6
Table of Contents

List of Materials
2
www.zephyronline.com
MODELS: ZRC-7000, ZRC-7036, ZRC-7042
PARTS SUPPLIED
1 - Air diverter box
2 - Charcoal filters (3 for ZRC-0742)
2 - Charcoal filter brackets (3 for ZRC-0742)
1 - Hardware package
HARDWARE PACKAGE CONTENTS
PARTS NOT SUPPLIED
- Ducting, conduit and all installation tools
- Cable connector (if required by local codes)
3/16 x 1/2” (4)
Pre-installed
M4 x 8” (8)

3
Installation – Specifications
38
2
5
#
2
4
27
#
8
2
3
#
3:
27
#
3:
26
27
#
5#
23#
8
9
#
3:
27
#
2
4
9
#
46
26
27
#
52
26
27
#
ps
ps
44
2
5
#
4:
4
27
#
ps ps
Top
Front
Side

4
www.zephyronline.com
Installation – Mounting the Diverter Box
Mounting the air diverter box
FOR USE WITH AK7000AS, AK7036AS, and AK7042AS ONLY
FOR USE WITH SINGLE INTERNAL BLOWER ONLY
NOT COMPATIBLE WITH DUAL INTERNAL BLOWER
1. Position the air diverter box under cabinet. Mark the (4) key-
holes for the 3/16” x 1/2” screws and electrical knock out
opening with a pencil. Remove air diverter box and install the
(4) 3/16” x 1/2” screws. Do not tighten screws all the way.
Drill out the electrical knock-out opening.
Note: Reinforce cabinet with 1” x 2” wood strips if additional
strengthening is required or if cabinets are framed.
2. Lift air diverter box and align the holes on top of the air
diverter box with the screws recently installed. Slide the air
diverter box towards the wall to temporarily lock in place.
Hand tighten the (4) screws. (Fig. A)
3. Lift Tempest I range hood and align the key-holes on top of
the hood with the screws protruding from the bottom of the
air diverter box. Slide hood towards wall to temporarily lock
in place. Hand tighten the (4) screws. (Fig. A)
Note: Electrical wiring will pass through the cabinet bottom,
air diverter box and connect to the hood wiring. See Tempest
I instruction manual for more details.
4. Further secure the hood to the air diverter box by fastening
M4 x 8 screws to each of the (8) holes on the bottom of the
air diverter box. You can gain access to the screw holes from
within the hood. The holes on top of the Tempest I will align
with the holes on the bottom of the air diverter box. (Fig. B)
(8) M4 x 8 screws go here
Fig. A
Fig. B

5
Installation – Charcoal Filters and Brackets
Mounting the Bracket and Baffle Filter
1. Insert the charcoal lter bracket into back side of baf e
lter (side without handles). The (2) tabs on the bottom
of the bracket should be inserted into the baf e lter
rst. Push the bracket towards the baf e lter to lock
bracket in place. There is a clip on top of the bracket
that will secure it to the baf e lter. (Fig. C) Repeat this
step for each bracket. tab
tab
clip
Fig. C
Fig. D
Installing the Charcoal Filter
1. Insert the charcoal lter into the bracket. Tab cut-out
side of the charcoal lter should be installed rst then
push down on the lter to lock in place. (Fig. D)

6
www.zephyronline.com
DESCRIPTION PART #
Replacement Parts
Charcoal Filter (each) Z0F-C002
To order parts, visit us online at http://store.zephyronline.com or call us at 1.888.880.8368
List of Parts and Accessories
