Zephyr ARC AHZ-M90ABX User manual

ARC COLLECTION
HORIZON
A dramatic, low-profile freefall just inches from the kitchen wall sweeps upward
in a thirty-degree lift. So begins Robert Brunner’s new-minimalist range hood, in
striking red, black or white glass on stainless steel. The glass surface may be etched
in one of our patterns—a leaf motif on white glass, or flower on black glass. The
removable front panel doubles as easy blower access for cleaning or service with
no heavy lifting. A duo of halogens completes the picture.
RF Remote Control
SIZE
AHZ-M90ABX
AHZ-M90ARX
AHZ-M90AWX
36”
36”
36”
35 3/8”
35 3/8”
35 3/8”
Stainless Steel/Black Glass
Stainless Steel/Red Glass
Stainless Steel/White Glass
COLOR NET WIDTH
ARC COLLECTION
1.888.880.VENT
www.zephyronline.com nov08.0101
Zephyr Corporation
2277 Harbor Bay Parkway
Alameda, CA 94502
HORIZON WALL
MODEL
AHZ-M90ABX
AHZ-M90ARX
AHZ-M90AWX
FEATURES
Controls
Speed Levels
Auto Delay-Off
CleanAir Function
Remote Control
Lighting
Tri-Level Lighting
Filters
Recirculating
Duct Cover Extension
*PERFORMANCE
Internal Blower - CBI-290A
Internal Blower - CBI-600A
In-Line Blower - PBN-1000A
External Blower - CBE-1000
AC INPUT
**AC POWER
Hood Only
MOUNTING HEIGHTS
Height from the cooking surface
HOOD HEIGHTS
Standard (No Cover)
Short Kit - Z1C-00HZ
Minimum
Maximum
Long Kit - Z1C-01HZ
Minimum
Maximum
DUCT SPECIFICATIONS
Vertical - Internal
Horizontal - Internal
Vertical/Horizontal -
In-Line/External
OPTIONAL ACCESSORIES
Recirculating Kit
Duct Cover Extension Kit, Short
(8’–9’ ceiling)
Duct Cover Extension Kit, Long
(9’–10’ ceiling)
Black Glass, Flower Pattern
White Glass, Leaf Pattern
36”
36”
36”
Memory Touch Glass
3
Yes
Yes
Yes, RF
Halogen, 20W x 2
Yes
Decorative Mesh x 3
Yes
Yes
290 CFM, 3.2 Sones Max.
600 CFM, 6 Sones Max.
1000 CFM, Sones NA
1000 CFM, Sones NA
120V - 60Hz
Max. 40W, 0.33 Amps
Min. 22”–Max. 34”
32 7/8”
35 7/8”
44 7/8”
44 7/8”
57 7/8”
6”
6”
10” to 8”***
ZRC-00HZ
Z1C-00HZ
Z1C-01HZ
AHG-00BL
AHG-00WH
Side
min./max.
no cover - 32 7/8”
Z1C-00HZ
Z1C-01HZ
10 13/16”
20 1/8”
32 7/8”
18 7/8”
6 11/16”
1 3/4”
1/4”
R6 1/8”
Back
Front
35 3/8”
15”
optional
duct cover
17 5/16”
31 5/16”
6 1/8”
13”
16 7/8”
ext. blower
connection
elec. k/o
6” or 8”
CL
9”
* Requires purchase of Zephyr blower, sold separately. **AC power listed above is for hood
with lights only. See blower specs on our website for more AC power details. ***10” round
duct connects to external and in-line blower. Must transition from 10” to 8” before duct
passes through ceiling. A 10” to 8” adapter is included with the external and in-line blowers.
