ZIEHL-ABEGG MAXvent User manual

MAXvent
Type FV31...FV14 and DN31...DN14
Axial fans for an explosive atmosphere
Assembly instructions
Keep for reference!
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
english

Content
1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Scope of documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Structure of the assembly instructions . . . . . . . . . . . . . . . . . . . . 4
1.3 Target group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Exclusion of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.5 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Improper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4 Explanations of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.5 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.6 Requirements placed on the personnel / due diligence . . . . . . . 8
2.7 Work on the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.8 Modifications / interventions in the device . . . . . . . . . . . . . . . . . 9
2.9 Operator’s obligation of diligence . . . . . . . . . . . . . . . . . . . . . . . . 10
2.10 Employment of external personnel . . . . . . . . . . . . . . . . . . . . . . . 10
3 Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 Application / operational area . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Transport, storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.3 Disposal / recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2 Special measures for fans used in Zone 21 . . . . . . . . . . . . . . . . 14
4.3 Miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.4 Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.5 Connection lead & terminal box . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.6 Assembly in a humid atmosphere . . . . . . . . . . . . . . . . . . . . . . . 17
4.7 Assembly of the MAXvent fan . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5 Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.1 Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.2 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.3 EMC-compatible installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Assembly instructions MAXvent
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
2/36

6 Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.1 Prerequisites for commissioning . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.2 Check before commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.3 During start-up check the following . . . . . . . . . . . . . . . . . . . . . . . 24
7 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7.1 Code of behaviour in the event of faults . . . . . . . . . . . . . . . . . . . 24
7.2 Possible causes and remedial measures . . . . . . . . . . . . . . . . . . 25
8 Service work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.1 Repairs / maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9 Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9.1 EC Declaration of Incorporation . . . . . . . . . . . . . . . . . . . . . . . . . 29
9.2 EU declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
9.3 Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
9.4 Manufacturer reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Assembly instructions MAXvent
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
3/36

1 General notes
1.1 Scope of documentation
This document is valid for MAXvent axial fans type FV… and DN… (see rating plate),
which are suitable for use in an explosive atmosphere.
The complete documentation for the product consists of these fan assembly instructions
and the motor operating instructions.
To ensure the final suitability of the product for the permissible conditions of use
specified in the order acknowledgement, it is absolutely imperative to observe the
fan assembly instructions and the motor operating instructions. In particular, this
applies to safety instructions, storage, transport, assembly and service.
If necessary, you can request the motor operating instructions from the motor manufac-
turer in your desired language.
Information
In the case of fans with the quality mark (
rating plate), please note the related
specifications depending on the application location.
1.2 Structure of the assembly instructions
Before installation and start-up, read this assembly instructions carefully to ensure
correct use!
We emphasize that these assembly instructions apply to specific units only, and are in
no way valid for the complete system!
Use these assembly instructions to work safely with and on the device. They contain
safety instructions that must be complied with as well as information that is required for
failure-free operation of the device.
Keep these assembly instructions together with the device. It must be ensured that all
persons that are to work on the device can refer to the assembly instructions at any time.
Keep the assembly instructions for continued use. They must be passed-on to all
successive owners, users and final customers.
1.3 Target group
The assembly instructions address persons entrusted with planning, installation, com-
missioning and maintenance and servicing and who have the corresponding qualifica-
tions and skills for their job.
1.4 Exclusion of liability
Concurrence between the contents of these assembly instructions and the described
hardware and software in the device has been examined. It is still possible that non-
compliances exist; no guarantee is assumed for complete conformity. To allow for future
developments, construction methods and technical data given are subject to alteration.
We do not accept any liability for possible errors or omissions in the information con-
tained in data, illustrations or drawings provided.
ZIEHL-ABEGG SE is not liable for damage due to misuse, incorrect use, improper use
or as a consequence of unauthorized repairs or modifications.
Assembly instructions MAXvent General notes
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
4/36

1.5 Copyright
These assembly instructions contain copyright protected information. The assembly
instructions may be neither completely nor partially photocopied, reproduced, translated
or put on data medium without previous explicit consent from ZIEHL-ABEGG SE. In-
fringements are liable for damages. All rights reserved, including those that arise through
patent issue or registration on a utility model.
2 Safety
2.1 Safety instructions
This chapter contains instructions to prevent personal injury and property damage.
These instructions do not lay claim to completeness. In case of questions and problems,
please consult our company technicians.
Attention!
•Non-compliance with the information and safety instructions listed in these assembly
instructions can cause serious health and safety risks!
•It is essential to observe the notes in the motor manufacturer’s assembly instructions,
which are part of the scope of supply.
It is essential to observe the following points:
•The fans are exclusively intended for use in explosive atmospheres of Zone 1 and 2
for gases or Zone 21 and 22 for dust (see rating plate).
•The conveyance of solid matter or solids content in the conveying medium is not
permissible and can lead to dangerous situations. ZIEHL-ABEGG rejects any liability
for damage of any kind as a result of such use.
•Frequency inverters are only permissible if explicitly specified, up to a maximum
frequency of 50 Hz (for 50 Hz driven motors) or 60 Hz (for 60 Hz driven motors).
•The temperature classes of fan and motor are allowed to be different, but they must
be defined according to the ignition temperature of conveying media.
•The fans must be operated in the temperature ranges specified on the rating plate.
•The operating data on the rating plate are specified for an air density of 1.2 kg/m
3
.
•Assembly and electrical connection may only be carried out by skilled personnel in
compliance of applicable standards and these assembly instructions.
•Start-up and maintenance of the device may only be carried out by skilled personnel,
who have completed ATEX training for correct performance of their work.
Assembly instructions MAXvent Safety
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
5/36

For example:
–Protection of the motor against unusual heating according to EN 60204
–Motor protection switches must be installed and set to the rated current specified
on the rating plate (a higher value is not permissible).
–The motor overheating protection equipment must be connected.
–Circuit breakers or overheating protection equipment not properly connected will
invalidate the manufacturer's warranty. Furthermore, this might lead to explosion
hazards.
–...
If the impeller is accessible, protective grilles must be installed according to EN 13857.
These must not be changed and must be adequately fastened.
Pay attention to objects at a greater height which might fall down.
Pay special attention to material combinations according to EN 14986.
Since a residual risk due to falling objects, incorrect behaviour, etc. cannot be completely
ruled out, the designer, operator or manufacturer of the installation or system in which
the fan is to be installed, must prevent any potentially hazardous situation from arising
by means of appropriate safety measures in line with standard EN ISO 12100 and
especially standard EN 14986.
The operator is responsible for maintenance of the fan.
Compliance with the EMC Directive only exists if the fan is directly connected to the
main power supply. If the fan is installed in a system or combined with other products,
the system manufacturer is responsible for compliance with the EMC Directive.
•The fans must be arranged at a reasonable distance from transmitters or be protected
by suitable shielding.
•The components (tubular housing, grille, etc.) made of stainless steel 1.4031 can
become magnetic through impact. This must be prevented by using austenitic and
non-magnetic steels (EN 14986).
Responsibility of users
•The owner or operator must ensure that the equipment (fan and electrical system) is
used according to the description in these instructions and kept in good operating
condition.
•The user shall only put the fan into operation after it has been properly installed.
•The fan must be operated in accordance with the assembly instructions.
•To ensure operability, safety devices (especially the overheating protection equip-
ment) must be checked regularly.
•The instructions for installation and use must be complete and available to users at
any time.
•Users must be trained with regard to the hazards associated with the operation of an
installation in an explosive atmosphere and the intended use of the installation.
•No safety and warning instructions on the fan may be removed, and the user must
make sure that they are legible.
•The persons responsible for the installation, start-up, operation and maintenance of
the device must be competent and possess sufficient experience to correctly perform
their work.
Assembly instructions MAXvent Safety
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
6/36

•In addition, they must know the European standards and guidelines (at national and
regional level and if applicable the in-house regulations) for safety and hazard
prevention. A new user may only work under the supervision of an experienced
operator.
•This device must not be used by persons with limited physical and mental abilities.
Moreover, the minimum legal age must be observed, and users must be adequately
trained.
2.2 Intended use
Attention!
•The fans are only intended for the conveyance of air or mixtures similar to air.
•Any other use above and beyond this is considered not for the intended purpose
unless agreed otherwise by contract. The manufacturer will not be liable for any
damage resulting from this. The individual or company using it bears the sole risk.
•Do not connect built-in fans to open flue pipes of gas and other firing devices.
•Built-in fans with VDE approval (see rating plate) are designed to be installed inside
devices and are not suitable for the direct mains connection.
•Reading these document and complying with all contained instructions -especially the
safety notifications contained therein -are considered part of intended use.
•To consider is also the documentation of attached components.
2.3 Improper use
Attention!
Any improper use may cause material damage and serious risk of injury or danger to life.
Not the manufacturer, rather the operator of the device is liable for any personal harm or
material damage arising from non-intended use.
Possible consequences of improper use: Damage to bearings, formation of corrosion,
imbalance, vibrations, warping, etc. as well as the development of risks for users and the
environment (risk of explosion).
Examples of improper use (list not intended to be exhaustive):
•Operation with ice particles
•Conveyance of abrasive or adhesive media.
•Conveying of gases with a temperature outside the operating temperature specified
on therating plate.
•Conveying of corrosive gases
•Transfer of solids or solids content in the transfer medium.
•Operation with iced up fan impellers.
•Conveyance of liquid media.
•Use of the fan and add-on parts (e.g. safety grille) as a resting surface or climbing aid.
•Unauthorised constructional modifications to the fan.
•Operation of the fan as a safety component or for the performance of safety-relevant
functions in the sense of EN ISO 13849-1.
•Blocking or braking of the fan by inserting objects.
•Holding or carrying the fan on the impeller
Assembly instructions MAXvent Safety
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
7/36

•Loosening of fan blade, impeller and balancing weight
•Dismantling of the impeller
•Every other use which can lead to a hazardous situation
•All applications not listed in the intended use.
2.4 Explanations of symbols
Safety instructions are highlighted with warning triangles and are depicted
according to the degree of hazard as follows.
Attention!
General hazardous area. Death or severe injury or significant property damage can
occur if the corresponding precautions are not taken!
Danger due to electric current
Danger by dangerous, electric voltage! Death or severe injury can occur if the
corresponding precautions are not taken!
Information
Important additional information and advice for user.
2.5 Product safety
The device conforms to the state of the art at the time of delivery and is fundamentally
considered to be reliable. The device and its accessories must only be used in a flawless
condition and installed and operated in compliance with the assembly instructions and/or
operating instructions. Operating outside the device's technical specifications (see name
plate and attachment / technical data) can lead to a defect in the device and additional
damage!
Information
A separate fault and performance monitoring-system with an alarm signal function is
necessary in order to prevent personal injuries and material damages during malfunc-
tions and in case the device fails. Substitute operation must be taken into consideration!
The design and installation of the system must comply with local regulations and
directives.
2.6 Requirements placed on the personnel / due diligence
Persons entrusted with the planning, installation, commissioning and maintenance and
servicing in connection with the frequency inverter must have the corresponding qual-
ifications and skills for these jobs.
In addition, they must be knowledgeable about the safety regulations, EU/EC directives,
rules for the prevention of accidents and the corresponding national as well as regional
and in-house regulations. Personnel to be trained or instructed and apprentices are only
permitted to work on the device under the supervision of an experienced person. This
also applies to personnel undergoing general training. Comply with the legal minimum
age.
Assembly instructions MAXvent Safety
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
8/36

2.7 Work on the device
Information
Mounting, electrical connection, and start-up operation may only be carried out by an
electrical specialist in accordance with electrotechnical regulations (e.g. DIN EN 50110
or DIN EN 60204)!
Danger due to electric current
•It is generally forbidden to carry out work on electrical live parts. Protection class of the
device when open is IP 00! It is possible to touch hazardous voltages directly.
•The safe isolation from the supply must be checked using a two-pole voltage
detector.
•When operation with a frequency inverter the protective conductor is carrying high
discharge currents (irrespective of the clock frequency, current-source voltage and
motor capacity). Earthing in compliance with VDE specifications shall therefore be
observed even for testing and trial conditions (EN 50 178, Art. 5.2.11). Without
earthing, dangerous voltages can be present on the motor housing.
•Maintenance work may only be carried out by suitably qualified personnel.
Attention, automatic restart!
•The fan / motor may switch on and off automatically for functional reasons.
•After power failure or mains disconnection an automatic restart of the fan takes place
after voltage return! Therefore the fan must be disconnected from voltage before
doing any work (
service work).
•Wait for the fan to come to a complete standstill before approaching it!
Danger of being sucked in!
Do not wear loose or hanging clothing, jewellery, etc., tie together long hair and cover it.
2.8 Modifications / interventions in the device
Attention!
For reasons of safety, no unauthorized interventions or modifications may be made on
the device. All planned modifications must be authorized by the manufacturer in writing.
Use only genuine spare parts / genuine wearing parts / genuine accessories from
ZIEHL-ABEGG.These parts were specifically designed for the device. There is no
guarantee that parts from non-original sources are designed and manufactured in
correspondence with load and safety requirements.
Parts and optional equipment not supplied by ZIEHL-ABEGG are not approved by
ZIEHL-ABEGG for use.
Assembly instructions MAXvent Safety
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
9/36

2.9 Operator’s obligation of diligence
•The contractor or owner must also ensure that the electric systems and equipment
are operated and maintained in accordance with electro-technical regulations.
•The owner is obliged to ensure that the device is operated in perfect working order
only.
•The device may only be used as intended (see “Application”).
•You must periodically examine the safety equipment for their properly functioning
condition.
•The assembly instructions and/or operating instructions are always readily available
at the location where the device is being used, are complete and are in legible
condition.
•These persons are regularly instructed in all applicable questions regarding occupa-
tional safety and environmental protection and are knowledgeable regarding the
assembly instructions and/or operating instructions and, especially, are familiar with
the safety instructions contained therein.
•All safety and warning notices attached to the device are never removed and remain
legible.
2.10 Employment of external personnel
Maintenance and service work are frequently carried out by external employees who
often do not recognize the specific situations and the thus resulting dangers.These
persons must be comprehensively informed about the hazards in their area of activity.
It is the site manager's task to obtain information about potential hazards related to the
ATEX Zone and to ensure that personnel are adequately trained in the tasks to be
performed.
You must monitor their working methods in order to intervene in good time if necessary.
Assembly instructions MAXvent Safety
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
10/36

3 Product overview
3.1 Application / operational area
The fans / motors are not ready-for-use products, but conceived as components for
ventilation systems (type designation see rating plate).
•Fans must be balanced according to DIN ISO 1940-1 / ISO 14694.
•These fans are equipped with internal rotor motors, whose ignition protection is
determined by their area of application.
•The motor is rated for S1 continuous operation.
•MAXvent axial fans type FV … and DN… of Group II, Categories 2G, 3G for gas and
2D, 3D for dust, with ignition protection type "c" achieved by constructive safety for
Groups IIA, IIB for gases in Zones 1 and 2 as well as IIIA, IIIB, IIIC for dusts in Zones
21 and 22.
•MAXvent axial fans type FV… and DN… suitable for use in an explosive atmosphere:
–II 2G c IIB T…, II 2G c T…, II 3G c IIB T…, II 2D c IIIB T…, II 2D c IIIC T…, II 3D c
IIIB T…, II 3D c IIIC T… with ignition protection type "c", constructive safety.
Attention!
•The fans may only be operated when they are installed as intended and safety is
ensured by means of protective devices according to DIN EN ISO 13857 (DIN EN ISO
12100) and the required structural explosion protection measures according to
EN 14986.
•Use is only permissible if the gas or dust group is the same on both sides of the
tubular housing (internal/external).
•ZIEHL-ABEGG axial fans comply with the provisions of EN 14986 with regard to the
regulations for selection of materials and protective measures in the possible contact
areas between moving and rigid parts (tubular housing/impeller). Moving parts
(impeller) can consist of parts made of steel, aluminium and composite materials.
•The installer of the system is responsible for the material selection of used
accessories (protective grilles, nozzles, flange rings, etc.). Only material combinations
according to EN 14986 may be used. The installer of the system is responsible for
the earth connection of all accessories!
•Unless explicitly specified, the use of electronic devices or transformers is not
permissible.
•The supplied and certified contact protection of ZIEHL-ABEGG SE fans is designed
according to DIN EN ISO 13857 Table 4 (from the age of 14 onwards). In the event of
deviations, further structural protective measures must be taken for safe operation.
Assembly instructions MAXvent Product overview
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
11/36

3.2 Transport, storage
Attention!
•Always observe the weight specifications and the permissible carrying loads of the
means of transport.
•Wear safety shoes and gloves for handling!
•Transport the fan(s) either in the original packaging or, in the case of larger fans, on
the dedicated transportation fixtures (holes in the wall plates) using a suitable means
of transportation. Observe the weight data on the identification plate.
•Do not transport the fan by the connecting cable!
•Avoid shocks and impacts to the device during the transport.
•Avoid extreme heat or cold (temperature range for storage and transport
Technical
data).
•Watch out for possible damage to the packaging or fan.
•Fix pallets during transport.
•Do not stack pallets.
•Only handle with suitable hoisting gear.
•Never stand underneath the suspended fan because defective transport equipment
could cause death.
•Store the fan / motor in the original packaging in a dry area protected from the weather
and protect it from dirt and weather until final installation.
•Avoid prolonged storage; we recommend a maximum of one year (consult the
manufacturer before starting if stored for longer).
•Inspect the bearing for proper operation prior to installation.
–Recommendation: Turn the impeller evenly by hand to avoid jamming and
damaging the bearing.
3.3 Disposal / recycling
Disposal must be carried out professionally and in an environmentally friendly way in
accordance with the respective national legal stipulations.
"Separate the materials by type and in an environmentally friendly way.
"If necessary, commission a specialist company with the waste disposal.
Assembly instructions MAXvent Product overview
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
12/36

4 Mounting
4.1 General notes
Attention!
•Check the fan for damage, e.g. cracks, dents or damage to the electric cables, before
assembly. Start-up is not allowed in the case of transport damage!
•The operator is responsible for installation and for ensuring the safety of the device.
Assembly must be carried out by qualified personnel in compliance with these
instructions and the motor operating instructions.
•Mounting is only to be undertaken by trained service personnel. The system
manufacturer or the machine builder and/or the user is responsible that the inherent
installation and security information are harmonized with the valid standard and
guidelines (EN ISO 12100 / 13857).
•Take into account easy access for cleaning and maintaining the fan.
•Wear safety shoes and gloves for handling!
•Lift the fan out of the packaging with a lifting gear (lifting beam). Attachment points are
solely the holes on the housing flange, motor bed, support plate, motor suspensions,
fastening brackets and any crane eyes of the fan (depending on the shape of the fan).
•The chain/rope may not touch the impeller and the possibly mounted frequency
inverter when lifting with the lifting beam, otherwise damage is possible.
•At a weight greater than 25 kg for men / 10 kg for women, the device should be lifted
out by two persons (according to REFA). The values may differ from country to
country.
•Prior to installing the fan, check whether safety distances according to EN ISO 13857
are complied with. If the installation height (danger zone) above the reference level is
greater than or equal to 2700 mm and is not reduced by auxiliary means such as
chairs, ladders, work platforms or bases on vehicles, a protection grating against
accidental contact is not necessary on the fan.
•If the fan is located in danger zone, then the manufacturer or operator shall ensure
that hazards shall be prevented by appropriare protective constuctions which meet
the requirements to EN ISO 13857.
•The custom designs must suit the prevailing conditions.
•Tighten the fastenings with the specified torques.
•Do not allow drilling chips, screws and other foreign bodies to reach the device
interior!
•Any use below -10 °C is dependent on not being subjected to unusual, sudden or
mechanical loads or stresses on the material (min. ambient temperature
Technical
data).
•Before the first switch-on, remove any items that may be present (borings, screws and
other foreign objects) from the intake area - risk of injury from any objects that may fly
out!
Assembly instructions MAXvent Mounting
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
13/36

4.2 Special measures for fans used in Zone 21
Attention!
For all fans used in Zone 21, a vibration monitoring system firmly attached to the
fan has been stipulated since May 2007, according to standard EN 14986.
The following points must be observed by the customer:
•Only vibration sensors approved for Zone 21 may be used.
•Vibration sensors must be attached to the fastening screws under the motor:
–1 in front of the motor
–1 behind the motor
–The sensor signal must be transmitted to a control system located outside the
potentially explosive atmosphere or to evaluation equipment.
–This controller must deactivate the fan when the critical vibration threshold value is
reached.
–Also see the operating instructions for these equipment.
The following vibration threshold values apply to fans used in industry:
Threshold values ac-
cording to ISO14694
Rigid attachment mm/s (rms) Flexible attachment mm/s
Start-up value 4.5 6.3
Alarm threshold 7.1 11.8
Switch-off value 9.0 12.5
4.3 Miscellaneous
•Do not use any materials or paints which become electrostatically charged and may
lead to sparking.
•If necessary, the system must be equipped with lightning protection.
•Systems must be set up at a sufficient safety distance from transmitters or be
protected by suitable shielding.
•Do not paint over the flameproof gap on the terminal box of the motor after
establishing the connection (between terminal box and cover).
Assembly instructions MAXvent Mounting
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
14/36

4.4 Handling
Attention!
•During handling always wear personal protective equipment (helmet, safety shoes,
etc.).
•Never drive under a load or park underneath!
•Pallets must be secured when unloading and during handling.
•Never hold or carry on the impeller.
•Never hold or carry on the grille(s).
•Never hold or carry on the cable(s).
•Check the weight of elements and use suitable lifting and conveying equipment.
After unpacking proceed as follows:
"The fan must be fastened to 4 points during transport so the flanges do not warp.
"The hooks must point "outwards" (see photo).
Assembly instructions MAXvent Mounting
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
15/36

"To turn the fan round, fasten the fan at 2 points so it does not warp.
"Handling in the "horizontal axis" must be done at 4 points to prevent the flanges from
warping.
Assembly instructions MAXvent Mounting
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
16/36

"The hooks must point "outwards" (see photo).
4.5 Connection lead & terminal box
Information
In demanding environments (wet areas, open air installation) all connections must
incorporate water drainage curves. To ensure that water cannot penetrate through to the
controller housing from the connections install a terminal box lower than the motor.
4.6 Assembly in a humid atmosphere
Information
If a fan / motor is stationary for long periods in a humid atmosphere, it should be switched
ON for minimum of two hours every month to remove any moisture that may have
condensed within the motor.
Assembly instructions MAXvent Mounting
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
17/36

4.7 Assembly of the MAXvent fan
Attention!
•Motor and accessories (protective grille etc.) must be connected to earth.
•Connection points must be reliably protected against the formation of corrosion.
Observe the following points for all types of fans:
•Do not install without suitable supports/brackets.
•Ensure adequate clearance on suction and pressure sides. When installing fans in
devices, ensure there is a suitable inlet opening through a minimum integration
distance, which corresponds to the rough diameter of a fan.
•Warping caused by the elasticity of the components must not cause the impeller to
rub against the tubular housing.
•Ensure that there is a constant gap dimension "a" (see figure below) betweenimpeller
and tubular housing.
•According to EN 14986, the minimum distance between non-moving and moving
parts must be complied with. The distance must not be less than 0.5 % of the
diameter (at least 2 mm and at most 20 mm).
Minimum gap dimension:
fan type a (min.) fan type a (min.)
FV31 / DN31 2.0 mm FV71 / DN71 3.55 mm
FV35 / DN35 2.0 mm FV80 / DN80 4.0 mm
FV40 / DN40 2.0 mm FV90 / DN90 4.5 mm
FV45 / DN45 2.25 mm FV10 / DN10 5.0 mm
FV50 / DN50 2.5 mm FV12 / DN12 6.25 mm
FV56 / DN56 2.8 mm FV14 / DN14 7.0 mm
FV63 / DN63 3.15 mm
Assembly instructions MAXvent Mounting
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
18/36

"Fasten the fan with suitable bolts using all the fastening points of the flanges.
"Fasten the accessories with suitable bolts.
"Ensure that all elements (including accessories) are connected to earth.
Tightening torques for fastening the fan and accessories:
Tightening torques M
A
Thread size
M6
(Special application
with 5-pitch)
M8 M10 M12
Property class 8.8, friction coefcient µges
0.12 9.5 Nm 23 Nm 46 Nm 79 Nm
Stainless steel A2-70, friction coefcient
µges 0.12 6.4 Nm 15.3 Nm 31 Nm 52 Nm
Screw penetration ≥ 1.5 x d ≥ 1.5 x d ≥ 1.5 x d ≥ 1.5 x d
Assembly instructions MAXvent Mounting
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
19/36

5 Electrical installation
5.1 Safety precautions
Danger due to electric current
•Work on electric components may only be carried out by trained electricians or by
persons instructed in electricity under the supervision of an electrician in accordance
with electrical engineering regulations.
•The 5 electrical safety rules must be observed!
•Connect fan only to electrical circuits that can be disconnected with an all-pole
isolating switch.
•The device owner is responsible for the EMC of the entire plant according to the
locally applicable standards.
•It is forbidden to carry out work on electrically live parts!
•Cover neighbouring electrical equipment during installation work.
•A second person must always be present when working on energized parts or lines
who disconnects in case of emergency.
•Do not use metal compression-gland fittings with plastic terminal boxes. - Danger of
an electric shock if connection is not made correctly!
•Electrical equipment must be checked regularly: Loose connections are to be re-
tightened and damaged cables must be replaced immediately.
Assembly instructions MAXvent Electrical installation
L-BAL-F076-GB 1747 Index 001 Part.-No. 00705156-GB
20/36
