Tornado Glo
AK8500AS
EN Use, Care, and Installation Guide
FR Guide d’utilisation, d’entretien et d’installation
Airflow Control Technology
TM
C

2Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE

3
Tornado Glo Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Contents
Page
Safety Information ............................................................................ 4-6
Types of Safety Warnings................................................................... 4
General Safety ..................................................................................4-5
Operation........................................................................................... 6
Electrical Requirements ...................................................................... 6
Federal Communication Commission Interface Statement................. 6
List of Materials................................................................................... 7
Installation Instructions.....................................................................8-15
Ducting Calculation Sheet.................................................................. 8
Mounting Height, Clearance, & Ducting ............................................. 9
Ducting Options .................................................................................10
Insert Specifications ...........................................................................11
Electrical Supply.................................................................................12
Cable Lock .........................................................................................12
Mounting the Insert ......................................................................... 13-14
Horizontal Ducting Conversion ...........................................................14
Ductless Recirculation ........................................................................15
Features & Controls..........................................................................16-20
Touch Controls ................................................................................ 16-18
Optional RF Remote Control............................................................19-20
Maintenance ...................................................................................... 21
Insert & Grease Filter Cleaning...........................................................21
ACT™ Conversion............................................................................ 22-23
Airflow Control Technology (ACT™) ................................................... 22
Enabling ACT™.................................................................................. 23
Wiring Diagram..................................................................................24
Troubleshooting............................................................................... 25-26
List of Parts & Accessories.................................................................. 27
Notes..................................................................................................28
Limited Warranty ...............................................................................29
Product Registration...........................................................................30

4Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE
Safety Information
Your safety and the safety of others are very important.
We have provided many important safety messages in this
manual for your appliance. Always read and obey all safety
messages.
This is the Safety Alert Symbol. This symbol alerts you to
potential hazards that can cause severe bodily injury or death.
All safety messages will follow the Safety Alert Symbol and either
the words “DANGER” “WARNING” or “CAUTION”
DANGER
Danger means that failure to heed this safety statement may
result in severe injury or death.
READ AND SAVE THESE INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the manufacturer.
b) Before servicing or cleaning unit, switch power o at service
panel and lock the service disconnecting means to prevent
power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service panel.
General Safety
WARNING
Warning means that failure to heed this safety statement
may result in extensive product damage, serious personal
injury, or death.
CAUTION
Caution means that failure to heed this safety statement
may result in minor or moderate personal injury, property or
equipment damage.
WARNING
To reduce the risk of fire or electric shock, do not use this fan
with any solid-state control device.
WARNING
CAUTION
For General Ventilating Use Only. Do Not Use To Exhaust
Hazardous Or Explosive Materials And Vapors. Take care
when using cleaning agents or detergents. Suitable for use in
household cooking area.
WARNING
WARNING - TO REDUCE THE RISK OF A RANGE TOP GREASE
FIRE:
a) Never leave surface units unattended at high settings.
Boilovers cause smoking and greasy spillovers that may ignite.
Heat oils slowly on low or medium settings.
b) Always turn insert ON when cooking at high heat or
when flambeing food. (i.e. Crepes Suzette, Cherries Jubilee,
Peppercorn Beef Flambe’).
c) Clean ventilating fans frequently. Grease should not be
allowed to accumulate on fan or filter.
d) Use proper pan size. Always use cookware appropriate for
the size of the surface element.

5
Tornado Glo Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Safety Information
WARNING
READ AND SAVE THESE INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF INJURY TO PERSONS
IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE
FOLLOWING:
a) SMOTHER FLAMES with a close-fitting lid, cookie sheet, or
metal tray, then turn o the burner. BE CAREFUL TO PREVENT
BURNS. If the flames do not go out immediately, EVACUATE AND
CALL THE FIRE DEPARTMENT.
b) NEVER PICK UP A FLAMING PAN – You may be burned.
c) DO NOT USE WATER, including wet dishcloths or towels – a
violent steam explosion will result.
d) Use an extinguisher ONLY if:
1) You know you have a Class ABC extinguisher, and you
already know how to operate it.
2) The fire is small and contained in the area where it
started.
3) The fire department is being called.
4) You can fight the fire with your back to an exit
Based on “Kitchen Firesafety Tips” published by NFPA.
WARNING
WARNING
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK.
CAUTION
To reduce risk of fire and to properly exhaust air outside, do
not vent exhaust air into spaces within walls, ceilings, attics,
crawl spaces, or garages.
WARNING
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a) Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable codes and
standards, including fire-rated construction.
b) Sucient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of fuel burning
equipment to prevent back drafting. Follow the heating
equipment manufacturer’s guideline and safety standards such
as those published by the National Fire Protection Association
(NFPA), and the American Society for Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE), and the local code
authorities.
c) When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
d) Ducted fans must always be vented to the outdoors.
e) If this unit is to be installed over a tub or shower, it must be
marked as appropriate for the application and be connected
to a GFCI (Ground Fault Circuit Interrupter) - protected branch
circuit.
WARNING
Prop. 65 Warning for California Residents: This product may
contain chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.

6Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE
Safety Information
Operation
ŹAlways leave safety grilles and filters in place. Without these components, operating blowers could catch onto hair, fingers and
loose clothing.
ŹThe manufacturer declines all responsibility in the event of failure to observe the instructions given here for installation,
maintenance and suitable use of the product. The manufacturer further declines all responsibility for injury due to negligence and
the warranty of the unit automatically expires due to improper maintenance.
NOTE: Please check www.zephyronline.com for revisions before doing any custom work.
Electrical Requirements
Important:
ŹObserve all governing codes and ordinances.
ŹIt is the customer’s responsibility to be aware of these below:
ŹTo contact a qualified electrical installer.
ŹTo assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/NFPA 70 latest
edition* or CSA standards C22.1-94, Canadian Electrical Code, Part 1 and C22.2 No.0-M91 - latest edition** and all local codes
and ordinances.
ŹIf codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path
is adequate.
ŹDo not ground to a gas pipe.
ŹCheck with a qualified electrician if you are not sure the insert is properly grounded.
ŹDo not have a fuse in the neutral or ground circuit.
ŹThis appliance requires a 120V 60Hz electrical supply and connected to an individual properly grounded branch circuit protected
by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire with ground. Please also refer to Electrical Diagram
on product.
ŹA cable locking connector (not supplied) might also be required by local codes. Check with local requirements, purchase and
install appropriate connector if necessary.
* National Fire Protection Association Batterymarch Park, Quincy, Massachusetts 02269
** CSA International 8501 East Pleasant Valley Road, Cleveland, Ohio 44131-5575
Federal Communication Commission Interface Statement
ŹThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
ŹThis equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one of the following
measures:
ŹReorient or relocate the receiving antenna.
ŹIncrease the separation between the equipment and receiver.
ŹConnect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
ŹConsult the dealer or an experienced radio/TV technician for help.
READ AND SAVE THESE INSTRUCTIONS

7
Tornado Glo Use, Care, and Installation Guide
ZEPHYRONLINE.COM
List of Materials
Wire Caps (3)
#6 x 1” (4)
#6 x 1-1/2” (4)
3/16 x 3/8” (2)
Parts Not Supplied
Ducting, conduit and all installation tools
Cable locking connector (if required by local codes)
Optional stainless steel liner (AK08xxAS)
Optional recirculating kit (ZRC-0085)
Optional RF remote control (14000005)
Parts Supplied
Quantity Part
1 Insert
1 Aluminum mesh filter
1 PAS panel (Perimeter Aspiration System) (pre-installed)
1 Single internal blower (pre-installed)
1 Round metal cap (for covering duct opening when
converting to horizontal ducting)
1 Hardware package

8Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE
Installation Instructions
Duct pieces To t al
Equivalent number
length x used =
3-1/ 4” x 10”
Rect.,
straight
1 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect. to
6” round
transition
5 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect. to
6” round
transition
900 elbow
20 Ft. x ( ) = Ft.
6”, 7”, 8”, 10”
Round,
900
15 Ft. x ( ) = Ft.
6”, 7”, 8”, 10”
Round,
450
9 Ft. x ( ) = Ft.
Ft.
6”, 7”, 8”, 10”
Round,
straight
1 Ft. x ( ) =Ft.
Subtotal column1 =
Duct pieces To t al
Equivalent number
length x used =
6”, 7”, 8”, 10”
Round, wall
cap with
damper
30 Ft. x ( ) = Ft.
Ft.
Ft.
Ft.
6”, 7”, 8”, 10”
Round
roof cap
30 Ft. x ( ) = Ft.
Subtotal column2 =
Subtotal column1 =
Total ductwork =
Maximum Duct Length: For satisfactory air movement,
the totalductlength
should not exceed 150 equivalent feet.
6” roundto
3-1/ 4” x 10”
rect.
transition
1 Ft. x ( ) = Ft.
6” roundto
3-1/ 4” x 10”
rect.
transition
900 elbow
16 Ft. x ( ) = Ft.
7” roundto
3 1/ 4” x 10”
rect.
transition
8 Ft. x ( ) = Ft.
7” roundto
3-1/ 4” x 10”
rect.
transition
900 elbow
23 Ft. x ( ) = Ft.
elbow
elbow
7” to 6” or
8” to 7” Round
tapered
reducer
25 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect. 900
elbow
15 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect. 450
elbow
9 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect. 900
flatelbow
24 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect.
wall cap
with damper
30 Ft. x ( ) = Ft.
Ft. x ( ) = Ft.
15
6”, 7“, 8”
Round
in-line
damper
Ducting Calculation Sheet

9
Tornado Glo Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Mounting Height, Clearance, & Ducting
A minimum of 6” round vertical or horizontal duct must be used
to maintain maximum air flow eciency.
Always use rigid type metal ducts only. Flexible ducts could
restrict air flow by up to 50%.
Also use calculation (on page 8) to compute total available duct
run when using elbows, transitions and caps.
ALWAYS, when possible, reduce the number or transitions and
turns. If long duct run is required, increase duct size.
If turns or transitions are required; install as far away from insert
duct output and as far apart, between the two as possible.
Minimum mount height between range top to insert bottom
should be no less than 24” above gas cooktops and 20” above
electric cooktops.
Maximum mount height should be no higher than 36”.
It is important to install the insert at the proper mounting height.
Inserts mounted too low could result in heat damage and fire
hazard; while inserts mounted too high will be hard to reach and
will lose its performance and eciency.
Electric Cooktop: Min 20” - Max 36”
36”
Gas Cooktop: Min 24” - Max 36”
If available, also refer range manufacturer’s height clearance requirements and recommended insert
mounting height above range.
For shipment and installation damages:
ŹPlease fully inspect unit for damage before installation.
ŹIf the unit is damaged in shipment, return the unit to the store in which it was bought for repair or
replacement.
ŹIf the unit is damaged by the customer, repair or replacement is the responsibility of the customer.
ŹIf the unit is damaged by the installer (if other than the customer), repair of replacement must be
made by arrangement between customer and installer.

10 Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE
Installation Instructions
Ducting Options
ŹUse single wall rigid metal ductwork only.
ŹFasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct
Tape.
Fire Hazard: NEVER exhaust air or terminate ductwork into
spaces between walls, crawl spaces, ceilings, attics, or garages.
All exhaust must be ducted to the outside, unless using the
recirculating option.
WARNING
Sot or crawl space
Roof Pitch w/
Flashing & Cap
Rear ducting
side wall cap
w/ gravity
damper
ductless
recirculating

11
Tornado Glo Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Ů
26-9/16”
13”
6”
27-3/16”
10-5/16”
3-3/4”
11-1/4”
12-7/16”
11-3/16”
FRONT
SIDEBOTTOM
3-1/2”
6”
BACK
6-1/8”
10” 9/16”
9/16”
PAS Panel 21-3/8”
2-1/4”
8-5/16”
13/16”

12 Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE
Installation Instructions
Electrical Supply
Electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards. Turn o
electrical power at service entrance before wiring.
WARNING
For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not
use extension cord or adapter plug with this appliance.
Follow national electrical codes or prevailing local codes and ordinances.
This appliance requires a 120V 60Hz electrical supply, and connected to an individual, properly
grounded branch circuit, protected by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring
must be 2 wire w/ ground. Please also refer to the Electrical Diagram labeled on product.
Cable Lock
A cable locking connector (not supplied) might be required by local codes. Check with local
requirements and codes, purchase and install appropriate connector if necessary. (FIG. A)
Cable Lock
FIG. A

13
Tornado Glo Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Mounting the Insert
At least two installers are required due to the
weight and size of the insert.
CAUTION
1. Install optional AK08xxAS Stainless Steel Liner.
Review manual included with liner for more
details.
2. If no liner is used, cut out an opening in bottom
of the cabinet by following the dimensions in
FIG. B.
3. The PAS panel needs to be opened up to install
the insert. Open it by pressing the right side
clip to disengage the panel and pull down to
release the panel from the magnets.
4. Securely lower the PAS panel by swinging it
open. It will be held by screws from the hinges.
5. Remove the PAS panel by (2) screws each side.
Disconnect the wiring and remove filter. FIG. C.
6. Remove the screws from the inner brackets on
the face plate, FIG. D. Remove the face plate.
7. If ducting vertically, continue to step 8. If
ducting horizontally, knock out the rear duct 6”
hole before installing the insert.
8. Lift insert into opening and ensure locking clip
has locked into position. Locking clip is located
on left side of insert. FIG. E.
9. Fasten (2) #6 screws into each long side of
the insert. If a liner is used, the screws will go
through the insert mounting holes, then the
liner and into the wood base.
FIG. B
cabinet bottom cut-out size
26- 7/8 ”
10-
5/8
”
FIG. E
Ductwork
wood base
metal or other non
combustible material
locking clip
mounting holes
Front View
FIG. C
FIG. D

14 Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE
Installation Instructions
Mounting the Insert
NOTE: Wood blocking may need to be added
to cabinet base if additional support is
needed. Refer to FIG. F.
10. If ducting horizontally, continue instructions on
Horizontal Ducting Conversion section.
11. Install duct work and seal with duct tape.
12. Install electrical and reconnect all the wiring.
13. Remove all packing materials before using
insert.
14. Switch power on and check for leaks around
duct tape.
15. Install face plate, PAS panel and filter.
Horizontal Ducting Conversion
Ignore these steps if the insert is vertically ducted.
NOTE: The insert must be installed before the
blower can be converted horizontally.
1. Remove (4) screws from FIG. G and (4) screws
from FIG. H.
2. Pull the motor out of the vertical ducting
position.
3. Secure round metal cap where the top duct
hole is located.
4. Orient the motor into the horizontal ducting
position.
5. Install the motor and secure in place with
screws.
6. Continue on step 11 on page 14.
FIG. G
FIG. H
FIG. F
wood base
2” minimum
secure (2) M4 screws to mounting
holes on each long side of Power Pack

15
Tornado Glo Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Ductless Recirculation
Ductless recirculation is intended for applications where an exhaust duct work is not possible to be
installed. When converted, the insert functions as a recirculating insert rather than an exhaust insert.
Fumes and exhaust from cooking are drawn and filtered by an optional charcoal filter. The air is then
purified and re-circulated back within the home.
We recommend to ALWAYS exhaust air outside of the home by employing existing or installing new
duct work, if possible. The insert is most eective and ecient as an exhaust insert. Only when the
exhaust option is not possible should you recourse to converting the insert into a recirculating insert.
When converted to be a recirculating insert, a charcoal filter is required on top of its standard mesh
grease filter. Order according to its part number below. The standard mesh grease filter is intended to
capture residue from cooking, and the optional charcoal filter helps to purify fumes exhausted from
cooking for recirculation.
Recirculating Kit Installation (required if no ducting is used)
For detailed installation instructions, please refer to the manual included with the recirculating kit.
Model Part Number Quantity to Order
AK85 ZRC-0085 1
1. Purchase recirculating kit per the part number above.
Remove mesh grease filter from insert. Place charcoal filter
on back side of mesh grease filter.
2. Place filter bracket over charcoal filter and secure in
place by tucking each end of bracket under the mesh grease
filter frame. FIG. I. Reinstall mesh grease filter.
Order replacement charcoal filters as follows:
Model Part Number Quantity to Order
AK85 Z0F-C085 1
DO NOT WASH CHARCOAL FILTERS. Charcoal filters may need to be changed more often depending
on cooking habits.
FIG. I

16 Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE
Features & Controls
1. Power On/O
By pressing the last retained blower fan speed and lights are
switched on and o.
ACT Verification
- Airflow Control Technology (ACT) allows the installer to set the
maximum blower CFM to align with local codes and regulations.
- To verify the maximum blower CFM:
- With hood o, hold the button for 3-4 seconds. If number
6 displays = default max. CFM, if number 3 displays = max. 390 CFM,
and if number 2 displays = max. 290 CFM.
2. Speed Selection
- Press to decrease fan speed. 6, 5, 4, 3, 2, 1.
- If fan is on Speed 1 and is pressed, the fan will power o.
- Press to increase fan speed. Fan On, 1, 2, 3, 4, 5, 6.
- If hood is o and is pressed, the fan will turn on speed 1.
ACT Enabled Speed Selections
- When ACT is enabled, the number of blower speeds will be
reduced as follows:
- 390 CFM = Maximum 3 speeds
- 290 CFM = Maximum 2 speeds
3. Delay O
This feature is used for programmed shut down of blower 5 min-
utes after the function is activated. Press once, a dot flashes in
the lower right side of display indicating the function is on. The
blower will completely shut down after 5 minutes.
4. Lights Low/High/O
Switch lights on to low by pressing once, press a second time for
high and again to shut o lights.
5. Display Window
The display window indicates speed levels and features such as
bae filter clean reminder, delay o and clean air indicator.
Lights Low/High/O
5 Min Delay O
Display (speed level, delay o, filter clean)
Adjust 6 Speed Levels
Power On/O
1
2
3
4
5
Touch Controls

17
Tornado Glo Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Features & Controls
Touch Controls
Charcoal Filter Change Reminder (charcoal filter, if installed)
When your hood is installed as a recirculating unit, it is fitted with a set of charcoal
filters to purify exhaust and fumes from cooking, then re-circulates the air within the
home. These charcoal filters are required to be replaced after every 200 hours of use.
The charcoal filters should never be cleaned or placed in a dish washer.
The filter change reminder function in the microprocessor needs to be switched on.
When switched on, the microprocessor will elapse and count usage time and indicate
by a flashing when charcoal filter replacements are needed.
Setting the Filter Change Reminder
When o, hold for approximately 5
seconds. The display will change from
(exhaust mode) to (recirculating mode)
this indicates that the elapse timer function
is switched on and charcoal filters are used.
Filter Replace Indicator
When the display starts flashing, the
charcoal filters need to be replaced.
Re-setting Function
Once filters are replaced, with hood o,
press and hold the display will appear;
hold for apprimately 5 seconds until
on displays disappears . The filter
change reminder is now re-set and a new
200 hour elapse cycle is initiated.
hold 5 sec. display from < - > to < C >
Set Mode
Set Mode
display < C > flashes
Change Filters
hold 5 sec. display from < C > to < >
To Reset
C
C
C
C
C
C
C

18 Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE
Features & Controls
Touch Controls
Mesh Filter Clean Reminder
An aluminum mesh filter is fitted by the factory, this filter is intended to filter out residue
from cooking. The filter need not be replaced on a regular basis but are required to be
kept clean. The Mesh Filter Clean reminder function in the microprocessor will automat-
ically indicate by a flashing when the filter need to be cleaned after every 60
hours of use. Filter can be cleaned by hand with non-abrasive soap or in a dishwasher.
Heavily soiled filter should also be soaked in grease cutting detergent prior to cleaning.
Mesh Filter Clean Indicator
When flashes on the display, the filter
needs to be cleaned. This will occur after
every 60 hours of use.
Reset the filter clean reminder timer after
filters are cleaned and re-installed. With
hood o, press and hold for approxi-
mately 5 seconds until on display
disappears . The filter clean reminder
function is now reset and a new 60 hours
elapse cycle is initiated.
Clean Filters
display < F > flashes
hold 5 sec. display from < F > to < >
To Reset
hold 3 sec. display from < A > to < >
To Disable
hold 3 sec.
To Enable
display < A > flashes
Clean Air Indicator
While Clean Air is active, the display will
alternate between , , , .
After 10 minutes of Clean Air operation, the
blower will power o and the 4 hour timer
will reset.
If the blower speed is changed while the
Clean Air Function is in use, the cycle will be
interrupted and the timer will reset after.
Clean Air Function
Clean Air is a feature that turns on the blower on low speed every 4 hours for 10 minutes
to remove stagnant air in the kitchen. The Clean Air function is disabled by default and
must be enabled by the user.
and
and
F
F
F
A
AA
11
A
F
F

19
Tornado Glo Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Features & Controls
Optional RF Remote Control
FCC Caution
To assure continued compliance, any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment. (Example -
use only shielded interface cables when connecting to computer or peripheral device. This device
complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. (1)
This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
Synchronization
To create a unique link between your liner and remote control please follow these steps.
1. With liner o, press and hold the “lights” button on the liner until the letter “F” shows on the display
screen.
2. Press the “lights” button on the remote, the lights on the liner will turn on and synchronization is
complete.
RF Remote Control Functions
Blower On / Speed Selection
Press to power on blower and cycle through all six blower speeds.
Blower On / Power O
By pressing , the blowers will power on at the last speed setting. Press
again and the entire hood will power o, including lights.
Delay O
Lights Low/High/O
Switch lights to Low by pressing once, again to High and again to switch O.
Blower On/
Speed Selection 1
1
2
3
4
Blower On/
Power O
2
5 Min Delay O 3Lights Low/High/O
4
By pressing , the blower and lights will enter Delay O mode. A dot will
appear in the lower right corner of the hood display indicating the function
is on. The blower will change to speed 1 and shut down after 5 minutes.

20 Tornado Glo Use, Care, and Installation Guide
TORNADO GLO
INSERT
CORE
Features & Controls
Optional RF Remote Control
RF Remote Features
The RF remote control is equipped with a magnet on the back for easy storage. The remote may
be placed on any magnetic surface such as a refrigerator or the Zephyr remote holder, FIG. J. The
remote holder can be inserted into a standard electrical outlet for easy storage. Note: The remote
holder does not charge the RF remote.
Maximum remote control communication distance is 15 feet from the liner.
RF Remote Maintenance
Clean the remote control using non abrasive detergents.
Follow instructions below for replacing battery. Using a small flat head screwdriver, raise the cover of
the battery door (A) in order to access the battery compartment. FIG. K.
Remove the battery and replace with battery type A23 12V. Negative end of battery should face the
spring inside the remote.
Re-install battery door and recycle old battery.
FIG. J
A
-
+
FIG. K
