Zephyr CACHE CCA-E30ASX Use Installation guide

Use, Care, and Installation Guide
www.zephyronline.com
Model number:
Serial Number:
Date of Purchase:
Sales Dealer:
NOV12.0301 © Zephyr Corporation
READ AND SAVE THESE INSTRUCTIONS
CACHE
CCA-E30ASX
CCA-E36ASX
CCA-E48ASX

www.zephyronline.com

1
SAFETY NOTICE ................................................................. 2-3
LIST OF MATERIALS....................................................... 4
INSTALLATION
Ducting Calculation Sheet....................................... 5
Mounting Height & Clearance................................ 6
Ducting Options ........................................................... 7
Hood Specifications ................................................... 8
Preparing the Electrical Wires ............................... 9
Internal Blower (Vertical Ducting)......................... 10-11
Internal Blower (Horizontal Ducting)................... 12-13
External Blower Prepartion..................................... 14
Mounting the Range Hood...................................... 15
FEATURES & CONTROLS
Touch Controls ............................................................. 16
Features.......................................................................... 17
MAINTENANCE
Cleaning and Installing Filters ............................... 18
Lights................................................................................ 19
TROUBLESHOOTING................................................................ 20
Table of Contents

Important Safety Notice
READ AND SAVE THESE INSTRUCTIONS
2
www.zephyronline.com
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY SOLID-STATE CONTROL DEVICE.
WARNING
TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a. Use this unit only in the manner intended by the manufacturer, if you have questions, contact the manufacturer.
b. Before servicing or cleaning unit, switch power off at service panel and lock panel to prevent power from being switched on accidentally.
When the service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service
panel.
CAUTION
For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. Take care when using cleaning
agents or detergents. Suitable for use in household cooking area.
WARNING
TO REDUCE THE RISK OF RANGE TOP GREASE FIRE:
a. Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly
on low or medium settings.
b. Always turn hood ON when cooking at high heat or when flaming food
c. Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan or filter.
d. Use proper pan size. Always use cookware appropriate for the size of the surface element.
e. Keep fan, filters and grease laden surfaces clean.
f. Use high setting on hood only when necessary.
g. Don’t leave hood unattended when cooking.
h. Always use cookware and utensils appropriate for the type of and amount of food being prepared.
WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE TOP FIRE, OBSERVE THE FOLLOWING:
a. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS.
If the flames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT.
b. NEVER PICK UP A FLAMING PAN – You may be burned.
c. DO NOT USE WATER, including wet dishcloths or towels – a violent steam explosion will result.
d. Use an extinguisher ONLY if:
1. You know you have a Class ABC extinguisher, and you already know how to operate it.
2. The fire is small and contained in the area where it started.
3. The fire department is being called.
4. You can fight the fire with your back to an exit
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a. Installation work and electrical wiring must be done by qualified person (s) in accordance with all applicable codes and standards.
Including fire-rated construction.
b. Sufficient air is needed for power combustion and exhausting of gases through the flue (chimney) of fuel burning equipment to prevent
back-drafting. Follow the heating equipment manufacturer’s guideline and safety standards such as those published by the National
Fire Protection Association (NFPA) and the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE) and
the local code authorities.
c. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
d. Ducted fans must always vent to the outdoors.
e. If this unit is to be installed over a tub or shower, it must be marked as appropriate for the application and be connected to a GFCL
(Ground Fault Interrupter protected branch circuit).
g. NEVER place a switch where it can be reached from a tub or shower.
h. Make sure the power is off before installing, wiring or maintenancing.

Important Safety Notice
3
CAUTION
To reduce the risk of fire and electric shock, install this range hood only with external blower models CBE-1000, rated
maximum 6.2 amps, 120V AC 60Hz or internal blowers manufactured by Zephyr Ventilation, models CBI-600A.
WARNING
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK.
CAUTION
To reduce risk of fire and to properly exhaust air outside - Do not vent exhaust air into spaces within walls, ceilings, attics,
crawl spaces or garages.
WARNING
TO REDUCE THE RISK OF SHOCK, THIS FAN MUST BE INSTALLED WITH AN ISOLATING WALL CONTROL/
SWITCH.
OPERATION
Always leave safety grills and filters in place. Without these components, operating blowers could catch onto hair, fingers
and loose clothing.
*NOTE: Please check www.zephyronline.com or call us for revisions before doing any custom work.
ELECTRICAL REQUIREMENTS
Important:
Observe all governing codes and ordinances.
It is the customer’s responsibility:
- To contact a qualified electrical installer.
- To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/NFPA 70
latest edition* or CSA standards C22.1-94, Canadian Electrical Code, Part 1 and C22.2 No.0-M91 - latest edition** and
all local codes and ordinances.
If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the
ground path is adequate.
Do not ground to a gas pipe.
Check with a qualified electrician if you are not sure the range hood is properly grounded.
Do not have a fuse in the neutral or ground circuit.
*National Fire Protection Association Batterymarch Park, Quincy, Massachusetts 02269
** CSA International 8501 East Pleasant Valley Road, Cleveland, Ohio 44131-5575
This appliance requires a 120V 60Hz electrical supply and connected to an individual properly grounded branch circuit
protected by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire with ground. Please also refer to
Electrical Diagram on product.
A cable locking connector (not supplied) might also be required by local codes. Check with local requirements, purchase
and install appropriate connector if necessary.

List of Materials
4
www.zephyronline.com
MODEL: CCA-E30ASX, CCA-E36ASX, CCA-E48ASX
1 - Hood
2 - Baffle filters (3) for 48” model
2 - Halogen light bulbs (4) for 48” model
1 - 6” round top mounting plate
1 - Solid top mounting plate
1 - Rectangular starting collar
1 - Round to rectangular adapter
2 - Blower brackets
1 - 8” round top mounting plate
1 - External blower wiring harness
1 - Hardware packet
Cache Hardware
Packet Contents
CBI-600A Hardware
light bulb removal
suction cup x 1
M6 * 1” x 4
M6 * 1-1/2” x 4
M6 * 2” x 4
M4 * 8
x 22
3/16” x 3/8”
x 4
M4 * 6
x 4
M3.5 * 10
x 4
zip tie x 1
zip tie holder x 1 wire cap x 3
allen key x 1
M4 * 10
x 2
M4 * 16
x 4

5
Duct pieces To t a l
Equivalent number
length x used =
3-1/ 4” x 10”
Rect.,
straight
1 Ft. x ( ) = Ft.
8” Round,
straight
1 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect.900
elbow
15 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect.450
elbow
9 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect.900
flat elbow
24 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect.
wall cap
with damper
30 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect.to
6” round
transition
5 Ft. x ( ) = Ft.
3-1/ 4” x 10”
Rect.to
6” round
transition
900 elbow
15 Ft. x ( ) = Ft.
6” Round,
900 elbow
15 Ft. x ( ) = Ft.
6” Round,
450 elbow
9 Ft. x ( ) = Ft.
Ft.
7” Round,
straight
1 Ft. x ( ) = Ft.
Subtotal column 1 =
Duct pieces To t a l
Equivalent number
length x used =
6”- 8”Round
wall cap
with damper
30 Ft. x ( ) = Ft.
Round
wall cap
with damper
30 Ft. x ( ) = Ft.
7” or 8”
Round,
900elbow
15 Ft. x ( ) = Ft.
7” or 8”
7” or 8”
Round,
450
elbow
9 Ft. x ( ) = Ft.
Ft.
Ft.
Ft.
6”- 8” Round,
roof cap
30 Ft. x ( ) = Ft.
7” or 8”
Round,
roof cap
30 Ft. x ( ) = Ft.
Subtotal column 2 =
Subtotal column 1 =
Total ductwork =
Maximum Duct Length: For satisfactory air movement,
the total duct length of a 3 1/ 4” x 10” rectangular 6”, 7” or 8”
diameter round duct should not exceed 100 e
q
uivalent feet.
6” round to
3-1/ 4” x 10”
rect.
transition
1 Ft. x ( ) = Ft.
6” round to
3-1/ 4” x 10”
rect.
transition
900 elbow
16 Ft. x ( ) = Ft.
7” round to
3 1/ 4” x 10”
rect.
transition
8 Ft. x ( ) = Ft.
7” round to
3-1/ 4” x 10”
rect.
transition
900 elbow
15 Ft. x ( ) = Ft.
Installation – Ducting Calculation Sheet

Installation – Mounting Height & Clearance
6
www.zephyronline.com
DUCTING
A minimum of 6” round or 3-1/4” x 10” rectangular
duct work must be used to maintain maximum air
flow efficiency with the 600 cfm internal blower.
A minimum of 10” to 8” round duct work must be
used with the 1000 cfm external blower.
Always use rigid type metal ducts only. Flexible
ducts could restrict air flow by up to 50%.
Use calculation (on page 5) to compute total
available duct run when using elbows, transitions
and caps.
ALWAYS, when possible, reduce the number or
transitions and turns. If long duct run is required,
increase duct size from 6” to 7 or 8”. If a reducer is
used, install a long reducer instead of a pancake
reducer. Reduce duct size as far away from
opening as possible.
If turns or transitions are required; install as far
away from opening and as far apart, between 2,
as possible.
Minimum mount height between range top and
hood bottom should be no less than 24”.
Maximum mount height should be no higher than
32”.
It is important to install the hood at the proper
mounting height. Hoods mounted too low could
result in heat damage and fire hazard; while hoods
mounted too high will be hard to reach and will
lose its performance and efficiency.
If available, also refer to range manufacturer’s
height clearance requirements and recommended
hood mounting height above range.
Vertical Ducting:
6” round minimum (internal blower)
10” to 8” round minimum (external blower)
Horizontal Ducting:
3-1/4”x10” minimum (internal blower)
No horizontal option available for external blower
DAMAGE-SHIPMENT / INSTALLATION:
• Please fully inspect unit for damage before
installation.
• If the unit is damaged in shipment, return the
unit to the store in which it was bought for
repair or replacement.
• If the unit is damaged by the customer, repair
or replacement is the responsibility of the
customer.
• If the unit is damaged by the installer (if other
than the customer), repair of replacement must
be made by arrangement between customer
and installer.
36”
24” min.
32” max.

7
WARNING FIRE HAZARD
NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages.
All exhaust must be ducted to the outside.
Use metal ductwork only.
Fasten all connections with sheet metal screws and tape all joints with certified Silver Tape or Duct Tape.
Some Ducting Options
Installation – Ducting Options
Soffit or crawl space
Roof Pitch w/
Flashing & Cap
Rear Ducting
External
Blower
External
Blower

8
www.zephyronline.com
Installation – Hood Specifications
27-7/8” - (30“), 33-7/8” - (36“), 45-53/64 - (48”)
29-61/64” - (30“), 35-61/64” - (36“), 47-29/32” - (48”)
1-1/8”
11-31/32”
2”
3-19/32” 12”
5-5/32”
10-23/64”
22-1/8”
R20”
4-3/16”
1-1/4”
2”
2-3/4”
9-29/32”
2”
8-5/8”
5-5/32”
5-7/8” or
7-7/8”
2-3/4”
ext. blower
knock-out
AC power
knock-out
4-3/16”
Front View Back View
Top View Side View

9
ELECTRICAL
WARNING
All Electrical work must by performed by qualified electrician or person with similar technical know
how and background.
For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not use
extension cord or adapter plug with this appliance.
Follow national electrical codes or prevailing local codes and ordinances.
Electrical Supply:
This appliance requires a 120V 60Hz electrical supply, and connected to an individual, properly grounded
branch circuit, protected by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire w/
ground. Please also refer Electrical Diagram labeled on product.
Cable Lock:
A cable locking connector (not supplied) might also be required by local codes. Check with local requirements
and codes, purchase and install appropriate connector if necessary.
Installation – Preparing the Electrical Wires
Cable Lock

10
www.zephyronline.com
INTERNAL BLOWER PREPARATION – VERTICAL DUCTING
1. Attach capacitor box to inside of hood using two
M4*10 screws included with internal blower.
2. Attach green ground wire to ground screw on
hood.
3. Connect 6 pin male connector from capacitor box
to 6 pin female connector on control board box.
4. Place 6” round mounting plate on top of hood
and secure using eight M4*8 screws.
5. Install internal blower into hood. 6. Secure internal blower to hood using four
M4*16 screws included with internal blower.
Installation – Internal Blower (Vertical Ducting)

11
7. Connect 9 pin male connector from blower to 9
pin female connector on capacitor box.
Installation – Internal Blower (Vertical Ducting)

12
www.zephyronline.com
Installation – Internal Blower (Horizontal Ducting)
1. Attach capacitor box to inside of hood using two
M4*10 screws included with internal blower.
2. Attach green ground wire to ground screw on
hood.
3. Connect 6 pin male connector from capacitor
box to 6 pin female connector on control board
box.
4. Place solid mounting plate on top of hood and
secure using eight M4*8 screws.
5. Remove rectangular cap from back of hood.
Place six M4*8 screws aside for later use.
6. Attach blower brackets to blower as shown above
using two M3.5*10 screws for each bracket.
There are two brackets total, one for each side of
the blower. NOTE: Drilled flange of both blower
brackets faces away from the blower casing.
INTERNAL BLOWER PREPARATION – HORIZONTAL DUCTING

13
7. Place blower over round to rectangular adapter
as shown above.
8. Install blower with round to rectangular adapter
into hood.
Installation – Internal Blower (Horizontal Ducting)
9. Mount blower brackets to hood using two
3/16” * 3/8” screws for each bracket. Screws
are included with internal blower.
10. Install rectangular starting collar to back of hood
using six M4*8 screws recently removed from
rectangular cap (three screws on each side).
Install four additional M4*8 screws in the top
and bottom middle of rectangular starting
collar. Check and verify inner adapter is firmly
secured.
11. Connect 9 pin male connector from blower to 9
pin female connector on control board box.

14
www.zephyronline.com
Installation – External Blower Preparation
3. Place cap over threaded cable lock and secure
by turning cap clockwise. NOTE: Due to the
size of the cap, it may be easier to install it
after the hood has been mounted.
4. Connect 6 pin male connector from external
blower wiring to 6 pin female connector on
control board box. Attach green ground wire
from external wiring to ground screw on hood.
EXTERNAL BLOWER PREPARATION
1. Place 8” round mounting plate on top of hood
and secure using eight M4*8 screws.
2. Install threaded cable lock and external
blower wiring through the knockout next to
the electrical wiring knockout.
NOTE: For instructions on mounting the external blower please refer to the CBE-1000 external blower manual
included in the external blower packaging or on our website. www.zephyronline.com

15
Hood is designed for installation under a
kitchen cabinet
1. Select preferred duct location (internal blower -
vertical or horizontal, external blower - vertical
only).
2. Begin installation by removing the baffle filters.
3. Reinforce cabinet with 1” x 2” wood strips if
additional strengthening is required. Must be
placed inside frameless cabinets.
4. Temporarily position the range hood in the
desired mounting location. Measure and
mark the mounting holes, duct and electrical
locations with a pencil.
NOTE: If using an internal blower a 6” round
duct opening is necessary. If using an external
blower an 8” round opening is necessary.
5. Drill/cut out the required openings for duct and
electrical access; make sure the duct opening
is large enough to apply duct tape.
NOTE: If installing an external blower, cut out a
minimum 1-1/2” opening for the external blower
wires to pass through. Refer to page 8 for
specifications.
6. Fasten hood onto cabinet with screws provided.
7. Install electrical.
8. Install duct work and seal with duct tape.
9. Reinstall baffle filters.
10. Power up hood and check for leaks around duct
tape.
duct/silver
tape
5. Duct
opening
cutout
3. Add 1x2
wood strips
2. Baffle
filters
Installation – Mounting the Range Hood

16
www.zephyronline.com
Blower On/Off
By pressing , the blower is switched On and Off. When switched on, the blower starts up on
the same speed it was turned off at. When switched off the entire hood powers off, including the lights.
Speed Selection
The 3 speed levels are selected by pressing to decrease and to increase speed level. The
display indicates level selected. Pressing when the hood is off will also turn it on.
Delay Off
This is used for programmed shut down of blower and lights 5 minutes after the function is
activated. Press once, a dot displays in the lower right hand side of display indicating
the function is on. The hood will change to speed 1 and shut down after 5 minutes.
Lights On/Off/ Dim
Switch lights On and Off by pressing once. To dim lights, press again.
Blower On/Off
Adjust 3 Speed Levels
5 Min Delay Off
Lights On/Off/Dim
Display (Speed level, Delay Off Indicator)
1
1
2
2
3
3
4
4
5
F
Baffle Filter Clean Reminder
After every 30 hours of use the display will start flashing an reminding you to clean the baffle filters
from residue and possible clogs.
Clean Air Feature
Clean Air is a feature that turns the blower on every 4 hours for 10 minutes to remove stagnant air in
the kitchen. This feature is disabled by default and must be enabled by the user.
Features & Controls – Touch Controls

17
Features & Controls – Features
Baffle Filter Clean Reminder
Whether your hood is installed as an exhaust or purifying unit, a set if baffle filters are fitted by the factory,
These baffle filters are intended to filter out residue from cooking. They need not be replaced on a regular
basis but are required to be kept clean. The filter clean reminder function in the microprocessor will
automatically indicate by a flashing when the baffle filters need to be cleaned after every 30 hours of
use. Filters can be cleaned by hand with non-abrasive soap or in a dishwasher. Heavily soiled filters
should also be soaked in grease cutting detergent prior to cleaning.
Baffle Filter Clean Indicator
When flashes on display, the baffle filters
installed are required to be cleaned. This will occur
after every 30 hours of use.
Re-setting Function
Reset the filter clean reminder timer when filters are
cleaned and re-installed (with hood off). Press and
hold for approximately 5 seconds, the display will
appear; hold for approximately 5 seconds until on
display disappears . The filter clean reminder
function is now reset and a new 30 hours elapse
cycle is initiated.
F
Clean Filters
display < F > flashes
F
hold 5 sec. display from < F > to < >
To Reset
F
F
F
To enable Clean Air Feature
With hood off, press and hold for approximately 5
seconds until the display shows then .
To disable Clean Air Feature
With hood off, press and hold for approximately 5
seconds until the display shows then .
A
-
Clean Air Feature
Clean Air is a feature that turns the fan on every 4 hours for 10 minutes to remove stagnant air in the kitchen.
This feature is disabled by default and must be enabled by the user. When the clean air function is enabled,
the blower will turn on speed 1, the display will flash between and until the 10 minute cycle has
elapsed and the blower shuts down.
1
-
hold 5 sec. display from < - > to < A >
To Enable
AA
-
A
-
hold 5 sec. display from < A > to < - >
To Disable
A

18
www.zephyronline.com
SURFACE MAINTENANCE:
Clean periodically with hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent, or
steel wool/scoring pads which will scratch and damage surface.
For heavier soil use liquid degreaser.
After cleaning, you may use non-abrasive stainless steel polish/ cleaners, to polish and buff out the stainless
luster and grain. Always scrub lightly using a micro fiber or clean cotton cloth and with the stainless steel grain.
Stainless Steel Baffle Filters
The stainless steel baffle filters fitted by the factory are intended to trap residue and grease from cooking.
Although the filters never need replacement, they are required to be cleaned every 30 - 60 days or more often
depending on cooking habits.
Filters may be placed in dishwasher at low heat or soaked in hot soapy water.
1
2
3
1
2
3
Maintenance – Cleaning and Installing Filters
Installing Baffle Filters
1. Insert filter in metal groove on bottom of hood.
Push filter towards back of hood using
handles.
2. Pivot front of filter upward until it is flush with
the hood.
3. Lock filter in place by pulling away from hood.
Removing Baffle Filters
1. Pull filter toward back of range hood using
handles.
2. Pivot front of filter upward.
3. Remove downwards to the rear.
